Banner Q4X Series User manual

Q4XStainlessSteelAnalogLaserSensor
InstructionManual
Original Instrucons
185624 Rev. E
21 November 2017
©Banner Engineering Corp. All rights reserved
185624

Contents
1 Product Descripon ..........................................................................................................................................................3
1.1 Models ...................................................................................................................................................................................................3
1.2 Overview ............................................................................................................................................................................................... 3
1.3 Features .................................................................................................................................................................................................4
1.3.1 Display and Indicators ............................................................................................................................................................... 4
1.3.2 Buons ..................................................................................................................................................................................... 4
1.4 Laser Descripon and Safety Informaon .............................................................................................................................................5
2 Installaon .......................................................................................................................................................................6
2.1 Install the Safety Label .......................................................................................................................................................................... 6
2.2 Sensor Orientaon ................................................................................................................................................................................ 6
2.3 Mount the Sensor ..................................................................................................................................................................................6
2.4 Wiring Diagram ..................................................................................................................................................................................... 7
2.5 Cleaning and Maintenance ....................................................................................................................................................................7
3 Sensor Programming ....................................................................................................................................................... 8
3.1 Setup Mode ...........................................................................................................................................................................................8
3.1.1 TEACH Menu ...........................................................................................................................................................................10
3.1.2 Base Measurement Rate ........................................................................................................................................................ 10
3.1.3 Averaging ................................................................................................................................................................................10
3.1.4 Slope .......................................................................................................................................................................................11
3.1.5 Zero Reference Locaon ........................................................................................................................................................ 12
3.1.6 Shi the Zero Reference Locaon aer a TEACH ...................................................................................................................12
3.1.7 Loss of Signal .......................................................................................................................................................................... 13
3.1.8 Input Wire Funcon ............................................................................................................................................................... 14
3.1.9 Trigger .................................................................................................................................................................................... 14
3.1.10 Display View ......................................................................................................................................................................... 15
3.1.11 Exit Setup Mode ................................................................................................................................................................... 15
3.1.12 Reset to Factory Defaults ..................................................................................................................................................... 15
3.2 Manual Adjustments ........................................................................................................................................................................... 16
3.2.1 Manual Adjustments in Two-Point TEACH Mode ...................................................................................................................16
3.2.2 Manual Adjustments in One-Point TEACH Mode ...................................................................................................................17
3.3 Remote Input ....................................................................................................................................................................................... 17
3.3.1 Select the TEACH Mode Using the Remote Input ...................................................................................................................17
3.3.2 Reset to Factory Defaults Using the Remote Input ................................................................................................................ 18
3.4 Locking and Unlocking the Sensor Buons .......................................................................................................................................... 18
3.5 TEACH Procedures ...............................................................................................................................................................................19
3.5.1 Two-Point TEACH ....................................................................................................................................................................19
3.5.2 One-Point TEACH ....................................................................................................................................................................20
3.6 Sync Master/Slave ...............................................................................................................................................................................21
4 Specicaons ................................................................................................................................................................ 22
4.1 Dimensions ..........................................................................................................................................................................................23
4.2 Performance Curves—Threaded Barrel Models ................................................................................................................................. 24
4.3 Performance Curves—Flush Mount Models ........................................................................................................................................ 25
5 Abbreviaons ................................................................................................................................................................27
6 Troubleshoong ............................................................................................................................................................ 29
7 Accessories .....................................................................................................................................................................30
7.1 Cordsets ...............................................................................................................................................................................................30
7.2 Brackets ...............................................................................................................................................................................................31
7.3 Aperture Kits—Threaded Barrel Models .............................................................................................................................................32
8 Contact Us .....................................................................................................................................................................33
9 Banner Engineering Corp. Limited Warranty ..................................................................................................................34
Q4X Stainless Steel Analog Laser Sensor

