Bartscher SNACK IV Plus Installation instructions

“SNACK IV“ Plus
A162824E

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]-
197
www.bartscher.com
Version: 1.0
Date of preparation: 2019-05-08
EN

A162824E 1 / 22
Original operating manual
1Safety............................................................................................................2
1.1 Explanation of signal words.....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended use............................................................................................6
1.4 Unintended Use.......................................................................................6
2General information.......................................................................................7
2.1 Liability and warranty...............................................................................7
2.2 Copyright protection.................................................................................7
2.3 Declaration of conformity.........................................................................7
3Transport, packaging and storage.................................................................8
3.1 Delivery Check.........................................................................................8
3.2 Packaging................................................................................................8
3.3 Storage....................................................................................................8
4Technical data...............................................................................................9
4.1 Technical specifications...........................................................................9
4.2 List of components of the appliance.......................................................10
4.3 Functions of the appliance..................................................................... 10
5Installation and operation ............................................................................11
5.1 Installation..............................................................................................11
5.2 Operation............................................................................................... 12
6Cleaning ......................................................................................................18
6.1 Safety Instructions for cleaning..............................................................18
6.2 Cleaning.................................................................................................18
7Possible Malfunctions..................................................................................19
8Disposal....................................................................................................... 20

Safety
2 / 22 A162824E
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Di e Kenntnis aller enthalt enenSic herheitshinw eiseu ndH andlungs anweisungen schafft die V oraussetzung f ürd as sichere und sac hgerechte Arbeite n mitd emG erät.D arüber hin aus müssen die für den Eins atzbereich des Geräts gelt enden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Bedi enungsanleitung is t Bestandteil des Pro dukts und muss in u nmittelbarer Nähe des Ger äts für das In¬stallations-, Bedienungs-, W artungs- und Reinigungsp ersonal jederzeit z ugänglich auf¬be wahrt werden. Wenn das Ger äta n eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of signal words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
A162824E 3 / 22
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 22 A162824E
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
Flammable materials
•Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
•To avoid fire hazard, clean the appliance regularly.
•Do not cover the appliance with, e.g., aluminium foil or cloths.
•Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
•Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
•Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
Hot surfaces
•Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
•Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.

Safety
A162824E 5 / 22
EN
Safety During Deep Fat Frying
•Never leave the operating appliance without supervision. Possible malfunctions
may lead to overheating and ignition of frying oil / fat in cubes (blocks).
•If due to overheating, the frying oil / fat in cubes (blocks) catches fire, put the lid
on and disconnect the appliance from the power supply.
•Spatters or outbursts of hot oil/fat may cause scalding of hands, arms and face.
Use protective kitchen mitts.
•Do not use wet nor humid products. Dry them before use. Remove excess of ice
from deep frozen products prior to frying them.
•Do not hang frozen food in the basket over the tank filled with hot frying oil / fat
in cubes (blocks). When deep frying in fat, even the smallest drop of water may
cause spatters of hot oil or even small outbursts.
Health Hazard Due to Burnt Food Products
•Acrylamides that are present in burnt food products are hazardous to health and
may cause cancer. In order to avoid or reduce acrylamide content, products
should always be fried to the point, when their colour is golden–yellowish, and
not dim and dark nor brown.
•Burnt left-overs and scrubs should be regularly removed from frying oil.
•Products containing starch —cereals and potato products in particular —
should be fried in a maximum temperature of 180°C.
Operating Personnel
•The appliance may only be operated by a qualified personnel and trained
specialist personnel.

Safety
6 / 22 A162824E
EN
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your
own.
•Do not introduce any changes in the appliance nor modify it.
1.3 Intended use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Deep fat frying of adequate food products.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Deep fat frying of inadequate food products.
–Deep fat frying of wet or humid food products.
–Do not hang frozen food in the fryer’s basket over the hot frying oil/fat.

General information
A162824E 7 / 22
EN
2 General information
2.1 Liability and warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, packaging and storage
8 / 22 A162824E
EN
3 Transport, packaging and storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical data
A162824E 9 / 22
EN
4 Technical data
4.1 Technical specifications
Name:
Deep fat fryer “SNACK IV“ Plus
Item No.:
A162824E
Material:
Stainless steel
Number of tanks:
2
Tank contents in litres:
9
Tank dimensions (W x D x H) in mm:
240 x 300 x 200
Number of baskets:
2
Basket dimensions (W x D x H) in mm:
210 x 220 x 120
Temperature range, min.–max., in °C:
50 - 190
Power supply:
6,6 kW / 230 V / 50 Hz
Dimensions (W x D x H) in mm:
575 x 530 x 385
Weight in kg:
11,9
We reserve the right to implement technical modifications!
Version / Characteristics
•Type: table-top appliance
•Type of power supply: electric
•Heating element: pivoting
•Fat drain tap with safety fixture
•Cold zone
•Safety thermostat
•Control: knob
•ON/OFF switch with power indicator light
•Indicator lights: ON/OFF, heating
•Intended for usage with frying oil and fat in cubes (blocks)
•Accessories (included): 2 baskets, 2 lids

