Basta Boatlifts 1.4k60 User manual

READ complete manual CAREFULLY
BEFORE attempting assembly or operation
01/23
L392-0084, REV G
1,400 lbs (635 kg) Capacity - Models 1.4k60 & 1.4k84
866-GO-BASTA
www.gobasta.com
ASSEMBLY
INSTALLATION
REPLACEMENT PARTS
Copyright 2023 Basta, Inc.
©
1.4k60/1.4k84
Manual & Electric drive versions

Assembly Instructions ..........................................................................Pages 10 - 24
First Use / Adjustments
..................................................................................Page 26
Parts List and Dimensions.................................................................Pages 4 - 9, 25
2
INDEX
Warning.........................................................................................................Page 2, 3
Warranty.............................…..........................................................................Page 27-28
NOTE:Your boat lift is a very heavy piece of equipment. Improper use could result in
serious injury or death. For the safety of people and property please review the safety
guidelines below for your new boat lift.
Do not exceed the maximum weight capacity
specified for the lift. SEE PAGE 15.
Passengers should stand clear of the lift and not
be aboard when the lift is in operation.
Do not play on or near the lift.
Service your lift regularly.
Do not service the unit with the boat on the lift.
Use a mooring line for additional security.
Visually inspect all parts and assemblies for
defects and damage prior to assembling the
lift.
Do not install the lift alone.
Install the lift only on a structurally sound and
level dock.
Verify the lift tower is vertical both side to side
and front to back before each use.
The lift should not be used for any other
purpose besides the lifting of watercraft.
WARNING
For a full list of patents, go to:
bastaboatlifts.com/patents
3
In the following pages various symbols are used:
indicates a major part described in the parts list on pages 4 - 9.
or indicate hardware items shown above and described in the parts list
on pages 4 - 9.
1&2
11
AA
After the lift is assembled and installed, all
fasteners should be checked for proper tightness
and reinspected periodically.
INSPECT
the lift monthly
for frayed cable, loose
fasteners and corrosion
Before Using:
Read this manual
completely!
!
!
We recommend that you hire a professional to install your lift.
INSTALLATION
good condition and securely attached. If necessary, cut a notch in any cosmetic dock fascia board
to allow the lift mount to be bolted through a heavier structural member.
Only stainless steel or galvanized hardware should be used to install the lift. Due to the highly
customized nature of each installation, installation hardware is not supplied with the lift kit.
CAUTION should be exercised to ensure your safety at all times.
For safety and proper operation, the lift tower should be plumb (vertical) side-to-side and
front to back so the carriage forks are horizontal.
The lower end of the tower must be securely attached to the dock.
Please inspect your dock thoroughly before installing the lift and make sure that all wood is in
Do not exceed the maximum weight capacity
specified for the lift.
1,400 LBS (635 kgs)
DANGER
MAXIMUM CAPACITY

Assembly Instructions ..........................................................................Pages 10 - 24
First Use / Adjustments
..................................................................................Page 26
Parts List and Dimensions.................................................................Pages 4 - 9, 25
2
INDEX
Warning.........................................................................................................Page 2, 3
Warranty.............................…..........................................................................Page 27-28
NOTE:Your boat lift is a very heavy piece of equipment. Improper use could result in
serious injury or death. For the safety of people and property please review the safety
guidelines below for your new boat lift.
Do not exceed the maximum weight capacity
specified for the lift. SEE PAGE 15.
Passengers should stand clear of the lift and not
be aboard when the lift is in operation.
Do not play on or near the lift.
Service your lift regularly.
Do not service the unit with the boat on the lift.
Use a mooring line for additional security.
Visually inspect all parts and assemblies for
defects and damage prior to assembling the
lift.
Do not install the lift alone.
Install the lift only on a structurally sound and
level dock.
Verify the lift tower is vertical both side to side
and front to back before each use.
The lift should not be used for any other
purpose besides the lifting of watercraft.
WARNING
For a full list of patents, go to:
bastaboatlifts.com/patents
3
In the following pages various symbols are used:
indicates a major part described in the parts list on pages 4 - 9.
or indicate hardware items shown above and described in the parts list
on pages 4 - 9.
1&2
11
AA
After the lift is assembled and installed, all
fasteners should be checked for proper tightness
and reinspected periodically.
INSPECT
the lift monthly
for frayed cable, loose
fasteners and corrosion
Before Using:
Read this manual
completely!
!
!
We recommend that you hire a professional to install your lift.
INSTALLATION
good condition and securely attached. If necessary, cut a notch in any cosmetic dock fascia board
to allow the lift mount to be bolted through a heavier structural member.
Only stainless steel or galvanized hardware should be used to install the lift. Due to the highly
customized nature of each installation, installation hardware is not supplied with the lift kit.
CAUTION should be exercised to ensure your safety at all times.
For safety and proper operation, the lift tower should be plumb (vertical) side-to-side and
front to back so the carriage forks are horizontal.
The lower end of the tower must be securely attached to the dock.
Please inspect your dock thoroughly before installing the lift and make sure that all wood is in
Do not exceed the maximum weight capacity
specified for the lift.
1,400 LBS (635 kgs)
DANGER
MAXIMUM CAPACITY

