Balboa EL Series User manual

900854
J1
J2
BL
LT
HT
FC
OZ
Enter
Jets 2Jets 1
LightBlower
39.0ºC
J1
J2
BL
LT
HT
FC
OZ
Enter
Jets 2Jets 1
LightBlower
102ºF
Page 1
MLM990S User Guide
Panel Software Version 1.1.0
EL/GL Series - Mach 3
Note regarding EL and GL systems: Mach 3 EL and GL systems function
identically, but conform to different International requirements. This
user guide will refer to EL systems for the sake of simplicity, but the
information given applies to both EL and GL products.
balboa-instruments.com

Page 2

Page 1
EL/GL SERIES (Mach 3) CONTROL WITH MLM990S PANEL
The MLM990S panel can be used with the EL8000,
EL5000, EL2000 and EL1000 systems. System software
version 28 or higher is required for this panel. This user
guide lists all features that are available. The features
shown on your panel menus may vary depending on
the system and equipment used.
The pump responsible for heating and filtration
(pump 1 low on non-circ systems, or the circ pump on
circ systems) will be referred to simply as the pump.
Time-outs refer to a preset length of time that a
function is programmed to operate before shutting off
automatically. Certain conditions (filters or freeze) can
cause a function to operate longer, while faults can
cause a function to operate for a shorter length of time.
The system keeps track of time-outs regardless of other
conditions occurring.
A. Overview of a Start Up and Screen Displays . . . 2
Initial Start-up.............2
Use the Arrow and Enter Keys to Navigate . . 2
Home Display Screen (or “Home”) . . . . . 2
Setting the Time . . . . . . . . . . . . 2
Setting the Spa Temperature Using Fast Keys. . 2
Front Panel Buttons and Lights.......2
Jets 1 Button . . . . . . . . . . . . . . . . 2
Jets 2 Button . . . . . . . . . . . . . . . . 2
Blower Button ...............2
Light Button ................3
B. Fast Keys Give Quick Access to System Set-up . . 3
C. Spa Functions Turn Equipment On or Off . . . . 3
Jet Control . . . . . . . . . . . . . . 3
Jets 2-6 . . . . . . . . . . . . . . . . . . . 3
Lighting . . . . . . . . . . . . . . . 3
Blower Option ............3
Mister Control.............3
Options . . . . . . . . . . . . . . . 4
D. Set Menu Presets Your Equipment .......4
The “Spa Settings” Submenu .......4
Set Temp . . . . . . . . . . . . . . 4
Filter Cycles, to Program . . . . . . . . . 4
Fast Keys, to Program . . . . . . . . . . 4
Mode, Change Heat Mode . . . . . . . . 4
Time of Day . . . . . . . . . . . . . 4
User Settings . . . . . . . . . . . . . 5
Panel Settings .............5
Diagnostics..............5
Versions/Version Information . . . . . . . 5
E. Additional Options . . . . . . . . . . . . . . . 5
Freeze Protection ...........5
Clean-up Cycle . . . . . . . . . . . . 5
Circ Pump . . . . . . . . . . . . . . 5
Ozone . . . . . . . . . . . . . . . 5
Diagnostic Messages . . . . . . . . . . . . . . . . 6
Periodic Reminder Messages ...........8
GFCI Protection . . . . . . . . . . . . . . . . . . 8
Optional Auxiliary Panels .............9
Jets 4 (optional on some systems) . . . . . 9
Jets 5, Jets 6 (optional on some systems). . . 9
Mister (optional) . . . . . . . . . . . 9
TV Lift (optional) . . . . . . . . . . . 9
Basic Installation & Configuration for Mach 3 . . . . 10
Guidelines for Mach 3 EL-Series Spa Controllers. . . 10
CSA Compliance/Conformité . . . . . . . . . . . . 10
Warning! GFCI Protection. . . . . . . . . . . . . . 10
Front Panel Screen and LEDs
LEDs are lit when functions are on
Lights
J1
J2
BL
LT
HT
OZ
FC
Jet Number 1
Jet Number 2
Blower
Heater
Filter Cycle
Ozone
Diagnostic and Reminder messages appear in place
of Any Diagnostic Messages
102ºF
To exit a menu,
Arrow Left
Table of Contents

Page 2
A. Overview of a Start Up and Screen Displays
Initial Start-up
When your spa is first actuated, it will go into Priming
mode and then a quick configuration. Please see the
M-7 Installation Instruction Manual for complete
instructions on Power-up and Pump Priming.
