Backyard Creations BAZEMORE 272-1027 User manual

ANT00517K01
IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD, AND RECEIPT.
Page 2
Step 5:
Note:
Do not over tighten
After making any necessary adjustments to the
alignment of the table top, use the hex bolt driver to
tighten all bolts. each bolt must be tightened a
few revolutions at a time. In order to apply equal
pressure to all bolt joints, we recommend working in a
cross corner (X fashion). Repeat until all bolts are tight.
. Over tightening may strip bolts.
Cover all bolts and nuts with covers.
With the help of another person, turn the table in the
upright position. Your table is now ready for use. If you
have any questions, please call our Customer Service
Center at 1-800-416-3511.
Step 6:
IMPORTANT NOTE: Damage to welds or frames resulting
from over tightened bolts or improper assembly is not covered
under our warranty. Please read all instructions carefully
before assembly. If you have any questions regarding your
assembly, call our Customer Service Center at 1-800-416-3511.
Step 1:
Do not attempt
assembly if any parts are missing or damaged.
Remove all protective materials and set parts on a flat,
non-abrasive surface. Identify the parts packed in the
carton against the parts list. If you are missing any parts or
unsure how to proceed with assembly, call our Customer
Service Center at 1-800-416-3511.
Step 2:
Hand tighten
only 2-3 turns.
Attach three table legs to the table top by using six
bolts and Ø20xØ6.5x2.0mm washers as shown in
. Guide the bolts through the holes in the leg
into the pre-drilled holes in the table top.
F1
Place the table top upside down on a flat, non-abrasive
surface.
igure
8
HW0594
ØX20 Ø6.5 X 2.0 MM
WASHER
PARTS LIST DESCRIPTION ORDER PART # QTY
1
A
B
C
D
E
F
G
H
I
J
K
1
BOLT COVER
TABLE LEG
LEG CONNECTOR
BAR
HW0105
HW0004
HW0006
FOOT CAP
FACTORY ASSEMBLY
1
*NOTE:PARTSSHOWNONPARTSLISTARENOTTOSCALE
Ø6.5 X 1.0 MM
WASHER
FC0607
1/4" X 30 MM BOLT HW0038 8
4
TABLE TOP
8
HW0009 1
NUT COVER HW0027 8
1/4" NUT HW0014 8
HEX WRENCH
G0157
UMBRELLA HOLE
PROTECTIVE RING
FACTORY ASSEMBLY
HEX BOLT DRIVER
8
Step 3: Attach three legs to the leg connector bracket by carefully
guiding the bolts already in place on the table legs
(each leg has two bolts) through the holes in the leg
connector bracket. Add a washer and a nut to the end
of each bolt as shown in the .F2Hand tighten
2-3 turns only.
igure
AT53120
AT53121
AT53122
Figure 1
FOOT CAP
A
C
D
F
I
B
G
E
H
Figure 3
Step : Repeat above process( & 2) for the last leg as
shown in the .
4Figure 1
F3igure
C
Figure 2

Page 1
PATIO FURNITURE & ACCESSORIES
ASSEMBLY INSTRUCTIONS
IMPORTANT
ACOV113
CARE AND MAINTENANCE
CERAMIC TILE
SPECIAL WARNINGS!!!
LIMITED WARRANTY
FRAMES
UMBRELLA USAGE WARNING!
Frames.
Finishes.
Fabrics.
Straps and/or wicker.
Umbrellas
Table tops
Warranty limitations:
Warranty exclusions:
Some states do not allow exclusion or limitation of incidental or consequential damages, so that limitation above may not apply
to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Cleaning
Maintenance
- Use mild soap and warm water. Do not use abrasive materials, cleansers, or bleach products. Rinse with clean water and
dry thoroughly.
- Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. To thoroughly drain
frames, remove foot caps and tilt the frames, if necessary, to remove all water. This is critical. Water allowed to accumulate inside the
frames and then exposed to sub-freezing temperatures can cause damage to the frame tubing. Such damage is not covered under
warranty. Always clean, drain, and dry thoroughly before storing for the winter. For best results, always store or cover your furniture
when not in use. We recommend commercially available outdoor furniture covers. Any small nicks or scratches can be covered with a
light application of touch-up paint.
** When cleaning or moving large or heavy items, always have two people work together. Never drag furniture.
Use clean water and mild detergent or commercially available ceramic tile cleaners as necessary. Do not use abrasive materials or
cleansers as they may scratch the surface of the tiles. Dry with soft cloth. Do not use commercially available ceramic tile cleaners on
table frame.
If you will be using an umbrella with your table, make sure the plastic umbrella ring is inserted into the hole in the center of the table.
