WORLD-BEAM QS18 Expert with IO-Link
Instruction Manual
Original Instructions
196872 Rev. B
19 September 2019
©Banner Engineering Corp. All rights reserved
196872

Contents
1 Product Description ........................................................................................................................................................3
1.1 Models ............................................................................................................................................................................................. 4
1.2 Overview ......................................................................................................................................................................................... 5
1.3 Opposed-Mode Models: Noise and Crosstalk Immunity ............................................................................................................... 5
2 Installation ....................................................................................................................................................................... 6
2.1 Mount the Device ............................................................................................................................................................................6
2.2 Wiring Diagrams ..............................................................................................................................................................................6
3 Sensor Configuration ......................................................................................................................................................8
3.1 IO-Link Interface ........................................................................................................................................................................... 11
3.2 Push Button Enable/Disable ......................................................................................................................................................... 12
4 Select TEACH/SET Method ..........................................................................................................................................14
5 Configure TEACH/SET ................................................................................................................................................. 15
6 TEACH/SET ................................................................................................................................................................... 17
7 Specifications ............................................................................................................................................................... 19
7.1 Self-Contained Models: Specifications ........................................................................................................................................ 19
7.2 Opposed-Mode Models: Specifications ....................................................................................................................................... 20
7.3 Dimensions ................................................................................................................................................................................... 21
7.4 Self-Contained Models: Performance Curves ............................................................................................................................... 22
7.5 Opposed-Mode Models: Performance Curves .............................................................................................................................25
8 Accessories ................................................................................................................................................................... 26
8.1 Cordsets ....................................................................................................................................................................................... 26
8.2 Brackets ........................................................................................................................................................................................27
8.3 Retroreflectors .............................................................................................................................................................................. 28
9 Contact Us .....................................................................................................................................................................29
10 Banner Engineering Corp. Limited Warranty ..............................................................................................................30
WORLD-BEAM QS18 Expert with IO-Link

1 Product Description
Expert™Sensor with IO-Link
•Self-Contained Models:
◦IO-Link communication for sensor health monitoring and remote configuration
◦Easy-to-use Expert-style Two-Point Static and Dynamic TEACH methods, plus
Window, Light, and Dark SET, using IO-Link, push button or remote input
◦Smart power-control algorithm to maximize performance in low-contrast
applications
•Opposed-Mode Models:
◦Infrared and visible beam emitter/receiver pairs with a range of 20 m (66 ft)
◦Robust ambient light immunity utilizing a software-based algorithm to prevent
unintentional triggering
◦Optical synchronization provides crosstalk avoidance with 3 frequency channels
for side by side sensor mounting
◦Two-Point Static and Dynamic TEACH methods, plus Window, Light, and Dark
SET and Opaque mode for reliable long range detection of very dark objects
◦Health data available over IO-Link
•Auto compensation algorithm provides long and reliable operation by compensating for
dust build up and ambient temperature changes.
• Fast response speed for high-speed applications
• User-selectable threshold offset percentage to optimize performance for the type of
object being detected
• Easy configuration of the sensor by IO-Link, remote input or push button
•Convenient mounting options available for 18 mm barrel or side mount
• Bright indicator LEDs show operating status from 360°
• IEC IP67 rated ABS housing
WARNING:
•Do not use this device for personnel protection
•Using this device for personnel protection could result in serious injury or death.
• This device does not include the self-checking redundant circuitry necessary to allow its use in
personnel safety applications. A device failure or malfunction can cause either an energized (on)
or de-energized (off) output condition.
WORLD-BEAM QS18 Expert with IO-Link
www.bannerengineering.com - Tel: + 1 888 373 6767 3