The Priming mode will last for up to 4 minutes and
then the spa will begin to heat and maintain the water
temperature in the Standard mode. You will be given
options as to whether you want the priming modes
to continue or not. Follow the on-screen instructions.
Highlight your choice and press Enter ( ). If left
alone, the system will resume after 4 minutes. The
Home display screen will appear after completion.
Use the Arrow and Enter Keys to Navigate
Use the buttons on the front panel to move within
the menu: Up , Left , Right , or Down .
Enter ( ) chooses your menu selection.
To exit menus and go back to Home, press the left
arrow key until the Home display screen appears.
Home Display Screen (or “Home”)
The three basic function keys on the main display screen
are “Fast Keys”, “Spa”, and “Set”. The spa temperature
will appear after the system has ran its diagnostic tests.
The “Standard” heat mode is displayed in this example.
Note: Depending on your installed equipment, the
screen may look different.
102ºF
Home Display Screen
Setting the Time
The time should be set first. All timed functions are
dependant on this. Starting at the Home display screen,
highlight “Set”, then press .
Use the arrow keys to highlight “Time of Day”. Press .
Press or to change hour. to highlight minutes.
Press or to change minutes. to highlight AM.
Press or to choose AM or PM.
To Save and Exit: , , .
Setting the Spa Temperature Using Fast Keys
With “Fast Keys” highlighted on the Home display
screen, press . Set the desired spa temperature with
or , then to return Home.
You can also change the Spa temperature from within
the menus: Set > Spa Settings > Set Temp > .
Then press the left or right arrow keys to adjust the
temperature. To Save and Exit: , .
Front Panel Buttons and Lights
For instant activation of devices, press Jets 1, Jets 2,
Blower or Light. The left LEDs will light when activated.
The Right LEDs will light when HT (Heater), FC (Filter
Cycle), and OZ (Ozone Filter) are activated.
Jets 1 Button
Press the Jets 1 button once to turn pump 1 on or off,
and to shift between low and high speeds if equipped.
If left running, the pump will turn off after a time-
out period. The pump 1 low speed time-out on some
systems may be as long as 4 hours.
On non-circ systems, the low speed of pump 1 runs
when the blower or any other pump is on. It may also
activate for at least 1 minute every 30 minutes to detect
the spa temperature (polling) and then to heat to the
set temperature if needed, depending upon mode.
When the low speed turns on automatically, it cannot
be deactivated from the panel; however, the high speed
may be started.
Jets 2 Button
Press the Jets 2 button once to turn pump 2 on or off,
and to shift between low and high speeds if it is a
two-speed pump. If left running, the pump will turn off
after a time-out period.
Blower Button
1-speed operation: On/Off
2-speed operation: High/Med/Off
3-speed operation: High/Med/Low/Off
If left on, the blower will automatically turn off after a
time-out period.

Page 3
Light Button
Some systems are equipped with both a spa light and
a fiber optic light; however, only one can be accessed
by this panel. (Larger panels may be purchased so
that both the spa light and fiber optic light can be
utilized.) Depending upon how your spa is equipped
and configured, the “Light” button will operate in one
of three ways.
1) Press the “Light” button to turn the spa light on and
off, and to shift between dim and bright settings if
your light is dimmable.
2) If a fiber-optic light with wheel is installed, press the
“Light” button once to start the light and wheel. Press
it again to stop the wheel; again to turn the light off.
3) If a fiber-optic light without a separate wheel stop
is installed, press the “Light” button to turn it on
and off.
Both a spa light and a fiber optic light may be used
simultaneously on the EL8000 and EL5000 systems
with a different panel. If any light is left on, it will
automatically turn off after a factory programmed
time period.
B. Fast Keys Give Quick Access to System Set-up
Fast Keys allows you to go directly to a programmed
device and quickly view its status or change it. (See
“Fast Keys, to Program”.) For example, from the Home
display screen, pressing “Enter” ( ) with “Fast Keys”
highlighted shows a menu with the four directional
keys, their preassigned functions, and status.
