#27531 Wide Body LCD TV Cart
with 2 Pull-out Shelves & Locking Cabinet
Assembly Instructions

2
P13 Inner Slide 14 2 EA
P14 Outer Slide 14 2 EA
P15 Inner Slide 18 2 EA
P16 Outer Slide 18 2 EA
P17 Laptop Shelf 19x14 1 EA
P18 Laptop Shelf 19x18 1 EA
P19 Shelf Support 4 EA
P20 Cabinet Shelf 1 EA
P21 Left Support Tubes 1 EA
P22 Right Support Tubes 1 EA
P23 LCD Bracket 2 EA
P24 Verticle Adj Straps 2 EA
P25 Cord Winder 1 EA
P26 Electrical Outlet 1 EA
P1 FormedLeg”O” 2 EA
P2 FormedLeg”X” 2 EA
P3 TopShelf 2 EA
P4 Middle Shelf 1 EA
P5 Bottom Shelf 1 EA
P6 Side Panel w/brackets 2 EA
P7Back Panel 1 EA
P8 Left Door w/Lock 1 EA
P9 Right Door 1 EA
P10 Angle Bracket-Lap Shelf 4 EA
P11Left Laptop Support 1 EA
P12 Right Laptop Support 1 EA
Part Drawing Description Qty Part Drawing Description Qty
#27531 Wide Body LCD Cart
Do not use unless all screws are tight. At least every six months, check all screws to be sure
they are tight. If parts are missing, broken, damaged, or worn, stop use of the product
until repairs are made by your dealer using factory authorized parts.
SIDE WELDED

3
Hardware List
ASq Hd Screw M8x15mm 24 EA
A1 Screw Pan HD M4X10mm 18 EA
A2 Screw M5X70mm Pan Hd 2 EA
A3 Screw M8X25mm Pan Hd 4 EA
A4 Screw M6X35mm Pan Hd 4 EA
A5 Screw M8X20mm SocketHd 2 EA
A6 Screw M6X20mm Pan Hd 4 EA
A7 Screw Pan HD M5X10mm 24 EA
A8 Screw Pan HD M6X15mm 4 EA
BHex nut M8 w/Flange 24 EA
B1 Hex nut M4 w/Flange 18 EA
B2 Hex nut M5 w/Flange 2 EA
B3 Hex nut M8 4 EA
B4 Hex nut M6 8 EA
C1 Flat Washer M5 24 EA
C2 Flat Washer M8 6 EA
D4” Locking Caster 2 EA
E4” Caster 2 EA
We recommend that you assemble this
unit on a table.
Tools required: PhillipsHeadScrewdriver,
AdjustableCrescentWrench
electrical
back of monitor tube
kb hangers
for inside cabinet
for inside cabinet
for slide assembly
for slide assembly
kb hangers
electrical
#27531 Wide Body LCD Cart

4
#27531 Wide Body LCD Cart
Assembly Diagram
Identifyand Separateall theParts andHardware.
Illustration # 1
1.)
2.)
R EAD T HROUGH I NSTRUCTIONS FROM BEGINNING TO END BEFORE STARTING TO ASSEMBLE UNIT .
Attach 2 Legs (P-1) and 2 Legs
(P-2)to theTopShelf(P-3)using 8
screws(A), and8 Nuts (B).
P-3
P1
Illustration #2B
3.)
P1
P-2
P-2
A
A
Note-“X”or“O”
stamped in Bracket on
eachleg
A
P-3
P1
P-2
A
B
B
B
B
A
P-5
P-4
P-5
Door stop
Grommet
P-3
P-4
SlideMiddle Shelf (P-4) inbetween
the 4 Legs (P1 & P-2) and attach
using8 screws (A),and 8 Nuts(B)
asshown inillustrations#2A &2B.
SlideBottomShelf (P-5) in
between the 4 Legs (P1 & P-2) as
shownin illustrations#2A &2B.
Note Shelf & Doorstop
Locations
Illustration #2A
4.)
Note-“X”or“O”
stamped in Bracket on
eachleg

5
Press 2 Locking Casters
(D)and 2non-locking
casters(E) intothe factory
installednyloninserts in
the Base Cabinet (P-1) as
showninillustration#3B.
Note: Be sure that Door stop on Bottom
Shelf(P5) isorientedtowared thefront of
cart. GrommetsinTopShelf(P3) and
Middle Shelf (P4) are toward the back as
shownin illustration#3A.
Door stop
Grommet
Door stop-this side
Grommet
P7
P6
P5
P6
E
D
A
B
B
A
A
Attach 2 side Panels (P-6) and Middle
Shelf (P-4) to the 4 Legs (P-1 & P-2)
using 4 screws (A) and 4 Nuts (B) as
shownin illustration# 3Aand 3B.
AttachBack Panel (P-7)and Middle Shelf
(P-2) to the 4 Legs (P-1 & P-2) using 4
screws(A) and 4 Nuts(B). as shownin
illustration# 3Aand 3B.
Illustration #3A
Illustration #3B
5.)
6.)
7.)
P-5
P-3
P-4
P1
P-2
P2
P1
P-2
P6
P6