4 5
18
17
16
12
11
10
3
2
2
9
9
8
7
20
21
19
1
4
13
2
15
22
5
6
14
3
ITEM PART NO.
1
1
QTY.
AA
BB
CC
DD
EE
N/A
2
1
DESCRIPTION
W125-0004
W125-0001
W125-0006
A427-0016
W114-0010
N/A
1
FF
GG
HH
2
W410-0068
W125-0002
W125-0003
Carriage Weldment
Tower Weldment (1.4k60)
Dock Mount Weldment
Tower Clamp
Blue Bunk Board (part of LL)
Bunk Rail Assembly (EE + FF)
Bunk Rail Weldment (part of LL)
Tower Weldment (1.4k84)
BB or CC
AA
FF
DD
GG
HH
DD
FF
HH
Lift Tower
Carpeted
Bunk Board
Dock Mount
Tower Clamp
Carriage Weldment
Bunk Rail
Bunk Rail
Tower Clamp
(This Side Not Shown)
Carpeted
Bunk Board
UNIVERSAL PARTS UNIVERSAL PARTS LIST
EE
Bunk Rail
weldment
EE
Bunk Rail
weldment
ITEM PART NO. DESCRIPTION QTY.
1
2
3
4
5
6
S103-0506
S313-0008
S342-0008
S170-6507
S501-0507
bolt, hex head 3/8-16 x 1.25 SS
washer, flat 3/8 SS
nut 3/8-16 SS
U-bolt, square 3/8 x 2 x 6 SS
4
22
5
4
1
13
ITEM PART NO. DESCRIPTION QTY.
S103-0511
bolt, hex head 3/8-16 x 2.5 SS
1
14
16
S362-0007
nut, 5/16-18 SS (part of LL)
4
S313-0007 washer, flat 5/16 SS (part of LL)
4
7
17
S322-0007
washer, lock 5/16 SS (part of LL)
4
8
20
18
M413-1001 sheave
1
M532-6601 axle
2
M502-6002 roller
4
9
21
10
22
11
19
anti-seize compound
1
Y356-0003
S103-0709
bolt, hex head 1/2-13 x 2 SS
6
S362-0010
nut, 1/2-13 nylock SS
6
S103-0306 bolt, hex head 1/4 x 1.25 SS 2
S322-0006
washer, lock 1/4 SS
2
S522-0801 ring type cotter pin, SS 1
clevis pin, 1/2 x 2-1/2 SS
S313-0010 washer, flat 1/2 SS 12
S322-0008
washer, lock 3/8 SS
8
12
2
S313-0006
washer, flat 1/4 SS
8
15
nut, 3/8-16 nylock SS
S362-0008