In the example below, “Jets 1” is on Low; “Jets 2” is
not available (not installed); “Blower” is not available
(not installed); Spa “Light” is Off. These devices and
functions can be found under section C. Spa Functions.
The panel Up Arrow ( ) toggles Jets 1, High or Low.
The panel Down Arrow ( ) toggles the spa lights
On or Off. The panel LED indicators will light when
activated.
The spa temperature is shown in the upper right corner.
“Home” ( ) to go back to the Home display screen.
Jets 1 L
Light Off
Jets 2
NA Blower
NA
Home
75°F
Fast Keys Pictorial Screen
C. Spa Functions Turn Equipment On or Off
In the “Spa” menu (shown on the “Home” display
screen), you can control the devices on your system.
The menu also shows the status of devices you may
have in installed on your system.
“Home” > Spa > > Spa Functions menu.
The Spa Functions menu displays the following
equipment: Jet Control, Mister, Lighting, Options,
and Blower. Highlight the selected device, then press
Enter ( ). Use the direction keys to move within each
menu and press to turn the device On or Off, or to
advance through the available options (High/Med/Low).
Left Arrow ( ) to Back up and to exit.
If you do not have a device installed, the menu will
reflect it by stating “None” next to it.
Jet Control
If Jets are programmed, they will be set to shift between
low and high speeds if equipped. If left running, the
pump will turn off after a time-out period. The pump 1
low speed time-out on some systems may be as long as
4 hours.
On non-circ systems, the low speed of pump 1 runs
when the blower or any other pump is on. It may also
activate for at least 1 minute every 30 minutes to detect
the spa temperature (polling) and then to heat to the
set temperature if needed, depending upon the mode.
When the low speed turns on automatically, it cannot
be deactivated from the panel; however, the high speed
may be started.
Jets 2-6
If these are installed, and if it is a two-speed pump,
then the change in mode will be between low and
high speeds. If left running, the pump will turn off
after a time-out period. Please refer to “Optional
Auxiliary Panels”.
Lighting
Light-On/Off
Fiber Wheel-On/Off/None
Blower Option
1-speed operation: On/Off
2-speed operation: High/Med or Off
3-speed operation: High/Med/Low or Off
If left on, the blower will automatically turn off after
a time-out period.
Mister Control
Mister Control - On/Off/None

Page 4
Options
Option 1 - None
Option 2 - On/Off
Option 3 - On/Off
Note: Options may include Waterfall, TV, CD, etc.
D. Set Menu Presets Your Equipment
In the “Set” menu (shown on the “Home” display
screen), you can preset (program) the equipment
on your system, and view diagnostic and software
version information.
“Home” > Set > > Spa Settings menu.
From within the “Spa Settings” menu, choose which
setting you’d like to change by using the arrow keys.
The “Spa Settings” Submenu
Set Temp
From within “Spa Settings”, highlight “Set Temp”,
,or to set the temperature, ,to exit.
(Note: The available range for adjustment of spa
temperature is 80°F - 104°F (26.0°C - 40.0°C). Also, the
last measured spa temperature displayed is current only
when the pump has been running for at least 1 minute.)
Note: To change the format from Fahrenheit to
Centigrade, access the “User Settings” within the “Spa
Settings” menu. See User Settings under this section.
Filter Cycles, to Program
“Home” > Set > > Filter Cycle > .
You are not required to set filter cycles; however, it is an
option available to you.
On all systems, the pump and the ozone generator will
run during filtration. At the start of each filter cycle, the
blower will run briefly on its highest speed to purge the
air channels. The lowest speed of any other pumps and
the Mister will also run briefly. On some circ systems,
Pump 1 may also run for the duration of the filter. There
are two filter cycles per day.
The start/end times of each cycle are programmable. To
program the cycles, the clock must be set. Under “Spa
Settings”, highlight “Filter Cycle” and Enter ( ). Select
Filter Cycle 1 or 2 by pressing or . Arrow Down to
the Start Time, then . Select or to choose the
“Start Time” hour. Press to change minutes, then use
the or to select the minutes start time.
Arrow Right to change AM or PM if on a 12 hour clock
(see “User Settings” if you don’t see AM or PM). Press
“Enter” ( )to Save. Arrow Down to “Stop Time” and
repeat. Once finished, Arrow Left to Exit or resume to
set Filter Cycle 2.
