Bartscher CHEF IDEE CI2X8L User manual

A162808 / 8L
A162809 / 2 x 8L
Original-Gebrauchsanleitung
V1/0617

- 25 -
ENGLISH
Table of contents
1.Safety ........................................................................................................................ 26
1.1 Key to symbols..................................................................................................... 26
1.2 Safety instructions................................................................................................ 27
1.3 Proper use............................................................................................................ 31
2. General information................................................................................................ 32
2.1 Liability and Warrantees....................................................................................... 32
2.2 Copyright protection ............................................................................................. 32
2.3 Declaration of conformity...................................................................................... 33
3. Transport, packaging and storage......................................................................... 33
3.1 Delivery check...................................................................................................... 33
3.2 Packaging............................................................................................................. 33
3.3 Storage................................................................................................................. 34
4. Technical data ......................................................................................................... 34
4.1 Technical specification ......................................................................................... 34
4.2 Overview of parts ................................................................................................. 36
5. Installation and operation....................................................................................... 38
5.1 Installation............................................................................................................ 38
5.2 Operation.............................................................................................................. 39
6. Cleaning................................................................................................................... 45
7. Possible Malfunctions ............................................................................................ 47
8. Waste disposal........................................................................................................ 48
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 26 -
Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
Please keep these instructions and give them to future owners of the device.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards which could lead to injury.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.

- 27 -
HOT SURFACE!
This symbol is a warning that the device surface is hot when in use.
Ignoring this warning may result in burns!
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
1.2 Safety instructions
The device is not intended for use by individuals (including
children) with physical or mental disabilities, insufficient
experience, and/or insufficient knowledge unless such persons
are under the care of a person responsible for their safety or
have received instructions regarding appropriate use of the
device.
Children should be observed to ensure that they are not playing
with or starting the device.
Only use the device indoors.
The device is not adapted for use with an external timer or
remote control.
The device must be operated in correct and safe technical
condition only. In case of operational problems disconnect the
device from the power supply (pull the plug from the socket) and
contact the service company.

- 28 -
Do not leave the device unattended during operation since
there might occur malfunctions which could result in over-
heating of the oil. In case of high temperatures oil might ignite.
Prevent access of children to the package materials like plastic
bags and foamed polystyrene elements. Suffocation hazard!
Only a qualified technician and using original spare parts and
accessories should carry out repairs and maintenance of the
device. Do not attempt to repair the device yourself.
Do not use any accessory or spare parts that have not been
recommended by the manufacturer. These can be dangerous
for the user or lead to damages of the device or personal injury,
and further, the warranty expires.
To prevent hazards and to ensure optimum efficiency, no
modifications or alterations to the device that are not explicitly
approved by the manufacturer may be undertaken.
DANGER! Electric shock hazard!
To avoid the hazard results please follow the safety instructions
below.
Never allow the power cable to come into contact with heat
sources or sharp edges. The power cable should not hang over
the side of the working surface. Ensure that no one can step on
or trip over the cable.
The power cable must not be folded, bent or tangled, and must
always remain fully unrolled. Never place the device or other
objects on the power cable.

- 29 -
Do not lay the cable over carpets or heat insulations. Do not
cover the cable. Keep away the cable from operating range
and do not dunk it into water.
Inspect the power cable regularly for damage. Never use the
device if the cable is damaged. If the power cable is damaged,
have an authorised service center or qualified electrician
replace it.
The supply cable must be disconnected from the socket
only by pulling the plug.
Never carry or lift the device by the supply cable.
In any case do not open the device housing. In case of
electrical or mechanical modifications the electric shock
hazard will occur.
Do not use any acid agents and make sure no water ingresses
the device.
Never operate the device with moist hands or standing on wet
floor.
Disconnect the device from the power supply:
-when the device is not used,
-in case of anomalies during operation,
-before cleaning.

- 30 -
HOT SURFACE! Burn hazard!
To avoid the effects of this risk, follow the safety instructions
presented below.
During the operation the surface of the device is very hot!
To avoid burns to the hands and fingers, do not touch the hot
surface of the device! Operate the device only using the
designated handles and switches.
Also after switching off, the frying oil/fat remaining in the basin
remains hot for some time. Before cleaning or moving it to
another place oil must cool down first. Hot oil/fat splashes or
explosions may cause burns at hands, arms and face!
Do not use moisten frying goods. Always remove the extra
ice from deep frozen products first. Do not leave any frozen
products in the basket hanging over the chamber filled in with
the hot oil/fat. Even the smallest water drops may cause oil
splashes or lead to explosions during frying.
WARNING! Fire or explosion hazard!
Follow the safety instructions listed in order to avoid the hazard:
Never operate the device near combustible, easily flammable
materials (e.g. petrol, spirit, alcohol etc.). They evaporate
through heating and in case of contact with ignition sources
deflagrations can occur which can lead to serious personal
injuries and property damages.
Never use the device near flammable objects, e.g. curtains,
beneath cupboards.