6
AttachCord Winder (P-25)and Electrical
Outlet(P-26) toTopShelf (P-3)using2
screws(A2) and 2Nuts (B2).
Attach Leftand RightSupportTubes
(P-21 & P-22) to Top Shelf (P-3) using 2
screws(A4) and 2Washers(C2)as shown
inillustration #4.
Attach 2 LCD Brackets (P-23)
to Leftand RightSupportTubes
(P-21 & P-22) at desired height
using4 screws (A6)as shown
inillustration #5.
Attach 2 VerticleAdj Straps
(P-24) to the 2 LCD Brackets
(P-23) at desired width using 4
screws(A3), 4 Washers (C2)
and4 HexNuts (B3)as shown
inillustration #5.
Illustration #5
Illustration #4
Theproductyouhave purchasedisguaranteedagainstmaterial andworkmanshipdefects. Thisguarantee
extends1year from dateofpurchase. Should thisproductfailto functionsatisfactorilyundernormal usedueto
defectorimperfection, thedefectivepart orproductwill bereplaced. Damage caused bycommon carriers during
shipmentisnotincludedinthisguarantee.
This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed or
impliedshallapply. Failure tofollow instructionsfound inImportant InformationSection ofOwnerSheet
shallvoid the guarantee. Consequential orincidentaldamagesand or costs arenotrefundable.
Important
C2
A2
A2
P-22
A5
B2
B3
P-3
A3
A6
B3
A3
P-4
8.)
9.)
10.)
11.)
P-24
C2
P-23
P-21
P-25
P-26
P-3
P-23
P-24

7
Attach 2 inner Slides 14 (P-13)
toLaptopShelf 19x14 (P-17)
using4 screws (A1) and4 Hex
Nuts(B1) asshown in
illustration #7.
Illustration #7
Attach2 inner Slides18
(P-15)to Laptop Shelf
19x18(P-18) using 4
screws(A1) and 4Hex
Nuts(B1) asshown
inillustration #8.
16.)
15.)
A1
B1
P-18
P-15
P-15 B1
A1
A1
B1
P-17
P-13
P-13 B1
AttachLeft Door w/Lock (P-8)to
theLeft Front Leg(P-1) using 3
screws(A7)and 3 Washers(C1)
asshown inillustration #6.
AttachRight Door (P-9) tothe
RightFront Leg (P-2)using 3
screws(A7) and 3Washers(C1).
Secure 2 side Panels (P-6) and
Back Panel (P-7) to the Legs
(P-1 & P-2) using 18 screws (A7)
and18 Washers
(C1)as shown in
illustration# 6.
12.)
13.)
14.)
P-9
P-4
A7
C1
A7
C1
A7
C1
P-8
A7
C1
P-1
P-2
Illustration #6
P-6
P-7

8
Slide Laptop Shelf 19x14 (P-17)
in the 2 Outer Slides14 (P14) as
showninillustration #9.
Slide Laptop Shelf 19x18 (P-18)
inthe 2 Outer Slides18(P16).
Illustration #9
P-14
P-17
P-16
P-18
P-15
P-13
20.)
21.)
Illustration #8
Attach4 angle Brackets
(P-10)to the Leftand
RightLaptop Supports
(P-11 & P-12) using 4
screws(A8) and 4Hex
Nuts(B4) asshown in
illustration# 8.
B1
A8
A1
B1
Attach 1 Outer Slide 14 (P-14) and 1 Outer Slide 18 (P-16) to the Right Laptop Support (P-12)
using5 screws (A1)and 5Hex Nuts (B1)as shown inillustration #8.
17.)
19.)
P-14
P-16
P-16
P-14
A1
P-11
P-12
B4
A8
A1
B4
18.)
Attach 1 Outer Slide 14 (P-14) and 1 Outer Slide
18 (P-16) to the Left Laptop Support (P-11)
using5 screws (A1) and5 Hex Nuts(B1)as
showninillustration #8.

9
PlaceCabinetShelf (P-20) on
topof Shelf Supports (P-19)as
shownin illustration#11.
Illustration #11
P-20
P-19
P-19
Insert4 ShelfSupports (P-19)in
the slots in the 2 Side Panels (P-6)
asshown inillustration #11.
P-6
P-6
23.)
24.)
27531 -01/18/08
Illustration #10
P-11
P-12
P-10
P-10
A4
B4
A4
B4
22.)
Tighten allscrewsusing
Phillip’shead screwdriver and
Wrench(Not Provided).
Attach4AngleBrackets(P-10)to the
4 Legs (P-1 & P-2) using 4 screws
(A4)and 4 Nuts(B4 )as shownin
illustration# 10.