If you would like to select continuous filtration, set the
Filter 1 start and end times to be the exact same time.
In this case, Filter 2 Start Time only controls when
the second purge happens. Filter 2 end time will
be unavailable.
(The following is specific to all systems that are
programmed according to time)
Default filter cycles can vary from system to system. A
common default is 8:00 AM to 10:00 AM and 8:00 PM to
10:00 PM. From the Home display screen, select “Set”
then “Enter” ( ). on “Filter Cycle” to view how the
filter cycle times that are currently set.
Also, each filter cycle automatically operates the pump
for the duration of the filter cycle. The filter “FC” LED
will light on the panel when any filter is running.
Fast Keys, to Program
“Home” > Set > > Fast Keys > .
Here you can designate how each key will respond
when accessing the “Fast Keys” menu (page 3). The
following equipment are available for each of the four
Fast Keys: None, Jets 1-6, Blower, Light, Fiber Wheel,
Mister, and Option 1-3.
In the menu “Program Fast Keys”, highlight a direction
key to program, then . Scroll to the device you
choose to place on the Fast Keys menu. For more
options, Arrow Right ( ). Choose your device by
highlighting it. Press Enter ( ).
Left Arrow ( ) to go back to the “Program Fast Keys”
menu to program the other Fast Keys, or continue
() to exit.
Note: Within a Program menu, the current choice of the
fast key chosen appears in parenthesis.
Mode, Change Heat Mode
“Home” > Set > > Mode > .
This screen allows options for Standard, Economy, or
Sleep modes when using the heater. Select the mode,
then .
Standard mode maintains the desired temperature.
Economy mode heats the spa to set temperature only
during filter cycles.
Sleep mode heats the spa to within 20°F (11°C) of the
set temperature only during filter cycles.
Arrow Left to return to “Spa Settings”.
Time of Day
“Home” > Set > > Time of Day > .
Under “Set Time of Day”, follow the on screen
instructions: Press Up or Down to change; the left and
right arrow keys designate what to change: hour, minute,
AM or PM. “Enter” to Save.

Page 5
User Settings
“Home” > Set > > User Settings > .
Pressing Enter ( ) on any setting within the User
Settings menu toggles the choices:
1) Temp Format from F to C.
2) Time Format 12HR/24HR
3) Dolphin Address: 0 (zero) - 7. (See Dolphin manual
for addressing one or two Dolphins)
4) Suppress Reminders, On/Off.
When “On”, Reminders are never displayed on the
panel. When “Off”, Reminders are displayed on the
panel periodically. (See page 8 for Reminders.)
to Exit.
Panel Settings
“Home” > Set > > Panel Settings > .
again to adjust the “LCD Contrast” using the arrow
keys ( /). to finish and exit.
Arrow Left ( ) to exit and to return to “Spa Settings”.
Diagnostics
“Home” > Set > > Diagnostics > .
to view “Diagnostic Info”. Use the direction keys and
Enter ( ) key to view your settings. ( ) to exit.
The available menus are:
1) Sensor Temperatures (Sensors A & B)
2) Switches-Bank A. . Option A1-A12, On/Off
3) Switches-Bank B. . Option B1-B6, On/Off
Arrow Left ( ) to return to “Spa Settings”.
Versions/Version Information
“Home” > Set > > Versions > .
If you call technical support, you may be required to
provide system and panel information.
Highlight “Versions”, to enter the “Version Info”
Display. Here you will find the System and Panel version
information. Arrow Left ( ) to exit.
E. Additional Options
Freeze Protection
If the temperature sensors within the heater detect a low
enough temperature, then the pump(s) and the blower
automatically activate to provide freeze protection. The
pump(s) and blower will run either continuously or
periodically depending on conditions.
In colder climates, an optional additional freeze sensor
may be added to protect against freeze conditions that
may not be sensed by the standard sensors. Auxiliary
freeze sensor protection acts similarly except with the
temperature thresholds determined by the switch. See
your dealer for details.
Clean-up Cycle
When a pump or blower is turned on by a button
press, a clean-up cycle begins 30 minutes after the
pump or blower is turned off or times out. The pump
and the ozone generator will run for one to four hours,
depending on the system (on some systems, you can
change this setting; see the “User Preferences” section.)