- 31 -
When a fire arises unplug the power cord from the socket before
you initiate appropriate measures for fire-fighting. Provide
sufficient supply of fresh air. Caution: Never extinguish the fire
with water when the power plug is connected to the socket.
Electric shock hazard!
1.3 Proper use
The operational safety of the device is assured only in case of proper use, according
to the operation manual.
All technical activities like installation and maintenance must be performed by the
qualified service personnel only.
The deep fat fryer is designed only for deep fat frying of suitable food products.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.

- 32 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
-violation of advice concerning operation and cleaning;
-use other than designed;
-alterations made by user;
-use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.

- 33 -
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in
your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.

- 34 -
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.
4. Technical data
4.1 Technical specification
Name
Deep Fat Fryer CI8L
Code-no.:
A162808
Material:
Chrome nickel steel
Design:
Designed for frying oil and block grease
Safety thermostat
Oil drain tap
Cold zone
ON/OFF switch with indicator light
Heating indicator
Basin:
Number: 1, capacity: 8 litres;
Basin dimensions: W 238 x D 300 x H 190 mm
Basket:
Number: 1, capacity: 6.6 litres
Basket dimensions: W 190 x D 240 x H 145 mm
Temperature range:
50 °C –190 °C
Power supply:
3.25 kW / 230 V 50 Hz
Dimensions:
W 315 x D 460 x H 385 mm
Weight:
7.9 kg
Accessories:
1 lid, 1 heating element shield, 1 frying basket

- 35 -
Name
Deep fat fryer CI2X8L
Code-no.:
A162809
Material:
Chrome nickel steel
Design:
Designed for frying oil and block grease
Safety thermostat
2 oil drain taps
Cold zone
2 ON/OFF switches with indicator light
2 heating indicators
2 separate sockets required
Basin:
Number: 2, capacity: 8 litres (each);
Basin dimensions: W 238 x D 300 x H 190 mm
Basket:
Number: 2, capacity: 6.6 litres (each);
Basket dimensions: W 190 x D 240 x H 145 mm
Temperature range:
50 °C –190 °C
Power supply:
2 x 3,25 kW / 230 V 50 Hz
Dimensions:
W 603 x D 460 x H 385 mm
Weight:
14.65 kg
Accessories:
2 lids, 2 heating element shields,
2 frying baskets
Subject to technical changes and alterations!

- 36 -
4.2 Overview of parts
A162808
1
Main device
2
Handle (2)
3
Frying basket with handle
4
Control box with heating element
5
Control panel
6
Basin
7
Oil drain tap
8
Feet (4)
9
MIN/MAX marks
10
Heating element shield
11
Lid with handle
1
3
8
2
9
4
5
10
11
6
7

- 37 -
A162809
1
Main device
2
Handle (2)
3
Frying basket with handle (2)
4
Basin (2)
5
Control box with heating element (2)
6
Control panel (2)
7
Feet (4)
8
Oil drain tap (2)
9
MIN/MAX marks
10
Heating element shield (2)
11
Lid with handle (2)
1
5
2
3
5
6
6
6
4
4
3
7
9
8
8
9
10
10
11
11

- 38 -
5. Installation and operation
5.1 Installation
CAUTION!
Any installation, connection and maintenance work related to the device
may be performed by the qualified and authorised technician only,
according to the valid international, national and local regulations.
Positioning
Unpack the device and remove all packing material.
Place the device on top of an even, stable, dry and water-resistant surface which
supports the weight of the device and is not heat sensitive.
Never place the device on the flammable surfaces.
You must not position the device near open fireplaces, electric ovens/arc furnaces,
furnaces/electric heaters or other heat sources.
Never place the device at the edge of a table to avoid accidents.
Never place the device in humid or wet environment.
When locating the device make sure there is a 10 cm gap from any walls or other
objects.
Place the device so that the plug is easily accessible for quick disconnection of the
device from power supply, if necessary.
Before the first use, remove the protective foil from the device. Remove the foil slowly
not to leave glue residues. Remove possible glue residues with appropriate solvent.
CAUTION!
Never remove the type plate and warning signs from the device.

