Balt 85052 web-av User manual

123456789012345678901234567890121234567890123456789012345678901212345678901234

85052

Web-AV

Assembly Instructions

123456789012345678901234567890121234567890123456789012345678901212345678901234

#85052 Web-AV

Adjustable Bi-Level

Presentation/Stand-Up Workstation

Assembly Instructions

A9/16”SocketScrew 12 EA

A1 1-7/8”SocketScrew 4 EA

A2 2-1/2”SocketScrew 8 EA

CSquareNut 4 EA

D3”LockingCaster 2 EA

E3”Caster 2 EA

FBlack Plastic Spacer 2 EA

GHexNut 4 EA

HFlat Washer 4 EA

JAllenWrench 1 EA

KOpenEndWrench 1 EA

Part Drawing Description Qty Part Drawing Description Qty

Hardware List

P-1 MonitorShelf 1 EA

P-2 KeyboardShelf 1 EA

P-3 RightUpperInsert 1 EA

P-4 LeftUpperInsert 1 EA

P-5 Stability Panel 1 EA

P-6 CDRack 1 EA

P-7 Accessory Shelf 1 EA

P-8 RightLegReceiver 1 EA

P-9 LeftLegReceiver 1 EA

P-10 CPU Sleeve 1 EA

P-11CPU Rod 2 EA

AssemblyDiagram

To Assemble:

SeparateandIdentifyalltheParts

andHardware.

AttachMonitorShelf(P-1) to

RightUpperInsert (P-3) and Left

UpperInsert (P-4), using 4 each

(A2)Socket Screws.Attach

KeyboardShelf (P-2) using 4each

(A2)Socket Screws as shown in

illustration#1.

AttachCD Rack(P-6) using 4 each (A)

screws.Attachasshowninillustration#1.

AttachStabilityPanel(P-5)to the

Leftupper insert and Right Upper

Insert (P-4 & P-3) using 4 each (A)

Screwsas shown inillustration#2.

Illustration # 1

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

1.)

2.)

3.)

Illustration # 2

P-4

P-5

P-1

P-4

P-3

A2 P-2

P-6

P-1

P-3

P-2

4.)

AttachAccessory Shelf (P-7) toLeft &

RightLegReceivers(P-9& P-8) using

4(A1)screwsas shown in illustration#3.

Attach 2 each CPU Rods (P-11) to

the Left Leg Receiver (P-9) (orRight Leg

Receiver (P-8)). Secure each rod with 2

each(G) Hex nuts, 2 each(H) Flat

Washers and 1 each (F) Black spacer.

Slide CPU Sleeve (P-10) over ends of CPU

Rods (P-12) as shown.

AttachRight Leg Receiver (P-8)to

RightUpperInsert (P-3) using 2each

(A) Screws and 2 each (C) Square

nuts.AttachLeft Leg Receiver (P-9)to

LeftUpper Insert (P-4)using2 each

(A) Screws and 2 each (C) Square

nuts.(flat side ofthenut should be next to

themetal)

Illustration # 3

Illustration # 4

5.)

6.)

7.)

TightenallscrewsSecurely

usingAllenWrench(J).

8.)

9.)

Attach2each(D) Locking

Casterstothe front of theunit,

and 2 each (E) Casters to the

backoftheunitas shown in

illustration#4.Tightenusing

OpenEndWrench(K).

P-7

P-9

P-8

P-4

P-3

P-9

P-11

P-10

P-8

85052_1-9-14

85052

Web-AV

123456789012345678901234567890121234567890123456789012345678901212345678901234

#85052 Web-AV

Adjustable Bi-Level

Presentation/Stand-Up Workstation

Assembly Instructions

38 1/2”-44 1/2”

24”

18”

14”

24”

3”Casters