Circ Pump
If your system is equipped with a circ pump, it may be
configured to work in one of three different ways:
1) The circ pump operates continuously (24 hours) with
the exception of turning off for 30 minutes at a time
when the water temperature reaches 3°F (1.5°C) above
the set temperature (most likely to happen in very
hot climates).
2) The circ pump stays on continuously, regardless of
water temperature.
3) The circ pump will come on when the system is
checking temperature (polling), during filter cycles,
during freeze conditions, or when another pump
is on.
Ozone
On most systems, the ozone generator (if installed) runs
during filter cycles (except when pump 1 is operating at
high speed on a non-circ system) and during clean-up
cycles. On some systems, the ozone generator operates
whenever the pump runs.
If your system is configured with the optional ozone
suppress feature, the ozone generator will turn off
for 1 hour any time a function button (Jets 1, Jets 2,
Blower, etc.) is pressed.

Page 6
Diagnostic Messages
Message Meaning
No message on display.
Power has been cut off to the spa.
Heater
Overheat
“Overheat” - The spa has shut
down.1On some systems, an
alarm may sound. One of the
sensors has detected 118°F
(approximately 47.8°C) at
the heater.
“Overheat” - The spa has shut
down.1One of the sensors has
detected that the spa water is
110°F (approximately 43.3°C).
“Ice” - Potential freeze
condition detected.
Spa is shut down.1The sensor that
is plugged into the Sensor “A” jack
is not working.
Spa is shut down.1The sensor that
is plugged into the Sensor “B” jack
is not working.
Sensors are out of balance.
If this is alternating with the
temperature, it may just be a
temporary condition. If the
display shows only this message
(periodically blinking), the spa is
shut down.1
A substantial difference between
the temperature sensors was
detected. This could indicate a
flow problem.
Persistent low flow problems.
(Displays on the fifth occurrence
of the “Heater Flow Low”
message within 24 hours.)
Heater is shut down, but other
spa functions continue to
run normally.
Inadequate water detected
in heater.
Heater Dry Inadequate water detected in
heater. (Displays on third
occurrence of the above message.)
Spa is shut down.1
Action Required
The control panel will be disabled until power returns.
Time of day will be preserved for 30 days with a battery
back-up on EL8000 and EL5000 systems. EL1000 and
some EL2000 systems reset the time of day on each
power-up. Spa settings are preserved on all systems.
DO NOT ENTER THE WATER. Remove the spa cover
and allow water to cool. Once the heater has cooled,
reset by pushing any button. If spa does not reset,
shut off the power to the spa and call your dealer or
service organization.
DO NOT ENTER THE WATER. Remove the spa cover
and allow water to cool. At 107°F (approximately 41.7°C),
the spa should automatically reset. If spa does not reset,
shut off the power to the spa and call your dealer or
service organization.
No action required. The pumps and the blower will
automatically activate regardless of spa status.
If the problem persists, contact your dealer or service
organization. (May appear temporarily in an overheat
situation and disappear when the heater cools.)
If the problem persists, contact your dealer or service
organization. (May appear temporarily in an overheat
situation and disappear when the heater cools.)
If the problem persists, contact your dealer or
service organization.
Check water level in spa. Refill if necessary. If the water
level is okay, make sure the pumps have been primed.
Press any button to reset.
Follow action required for “Heater Flow Low” message.
Heating capacity of the spa will not reset automatically;
you may press any button to reset.
Check water level in spa. Refill if necessary. If the water
level is okay, make sure the pumps have been primed.
Press any button to reset.
Follow action required for the above message. Spa
will not automatically reset; you may press any button
to reset.
Spa Overheat
Freeze
Condition
Sensor A
Fault
Sensor B
Fault
Sensor
Balance
Transient
Low Flow
Heater Maybe
Dry
Heater
Flow Low

Page 7
Diagnostic Messages (continued)
Message Meaning
Priming Mode When your spa is first actuated, it
will go into Priming mode.
--F --C Temperature unknown.
------ ------ Temperature not current in
Economy or Sleep mode.
Standby Mode Standby Mode has been activated
by pressing a button combination
on the user panel.
pH Low pH is low.
pH High pH is high.
Sanitizer Low Sanitizer is low.
Sanitizer High Sanitizer is high.
Drain Water The pump is on during Standby
Mode to assist in draining the spa.