1 Product Descripon
Class 1 laser CMOS analog sensor with an analog output. Patent pending.
• Reliably detects submillimeter distance changes
•Connuous measurement of challenging targets from dark to reecve, out to 500 mm
(threaded barrel models) or 310 mm (ush mount models), depending on model
•Resists mechanical impact, over ghtening, and extreme vibraon
•Simplied user experience with analog (V or mA) or distance (mm) readout from the angled,
four-digit display
•Easy setup with responsive buons
• Durable and robust construcon resists mechanical impact, over ghtening, and extreme
vibraon
• FDA grade stainless steel, rated to IP67, IP68, and IP69K, ECOLAB®cered chemically-
resistant materials, and laser marked sensor informaon withstands aggressive cleaning
procedures
• Superior ambient light resistance
For illustraon purposes, the threaded barrel model Q4X images are used throughout this document.
WARNING: Not To Be Used for Personnel Protecon
Never use this device as a sensing device for personnel protecon. Doing so could lead to serious injury or death.
This device does not include the self-checking redundant circuitry necessary to allow its use in personnel safety
applicaons. A sensor failure or malfuncon can cause either an energized or de-energized sensor output
condion.
1.1 Models
Model Sensing Range Output Connecon1
Q4XTULAF500-Q8 25 mm to 500 mm (0.98 in to
19.68 in) Analog voltage (0 to 10 V)
Integral 5-pin M12/Euro-style male
quick disconnect (QD)
Q4XTILAF500-Q8 Analog current (4 to 20 mA)
Q4XTULAF300-Q8 25 mm to 300 mm (0.98 in to
11.81 in) Analog voltage (0 to 10 V)
Q4XTILAF300-Q8 Analog current (4 to 20 mA)
Q4XTULAF100-Q8 25 mm to 100 mm (0.98 in to
3.94 in) Analog voltage (0 to 10 V)
Q4XTILAF100-Q8 Analog current (4 to 20 mA)
Q4XFULAF310-Q8 35 mm to 310 mm (1.38 in to
12.20 in) Analog voltage (0 to 10 V)
Q4XFILAF310-Q8 Analog current (4 to 20 mA)
Q4XFULAF110-Q8 35 mm to 110 mm (1.38 in to
4.33 in) Analog voltage (0 to 10 V)
Q4XFILAF110-Q8 Analog current (4 to 20 mA)
1.2 Overview
The Q4X Analog Sensor is a Class 1 laser CMOS measuring sensor that uses a 0 to 10 V (4 to 20 mA) output to represent the distance
measured.
When the sensor is in Run mode, the display shows the current measurement reading or corresponding analog output value. The size
and locaon of the analog output window can be manually adjusted or the selected TEACH method can be performed.
When the sensor is in Setup mode, all standard operang parameters, including TEACH mode, analog slope, response me, and more
can be adjusted, or a factory reset can be performed.
1QD models require a mang cordset.
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

1.3 Features
1
2
3
Figure 1. Sensor Features
1. Output Indicator (Amber)
2. Display
3. Buons
1.3.1 Display and Indicators
The display is a 4-digit, 7-segment LED. The main screen is the Run Mode screen, which shows the current distance to the target in
millimeters.
Figure 2. Display in Run Mode
1. Stability Indicator (STB = Green)
2. Acve TEACH Indicators
•2-PT = Two-Point TEACH (Amber)
• 1-PT = One-Point TEACH (Amber)
3. Display Value Indicator (MM = Amber)
Output Indicator
•On—Displayed distance is within the taught analog
output window
•O—Displayed distance is outside of the taught analog
output window
Stability Indicator (STB)
•On—Stable signal within the specied sensing range
•Flashing—Marginal signal, the target is outside of the
limits of the specied sensing range, or a mulple peak
condion exists
•O—No target detected within the specied sensing
range
Acve TEACH Indicators (2PT and 1PT)
•2-PT on—Two-point TEACH mode selected (default)
• 1-PT on—One-point TEACH mode selected
Display Value Indicator (MM)
•On—Display shows the distance in millimeters (default)
•O—Display shows the analog output value
1.3.2 Buons
Use the sensor buons (SELECT)(TEACH), (+)(DISP), and (-)(MODE) to program the sensor.
Q4X Stainless Steel Analog Laser Sensor
4 www.bannerengineering.com - Tel: [phone]

(SELECT)(TEACH)
•Press and hold for longer than 2 seconds to start the
currently selected TEACH mode (the default is two-point
TEACH)
• Press to select menu items in Setup mode
(-)(MODE)
• Press to change the distance seng for the 0 V (4 mA )
point; press and hold to decrease numeric values
• Press and hold for longer than 2 seconds to enter Setup
mode
• Press to navigate the sensor menu in Setup mode
(+)(DISP)
•Press to change the distance seng for the 10 V (20 mA)
point; press and hold to increase numeric values
• Press and hold for longer than 2 seconds to toggle the
display value between the distance and the analog output
• Press to navigate the sensor menu in Setup mode
Note: When navigang the menu, the menu items
loop.
1.4 Laser Descripon and Safety Informaon
CAUTION: Use of controls or adjustments or performance of procedures other than those specied herein may result in
hazardous radiaon exposure. Do not aempt to disassemble this sensor for repair. A defecve unit must be returned to the
manufacturer.
Class 1 Lasers
Class 1 lasers are lasers that are safe under reasonably foreseeable condions of operaon, including the use of opcal instruments
for intrabeam viewing.
Laser wavelength: 655 nm Output: < 0.20 mW Pulse Duraon: 7 µs to 2 ms
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

