Balt 34445 User manual

123456789012345678901234567890121234567890123456789012345678901212345678901234

#34445 Optional Door/Rack

Xtra-Wide Presentation Cart

Assembly Instructions

P-1 MetalDoor 1 EA

P-2 Hinge 2 EA

P-3 Lock 1 EA

P-4 Lock Ring 1 EA

P-5 Rack Rail 2 EA

Part Drawing Description Qty Part Drawing Description Qty

#34445 Optional Door/Rack Xtra-Wide Presentation Cart

Hardware List

AM6X12mm Socket Screw 4 EA

BM4X10mm Csink Screw 12 EA

CSheet Metal Screw 4 EA

DLock Nut M6 4 EA

EAllen Wrench 1 EA

FKey 2 EA

GWrench 1 EA

IdentifyandSeparateallthePartsandHardware.

Attach2 Hinges (P-2)to the MetalDoor (P-1) using6

Countersinkscrews(B) asshowninillustration # 1.

Tighten screws using phillips screwdriver.

Insert1Lock(P-3)into the large hole as shown in

illustration#1. Press Lock Ring (P-4) overprotruding

endof Door Lock (P-3) as shown inillustration # 1.

Secureusing4Screws (C).

1.)

2.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

BP-2

P-2

Illustration # 1

P-1

P-3

P-4

3.)

(ForLock)

#34445 Optional Door & Rack for Xtra-Wide Presentation Cart

4.)Attach2 Rack Rails (P-5)totheLeft

andRightLegAssemblyofXtra-

wide Presentation Cart #27517

using4 screws (A) and 4Locknuts

(D)asshowninillustration # 3.

Illustration # 2

Should you require assistance

duringassembly,

please call our Customer Service

Department Monday - Friday

8 a.m. - 5 p.m.

CentralStandardTime

1-800-749-2258

P-5

#27517 Right Leg

#27517 Left Leg

Tighten screws using

Allen Wrench (E) and

Wrench(G).

TheBaltproductyou have purchasedis guaranteedagainst material andworkmanship defects. This

guaranteeextends1yearfrom date ofpurchase. Should this productfail to functionsatisfactorily under normal

usedue todefect orimperfection,the defectivepartorproduct willbereplaced. Damage causedby common

carriersduringshipmentisnotincludedinthisguarantee.

This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed or

impliedshallapply. FailuretofollowinstructionsfoundinImportantInformation SectionofOwner

Sheetshallvoidtheguarantee. Consequential orincidental damagesand orcosts arenotrefundable.

Important

4#34445-02/23/12

Illustration # 3

#27517 Right Leg

P-1

P-2

AttachMetalDoor (P-1) to the Right

Leg (P-2) of Xtra-Wide Presentation

Cart #27517 using 6 screws (B) as

showninillustration#3.

P-1

P-5

5.)

Missing Parts or UPS Damaged Parts

ForYourConvenienceyoucan

EMAILusat

[email protected]

24HOURS 7 DAYSAWEEK F

P-3

Illustration # 4

Lock Door using Key (F) as shown in

illustration#4.

6.)