RTC Failure Hardware failure.
Persistent
Memory Fail Hardware failure.
Checksum
Failure
Firmware install problem.
Configuration error. Spa cannot
start up.
GFCI Failure Spa could not trip GFCI.
Stuck Msg A pump appears to be stuck on,
causing the water temperature to
creep up, possibly to
hazardous levels.
A pump appears to have been
stuck on the last time spa
was powered.
Action Required
See the M-7 Installation Instruction Manual for complete
instructions on Power-up and Pump Priming. The
Priming mode will last for up to 4 minutes and then
the spa will begin to heat and maintain the water
temperature in the Standard mode.
After the pump has been running for 1 minute, the
temperature will be displayed.
In Economy or Sleep mode, the pump may be off for
hours outside a filter. If you wish to see the current spa
temperature, either switch to Standard mode or turn
Jets 1 on for at least 1 minute.
Press any button to leave Standby Mode and return to
normal operation.
Add pH increaser according to
manufacturer’s instructions.
Add pH reducer according to manufacturer’s instructions.
Add sanitizer according to manufacturer’s instructions.
Remove spa cover and allow sanitizer to dissipate.
Press “Jets 1” to turn off the pump when water has
drained (or power off the spa.)
Contact your dealer or service organization.
Contact your dealer or service organization if message
appears on more than one power up.
Contact your dealer or service organization if message
appears on more than one power up.
Contact your dealer or service organization.
Contact your dealer or service organization. Continued
operation may be unsafe.
POWER DOWN SPA IMMEDIATELY. DO NOT ENTER
THE WATER. Contact your dealer or service organization.
POWER DOWN SPA IMMEDIATELY. DO NOT ENTER
THE WATER. Contact your dealer or service organization.
1On some systems even when spa is shut down, some equipment may occasionally turn on to continue monitoring temperature or if
freeze protection is needed.
Configuration
Error
HOT
(Call Service)

Page 8
GFCI Protection
Your spa may be equipped with a GFCI Protection
feature. If your spa does have this feature enabled, the
GFCI Trip Test must occur to allow proper spa function.
Within 1 to 7 days after startup, the spa will trip
the GFCI to test it. (The number of days is factory
programmed.) The GFCI must be reset once it has been
tripped. After passing the GFCI Trip Test, subsequent
GFCI trips will indicate a ground fault or other unsafe
condition requiring the power to the spa to be shut off.
Periodic Reminder Messages
(Press the “Mode” button to reset a displayed reminder.*)
Message ** Frequency *** Action Required
Check pH Every 7 days Test and adjust pH chemical levels per manufacturer’s instructions.
Check Sanitizer Every 7 days Test and adjust sanitizer chemical levels per manufacturer’s instructions.
Clean Filter Every 30 days Remove, clean, and reinstall filter per manufacturer’s instructions.
Test GFCI Every 30 days Test & reset GFCI per manufacturer’s instructions.
Drain Water Every 90 days Drain and refill spa per manufacturer’s instructions.
Clean Cover Every 180 days Clean and condition cover per manufacturer’s instructions.
Treat Wood Every 180 days Clean and condition wood per manufacturer’s instructions.
Change Filter Every 365 days Install new filter.
Change Cartridge As needed Install new Mineral cartridge.
* User can suppress all reminders in User Preferences.
** All of these Periodic Messages can be disabled individually by the spa manufacturer.
*** Any of these frequencies may be changed by the spa manufacturer.
Warning: The Owner should test and reset the GFCI
on a regular basis to verify its function.
Note: The GFCI section does not apply on EL systems used outside the United States.
This GFCI section does not apply to GL Systems.

BlowerJets 1Jets 1 Jets 2 LightLight
BlowerJets 1Jets 1 Jets 2
Jets 1 Jets 2Jets 1 Jets 2
Jets 1Jets 1
Jets 2Jets 2
BlowerBlower
Page 9
Jets 3, Jets 4 (optional on some systems)
Press the “Jets 3” button once to turn pump 3 on or
off, and to shift between low and high speeds if it is a
two-speed pump. If left running, the pump will turn off
after a time-out period. “Jets 4” operates the same way
as “Jets 3”.
Jets 5, Jets 6 (optional on some systems)
Press the “Jets 5” button once to turn pump 5 on or off.