2 Installaon
2.1 Install the Safety Label
The safety label must be installed on Q4X sensors that are used in the United
States.
Note: Posion the label on the cable in a locaon that has minimal
chemical exposure.
1. Remove the protecve cover from the adhesive on the label.
2. Wrap the label around the Q4X cable, as shown.
3. Press the two halves of the label together.
COMPLIES WITH IEC 60825-1:2007
CLASS 1
LASER PRODUCT
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR DEVIATIONS PURSUANT TO
LASER NOTICE No. 50, DATED JUNE 24, 2007.
BANNER ENGINEERING CORP.
9714 10TH AVENUE NORTH
MINNEAPOLIS, MN 55441
COMPLIES WITH IEC 60825-1:2007
CLASS 1
LASER PRODUCT
Figure 3. Safety Label Installaon
2.2 Sensor Orientaon
Opmize detecon reliability and performance with correct sensor-to-target orientaon. To ensure reliable detecon, orient the sensor
as shown in relaon to the target to be detected.
Figure 4. Opmal Orientaon of Target to Sensor
See the following gures for examples of correct and incorrect sensor-to-target orientaon as certain placements may pose problems
for sensing some targets.
Incorrect
Correct
Figure 5. Orientaon by a wall
Incorrect
Correct
Figure 6. Orientaon for a turning object
Incorrect
Correct
Figure 7. Orientaon for a height dierence
Horizontal
Orientation
Vertical
Orientation
(Optimal)
Figure 8. Orientaon for a color or luster
dierence
Reflective
Surface
(optional)
Figure 9. Orientaon for highly reecve target2
2.3 Mount the Sensor
1. If a bracket is needed, mount the sensor onto the bracket.
2. Mount the sensor (or the sensor and the bracket) to the machine or equipment at the desired locaon. Do not ghten the
mounng screws at this me.
2Applying lt to sensor may improve performance on reecve targets. The direcon and magnitude of the lt depends on the applicaon, but a 15° lt is oen sucient.
Q4X Stainless Steel Analog Laser Sensor
6 www.bannerengineering.com - Tel: [phone]

3. Check the sensor alignment.
4. Tighten the mounng screws to secure the sensor (or the sensor and the bracket) in the aligned posion.
2.4 Wiring Diagram
3
1
2
4
5
12-30V dc
Remote
Teach
Shield
Load
+
–
Analog Out
Analog Gnd
Note: Open lead wires must be connected to a terminal block.
1
4
5
3
2
Key1 = Brown
2 = White
3 = Blue
4 = Black
5 = Gray
Note: The input wire funcon is user-selectable. The default for the input wire funcon is o (disabled).
Note: Shielded cordsets are recommended for all models with quick disconnect ngs. It is recommended that the shield
wire be connected to -V dc (the blue wire).
2.5 Cleaning and Maintenance
Handle the sensor with care during installaon and operaon. Sensor windows soiled by ngerprints, dust, water, oil, etc. may create
stray light that may degrade the peak performance of the sensor. Blow the window clear using ltered, compressed air, then clean as
necessary using water and a lint-free cloth.
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

3 Sensor Programming
Program the sensor using the buons on the sensor or the remote input (limited programming opons).
In addion to programming the sensor, use the remote input to disable the buons for security, prevenng unauthorized or accidental
programming changes. See Locking and Unlocking the Sensor Buons on page 18 for more informaon.
3.1 Setup Mode
1. Access Setup mode and the sensor menu from Run mode by pressing and holding MODE for longer than 2 seconds.
2. Use and to navigate through the menu.
3. Press SELECT to select a menu opon and access the submenus.
4. Use and to navigate through the submenus.
5. Select a submenu opon.
• Press SELECT to select a submenu opon and return to the top menu.
•Press and hold SELECT for longer than 2 seconds to select a submenu opon and return immediately to Run mode.
To exit Setup mode and return to Run mode, navigate to and press SELECT.
Q4X Stainless Steel Analog Laser Sensor
8 www.bannerengineering.com - Tel: [phone]

