Bartscher 700FX-G396-GCR User manual

700FX-G396-GCR / 700FX-G796-G /
700FX-G796-GCR / 700FX-G796-GR
2834431 - 2838131 - 2838231 - 2838331
DOC.NO
CR1368860BA
EDITION
001
2232

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Service hotline: [phone]
www.bartscher.com
0085DL0171
Version: 1.0
Date of preparation: 2022-08-03
EN
2

2834431 1 / 36
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................4
1.3 Residual Risks.........................................................................................7
1.4 Personal Protective Equipment................................................................9
1.5 Intended Use ......................................................................................... 10
1.6 Unintended Use.....................................................................................10
2General information.....................................................................................11
2.1 Liability and Warranty ............................................................................ 11
2.2 Copyright Protection ..............................................................................11
2.3 Declaration of Conformity ......................................................................11
3Transport, Packaging and Storage.............................................................. 12
3.1 Delivery Check.......................................................................................12
3.2 Packaging..............................................................................................12
3.3 Storage..................................................................................................12
4Technical Data.............................................................................................13
4.1 Technical Specifications ........................................................................13
4.2 Functions of the Appliance.....................................................................20
4.3 List of Components of the Appliance .....................................................21
5Installation Instructions................................................................................22
5.1 Installation..............................................................................................22
6Operating Instruction...................................................................................28
6.1 Operation...............................................................................................29
7Cleaning and Maintenance..........................................................................32
7.1 Safety Instructions for Cleaning.............................................................32
7.2 Cleaning.................................................................................................33
7.3 Maintenance ..........................................................................................33
8Possible Malfunctions..................................................................................35
9Disposal....................................................................................................... 36

Safety
2 / 36 2834431
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u nd gilt als wichtige Infor mationsquelle und N achschlagewer k.Die Ke nntnis aller enthalten enSic herheitshinweis eu ndH andlungsan weisungen sch afft die Voraussetzu ngf ürd as sichere und sachg erechte Arbeiten mit d emG erät.D arüber hin aus müssen die für den Eins atzbereich des Gerät sg eltenden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Be dienungsanleitung is t Bestandteil des Prod ukts und muss in unmitt elbarerN ähe des Geräts für d as In¬stallations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn das Ger ät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
2834431 3 / 36
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.

Safety
4 / 36 2834431
EN
1.2 Safety instructions
Safety of Gas Supplied Appliances
•Do not use a gas supplied appliance in the event of a malfunction or damage or
in the case of a suspected malfunction or damage. In such a case set the
knob(s) to 'O' and close the main gas valve. Contact the service company
immediately.
•Regularly conduct tightness checks using suds (a spray for detecting leakages).
Do not use open flame for checking tightness of gas installation!
WARNING!
Suffocation and explosion hazard due to leaking gas!
•When you sense gas odour, observe the following rules:
–immediately close the knob(s) and the main gas valve;
–provide for sufficient venting of rooms: open wide all doors and windows;
–do not light up any open flame, quench flames;
–do not smoke;
–do not produce sparks, do not actuate any electric switches, do not use
phones (irrespective of it being landline phone or mobile phone);
–do not operate any electric appliances in the vicinity of a gas supplied
appliance;
–if needed, notify all persons in a building by calling loud and knocking on
doors;
–leave building;
–when outside of a building, contact the service company. If it is
impossible to precisely locate gas leak, immediately phone fire fighters
and notify gas supplier.

Safety
2834431 5 / 36
EN
Flammable Materials
•Never use the appliance near flammable or easily combustible materials (e.g.:
petrol, spirit, alcohol). High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•Use the appliance only with materials designed to this end and with correct
temperature settings. Materials, food products and left-overs of food products
remaining in the appliance may catch fire.
•To avoid fire hazard, clean the appliance regularly.
•Never leave the appliance unattended, especially when cooking with fats or oils
as they may cause fire.
•Close the gas shut-off valve should the fire emerge. Never put the flame out with
water; to suppress fire, use a lid or a fire-blanket. Following extinction of fire,
ensure sufficient fresh air inflow.
Hot Surfaces
•Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
•Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.

Safety
6 / 36 2834431
EN
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.