If left running, the pump will turn off after a time-out
period. “Jets 6” operates the same way as “Jets 5”.
Mister (optional)
Press the “Mister” button to turn the Mister on and off.
If left on, the mister will automatically turn off after
15 minutes.
TV Lift (optional)
Press the “TV Lift” button to raise and lower the TV Lift
device. There is no time-out for this feature.
Stir (optional on some systems)
Press the “Stir” button after adding new chemicals into
the spa. This will turn all pumps on at high-speed for
5 minutes to thoroughly mix in the chemicals.
Optional Auxiliary Panels
Note: Below is a partial list of optional auxiliary panels and their basic functions.
Please contact your local dealer for a complete list of options that will work with your spa.

Page 10
Warning! Shock Hazard! No User Serviceable Parts.
Do not attempt service of this control system. Contact your dealer or service organization for assistance. Follow
all owner’s manual power connection instructions. Installation must be performed by a licensed electrician and all
grounding connections must be properly installed.
Basic Installation & Configuration for Mach 3
Guidelines for Mach 3 EL-Series Spa Controllers.
Use minimum 6AWG copper conductors only.
Torque field connections between 21 and 23 in-lbs.
Readily accessible disconnecting means to be provided at
time of installation.
Permanently connected.
Connect only to a circuit protected by a Class A Ground Fault
Circuit Interrupter (GFCI) mounted at least 5’ (1.52M) from the
inside walls of the spa/hot tub and in line of sight from the
equipment compartment.
CSA enclosure: Type 2
Typical field connections
for main power.
Refer to Wiring Diagram
inside the cover of the
control enclosure.
Refer to Installation and
Safety Instructions provided
by the spa manufacturer.
Warning: People with infectious diseases should not use a
spa or hot tub.
Warning: To avoid injury, exercise care when entering or
exiting the spa or hot tub.
Warning: Do not use a spa or hot tub immediately following
strenuous exercise
Warning: Prolonged immersion in a spa or hot tub may be
injurious to your health
Caution: Maintain water chemistry in accordance with the
Manufacturers instructions.
Caution: The equipment and controls shall be located not
less than 1.5 meters horizontally from the spa or hot tub.
CSA Compliance/Conformité
Caution:
• Test the ground fault circuit interrupter before each use of
the spa.
• Read the instruction manual.
• Adequate drainage must be provided if the equipment is to
be installed in a pit.
• For use only within an enclosure rated CSA Enclosure 3.
• Connect only to a circuit protected by a Class A ground
fault circuit interrupter.
• To ensure continued protection against shock hazard, use
only identical replacement parts when servicing.
• Install a suitably rated suction guard to match the
maximum flow rate marked.
Warning:
• Water temperature in excess of 38°C may be injurious to
your health.
• Disconnect the electrical power before servicing.
Attention:
• Toujours verifier l’efficacite du disjoncteur differentiel avant
d’utiliser differentiel avant d’utiliser le bain.
• Lire la notice technique.
• Lorsque l’appareillage est installe dans une fosse, on doit
assurer un drainage adequat.
• Employer uniquement a l’interieur d’une cloture CSA
Enclosure 3.
• Connecter uniquement a un circuit protege par un
disjoncteur differentiel de Class A.
• Afin d’assurer une protection permanente contre le danger
de shock electrique, lors de l’entretien employer seulement
des pieces de rechange identiques.
• Les prises d’aspiration doivent etre equipees de grilles
convenant au debit maximal indique.
Avertissement:
• Des temperatures de l’eau superieures a 38°C peuvent
presenter un danger pour la sante.
• Deconnecter du circuit d’alimentation electrique
avante l’entretien.
Warning/Advertissement:
• Disconnect the electric power before servicing. Keep access
door closed.
• Deconnecter du circuit d’alimentation electrique avant
l’entretien. Garder la porte fermer.
GREEN
WHITE
WHITE AC (120 V)
FOR W-WIRES
RED AC (240 V)
FOR W-WIRES
BLACK
RED
FROM GFCI
J23 J19 J28
J43 J42 J48
J53 J54
J55 J25
J26
Warning! GFCI Protection.
The Owner should test and reset the GFCI on a regular
basis to verify its function.
Warning! Qualified technician required for service and installation.
pn: 40711-99_B 04-25-2007