two-point teach
one-point teach
Top Menu
set Base Measurement Rate to 0.3 ms
set Base Measurement Rate to 0.5 ms
set Base Measurement Rate to 1.0 ms
set Base Measurement Rate to 5.0 ms
set Base Measurement Rate to 2.5 ms
near: set zero displayed value to end of 18 mm barrel
far: set zero displayed value to maximum detection range
laser off when pulled low
set: Remote Teach input
off: remote teach input is not active
master
laser on when pulled low
slave
trigger
display on
display on, inverted
display off (enters sleep mode after 60 seconds)
display off, inverted (enters sleep mode after 60 seconds)
end: select to exit setup
no: do not reset to factory defaults
yes: reset to factory defaults
on: move the zero point after each teach
hold
off: zero point is either at end of barrel or
maximum detection range
Teach Process Selection
Base Measurement Rate
Select Zero Reference Location
Shift Zero Reference after Teach
Input Wire Function
Display Read
Exit Setup
Reset to Factory Defaults
Sub Menus
( default setting)
Trigger Mode appears when Input Wire Function is set to “trigger”
positive slope
negative slope
Slope
average 1 measurement for analog output
average 2 measurements for analog output
average 4 measurements for analog output
average 8 measurements for analog output
average 16 measurements for analog output
average 32 measurements for analog output
average 64 measurements for analog output
average 128 measurements for analog output
average 256 measurements for analog output
average 512 measurements for analog output
Averaging
(3.5 mA)
(20.5 mA)
Loss of Signal
max. distance
range (max. dist - min. dist)
average measurement
track max. distance
min. distance
track min. distance
sample measurement
Trigger Mode
hold
(0 V)
(10.5 V)
voltage modelscurrent models
Figure 10. Sensor Menu Map
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

3.1.1 TEACH Menu
Use this menu to select the TEACH mode. The default is two-point TEACH.
• —Two-point
• —One-point TEACH
Aer the TEACH mode is selected, from Run mode, press and hold TEACH for longer than 2 seconds to start the TEACH mode and
program the sensor. See TEACH Procedures on page 19 for addional informaon and remote input TEACH instrucons.
3.1.2 Base Measurement Rate
Use this menu to select the base measurement rate. The total response speed depends upon the measurement rate seng and the
averaging seng. See Averaging on page 10 for more informaon.
•—0.3 ms
• —0.5 ms
• —1.0 ms
•—2.5 ms
• —5.0 ms
Table 1: Tradeos—Threaded Barrel Models
Base Measurement Rate
(ms) Base Measurement Rate in Sync Mode (ms) Ambient Light Rejecon Excess Gain—90% white card
at 25 mm at 100 mm at 300 mm at 500 mm
0.3 0.5 Disabled 200 100 20 7
0.5 1.0 Enabled 200 100 20 7
1.0 2.0 Enabled 1000 500 100 36 (18)
2.5 5.0 Enabled 2500 1250 250 90 (36)
5.0 10.0 Enabled 5000 2500 500 180 (90)
Table 2: Tradeos—Flush Mount Models
Base Measurement Rate (ms) Base Measurement Rate in
Sync Mode (ms) Ambient Light Rejecon Excess Gain—90% white card
at 35 mm at 110 mm at 310 mm
0.3 0.5 Disabled 200 100 20
0.5 1.0 Enabled 200 100 20
1.0 2.0 Enabled 1000 500 100
2.5 5.0 Enabled 2500 1250 250
5.0 10.0 Enabled 5000 2500 500
3.1.3 Averaging
Use this menu to set the number of measurements that are averaged together for the analog output. Increasing the averaging improves
repeatability, but increases the total response speed. The default is 1. The lter can be set to 1, 2, 4, 8, 16, 32, 64, 128, 256, or 512. Use
the table to determine the total response speed.
Q4X Stainless Steel Analog Laser Sensor
10 www.bannerengineering.com - Tel: [phone]

Table 3: Response Speed
Base Measurement
Rate Filter Seng
1 2 4 8 16 32 64 128 256 512
0.3 ms 0.5 ms 0.75 ms 1.5 ms 4 ms 8 ms 15 ms 30 ms 60 ms 120 ms 240 ms
0.5 ms 0.5 ms 1 ms 2 ms 5 ms 10 ms 25 ms 50 ms 100 ms 200 ms 350 ms
1 ms 1 ms 3 ms 5 ms 10 ms 20 ms 40 ms 75 ms 150 ms 300 ms 600 ms
2.5 ms 2.5 ms 5 ms 10 ms 25 ms 45 ms 80 ms 160 ms 320 ms 640 ms 1280 ms
5 ms 5 ms 10 ms 20 ms 40 ms 80 ms 160 ms 320 ms 640 ms 1280 ms 2560 ms
Table 4: Lateral Entry Response
Base Measurement Rate Lateral Entry Response
0.3 ms 1.5 ms
0.5 ms 3 ms
1 ms 10 ms
2.5 ms 25 ms
5 ms 50 ms
When lateral entry needs to be considered, the lateral entry
response is added to calculate the total response me.
Note: The Q4X uses a dynamic measurement rate, so these response mes are worst-case.
3.1.4 Slope
Use this menu to set the slope as posive or negave. This swaps the 0 V and 10 V (4 and 20 mA) values. The default is posive. The
slope is dened relave to the zero reference, so if the zero seng is changed from near to far, a slope will be considered posive if the
analog output increases as the target becomes closer to the face of the sensor.
•—the slope is posive
• —the slope is negave
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