- 39 -
Connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid
specification should be compared with that of the device
(see rating plate).
Connect the device only in case of compliance!
The electrical circuit in the socket must be secured to at least 16A. Only connect the
device directly to the wall socket; do not use any extension cords or power strips.
Two separate grounded sockets are required for connecting the double deep fat fryer
A162809.
5.2 Operation
CAUTION!
The deep fryer can only be used by individuals who have been instructed in the
proper use of the device and dangers that may arise during the frying process.
Control panel
Temperature
adjustement knob
OFF position
Melting point
position
ON/OFF switch
with integrated mains
indicator (green)
Heating indicator light
(orange)

- 40 -
CAUTION!
During cleaning and preparation of the device, make sure the device is
not connected to the power supply and that the temperature adjustment
knob is in “OFF” position.
Prepare the device
Remove the lid and take out the frying basket and the heating element shield out of
the device.
Place the frying basket handle in the
intended place; in order to do this lift
it, place on the mounting hook and
insert making sure that both
elements click together.
Detach the control box from the device by lifting it carefully.
Before the first device operation clean it and its equipment according to the
instructions in section 6“Cleaning”. Protect the electric system and the
connection box from the water penetration. Then thoroughly dry the device
and all equipment elements!
Carefully place the control box in the guide on the rear side of the body. Both pivots
at the bottom of the control box must be placed in the openings of the guide for the
device to be set correctly.
Note: For safety reasons the device only operates when the control box is properly
mounted to it, so that the micro-switches enable the device to function.
Mounty the shield on the heating element.
There may be no water at the bottom of the basin before filling it with the frying oil
or block grease. The basin must be clean and dry.
The oil drain tap must be closed (lever turned left and
facing down) (see figure on the right).
Frying
basket
handle
Mounting
hook

- 41 -
Tips regarding the use of oil or fat in blocks
Use appropriate oil for frying (e.g. vegetable, sunflower, groundnut oil etc.)
or fat in blocks.
Use only oil or fats suitable for high temperature cooking.
Do not mix different types of oil or fat, because they may have different boiling
points.
WARNING! Risk of burns!
Do not use stale oil for frying, as a lowered flash point
increases a risk of ignition. Furthermore, it tends to foam
more and it also emits more smoke and odour.
Tips regarding melting of fat in blocks
In the deep fat fryer
Remove the basket and heating element shield.
Place blocks of fat directly on the heating element so that it is completely
covered.
In order to switch the device on follow the instructions in section „Device
start-up“.
Set the temperature dial in the melting point position and wait until
the fat melts off.
When the heating element is covered with liquid fat, you can set the temperature
controller to the maximum temperature. Place more blocks of fat in the basin for
melting in order to reach the appropriate level of fat in the basin.
Next, carefully place the shield on the heating element.
WARNING! Risk of burns!
Oil/fat splashes may cause burns of hands, arms and face!

- 42 -
In a separate container
In order to quickly melt the fat in blocks, use a separate container (e.g. cooking
pan) placing it on the cooker. Then pour the melted fat to the basin of the deep
fat fryer.
Filling in the basin with oil or fat in blocks
Fill in the basin with frying oil or fat in blocks.
Carefully pour oil to the basin until the appropriate level is reached (between
„MIN“ and „MAX“ marks). Marks are located on the side wall of the basin.
WARNING!
Never start the device without frying oil or fat in blocks in
the basin. Always make sure that the oil or fat level is
between “MIN”- and “MAX”marks in the basin.
RISK OF FIRE!
Reducing the oil or fat level below the “MIN”mark creates a
fire hazard.
RISK OF BURNS!
If the oil or fat level is above the “MAX”mark, it may
lead to boiling of hot oil or fat.
Device start-up
Connect the device to the single grounded socket.
Turn the device on with use of ON/OFF switch.The green indicator integrated with
the switch will come on.
Turn the temperature adjustment knob to the right to the desired temperature within
the range from 50 °C to 190 °C.
While heating up the orange heating indicator light will come on, and will go off when
the pre-set temperature is reached. When the temperature in the basin drops the red
indicator light comes on again and the device heats again.

- 43 -
WARNING! Risk of burns!
When in use the deep fat fryer and oil in the container are
very hot, and there is a risk of oil catching fire.
The device should not remain in use for extended periods
of time!
For best results wait until the device reaches the desired temperature and then place
the food product in the frying basin.
Do not use the frying oil/fat for too long in excessively high temperature as it loses
its usability.
In case of longer interruptions between the frying processes set the temperature
controller to lower value.
Put the prepared food products to the frying basket.
Never overfill the basket. This leads to the decrease of temperature of oil/grease
and the fried products will absorb too much fat.
CAUTION!
Do not fry more than the following amount of food products when frying in
deep fat:
8-litre single deep fat fryer 0.6 kg
2 x 8-litre, double deep fat fryer 0.6 kg per basin
Slowly dip the frying basket in the oil using
the fixed handle, place it on the heating
element shield and start frying.
When the frying is finished, carefully lift the
basket, hang it on the rail of the control box
and leave to drip.
Set the temperature adjustment knob to “OFF” position and switch the device off
using ON/OFF switch as soon as the frying process ends the device is not used
any longer.
Control box
hooks
Frying
basket
hooks
