#27544 Platinum Series

Plasma/LCD Cart

Assembly Instructions

AScrew M6X13mm 6 EA

A1 ScrewM8X40mm 4 EA

A2 ScrewM6X8mm 8 EA

BPlastic Washer 2 EA

B1 Plastic Bushing 2 EA

CClamp 2 EA

DThreaded Metal Cap 2 EA

E4” Locking Caster 2 EA

F4” Caster 2 EA

GAllen Wrench 1 EA

HCaster Wrench 1 EA

P1 LeftLeg 1 EA

P2 RightLeg 1 EA

P3 LCD Tube 2 EA

P4 Lower Cross Brace 1 EA

P5 Stability Panel 1 EA

P6 Left Shelf Bracket 1 EA

P7 Right Shelf Bracket 1 EA

P8 WoodShelf 1 EA

P9 Rotation Bracket-left 1 EA

P10 Rotation Bracket-right 1 EA

P11Adj Bracket-left 1 EA

P12 Adj Bracket-right 1 EA

Part Drawing Description Qty Part Drawing Description Qty

#27544 Platinum LCD Cart

Hardware List

NOTE:

Two people are required

to asssemble this unit.

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product

until repairs are made by your dealer using factory authorized parts.

#27544 Platinum LCD Cart

Assembly Diagram

IdentifyandSeparateallthePartsandHardware.

1.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

Illustration # 2

Illustration # 1

Slide Left and Right Rotation Bracket (P9 & P10) onto 1 LCD

Tube (P3) as shown in illustration # 1.

Missing Parts or UPS Damaged Parts

ForYourConvenienceyoucan

EMAILusat

[email protected]

24HOURS 7 DAYSAWEEK

2.)

3.)

4.)Attach Left and Right Shelf Brackets (P6 & P7) to

the Left and Right Legs (P1 & P2) using 4 screws

(A2)asshowninillustration # 2.

Slide Left and RightAdj Bracket

(P11 & P12) onto 1 LCD Tube

(P3)asshowninillustration # 1.

P-9

P10

P11

P12

Attach 2 Locking Casters (E)

and 2 Casters (F) to the

bottom of the Left Leg (P1) &

RightLeg(P2) asshown in

illustration#4.Tighten

Castersusing Caster

Wrench(H).

A1 P2 P3

Slide Left and Right Rotation Bracket (P3 & P4) onto 1 LCD

Insert2LCDTubes(P3)intothe LeftandRight

Legs (P1 & P2) as shown in illustration # 3.

Should you require assistance

duringassembly,

please call our Customer Service

Department Monday - Friday

8 a.m. - 5 p.m.

CentralStandardTime

1-800-749-2258

Attach LeftandRightShelf

Brackets (P-6 & P-7) to

WoodShelf (P-8) using 4

screws(A)asshown in

illustration#4.

Donottighten.

8.)

Attach LeftandRight

Legs (P1 & P2) to the

Lower Cross Brace (P4)

using 4 screws (A1) as

showninillustration#3.

Attach StabilityPanel(P5)to

the Left and Right Legs (P1 &

P2) using 4 screws (A2) as

showninillustration#3.

Illustration # 3

Illustration # 4

5.)

6.)

7.)

9.)

Illustration # 5

10.)

P11

Illustration # 6

TheBaltproductyou havepurchased is guaranteedagainst materialand workmanship defects. Thisguarantee

extends1year fromdate of purchase. Shouldthis productfail tofunction satisfactorilyunder normaluse dueto

defectorimperfection, thedefectivepartor productwill bereplaced. Damagecausedby commoncarriers during

shipmentisnotincludedinthisguarantee.

This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed or

impliedshallapply. FailuretofollowinstructionsfoundinImportantInformationSectionofOwnerSheet

shallvoidtheguarantee. Consequentialorincidentaldamages andor costsare notrefundable.

Important

Secure RotationBrackets

(P9 & P10) using 2 Clamps (C), 2

Plastic Washers (B), 2 Plastic

Bushings(B1),and2Threaded

MetalCaps (D) as shown

inillustration#5. D

BB1

P12

Secure Brackets at desired width

bytightening(A)screwsusing

Phillip’sheadscrewdriver

P-9

P10

27544a -06/06/08

Tighten (A) & (A1)Screws

usingAllenWrench(G).