0
Near
Window
Far
Window
10
Analog Output (V dc)
Positive
Slope
Target Position
The analog voltage output tracks slightly beyond the upper window limit (up to
10.2 V)
Figure 11. Slope—Voltage Sourcing Models
4
Near
Window
Far
Window
20
Target Position
Analog Output (mA)
Positive
Slope
The analog current output tracks slightly beyond each window limit (from 3.8 mA
to 20.2 mA)
Figure 12. Slope—Current-Sourcing Models
3.1.5 Zero Reference Locaon
Use this menu to select the zero reference locaon. The default is , 0 = the front of the sensor.
• —0 = the front of the sensor; the measurement increases further from the sensor
• —0 = maximum range; the measurement increases closer to the sensor
3.1.6 Shi the Zero Reference Locaon aer a TEACH
Use this menu to select whether the sensor shis the zero reference locaon based on the last TEACH process. The default is , 0
= the front of the sensor or the maximum range.
•—Shi the zero reference locaon to one of the taught posions with each TEACH
• —0 = the front of the sensor or the maximum range, depending on the seng
This gure illustrates three examples of how changes to the zero and shi sengs aect what distance readout is shown on the display
when in 2-pt TEACH mode. Changes to the zero seng aect the direcon in which the distance increases. Turning the shi seng on
sets the taught locaon as the reference point for any distance measurement. For two-point TEACH, this is the 0 V (4 mA) point. For
one-point TEACH, this is the 5 V (12 mA) point.
Q4X Stainless Steel Analog Laser Sensor
12 www.bannerengineering.com - Tel: [phone]

Zero = Near
(Default Setting)
Shift = Off
=
=
Zero = Far
Shift = Off
=
=
Zero = Far
Shift = On
=
=
0 V
0 V
10 V
Display Reference Display Reference
10 V
50 mm
10 V
50 mm
50 mm
Display Reference Display Reference
0 V
Display Reference
100
0
200
300
mm
0
-100
100
200
mm
0
-100
100
200
mm
100
0
200
300
mm
200
0
100
300
mm
200
0
100
300
mm
0 V
Display Reference
Figure 13. Example Zero and Shi sengs
3.1.7 Loss of Signal
Use this menu to select the Analog Output value used by the sensor during a loss of signal. When a signal is restored, measurement
resumes. The default is 0 V (4 mA).
Opon Descripon
0 V (4 mA)—default The Analog Output switches to this value 2 seconds aer a loss of signal. When advanced
measurements are enabled, the Analog Output is updated to this value immediately upon the release
of the trigger input. For Voltage models, this is 0 V (4 mA). (Default)
10.5 V (20.5 mA) The Analog Output switches to this value 2 seconds aer a loss of signal. When advanced
measurements are enabled, the Analog Output is updated to this value immediately upon the release
of the trigger input. For Voltage models, this is 10.5 V (20.5 mA).
Hold The Analog Output holds the last value indenitely during a loss of signal. When advanced
measurements are enabled, the last value is held across the triggered measurement periods.
The Range advanced measurement behavior is aected by the Loss of Signal opon. For addional informaon on advanced
measurements, see Trigger on page 14. The Range advanced measurement tracks a maximum and a minimum during the
measurement period, and calculates the range as follows:
Range = maximum distance – minimum distance
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

