BassBoss SV8 Powered MicroMain User manual

SV8 Powered MicroMain
Owner’s Manual

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free
TABLE OF CONTENTS
Overview....................................................................................... 3
Technical Specifications............................................................ 4
Photos........................................................................................... 5
Safety Information..................................................................... 6
Setup Instructions...................................................................... 7
Troubleshooting......................................................................... 7
Warranty...................................................................................... 8
FCC Compliance Notice............................................................. 9
Need more assistance? Support is available via phone or email.
Email: [email protected]
Phone: [phone] toll free or 512-368-3268
Web Site: www.bassboss.com
SV8 Powered MicroMain SV8 Powered MicroMain
Owner’s Manual

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free Page 3
The SV8 delivers remarkable bass performance and
outstanding sound quality, in keeping with BASSBOSS
tradition. This single 8” loudspeaker compares to
others’ 12” loudspeakers for response and output.
The cabinet is made in the USA from 15mm Baltic Birch.
Every effort was made to deliver full, rich, smooth
sound from a very compact enclosure.
The SV8 is suitable for use as a studio monitor and
is equally at home in a live environment. It provides
extremely flat frequency response with a neutral
character for critical monitoring duties and it’s capable
of remarkably high output, especially for its size. A pair
of SV8s delivers extremely high fidelity sound with the
added bonus of high output plus the flexibility to extend
their output even further by adding a subwoofer or two.
A large port, positioned clear of the woofer grill,
provides deep response without port compression or air
velocity noise at high levels. The high-frequency horn
is mounted to its own baffle to eliminate reflections
from side-walls and is mounted clear of the grill to
ensure uncompromised sound quality. The rear-mounted
amplifier is protected by a set of integrated handles,
which make carrying the boxes a breeze and provide
clean, elegant lines to the enclosure. A standard 35mm
die-cast zinc pole socket is provided in the bottom of
the enclosure and there are four 3/8” threaded fly points
also provided.
The digital processor in the amplifier provides
4 presets, which allow the speaker to be used as a
full-range system, as a satellite for a small subwoofer
or as a main speaker with a larger subwoofer. Preset
1 has the SV8 in full-range mode, offering frequency
response to 40Hz with limiters engaged to prevent
overdriving. Preset 2 offers slightly more SPL and
response to 60Hz. Preset 3 provides another step up in
SPL with the high-pass filter moved to 80Hz. Preset 4
offers the highest peak SPL with the high-pass filter set
at 100Hz. Presets 3 and 4 are recommended when the
SV8 is used with a subwoofer.
SV8 Powered MicroMain
• Compact, High Fidelity, High Output
• Broad Frequency Range
• Long Throw
• Rotatable High Frequency Horn
• Use as Main, Fill or Monitor
• Studio Monitors, Gyms, Restaurants, Venues

Page 4
Our proactive philosophy causes specifications to be subject to change whenever improvements are made.
ACOUSTICAL
Loudspeaker Description: Wide dispersion compact full-range self-powered loudspeaker
with additional presets for satelite mode operation
Frequency Response (±3 dB): 50 – 19,000 Hz (full range)
Maximum Sustained Output: 112dB SPL, 1m, 2pi, half-space
Nominal Dispersion (°H x °V): 90 x 60 (Rotatable)
Amplifier: 700 W – two channel Powersoft Class D Amplifier
DSP: Integrated comprehensive DSP provides high pass, low pass, equalization, phase alignment and limiting
Electrical Connectors, Amplifier: Neutrik Powercon
Electrical Connector, Mains: NEMA5-15 (Edison) standard 3-pin grounded plug
Voltage Operating Range: 90 – 250V Auto-sensing, auto switching pfc universal supply
Current Draw, Nominal: 1.6A @ 1/8 power
Signal Input Connector: XLR-F
Signal Output Connector: XLR-M pass-through only
ELECTRICAL
Enclosure Type: 2-way full-range/mid-high. Direct radiating vented LF section, horn-loaded HF section
Transducer, LF: 1 x 8 in. dia (200 mm) neodymium motor woofers with 2 in. (51mm) copper winding voice coil.
Transducer, HF: 1.7 in. (44mm) diaphragm compression driver on 1 in. throat 90 x 60 degree constant directivity horn
Cabinet Construction: 15 mm Baltic Birch plywood. Equipped with 2 handles. Includes 4 internally braced fly points and a 35mm pole socket
Suspension Points (Optional): 4 x 3/8” 16tpi, 2 top, front and rear, 2 bottom, front and rear
Dimensions (HxWxD): 18” (45.5cm) x 9.5” (24cm) front, 7” (18cm) rear, x 14” (35.5cm)
Net Weight: 26 lbs (11.8 kg)
Shipping Weight: 31 lbs (14 kg)
Exterior Finish, Standard: Black Weatherproof bonded high-pressure polyurethane
Exterior Finish, Optional: White Textured Epoxy Paint
Grill: Perforated, Powder-coated Steel
Physical
Shoulder Eye Bolts For use when flying cabinets vertically
Side-pull Anchors For use when flying cabinets horizontally
Tripod Stands Supports loudspeaker from ground
35mm Pole Stand Supports loudspeaker above subwoofer equipped with pole socket
Cover/Carrier Heavy-duty padded nylon transport cover and carrying bag
Online Information: bassboss.com/sv8
Optional
Response Graph