Safety
2834431 7 / 36
EN
1.3 Residual Risks
Residual Risks
Dangerous situation
Warning
Danger of slipping
or falling
User may slip on the floor due to
the presence of water or dirt.
Wear non-skid safety
shoes when using the
device.
Burn
Operator is deliberately touches
the machine components.
Operator is deliberately touching
hot substances (oil, water, steam,
...).
Danger of falling
Operator performs actions on the
upper part of the device using
inappropriate aids (e.g. a ladder
with rungs or climbs the device).
Do not work on the top
of the device with
unsuitable aids (e.g.
ladders with rungs or by
climbing on the device).
Danger of the load
tipping over
Moving the device or its elements
with inappropriate aids.
Appropriate lifting aids or
equipment must be used
when moving the device
or its packaging.

Safety
8 / 36 2834431
EN
Residual Risks
Dangerous situation
Warning
Chemicals
Operator is dealing with
chemicals (e.g. cleaners,
descaling agents, etc.)
Appropriate precautions
should be taken. Always
follow the instructions on
the safety data sheets
and labels for the
products you use. Use
personal protection
measures recommended
in the safety data
sheets.
Danger of injury
There is a risk of injury during
maintenance work if you touch
the internal parts of the machine
frame.
Maintenance work may
only be performed by
qualified personnel,
equipped with
appropriate personal
protective equipment
(cut-resistant protective
gloves, forearm
protectors).
Danger of crushing
The personnel may crush their
fingers or hands when moving
parts.
Maintenance work may
only be performed by
qualified personnel,
equipped with personal
protective equipment.
Ergonomics
Operator works on the device
without using the necessary
personal protective equipment.
Operator working on the
device must use
personal protective
equipment.

Safety
2834431 9 / 36
EN
1.4 Personal Protective Equipment
Phase
Safety
clothing
Safety
footwear
Gloves
Eye protection
Hearing
protection
Respiratory
tract
protection
Head
protection
Transport
X
Moving
X
Unpacking
X
Assembly
X
Standard usage
X
X
X (*)
Settings
X
Standard
cleaning
X
Special cleaning
X
X
Maintenance
X
X (*)
Dismantling
X
Disposal
X
X
Personal protective equipment provided
Personal protective equipment is available or
must be used if required
Personal protective equipment not provided
* Gloves intended for standard usage and maintenance works must be resistant to
high temperatures to protect operator's hands when the operator touches hot
elements of the appliance or hot substances (oil, water, steam, etc.).

Safety
10 / 36 2834431
EN
1.5 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
- Grilling of meat, fish and vegetables.
1.6 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Grilling of unsuitable food products.

General information
2834431 11 / 36
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
12 / 36 2834431
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
2834431 13 / 36
EN
4 Technical Data
4.1 Technical Specifications
Version / Design
•Operating mode: gas
•Gas type:
–natural gas E
–Propane nozzles included
•Ignition type: piezoelectric ignition
•Adjustable separately heating zones (only in 2838131, 2838231, 2838331)
•Safety thermostat (only in 2834431, 2838231)
•Material: pressure embossed surface with Scotch-Brite cut
•Grease collection container
•Splash guard
•The set includes: 4 feet
•May be used as a tabletop appliance or in connection with the base as a free-
standing appliance
•Can be connected and installed in series with other 700FX series devices
We reserve the right to implement technical modifications.
<Endergebnis>

Technical Data
14 / 36 2834431
EN
Name:
Griddle plate 700FX-G396-GCR
Art. No.:
2834431
Material:
CNS 18/10
Roasting surface material:
Steel, hard-chrome
Roasting surface design:
smooth
Roasting surface dimensions (W x D),
in mm:
396 x 520
Number of heating zones:
1
Temperature range, min.–max., in °C:
90 - 280
Connected load:
6,5 kW
Dimensions (W x D x H), in mm:
400 x 700 x 295
Weight, in kg:
44,0
Name:
Griddle plate 700FX-G796-G
Art. No.:
2838131
Material:
CNS 18/10
Roasting surface material:
Stainless steel
Roasting surface design:
smooth
Roasting surface dimensions (W x D),
in mm:
796 x 520
Number of heating zones:
2
Temperature range, min.–max., in °C:
90 - 280
Connected load:
13 kW
Dimensions (W x D x H), in mm:
800 x 700 x 295
Weight, in kg:
72,0

