Backyard Discovery READY SHED User manual

Save this assembly manual for future reference in the event that
you need to order replacement parts.
READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING CONSTRUCTION.
INS- 817220010-A-BARN SHED DISASSEMBLY-ENG 4-13-17
Manufacturer: Backyard Discovery
3305 Airport Drive
Pittsburg, KS 66762
1-800-856-4445
READY SHED
8X8 BARN SHED
DISASSEMBLY
MODEL: # 817220010

IMPORTANT!
READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
BEFORE YOU BEGIN
• SAFETY FIRST
Your safety is what matters, follow the instructions fully to ensure it gets dissassembled correctly
and safely.
• SURFACE PREPARATION
To ensure proper disassembly you must uncrate your shed on a level firm surface.
• HANDLE WITH CARE
This crate is your shed, handle all parts with care as you follow the instructions to take it apart.
• DON'T THROW ANYTHING AWAY
Keep all parts during the disassembly until you are able to inventory the parts using the next Instruction
Manual found in your shed crate.
• DON'T SKIP ANY STEPS
This crate has been designed to keep it's parts from being damaged and from falling over.
Skipping steps could cause parts to fall and land on you or cause damage to your shed or
surrounding structures.
STOP!
DO NOT RETURN THIS PRODUCT TO STORE!
If you have questions or concerns,
please call 800-856-4445
or
email [e-mail]
1

2
DISASSEMBLY TOOLS REQUIRED
OTHER TOOLS WE SUGGEST
• Utility Knife • 6' Ladder • Gloves
• Phillips Bit Driver
• Drill

PARTS BEING REMOVED
DON'T SKIP ANY STEPS
This crate has been designed to keep it's parts from being damaged and from falling over.
Skipping steps could cause parts to fall and land on you or cause damage to your shed or
surrounding structures.
•These instructions will take you step by step through the disassembly process.
• Only remove screws shown in the current step, do not skip foward or take out any additional screws
until instructed to.
REMOVE ONLY THE 5 SCREWS
SHOWN HERE.
REMOVE ONLY THIS PIECE.
NEXT: REMOVE SCREW
(2 PLS)
- 5/8" OSB FLOOR SHEATHING - W4L07734
5/8"x16"x92"
(1)
- FLOOR JOIST - W4L07662
1 1/2"x3 1/2"x89" TREATED
(1)
3

REMOVE SCREW
(2 PLS)
- FLOOR JOIST - W4L07662
1 1/2"x3 1/2"x89" TREATED
(1)
PARTS BEING REMOVED
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
(1) RP1 - ROOF PANEL - W2A02123
NEXT: REMOVE SCREW
(2 PLS)
TOP VIEW
REMOVE
4

•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
TOP VIEW
REMOVE SCREW
(2 PLS)
REMOVE
(1) WP5 - UNIVERSAL RIGHT
WALL PANEL - W2A02122
5

TOP VIEW
REMOVE SCREW
(2 PLS)
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
REMOVE
(1) WP5 - UNIVERSAL RIGHT
WALL PANEL - W2A02122
6

TOP VIEW
REMOVE SCREW
(2 PLS)
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
(1) WP4 - UNIVERSAL LEFT
WALL PANEL - W2A02121
REMOVE
7

REMOVE 2 SCREWS
TOP VIEW
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
(1) WP4 - UNIVERSAL LEFT
WALL PANEL - W2A02121
PARTS BEING REMOVED
REMOVE
8

PARTS BEING REMOVED
TOP VIEW
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
REMOVE SCREW
(2 PLS)
REMOVE
REMOVE SCREW
(2 PLS)
(1) WP3 - FRONT CENTER WALL PANEL - W2A02120
9

REMOVE SCREW
(2 PLS) REMOVE SCREW
(2 PLS)
TOP VIEW
PARTS BEING REMOVED
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
REMOVE
(1) WP2 - REAR CENTER WALL PANEL - W2A02119
CAUTION
LOOSE PARTS BEHIND, MOVE WITH
CAUTION.
10

STOP
ONLY REMOVE LOOSE PARTS AND
MOVE TO NEXT STEP.
•Only remove item's shown in the current step, do not skip foward or take out any additional parts until instructed to.
PARTS BEING REMOVED
SHINGLES
REMOVE SHINGLES
AND LEVELING
MATERIALS
11
- LEVELING BLOCK - W4L07756
1 1/2"x5 1/2"x6"
(2)
- LEVELING BLOCK - W4L07757
1"x5 1/2"x6"
(2)
- 4" CONCRETE BLOCK - CB000001
(1)
- 2" CONCRETE BLOCK - CB000002
(2)