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free Page 5
Available in White or Black.
SV8 Powered Micromain - page 3

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free Page 6
SAFETY INFORMATION
Important information regarding safety and the use of your loudspeakers:
Never stand in the immediate vicinity of loudspeakers driven at a high level. Professional loudspeaker systems are capable of causing a
sound pressure level detrimental to human health. Seemingly non-critical sound levels (from approx. 95 dB SPL) can cause hearing damage
if people are exposed to it over a long period. To prevent potentially dangerous exposure to high levels of acoustic pressure, anyone who
is exposed to these levels should use adequate protection devices.
When a transducer capable of producing high sound levels is being used, it is therefore necessary to wear ear plugs or protective earphones.
See the manual technical specifications to know the maximum sound pressure level.
In order to prevent accidents when setting up the loudspeakers or loudspeaker stands, make sure they are standing on a firm surface.
Ensure that all additional hardware, fixings and fasteners used for installation or mobile deployment are of an appropriate size and load
safety factor.
Pay attention to the manufacturers’ instructions and to the relevant safety guidelines.
Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
Regularly check all load bearing bolts in the mounting devices.
Caution: Loudspeakers produce a static magnetic field even if they are not connected or are not in use. Therefore make sure when erecting
and transporting loudspeakers that they are nowhere near equipment and objects which may be impaired or damaged by an external
magnetic field. A distance of 3 feet (1m) should be maintained between loudspeakers and sensitive equipment such as CRT monitors or
magnetic storage media.
Never attempt to carry out any operations, modifications or repairs that are not expressly described in this manual.
Contact your dealer or BASSBOSS support if the product is not functioning properly.
BASSBOSS strongly recommends this product be installed by a qualified, professional installer who can ensure correct installation and
certify that is is installed in compliance with the regulations in force.
The entire audio system must comply with the current local standards and regulations regarding electrical systems.
IMPORTANT NOTES
To prevent the occurrence of noise on signal cables, use shielded cables only. Avoid routing signal cables close to equipment that produces
high-intensity electromagnetic fields such as transformers, power cables and loudspeaker wires. Do not coil excess power cable. Do not coil
or wrap power cables and signal cables together.

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free Page 7
SET UP INSTRUCTIONS
1. Place loudspeaker in the desired location. Ensure that it is secure and stable.
2. Rotate the input attenuator knob counterclockwise to the lowest setting.
3. Connect signal via the XLR input jack.
4. Connect the amplifier module’s power supply cord using the blue PowerCON connectors. To insert, align the indexing tabs on the PowerCON
connector, insert it into the socket and rotate clockwise until the latch catches.
5. Connect the electrical plug to a power source.
6. Select the desired preset via the PGM SEL button.
7. Rotate the input attenuator clockwise to achieve the desired sound level.
System Setup Addendum:
When connecting multiple loudspeakers in a system, signal can be passed through from one powered loudspeaker to another using balanced, shielded XLR
cables. No processing is applied to the signal as it passes through from the input to the output connectors in each loudspeaker. Signal can be routed in
any sequence because each loudspeaker receives a full-range signal and applies the necessary processing in order to operate as part of the overall system.
It is recommended to run signal to the nearest box first and patch to the next nearest box in sequence.
TROUBLESHOOTING
If after following the above instructions for setup you have no output from the loudspeakers, please check the following:
Verify that the green power (PWR) LED is on. If not, check the following:
1. Is the power cord plugged into a live outlet?
2. Is the Neutrik PowerCON connector rotated into the locked position?
If the power LED is on, check the following:
Is the green “signal present” LED (SIG) illuminating? If not:
1. Is the signal cable connected to the input?
2. Is the signal cable connected to an operating output at the other end?
3. Is the signal flowing to the input? Check the integrity of the cable.