Technical Data
2834431 15 / 36
EN
Name:
Griddle plate 700FX-G796-GCR
Art. No.:
2838231
Material:
CNS 18/10
Roasting surface material:
Steel, hard-chrome
Roasting surface design:
smooth
Roasting surface dimensions (W x D),
in mm:
796 x 520
Number of heating zones:
2
Temperature range, min.–max., in °C:
90 - 280
Connected load:
13 kW
Dimensions (W x D x H), in mm:
800 x 700 x 295
Weight, in kg:
72,0
Name:
Griddle plate 700FX-G796-GR
Art. No.:
2838331
Material:
CNS 18/10
Roasting surface material:
Steel, hard-chrome
Roasting surface design:
2/3 smooth, 1/3 grooved
Roasting surface dimensions (W x D),
in mm:
796 x 520
Number of heating zones:
2
Temperature range, min.–max., in °C:
90 - 280
Power supply:
13 kW
Dimensions (W x D x H), in mm:
800 x 700 x 295
Weight, in kg:
72,0

Technical Data
16 / 36 2834431
EN
Gas Pressure Table
Countries
Appliance
categories
Gas
pressure
(mbar)
Connection pressure (mbar)
Rated
Min.
Max.
LU-PL
I2E
G20
20
17
25
NO
I2H
G20
20
17
25
NL
I2L
G25
25
20
30
NL
I2EK
G20
20
17
25
G25.3
25
20
30
NO-NL-CY-
MT
I3B/P
G30/G31
28-30
25
35
PL
I3B/P
G30/G31
37
25
45
BE-FR
II2E+3+
G20/G25
20/25
17
25/30
G30/G31
28-30/37
20/25
35/45
DE
II2ELL3B/P
G20
20
17
25
G25
20
18
25
G30/G31
50
42.5
57.5
ES-GB-GR-IE-
IT-PT-SK
II2H3+
G20
20
17
25
G30/G31
28-30/37
20/25
35/45
DK-FI-SE-BG-
EE-LV-LT-CZ-
SI-TR-HR-RO
II2H3B/P
G20
20
17
25
G30/G31
28-30
25
35
AT-CH
II2H3B/P
G20
20
17
25
G30/G31
50
42.5
57.5
HU
II2HS3B/P
G20
25
18
33
G25.1
25
18
33
G30/G31
28-30
25
35
HU
II2HS3B/P
G20
25
18
33
G25.1
25
18
33
G30/G31
50
42.5
57.5

Technical Data
2834431 17 / 36
EN
Countries
Appliance
categories
Gas
pressure
(mbar)
Connection pressure (mbar)
Rated
Min.
Max.
DK-SE
III1a2H3BP
G20
20
17
25
G30/G31
28-30
25
35
G110
8
6
15
IT-CH
II1a2H
G20
20
17
25
G110
8
6
15
NL
II2EK3B/P
G20
20
17
25
G25.3
25
20
30
G30/G31
28-30
25
35
Tab. 1

Technical Data
18 / 36 2834431
EN
Nozzles and settings
Countries
Gas type
Pa
(mbar)
Ref.
Art. No.
2834431 /
74GFTTCST
2838231 /
78GFTTCST
2838131 /
78GFTAST
2838331 /
78GFTASRT
AT-BE-BG-CH-CZ-
DE-DK-EE-ES-FI-
FR-GB-GR-HR-IE-
IT-LT-LU-LV-NO-
PL-PT-RO-SE-SI-
SK-TR
G20
G20/ G25
20
20/25
UM
185R
185R
UP
27.2
27.2
A(mm)
4
4
Um
-
130
DE
G25
20
UM
200R
200R
UP
27.2
27.2
A(mm)
3
3
Um
-
130
NL
G25.3
25
UM
185R
185R
UP
27.2
27.2
A(mm)
4
4
Um
-
130
HU
G20
25
UM
175R
175R
UP
27.2
27.2
A(mm)
4
4
Um
-
130
HU
G25.1
25
UM
195R
195R
UP
27.2
27.2
A(mm)
2
2
Um
-
130