4 5
18
17
16
12
11
10
3
2
2
9
9
8
7
20
21
19
1
4
13
2
15
22
5
6
14
3
ITEM PART NO.
1
1
QTY.
AA
BB
CC
DD
EE
N/A
2
1
DESCRIPTION
W125-0004
W125-0001
W125-0006
A427-0016
W114-0010
N/A
1
FF
GG
HH
2
W410-0068
W125-0002
W125-0003
Carriage Weldment
Tower Weldment (1.4k60)
Dock Mount Weldment
Tower Clamp
Blue Bunk Board (part of LL)
Bunk Rail Assembly (EE + FF)
Bunk Rail Weldment (part of LL)
Tower Weldment (1.4k84)
BB or CC
AA
FF
DD
GG
HH
DD
FF
HH
Lift Tower
Carpeted
Bunk Board
Dock Mount
Tower Clamp
Carriage Weldment
Bunk Rail
Bunk Rail
Tower Clamp
(This Side Not Shown)
Carpeted
Bunk Board
UNIVERSAL PARTS UNIVERSAL PARTS LIST
EE
Bunk Rail
weldment
EE
Bunk Rail
weldment
ITEM PART NO. DESCRIPTION QTY.
1
2
3
4
5
6
S103-0506
S313-0008
S342-0008
S170-6507
S501-0507
bolt, hex head 3/8-16 x 1.25 SS
washer, flat 3/8 SS
nut 3/8-16 SS
U-bolt, square 3/8 x 2 x 6 SS
4
22
5
4
1
13
ITEM PART NO. DESCRIPTION QTY.
S103-0511
bolt, hex head 3/8-16 x 2.5 SS
1
14
16
S362-0007
nut, 5/16-18 SS (part of LL)
4
S313-0007 washer, flat 5/16 SS (part of LL)
4
7
17
S322-0007
washer, lock 5/16 SS (part of LL)
4
8
20
18
M413-1001 sheave
1
M532-6601 axle
2
M502-6002 roller
4
9
21
10
22
11
19
anti-seize compound
1
Y356-0003
S103-0709
bolt, hex head 1/2-13 x 2 SS
6
S362-0010
nut, 1/2-13 nylock SS
6
S103-0306 bolt, hex head 1/4 x 1.25 SS 2
S322-0006
washer, lock 1/4 SS
2
S522-0801 ring type cotter pin, SS 1
clevis pin, 1/2 x 2-1/2 SS
S313-0010 washer, flat 1/2 SS 12
S322-0008
washer, lock 3/8 SS
8
12
2
S313-0006
washer, flat 1/4 SS
8
15
nut, 3/8-16 nylock SS
S362-0008

JJ
KK
LL
PP
ITEM PART NO.
1
1
QTY.
JJ
KK
LL
MM
NN
1
1
1
DESCRIPTION
A412-0003
C250-0002
M710-3001
K205-0014
K205-0013
Hand Wheel
Winch cover
Winch
Sheave Plate, Outer
Sheave Plate, Inner
W125-0005
Winch Bracket Weldment
PP
1
M330-0001
QQ
1
cable assembly
QQ
32
24
23
31
33
30
29
27
26
23
25
34
24
28
23
23
ITEM PART NO.
34
23
24
25
26
27
28
29
30
31
QTY.
3
8
10
2
3
3
3
1
DESCRIPTION
1
1
S103-0506
S313-0008
bolt, hex head 3/8-16 x 1.25 SS
washer, flat 3/8 SS
S362-0008
nut, 3/8-16 nylock SS
S103-0507
bolt, hex head 3/8 x 1.5 SS
S103-0301
bolt, hex head 1/4 x 0.50 SS
S313-0006
washer, flat 1/4 SS
S160-6537
3/8”-24 x 3/8” cut point set screw
S501-0503
clevis pin, 1/2 x 1-1/2 SS
S520-1504
cotter pin, 1/8 x 1-1/2 SS
Q501-2001
Allen wrench 3/16”
32
1
M750-0002
winch cable clamp assembly (part of LL)
33
1
M413-1001
sheave
Cable Assembly
Hand Wheel
Outer & Inner
Sheave Plates
Winch Cover
Winch
MM & NN
Winch Bracket
7
6
MANUAL PARTS MANUAL DRIVE PARTS LIST
same as 19