Technical data
10 / 22 A162824E
EN
4.2 List of components of the appliance
1 Control panel (2 pcs)
2 Control box (2 pcs)
3 MIN/MAX marks
4 Heating element with a
permanently fixed cover (2 pcs)
5 Fixture for hanging the basket (2 pcs)
6 Tank (2 pcs)
7 Basket with handle
8 Main appliance
9 Adjustable feet (4 pcs)
10 Fat drain tap (2 pcs)
11 Lid (2 pcs)
4.3 Functions of the appliance
The fryer is intended for frying food products in hot oil.

Installation and operation
A162824E 11 / 22
EN
5 Installation and operation
5.1 Installation
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
•Leave at least 20 cm clearance from flammable walls and items.

Installation and operation
12 / 22 A162824E
EN
Connection —electrical Power
•Check if technical specifications of the appliance (see rating plate) correspond
to local electrical grid specifications.
•Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
•The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
In order to connect the twin fryer, 2 separate sockets are necessary.
•Do not use the appliance with an external timer or remote control.
5.2 Operation
Warning indications
•Insertt he bottom co verin th e appliance. The cover acts as a sp acer between the he ating element and left- overf ood tray.
Carefully put the conn ection box with the heating ele ment on the back edge of the de vice.T he pini n the connecti onb oxl ower part must ent ert he hole in the main device. In this w ay the connection box is pro perly mounted.
WARNING!
Fire hazard!
Operation of the appliance with the oil level below MIN mark may lead to
overheating of frying oil and cause oil to catch fire.
The oil level should be between MIN and MAX marks on the cover of
heating element.
If overheated during operation, the frying oil or fat in cubes (blocks)
may catch fire.
The appliance should not remain in use for extended periods of time.
During breaks between subsequent frying processes, the temperature
control knob should be turned to lower settings.
Never place the lid on during or immediately after the frying process.
The lid is used only to protect the device from dust.
CAUTION!
Risk of burns!
Due to lower flashpoint, after frying the old oil exhibits a tendency for
self-ignition and favours frothing.
Do not use old oil for frying.
Regularly change frying oil.

Installation and operation
A162824E 13 / 22
EN
When the oil level is above the MAX mark during operation of the
appliance, hot oil may spill out.
The oil level should be between MIN and MAX marks on the cover of
heating element.
If the basket is overfilled with products for frying, the frying oil or fat in
cubes (blocks) may boil over.
Observe the maximum allowable level of filling the basket (3 kg) with
products for frying.
If water enters hot frying oil, it may cause spatters of oil and scalding.
Use only dry products for frying.
When draining hot frying oil / fat in cubes (blocks) be aware of the risk
of burns.
Cool the frying oil / fat in cubes (blocks) before draining.
Preparation of the appliance
1. Take out the equipment (lid, basket(s)) from the appliance.
2. Place the basket handle in the right position, spreading it upwards and pulling by
the fastening grip and snapping in place.
3. Remove the control box with heating element
and permanently fixed cover from the
appliance by pulling it out of fastening
element and upwards.
4. Prior to first use, thoroughly clean the appliance and equipment according to
instructions in section 6 “Cleaning”.

Installation and operation
14 / 22 A162824E
EN
NOTE!
For safety reasons the appliance operates only when the control box is
properly mounted on the housing, so that the micro-switch below the
control box sets the appliance ready for operation.
5. After cleaning, mount the control box with heating element on the fastening
element of the appliance.
Fat drain tap is equipped with a safeguard, preventing its
accidental opening. First, the tap must be pressed in —
only then may it be rotated.
6. Prior to filling the tank with frying oil / fat in cubes (blocks) close the fat drain tap.
Instructions of using frying oil or fat in cubes (blocks)
1. Use oil suitable for frying (e.g. vegetable oil, sunflower oil, peanut oil, etc.) or fat
in cubes/blocks only.
Note: Fat in cubes (blocks) should be melted first in a separate container
or in the fryer.
2. Use only oils and fats that are suitable for frying in high temperatures.
3. Never mix different types of oil or fat as their boiling points may vary.
Melting fat in cubes (blocks) in the fryer
1. Remove the basket from the tank.
2. Place the fat in cube (block) directly on the cover of the heating element, so that
it is covered.
In order to switch on the appliance, follow instructions in section “Switching On“.