1.1 Models
Self-Contained Models
Model Sensing Mode Range Output
QS18EK6LPQ8
P
POLAR RETRO
3.5 m (12 ft)1
IO-Link push/pull output and
multi-function input/output
QS18EK6DQ8
DIFFUSE
800 mm (31.5 in)2
QS18EK6DVQ8
DIFFUSE
600 mm (23.6 in)2
QS18EKCV15Q8
CONVERGENT
VISIBLE RED
16 mm (0.65 in)2
QS18EK6CV45Q8 43 mm (1.7 in)2
QS18EK6FPQ8
PLASTIC FIBER
Varies by mode and fiber optics used
Opposed-Mode Models
Model Opposed-Mode Range Teachable Range Output
QS18EK6EVQ8
(Visible red, 625 nm )
OPPOSED
High Power Emitter
Setting: 20m
Low Power Emitter
Setting: 4m
High Power Emitter
Setting: 1 m to 20 m
Low Power Emitter
Setting: 0 m to 4 m
IO-Link and multi-function
input
QS18EK6RVQ8 IO-Link push/pull output and
multi-function input/output
QS18EK6EQ8
(Infrared, 940 nm)
OPPOSED
IO-Link and multi-function
input
QS18EK6RQ8 IO-Link push/pull output and
multi-function input/output
4-Pin M12/Euro-style integral quick disconnect models listed.
•To order the 150 mm (6 in) PVC cable model with a 4-pin M12/Euro-style quick disconnect, replace the suffix "Q8"
with "Q5" in the model number. For example, QS18EK6LPQ5.
• To order the 4-in M8/Pico-style integral quick disconnect model, replace the suffix "Q8" with "Q7" in the model
number. For example, QS18EK6LPQ7.
• To order the 150 mm (6 in) PVC cable model with a 4-Pin M8/Pico-style quick disconnect model, replace the suffix
"Q8" with "Q" in the model number. For example, QS18EK6LPQ.
•Models with a quick disconnect require a mating cordset.
1With the use of a BRT-84 reflector.
2Based on 90% reflectance white test card.
WORLD-BEAM QS18 Expert with IO-Link
4 www.bannerengineering.com - Tel: + 1 888 373 6767

1.2 Overview
Amber LED
(Output Indicator)
Green LED
(Power Indicator) Push Button
The Banner QS18E sensor is a high performance photoelectric sensor
with IO-link and configurable multifunction input/output. For opposed-
mode models, the receiver has a configurable multifunction input/output
and the emitter has a configurable multifunction input.
Self-Contained Models and Opposed-Mode Receivers
Indicators
Sensor Condition (Run Mode) Green LED Amber LED
Output OFF ON OFF
Output ON ON ON
Self-Contained Models
Notification—Sensor needs to be
reconfigured for reliable detection
Opposed-Mode Models
Notification—Sensor needs to be
reconfigured for reliable detection
OR
The emitter is set to High Power,
and the receiver is saturated. Set the
emitter to Low Power.
Flashing ON/OFF
Notification—Push button has been
locked out
Flashes four times and
returns to solid On after
button press
ON/OFF
Opposed-Mode Emitter
Indicators
Sensor Condition Green LED Amber LED
Power On ON OFF
Notification—Push button has been
locked out
Flashes four times and
returns to solid On after
button press
OFF
1.3 Opposed-Mode Models: Noise and Crosstalk Immunity
Optical synchronization between the emitter and receiver provides ambient light immunity and crosstalk avoidance not
typically available in opposed-mode sensing. The sensor is highly resistant to light detection due to ambient light from high
efficiency light sources or from other light emitting industrial sensors. In addition, there are three user-selectable frequency
channels (A, B, or C) for crosstalk avoidance in side by side sensor mounting. The factory default channel is Frequency A.
WORLD-BEAM QS18 Expert with IO-Link
www.bannerengineering.com - Tel: + 1 888 373 6767 5