JJ
KK
LL
PP
ITEM PART NO.
1
1
QTY.
JJ
KK
LL
MM
NN
1
1
1
DESCRIPTION
A412-0003
C250-0002
M710-3001
K205-0014
K205-0013
Hand Wheel
Winch cover
Winch
Sheave Plate, Outer
Sheave Plate, Inner
W125-0005
Winch Bracket Weldment
PP
1
M330-0001
QQ
1
cable assembly
QQ
32
24
23
31
33
30
29
27
26
23
25
34
24
28
23
23
ITEM PART NO.
34
23
24
25
26
27
28
29
30
31
QTY.
3
8
10
2
3
3
3
1
DESCRIPTION
1
1
S103-0506
S313-0008
bolt, hex head 3/8-16 x 1.25 SS
washer, flat 3/8 SS
S362-0008
nut, 3/8-16 nylock SS
S103-0507
bolt, hex head 3/8 x 1.5 SS
S103-0301
bolt, hex head 1/4 x 0.50 SS
S313-0006
washer, flat 1/4 SS
S160-6537
3/8”-24 x 3/8” cut point set screw
S501-0503
clevis pin, 1/2 x 1-1/2 SS
S520-1504
cotter pin, 1/8 x 1-1/2 SS
Q501-2001
Allen wrench 3/16”
32
1
M750-0002
winch cable clamp assembly (part of LL)
33
1
M413-1001
sheave
Cable Assembly
Hand Wheel
Outer & Inner
Sheave Plates
Winch Cover
Winch
MM & NN
Winch Bracket
7
6
MANUAL PARTS MANUAL DRIVE PARTS LIST
same as 19

34
44
43
42
43
41
40
39
38
36
37
35
Preassembled Power Head
In Battery Box
9
Power Head
Assembly
Cover Assembly
Battery
SS
RR
UU
TT
WW
XX
YY
ZZ
AAA
BBB
CCC
DDD
ITEM PART NO.
42
43
44
34
35
36
37
38
S103-0512
S313-0008
S362-0008
S127-1803
S218-0507
S113-0101
S342-0003
39
40
S322-0006
S313-0006
S342-0006
QTY.
2
4
2
4
4
2
2
2
DESCRIPTION
Bolt, hex head 3/8-16 x 2.75 SS
Washer, flat 3/8 SS
Nut, 3/8-16 Nylock SS
Screw, thread cutting #14 x 1.0 SS
Washer, lock 1/4 SS
Washer, flat SS
Nut, 1/4-20 SS
Screw, socket flat M8 x 1.25 SS
Nut, #8 SS
Machine bolt, 8-32 x 0.5 SS
41
S103-0303
bolt, hex head 1/4-20 x 0.75 SS
2
2
2
8
EEE
12V ELECTRIC DRIVE 12V DRIVE PARTS LIST
33
ITEM PART NO.
1
QTY.
RR
SS
TT
UU
VV
A405-0009
A405-0011
R285-1005
R810-0013
R281-0004
R330-1020
WW R283-0002
1
1
1
1
1
DESCRIPTION
Power Head Assembly
Battery
Remote Control Assembly
Solar Panel Assembly
Fuse, 5A
Solar Panel Controller
XX M730-0003
1
Hoist
YY R321-0002
1
Hoist Contactor
ZZ W310-0001
1
Power Switch
AAA
M330-0004
1
Cable Assembly, 3/16”
BBB K205-4017
1
Upper Magnet Switch Plate
CCC W125-0011
1
Lower Magnet Switch Plate
DDD M651-0001
1
Tensioner Block
EEE
1
Cover Assembly