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free Page 8
Thanks for your BASSBOSS purchase!
WARRANTY INFORMATION
Beyond ensuring your satisfaction, our extensive “Sound Defense” transferable warranty which covers all BASSBOSS products.
STANDARD CABINET WARRANTY
BASSBOSS loudspeaker cabinet integrity, including all joinery, fasteners, handles and wood, is warranted against defects in materials and workmanship for a
period of six years from the date of purchase. This warranty does not cover items that are intended to wear and can be replaced if worn or damaged. Examples
of items not covered by this warranty are cabinet feet, grills and the finish or coating applied to the cabinet.
ENHANCED COMPONENT WARRANTY
BASSBOSS self-powered loudspeaker amps and electronic components are covered against failures due to defects in materials and/or workmanship for a period
of three years from the date of purchase. Speaker drivers and burned or open voice coils in subwoofers are covered for two years.
OUR SUPPORT
It is our goal to provide trouble-free loudspeakers. That objective begins as part of the design phase and continues on through to any service you may require.
In order to be able to provide the lowest possible failure rate, the best possible warranty service and the fastest turn-around time, we request that you contact
us immediately if you notice any problem with your system, and before you attempt any repairs. We can provide the best and fastest solution if we know the
details of the problem before any repair attempts are made. Often BASSBOSS technicians can troubleshoot problems that may arise and no repair or further
service will be necessary.
Warranty support is a service, and part of that service includes helping you prevent failures and minimize repair and shipping costs. Please do not ship products
without first obtaining a return authorization number by calling 512-368-3268 (855-822-7770 toll-free) or by emailing [email protected]. BASSBOSS
service technicians will provide assistance and instructions on shipping and packaging requirements specific to your service needs.
WARRANTY LIMITATIONS
During the warranty period, if your loudspeaker malfunctions or fails due to any defect in components or manufacturing, the failed parts will be repaired or
replaced. This warranty does not extend to damage resulting from improper installation, misuse, neglect or abuse. Warranty coverage will be determined upon
inspection by BASSBOSS personnel. This warranty does not cover labor other than that authorized and performed by BASSBOSS personnel. Service will be
performed upon the return of the failed unit, together with its original sales receipt or other proof of purchase, to BASSBOSS or an Authorized Service Facility.
Purchaser is responsible for all costs of shipping and handling. Cosmetic damage is specifically excluded from this warranty. This warranty is rendered void
if service, repairs and/or modifications are attempted or made by anyone not specifically authorized by BASSBOSS to perform said services. Please contact
BASSBOSS or your local BASSBOSS dealer before attempting any repairs and before shipping parts in for service.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state. For more information concerning BASSBOSS
service and warranty policies please contact us at 512-36-3268 or [phone] toll-free.
EXPORT WARRANTY
BASSBOSS products can be purchased worldwide. In countries without local BASSBOSS distributors, product requiring service must be shipped back to the US
for warranty repairs. In most cases, the entire cabinet will not need to be shipped. Generally only the individual affected parts will need to be shipped to the
factory for servicing. Please contact BASSBOSS before attempting any repairs and before shipping parts in for service.
SHIPPING AND PACKAGING
Please package your returns safely and securely. BASSBOSS does not cover damage that occurs in transit. Freight insurance is recommended.

www.bassboss.com
©®2018 True Lee Loudspeakers, LLC – [email protected] – 512-368-3268 855-8-BASS-70 Toll Free Page 9
FCC COMPLIANCE NOTICE
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
EC DECLARATION OF CONFORMITY
Manufacturer:
True Lee Loudspeakers, LLC – BASSBOSS
9501 Cargo Ave Ste 600 Austin TX 78719
We declare that under our sole responsibility the product: SV8 MicroMain
Intended use: Professional Audio Loudspeaker
Are in conformity with the provisions of the following EC Directives, including all amendments, and with national
legislation implementing these directives:
• 2006/95/EC Low Voltage Directive
• 2004/108/EC Electromagnetic Compatibility Directive
• 2002/95/CE RoHs Directive