Installation and operation
A162824E 15 / 22
EN
3. Rotate the temperature control knob to the marked position of melting point.
4. Wait for the fat in cube (block) to melt.
5. When the heating element is covered with liquid fat, the temperature control
knob may be set to maximum temperature setting.
6. Place subsequent blocks of fat for melting in the tank, until the right filling level is
reached.
Filling the tank with frying oil or fat in cubes (blocks)
NOTE!
Prior to filling with the frying oil / fat in cubes (blocks), the tank must be
clean and dry.
1. Prior to switching on, the tank must be filled with the required amount of frying
oil or fat in cubes (blocks).
2. During operation observe the level of oil in the tank and, if needed, top up with
frying oil or fat in cubes (blocks).
Operating Elements
1
Melting point position
2
Temperature control knob
3
Heating-up indicator light (red)
4
ON/OFF control light (green)
5
ON/OFF switch with integrated power indicator
light (green)

Installation and operation
16 / 22 A162824E
EN
Start-up
1. Connect the appliance to a single grounded socket.
The green power indicator light in the ON/OFF switch lights up.
2. Rotate the temperature control knob clockwise, to set the required temperature
in the range of 50 °C –190 °C.
During heating-up the red heating-up indicator light is on. As soon as the set
temperature is reached, the indicator light goes off. When the temperature in the
tank drops, the appliance heats up again, and the red heating-up indicator light
lights up again.
3. For best results, wait until the appliance reaches the desired temperature and
then place suitable food products in the fryer.
4. Do not use frying oil nor fat in cube (block) for an extended period of time in too
low a temperature, as they cease to be suitable for use.
Frying of food
1. Place the products for frying in the basket.
2. Using the handle slowly lower the basket into the tank with frying oil or fat in
cube (block).
3. Place the basket on the cover of the heating element.
4. Fry the food.
5. After frying carefully remove the basket using the
handle and use the hook to hang the basket on
the fixture for hanging on the control box.
6. Wait for the excess of fat to drip off of the fried
products.
7. When the frying process and operation of the appliance are completed, rotate
the temperature control knob to “0” position, and switch the ON/OFF switch to
“O” position.

Installation and operation
A162824E 17 / 22
EN
Draining off and removal of frying oil / liquid fat in cube (block)
1. The frying oil / liquid fat in cube (block) should be replaced when it no longer
fulfils legal requirements.
2. The used frying oil / fat in cube (block) should be disposed of according to
provisions of law on environment protection and local regulations in force.
3. After cooling, the frying oil or fat in cube (block) should be drained from the tank
via fat drain tap into a suitable container. Make sure that the container is placed
stably.
4. If the fat from cubes or blocks hardens in the fryer, it may only be melted after
rotating the temperature control knob to melting point position; then, the fat
should be drained through fat drain tap into a suitable container. Make sure that
the container is placed stably.
The overheating protection system
If the fryer is accidentally switched on without frying oil or fat in cube (block), or if
the tank is filled with fat to the level below required minimum, the overheating
protection system automatically switches off the appliance. This function serves the
purpose of protecting the appliance against possible damages.
1. Disconnect the appliance from the power supply.
2. Perform the following steps:
–leave the appliance to cool down completely;
–screw off plastic cover over the RESET button on the
rear wall of the control box, rotating it counter-
clockwise;
–press the button;
–screw the plastic cover anew, rotating it clockwise;
–switch on the appliance as usual.

Cleaning
18 / 22 A162824E
EN
6 Cleaning
6.1 Safety Instructions for cleaning
•Before cleaning, disconnect the appliance from the power supply.
•Leave the appliance to cool down completely.
•Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
•Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
•For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
6.2 Cleaning
1. At the end of a working day clean the appliance thoroughly.
2. Remove the basket from the tank.
3. Raise the heating element and leave it to drip off.
4. Drain the cooled frying oil from the tank.
NOTE!
Observe instructions in section “Draining off and removal of frying oil /
liquid fat in cube (block)”.
WARNING!
Electric shock hazard!
Moisture may enter electric installation or control box and cause
electric shock during switching on.
The appliance nor the connection cable may never be cleaned wet, nor
under running water or any other liquid.
5. Remove the control box with the heating element and its cover from the
appliance. This allows for easy washing of the heating element and the tank.
6. Clean the control box and the heating element with its cover using a damp, soft
cloth and mild cleaning agent. Wipe with a clean cloth.
7. The control panel may be wiped only with lightly damp cloth.