If the maximum and/or minimum measurements are outside of the taught range values, the Loss of Signal opon determines how the
range is calculated.
Opon Sensor Behavior in Range Mode
0 V (4 mA) If the maximum or minimum measurement is outside of the taught range values, the sensor outputs 0
V (4 mA) to indicate an out of range measurement.
10.5 V (20.5 mA) If the maximum or minimum measurement is outside of the taught range values, the sensor outputs
10.5 V (20.5 mA) to indicate an out of range measurement.
Hold The sensor limits the maximum and minimum measurements so that they cannot exceed the taught
range values.
3.1.8 Input Wire Funcon
Use this menu to select the input wire funcon. The default is o, ignore all remote input pulses.
• —Ignore all remote input pulses
• —Remote TEACH input
• —Laser o when pulled low
•—Laser on when pulled low
• —Master sync line output for two-sensor cross-talk avoidance
• —Slave sync line input for two-sensor cross-talk avoidance
•—Trigger mode for advanced measurements (see Trigger on page 14)
To congure sensors for master-slave operaon, see Sync Master/Slave on page 21.
3.1.9 Trigger
The Trigger opon sets the advanced measurement that is calculated when a trigger event is detected on the remote input. The analog
output updates with the new advanced measurement on each trigger event. To use these Trigger opons, the sensor Input Type opon
must be set to .
Trigger Submenus Descripon
Average The averaged distance since the last trigger event. (default)
Range The dierence between the maximum and minimum distance since the last trigger event. For addional informaon
on the Range measurement behavior when the maximum or minimum distance is outside of the taught values, see
Loss of Signal on page 13.
Maximum The maximum distance since the last trigger event.
Minimum The minimum distance since the last trigger event.
TrackMax The maximum distance since the last trigger event. The Analog Output tracks new maximum values during the
measurement period.
TrackMin The minimum distance since the last trigger event. The Analog Output tracks new minimum values during the
measurement period.
Sample The current distance at the me of the trigger event. The Analog Output tracks the sample values during the
measuring period.
Q4X Stainless Steel Analog Laser Sensor
14 www.bannerengineering.com - Tel: [phone]

Active
Sample
Inactive (t)
Input
Signal
Hold
Measurement Hold
Measurement
Measuring Period Measuring Period
REMOTE
INPUT
(Active Low shown)
Figure 14. Sample
Average
(t)
Input
Signal
Measuring Period Measuring Period
Hold
Measurement
Hold
Measurement
Active
Inactive
REMOTE
INPUT
(Active Low shown)
Figure 15. Average
Active
Hold
Measurement
Hold
Measurement
Inactive
Maximum
Minimum
Measuring Period (t)
Input
Signal
Hold
Measurement
REMOTE
INPUT
Measuring Period
(Active Low shown)
Measuring Period
Figure 16. Maximum and Minimum
Active
Inactive
Range
Measuring Period (t)
Input
Signal
Min
Max
Min'
(Max'-Min')
(Max-Min)
Max'
REMOTE
INPUT
(Active Low shown)
Measuring Period
Hold
Measurement
Hold
Measurement
Figure 17. Range
Active
Inactive
TrackMax
TrackMin
(t)
Input
Signal
Hold
Measurement
Hold
Measurement
REMOTE
INPUT
Measuring Period Measuring Period
(Active Low shown)
Figure 18. Track Maximum and Track Minimum
3.1.10 Display View
Use this menu to select the display view. The default is right-reading.
• —Right-reading
• —Inverted
• —Right-reading and the display enters sleep mode aer 60 seconds
• —Inverted and the display enters sleep mode aer 60 seconds
When the sensor is in sleep mode, the display wakes with the rst buon press.
3.1.11 Exit Setup Mode
Navigate to and press SELECT to exit Setup mode and return to Run mode.
3.1.12 Reset to Factory Defaults
Use this menu to restore the sensor to the factory default sengs. See Factory Default Sengs on page 16.
Select to return to the sensor menu without restoring the defaults. Select to apply the factory defaults and return to
Run mode.
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