Place the umbrella through the opening and into an umbrella stand made of cast iron, wrought iron, steel plate or blow molded plastic
filled with 20-50 lbs or 9-22 kgs of sand or water. If your table is 72" or 182 cm or larger, we recommend a weight of at least 50 lbs or
22 kgs or more. NEVER USE AN UMBRELLA WITH A TABLE WITHOUT USING AN UMBRELLA BASE OR RING AS
DESCRIBED ABOVE. ALWAYS REMOVE YOUR UMBRELLA FROM THE TABLE WHEN NOT IN USE. NEVER USE AN
UMBRELLA DURING STORMS OR WINDY CONDITIONS.
Frame construction is warranted against defects in material and workmanship for one year from purchase date.
Damage to frames or welds resulting from improper assembly or exposure to water and/or sub-freezing temperatures is not
covered.
Paint finishes are warranted against peeling, cracking and blistering for one year from purchase date provided the unit
has not been scratched or abraded. Chips and scratches resulting from normal wear and tear are not covered.
Fabric and cushions (if applicable) are warranted against separation at the seams for one year from purchase date.
Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any other cause is not
covered.
Straps and/or wicker weave (if applicable) are warranted against separation and tearing for one year
from purchase date. Fading and/or discoloration resulting from exposure to the elements, oils, spills, fluids, chemicals, or any
other cause is not covered.
. Umbrellas (if applicable) are warranted against defects in material and workmanship only for one year from
purchase date. Umbrella bases (if applicable) are not covered under any circumstance.
. Natural stone tabletops only are warranted against defects in materials or workmanship only for one year from
purchase date. All other table tops (including without limitation glass and faux stone) are not covered under any circumstances.
This warranty is subject to the limitations set forth above. In addition, this warranty is made to the original
purchaser only, and is effective only when item(s) is purchased from one of our authorized dealers. This warranty is not transferable.
For warranty replacements based on warranty claims submitted within the first year of purchase, we will pay shipping and handling
charges within the continental North America. After the first year, shipping and handling charges are your responsibility. We will not
be responsible for charges associated with shipments outside the continental North America at any time or for any reason.
This warranty is subject to the exclusions as set forth above. In addition, the following are excluded from
coverage under this warranty: any item used for commercial, contract or any other non-residential purpose; clearance items, display
models or items purchased "as is"; freight damage; items subject to misuse, abuse, neglect or lack of proper care and maintenance
(including without limitation as provided in any "care and maintenance guide"); normal wear and tear; damage caused by acts of
nature, acts of force majeure, vandalism, fire or other casualty, or improper assembly; hardware against corrosion or rusting; purchased
or replacement parts; and all plastic parts. Also excluded are loss of use or time; inconvenience; money; travel; packaging; or
incidental, special or consequential damages of any kind. Replacement of defective items as provided herein shall constitute your sole
and exclusive remedy for items which are not as warranted. In no event shall our responsibility exceed the purchase price of the items
found to be other than as warranted. This warranty is the exclusive statement of your rights with respect to the defects in the items you
have purchased and supersedes any other express warranty or statement, written or oral, made in connection with the purchase and sale
of such items. When used herein, the term "item" when used in the singular, refers to the specific item found to be defective, and not to
the entire set of which the item is a part.
·
·
·
·
·
·
SKU #272-1027
BAZEMORE 58" BALCONY TABLE
Customer Service 1-800-416-3511
STOP PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLY. MAKE SURE YOU HAVE ALL THE PARTS AND
HARDWARE AS IDENTIFIED ON THE PARTS LIST.
CALL OUR CUSTOMER SERVICE CENTER AT 1-800-416-3511
BETWEEN 9:00AM AND 5:00PM (EASTERN TIME) MONDAY
THROUGH FRIDAY (CLOSED HOLIDAYS).
OR, VISIT OUR WEBSITE AT: www.agio-usa.com
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, RETAIN THE
INSTRUCTION SHEET, WARRANTY CARD, AND RECEIPT FOR
FUTURE USE. YOU ARE ENCOURAGED TO REGISTER YOUR
PURCHASE ON OUR WEBSITE AT www.agio-usa.com
.
.
MISSING PARTS? DAMAGED PARTS? DON'T GO BACK TO THE
RETAILER. WE CAN HELP YOU FASTER
FOR ADDITIONAL ONLINE VIDEO SUPPORT ON ASSEMBLY,
TROUBLESHOOTING, AND CARE AND MAINTENANCE OF YOUR
AGIO OUTDOOR FURNITURE, PLEASE VISIT OUR WEBSITE AT:
www.agio-usa.com