2 Installation
2.1 Mount the Device
1. If a bracket is needed, mount the device onto the bracket.
2. Mount the device (or the device and the bracket) to the machine or equipment at the desired location. Do not tighten
the mounting screws at this time.
3. Check the device alignment.
4. Tighten the mounting screws to secure the device (or the device and the bracket) in the aligned position.
2.2 Wiring Diagrams
Follow the wiring diagram that is appropriate for your application.
Opposed-Mode Models: The following wiring diagrams apply to the receivers. The three wiring diagrams that include
remote input apply to the emitters.
IO-Link with PNP Output (Factory Default)
4
1
3
2
10-30V dc
CH1
CH2
+
–
PUSH-PULL
Load
Load
Figure 1. Channel 1 = IO-Link, Channel 2 = PNP Output
IO-Link with PNP Remote Input
4
1
3
2
10-30V dc
CH1
CH2
+
–
PUSH-PULL
Load
Remote
Input
Figure 2. Channel 1 = IO-Link, Channel 2 = PNP Remote
Input
Key
1. Brown
2. White
3. Blue
4. Black3
Note: NPN/PNP and Remote Input configurations are programmable using IO-Link.
Note: Enable the remote input wire function using IO-Link. The default for the remote input wire
function is Detection Output.
NPN Discrete Outputs
4
1
3
2
10-30V dc
CH1
CH2
+
–
Load
Load
Figure 3. Channel 1 = NPN Output, Channel 2 = NPN Output
PNP Discrete Outputs
4
1
3
2
10-30V dc
CH1
CH2
+
–
Load
Load
Figure 4. Channel 1 = PNP Output, Channel 2 = PNP Output
3Opposed-Mode Models: IO-Link only on emitters.
WORLD-BEAM QS18 Expert with IO-Link
6 www.bannerengineering.com - Tel: + 1 888 373 6767

NPN Output and Remote Input
4
1
3
2
10-30V dc
CH1
CH2
+
–
Load
Remote
Input
Figure 5. Channel 1 = NPN Output, Channel 2 = NPN Remote
Input
PNP Output and Remote Input
4
1
3
2
10-30V dc
CH1
CH2
+
–
Load
Remote
Input
Figure 6. Channel 1 = PNP Output, Channel 2 = PNP Remote
Input
1
4
3
2
Figure 7. Sensor Pinout M12/Euro-style Models (Male)
3
2
1
4
Figure 8. Sensor Pinout M8/Pico-Style Models (Male)
WORLD-BEAM QS18 Expert with IO-Link
www.bannerengineering.com - Tel: + 1 888 373 6767 7

3 Sensor Configuration
Configure the sensor using the TEACH or SET methods to define the sensing limits. Use the setup procedure to enable a 30
ms OFF-delay or to change the Light/Dark Operate setting.
Sensing limit configuration options include:
• Two-Point Static TEACH: One switching threshold, determined by two taught conditions
• Dynamic TEACH: One switching threshold, determined by multiple sampled conditions
• Window SET: A sensing window, centered around a single sensing condition
• Light SET and Dark SET: One switching threshold, offset from a single sensing condition
• Opposed-Mode Models: Opaque Mode: One switching threshold set to maximum excess gain
The sensor's output is disabled during all TEACH and SET procedures, and is enabled upon return to Run mode.
See the Input Flowcharts for configuration information.
•Self-contained models:
Figure 9 (p. 9)
• Opposed-mode emitters:
Figure 10 (p. 10)
• Opposed-mode receivers:
Figure 11 (p. 11)
Following any TEACH or SET procedure other than Two-Point Static TEACH, the Output ON condition (Light or Dark
Operate setting) remains as it was last configured. To change that setting, or the OFF-delay setting, see the Input
Flowchart.
Push Button Configuration
Use the push button to configure the sensor. Click the push button according to the Input Flowchart.
Remote Input Configuration
Enable the remote input wire using IO-Link. Use the remote input function to configure the sensor remotely. Connect the
white wire of the sensor as shown in the wiring diagram. Pulse the remote line according to the Input Flowchart.
WORLD-BEAM QS18 Expert with IO-Link
8 www.bannerengineering.com - Tel: + 1 888 373 6767