Factory Default Sengs
Seng Factory Default
Averaging ( )
Base Measurement Rate ( ) —1 ms
Display View ( ) —Right-reading, no sleep mode
Input Wire Funcon ( ) —Ignore all remote input pulses
If the sensor was reset using the remote input, the sensor remains
in mode to allow use of the remote input.
Loss of Signal ( ) —0 V (4 mA)
Shi the Zero Reference Locaon aer a TEACH ( ) —0 = the front of the sensor
Slope ( ) —posive
TEACH Mode ( ) —Two-point TEACH
Zero Reference Locaon ( ) —Measurement increases further from sensor
3.2 Manual Adjustments
Manually adjust the distance set for the 0 V (4 mA) and 10 V (20 mA) values using the and buons. The available adjustments
vary depending on the TEACH mode selected.
3.2.1 Manual Adjustments in Two-Point TEACH Mode
Adjust the 10 V (20 mA) Point
1. From Run mode, press to view and adjust the distance associated with the 10 V (20 mA) point. displays briey,
then the value slowly ashes indicang it can be changed.
Note: If no changes are made within 8 seconds, the current distance value ashes quickly and the sensor returns to Run
mode.
2. Press to move the value up or to move the value down.
Note: If no addional changes are made within 4 seconds, the current distance value ashes quickly and the sensor
returns to Run mode.
3. Press Select to conrm the new distance value. The new distance ashes rapidly, the new seng is accepted, and the sensor
returns to Run mode.
Adjust the 0 V (4 mA) Point
1. Press to view and adjust the distance associated with the 0 V (4 mA) point. ashes briey, then the value ashes.
Note: If no changes are made within 8 seconds, the current distance value ashes quickly and the sensor returns to Run
mode.
2. Press to move the value up or to move the value down.
Note: If no addional changes are made within 4 seconds, the current distance value ashes quickly and the sensor
returns to Run mode.
3. Press Select to conrm the new distance value. The new distance value ashes rapidly, the new seng is accepted, and the
sensor returns to Run mode.
Q4X Stainless Steel Analog Laser Sensor
16 www.bannerengineering.com - Tel: [phone]

3.2.2 Manual Adjustments in One-Point TEACH Mode
Adjust the 5 V (12 mA) Midpoint
1. From Run mode, press to view and adjust the distance seng associated with the 5 V (12 mA) midpoint (the mid point of
the analog span). displays briey, then the value slowly ashes indicang it can be changed.
Note: If no changes are made within 8 seconds, the current distance value ashes quickly and the sensor returns to Run
mode.
2. Press to move the midpoint up or to move the midpoint down.
Note: If no addional changes are made within 4 seconds, the current distance value ashes quickly and the sensor
returns to Run mode.
3. Press Select to conrm the new midpoint. The new midpoint value ashes rapidly, the new seng is accepted, and the sensor
returns to Run mode.
Adjust the Analog Window Size
1. Press to view and adjust the SPAN (the analog window size). ashes briey, then the value ashes.
2. Press to increase the size of the analog window or to decrease the size of the analog window.
3. Press Select to conrm the window size. The new window size ashes rapidly, the new seng is accepted, and the sensor
returns to Run mode.
3.3 Remote Input
Use the remote input to program the sensor remotely. The remote input provides limited programming opons and is Acve low. For
Acve low, connect the gray input wire to ground (0 V dc), with a remote switch connected between the wire and ground. Pulse the
remote input according to the diagram and the instrucons provided in this manual.
The length of the individual programming pulses is equal to the value T: 0.04 seconds ≤T ≤0.8 seconds.
Exit remote programming modes by seng the remote input low for longer than 2 seconds.
2x
1x Teach 10 V (20 mA)
Save 10 V (20 mA)
1x
2x Teach Selection
Enters selected Teach (same function as pressing Teach Button for > 2 sec)
1x Teach 0 V (4 mA)
0.04 seconds < T < 0.8 seconds
Timing between Pulse groups > 1 second
Pulse Timing (T)
Input = Set
Gray wire is remote teach input
2x
1x Two-point Teach
One-point Teach
4x
2x
1x Button Unlock (uloc)
Button Lock (loc)
Button Lock
8x Reset to Factory Defaults (maintain remote input = SET)
Remote
Input
2x Save 0 V (4 mA)
2x
1x Teach 10 V (20 mA)
Save 10 V (20 mA)
3x Operator Lock (OLoc)
Figure 19. Remote Input Map
3.3.1 Select the TEACH Mode Using the Remote Input
1. Access the TEACH selecon.
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

Acon Result
Double-pulse the remote input.
T T
T
displays.
2. Select the desired TEACH mode.
Acon Result
Pulses TEACH Mode
1
T
Two-point TEACH
2
T T
T
One-point TEACH
The selected TEACH method displays for a few
seconds and the sensor returns to Run mode.
3.3.2 Reset to Factory Defaults Using the Remote Input
Eight-pulse the remote input to apply the factory defaults and return to Run mode.
T
T
T
T
T
T
T
T
T
T
T
T T
T
T
Note: The input wire funcon remains at remote teach input ( ).
3.4 Locking and Unlocking the Sensor Buons
Use the lock and unlock feature to prevent unauthorized or accidental programming changes. Three sengs are available:
• —The sensor is unlocked and all sengs can be modied (default).
• — The sensor is locked and no changes can be made.
• —The value associated with 0 V (4 mA) and 10 V (20 mA ) can be changed by teaching or manual adjustment, but no
sensor sengs can be changed through the menu.
When in mode, displays when the (SELECT)(TEACH) buon is pressed. The analog point displays when (+)(DISP) or (-)
(MODE) are pressed, but displays if the buons are pressed and held.
When in mode, displays when (+)(DISP) or (-)(MODE) are pressed and held. To access the manual adjust opons,
briey press and release (+)(DISP) or (-)(MODE). To enter TEACH mode, press the (SELECT)(TEACH) buon and hold for longer than 2
seconds.
Buon Instrucons
To enter mode, hold and press four mes. To enter mode, hold and press seven mes. Holding
and pressing four mes unlocks the sensor from either lock mode and the sensor displays .
Remote Input Instrucons
1. Access the remote input.
Acon Result
Four-pulse the remote input.
T T
TTT
T T
The sensor is ready to have the buon state
dened and displays.
2. Lock or unlock the sensor buons.
Q4X Stainless Steel Analog Laser Sensor
18 www.bannerengineering.com - Tel: [phone]