NEXT:
REMOVE SCREW
(4 PLS)
TOP VIEW
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
REMOVE
REMOVE SCREW
(4 PLS)
REMOVE SCREW
(2 PLS)
- FLOOR JOIST - W4L07662
1 1/2"x3 1/2"x89" TREATED
(1)
(2) LP1 - LOFT PANEL - W2A02124
12

•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
TOP VIEW
REMOVE SCREW
(2 PLS)
REMOVE
NEXT:
REMOVE SCREW
(2 PLS)
- FLOOR JOIST - W4L07662
1 1/2"x3 1/2"x89" TREATED
(1)
(1) RP1 - ROOF PANEL - W2A02123
CAUTION
LOOSE PARTS BEHIND, MOVE WITH
CAUTION.
13

REMOVE SCREW
(2 PLS)
TOP VIEW
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
REMOVE
REMOVE
CAUTION
LOOSE PARTS BEHIND, MOVE WITH
CAUTION.
- DOOR DRIP BOARD - W4L07675
3/4"x1"x46 3/4" (20x24x1187)
(1)
- FASCIA BOARD - W4L07672
5/8"x2 3/8"x87 1/4" (16x60x2216)
(2)
(1) RP1 - ROOF PANEL - W2A02123
14

REMOVE ALL LOOSE
PARTS.
CAUTION
LOOSE PARTS, MOVE WITH CAUTION.
PARTS BEING REMOVED
- FILLER BOARD - W4L07701
1"x3 3/8"x21 3/8" (24x86x543)
(4)
- VERTICAL TRIM - W4L07674
5/8"x3 3/8"x44 1/2" (16x86x1130)
(4)
- SUPPORT BLOCK - W4L07669
1 1/2"x3 1/2"x3 1/2"
(6)
- SUPPORT BOARD - W4L07668
5/8"x3 3/8"x22 1/8" (16x86x562)
(4)
- 7/16" OSB GABLE BRACE - W4L07667
7/16"x6 1/8"x11" TREATED
(6)
- ANGLED ROOF TRIM - W4L07666
5/8"x3 3/8"x36" (16x86x914)
(8)
- SIDE VERTICAL TRIM - W4L07665
5/8"x2 3/8"x44 1/2" (16x60x1130)
(4)
15

•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
REMOVE SCREW
(3 PLS)
- FLOOR JOIST - W4L07662
1 1/2"x3 1/2"x89" TREATED
(3)
REMOVE SCREW
(3 PLS)
16

REMOVE SCREW
(2 PLS)
TOP VIEW
CAUTION
LOOSE PARTS BEHIND, MOVE WITH
CAUTION.
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
PARTS BEING REMOVED
REMOVE
(1) RP1 - ROOF PANEL - W2A02123
17

CAUTION
LOOSE PARTS, MOVE WITH CAUTION.
REMOVE
SHINGLES.
PARTS BEING
REMOVED
SHINGLES
REMOVE SCREW
(2 PLS)
NEXT
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
REMOVE SCREW
(2 PLS)
REMOVE LARGE SHEET.
- 5/8" OSB FLOOR SHEATHING - W4L07664
5/8"x43"x92"
(1)
CAUTION
REMOVING BOARD WILL
REDUCE STABILTY.
18
- 2" CONCRETE BLOCK - CB000002
(2)
- 4" CONCRETE BLOCK - CB000001
(1)
- LEVELING BLOCK - W4L07757
1"x5 1/2"x6"
(2)
- LEVELING BLOCK - W4L07756
1 1/2"x5 1/2"x6"
(2)

PARTS BEING REMOVED
•Only remove screws shown in the current step, do not skip foward or take out any additional screws until instructed to.
CAUTION
REMOVING BOARD WILL
REDUCE STABILTY.
REMOVE SCREW
(2 PLS)
TOP VIEW
- 5/8" OSB FLOOR SHEATHING - W4L07733
5/8"x31 7/8"x92"
(1)
- 4 x 4 RUNNER - W4L07670
3 3/4"x3 3/4"x92" TREATED
(2)
REMOVE
REMOVE
REMOVE REMOVE
REMOVE SCREW
(2 PLS)
REMOVE SCREW
(2 PLS)
REMOVE SCREW
(2 PLS)
CAUTION
REMOVE PARTS WITH
CAUTION.
19