SELF-CONTAINED MODELS
2x
1x
Unlock push buttons (flashing Green and Amber 1X followed by acceptance flash) default
Lock push buttons (flashing Green and Amber 2X followed by acceptance flash)
4x
3x
Enable Auto compensation (flashing Green and Amber 3X followed by acceptance flash)
Disable Auto compensation (flashing Green and Amber 4X followed by acceptance flash)
default
5x
Enable 30 ms Off Delay (flashing Green and Amber 5X followed by acceptance flash)
6x
Disable 30 ms Off Delay (flashing Green and Amber 6X followed by acceptance flash) default
1x
2x
Basic Configuration (alternating flashing Green and Amber LEDs at 1Hz)
Advanced Configuration (simultaneous flashing both Green and Amber LEDs at 1Hz)
Starts Selected Teach
(same function as pressing Teach Button for > 2 sec)
40 ms < T < 800 ms
Timing between Pulse groups > 800 ms
Rempte Input Wire Pulse Timing (T)
(White wire is remote input wire)
3x
Toggle TEACH Button Lock/Unlock (flashing both Green and Amber LEDs 4X followed by acceptance flash)
4x
Reset to Factory Defaults
** Remote Input Wire only. Using Push Button will not reset sensor to factory defaults.
(flashing both Green and Amber LEDs 8X followed by acceptance flash)
8x
Push Button or
Remote Input Wire* *Configuration using remote input wire
when enabled through IO-Link
1x
Second Pulse Completes Teach (2-Point Static and Dynamic Teach only)
Configure output to Light Operate (flashing Green and Amber 1X followed by acceptance flash)
Configure output to Dark Operate (flashing Green and Amber 2X followed by acceptance flash) default for LP models
default for D, DV, CV and FP models
Configure offset percentage to 10% (flashing Green and Amber 3X followed by acceptance flash)
Configure offset percentage to 30% (flashing Green and Amber 4X followed by acceptance flash)
Configure offset percentage to 50% (flashing Green and Amber 5X followed by acceptance flash)
Select 2-Point Static TEACH default for D, DV, CV, and FP models
Select Dynamic TEACH
Select Window SET
Select TEACH/SET Method (flashing Amber LED at 1Hz)
Select Light SET
Select Dark SET
2x
1x
4x
3x
5x
5x
2x
1x
4x
3x
5x
Note: Reconfiguration is required before a new TEACH/SET method takes effect.
default
default for LP models
Hold is > 2 sec. and < 4 sec.
Click is > 40 ms and < 800 ms
Push Button Input
**
Figure 9. Self-Contained Models Input Flowchart
WORLD-BEAM QS18 Expert with IO-Link
www.bannerengineering.com - Tel: + 1 888 373 6767 9

2x
1x
Unlock push buttons (flashing of both Green and Amber LEDs 1X followed by acceptance flash) default
Lock push buttons (flashing of both Green and Amber LEDs 2X followed by acceptance flash)
2x
Basic Configuration (alternating flashing Green and Amber LEDs at 1Hz)
Advanced Configuration (simultaneous flashing of both Green and Amber LEDs at 1Hz)
40 ms < T < 800 ms
Timing between Pulse groups > 800 ms
Remote Input Wire Pulse Timing (T)
(White wire is remote input wire)
3x
Toggle TEACH Button Lock/Unlock (flashing of both Green and Amber LEDs 4X followed by acceptance flash)
4x
Reset to Factory Defaults
** Remote Input Wire only.
(flashing of both Green and Amber LEDs 8X followed by acceptance flash)
8x
Push Button or
EMITTER
Remote Input Wire* *Configuration using remote input wire
when enabled through IO-Link
High Speed (flashing of both Green and Amber LEDs 1X followed by acceptance flash)
Configure to A Frequency (flashing of both Green and Amber LEDs 2X followed by acceptance flash)
Configure to B Frequency (flashing of both Green and Amber LEDs 3X followed by acceptance flash)
Configure to C Frequency (flashing of both Green and Amber LEDs 4X followed by acceptance flash)
Configure to High Power (flashing of both Green and Amber LEDs 5X followed by acceptance flash)
2x
1x
4x
3x
5x
default
default
Configure to Low Power (flashing of both Green and Amber LEDs 6X followed by acceptance flash)
6x
Hold is > 2 sec. and < 4 sec.
Click is > 40 ms and < 800 ms
Push Button Input
**
**
** Remote Input Wire only.
Figure 10. Opposed-Mode Models Emitter Input Flowchart
WORLD-BEAM QS18 Expert with IO-Link
10 www.bannerengineering.com - Tel: + 1 888 373 6767