Acon Result
Single-pulse the remote input to unlock the sensor.
T
displays and the sensor returns to Run
mode.
Double-pulse the remote input to lock the sensor.
T T
T
displays and the sensor returns to Run
mode.
Triple-pulse the remote input to apply the operator lock to
the sensor
T T
T
T
T
displays and the sensor returns to Run
mode
3.5 TEACH Procedures
Use the following procedures to teach the sensor.
To cancel a TEACH procedure, press TEACH for longer than 2 seconds, or hold the remote input low for longer than 2 seconds.
momentarily displays when a TEACH procedure is canceled.
3.5.1 Two-Point TEACH
Two-point TEACH sets the distance values associated with 0 V and 10 V (4 mA and 20 mA) based on taught target distances.
10 V
0 V
2
Press and Hold
> 2s
3
Press again
4
Teach 0 V
Teach 10 V
1
5
Press again
Figure 20. Two-Point TEACH
Note: The sensor must be set to = to use the following instrucons.
Note: To program the sensor using remote input, remote input must be enabled ( = ).
1. Present the target.
Method Acon Result
Push Buon Present the rst target. The sensor-to-target distance must be within the
sensor's range. The target's measurement value displays.
Remote Input
2. Start the TEACH mode.
Method Acon Result
Push Buon Press and hold TEACH for longer than 2 seconds. and ash alternately
on the display. The 2-Pt indicator ashes.
Remote Input Single-pulse the remote input.
T
3. Teach the sensor.
Q4X Stainless Steel Analog Laser Sensor
www.bannerengineering.com - Tel: [phone]

Method Acon Result
Push Buon Press TEACH to teach the target. The measurement value ashes briey,
and the sensor is taught the rst target.
and ash alternately
on the display. The 2-Pt indicator ashes.
Remote Input Single-pulse the remote input.
T
It is possible to skip teaching the 0 V (4 mA) point and connue to use the exisng seng. When using the push buon, hold
for four seconds. The sensor displays SAVE and then ashes the exisng value. When using the remote input, double-pulse the
remote input.
4. Present the target.
Method Acon Result
Push Buon Present the second target. The sensor-to-target distance must be within the
sensor's range. and ash alternately
on the display. The 2-Pt indicator ashes.
Remote Input
5. Teach the sensor.
Method Acon Result
Push Buon Press TEACH to teach the target. The new switch point ashes rapidly and
the sensor returns to Run mode.
Remote Input Single-pulse the remote input.
T
Note: If the same target is taught both mes, and ash alternately on the display, the 10 V (20 mA)
value is automacally adjusted to maintain the minimum window size, the new distance quickly ashes four mes, and
the sensor returns to Run mode.
It is possible to skip teaching the 10 V (20 mA) point and connue to use the exisng seng. When using the push buon, hold
for four seconds. The sensor displays SAVE and then ashes the exisng value. When using the remote input, double-pulse
the remote input.
3.5.2 One-Point TEACH
One-point TEACH mode denes the span of the analog output. One-point TEACH also denes the 5 V (12 mA) midpoint of the analog
output to center the analog output around a reference target posion.
Refer to Manual Adjustments in One-Point TEACH Mode on page 17 for more informaon.
10 V
0 V
2
Press and Hold
> 2s
Teach 5 V 5 V 5 V
10 V
0 V
5 V
1
Press again
3
Figure 21. One-Point Window
Note: The sensor must be set to = to use the following instrucons.
Note: To program the sensor using remote input, remote input must be enabled ( = ).
Q4X Stainless Steel Analog Laser Sensor
20 www.bannerengineering.com - Tel: [phone]