34
44
43
42
43
41
40
39
38
36
37
35
Preassembled Power Head
In Battery Box
9
Power Head
Assembly
Cover Assembly
Battery
SS
RR
UU
TT
WW
XX
YY
ZZ
AAA
BBB
CCC
DDD
ITEM PART NO.
42
43
44
34
35
36
37
38
S103-0512
S313-0008
S362-0008
S127-1803
S218-0507
S113-0101
S342-0003
39
40
S322-0006
S313-0006
S342-0006
QTY.
2
4
2
4
4
2
2
2
DESCRIPTION
Bolt, hex head 3/8-16 x 2.75 SS
Washer, flat 3/8 SS
Nut, 3/8-16 Nylock SS
Screw, thread cutting #14 x 1.0 SS
Washer, lock 1/4 SS
Washer, flat SS
Nut, 1/4-20 SS
Screw, socket flat M8 x 1.25 SS
Nut, #8 SS
Machine bolt, 8-32 x 0.5 SS
41
S103-0303
bolt, hex head 1/4-20 x 0.75 SS
2
2
2
8
EEE
12V ELECTRIC DRIVE 12V DRIVE PARTS LIST
33
ITEM PART NO.
1
QTY.
RR
SS
TT
UU
VV
A405-0009
A405-0011
R285-1005
R810-0013
R281-0004
R330-1020
WW R283-0002
1
1
1
1
1
DESCRIPTION
Power Head Assembly
Battery
Remote Control Assembly
Solar Panel Assembly
Fuse, 5A
Solar Panel Controller
XX M730-0003
1
Hoist
YY R321-0002
1
Hoist Contactor
ZZ W310-0001
1
Power Switch
AAA
M330-0004
1
Cable Assembly, 3/16”
BBB K205-4017
1
Upper Magnet Switch Plate
CCC W125-0011
1
Lower Magnet Switch Plate
DDD M651-0001
1
Tensioner Block
EEE
1
Cover Assembly

NOTE: use a small amount of anti-seize on bolt threads
ASSEMBLY INSTRUCTIONS
Roller Installation
21
10
11
12
20
21
12
11
10
21
21
20
QTY 2: 1/4 x 1.25" bolt ("10")
QTY 2: 1/4 flat washer ("12")
QTY 2: 1/4 lock washer ("11")
QTY 2: axle ("20”)
QTY 4: roller ("21")
1110
NOTE: use a small amount of anti-seize on bolt threads
ASSEMBLY INSTRUCTIONS
Tower Assembly
9
7
8
9
BB or CC
GG
HH
HH
Tower clamps are “L” shaped &
MUST face in direction shown above
HH
HH
14
3
QTY 6: 1/2 x 2.0" bolt ("7")
QTY 6: 1/2 nylock nut ("8")
QTY 12: 1/2 flat washer ("9")
QTY 1: 3/8 x 2.5" bolt ("14")
QTY 1: 3/8 nylock nut ("3")
Apply a small amount of anti-seize
inside of rollers prior to placing on
axle
AA

NOTE: use a small amount of anti-seize on bolt threads
ASSEMBLY INSTRUCTIONS
Roller Installation
21
10
11
12
20
21
12
11
10
21
21
20
QTY 2: 1/4 x 1.25" bolt ("10")
QTY 2: 1/4 flat washer ("12")
QTY 2: 1/4 lock washer ("11")
QTY 2: axle ("20”)
QTY 4: roller ("21")
1110
NOTE: use a small amount of anti-seize on bolt threads
ASSEMBLY INSTRUCTIONS
Tower Assembly
9
7
8
9
BB or CC
GG
HH
HH
Tower clamps are “L” shaped &
MUST face in direction shown above
HH
HH
14
3
QTY 6: 1/2 x 2.0" bolt ("7")
QTY 6: 1/2 nylock nut ("8")
QTY 12: 1/2 flat washer ("9")
QTY 1: 3/8 x 2.5" bolt ("14")
QTY 1: 3/8 nylock nut ("3")
Apply a small amount of anti-seize
inside of rollers prior to placing on
axle
AA

HH
QTY 1: 1/2 x 2-1/2 clevis pin ("5")
QTY 1: ring type cotter pin ("6")
QTY 1: sheave ("19")
ASSEMBLY INSTRUCTIONS
Cable Installation (Manual)
5
6
PIN
IN FRONT
OF PIN
BEHIND PIN
19
QTY 1: lift cable ("QQ")
NOTE: use a small amount of anti-seize on bolt threads
13
FOR THE MANUAL DRIVE SYSTEM: GO TO PG 13
FOR THE 12V ELEC. DRIVE SYSTEM: GO TO PG 14
12
QQ

HH
QTY 1: 1/2 x 2-1/2 clevis pin ("5")
QTY 1: ring type cotter pin ("6")
QTY 1: sheave ("19")
ASSEMBLY INSTRUCTIONS
Cable Installation (Manual)
5
6
PIN
IN FRONT
OF PIN
BEHIND PIN
19
QTY 1: lift cable ("QQ")
NOTE: use a small amount of anti-seize on bolt threads
13
FOR THE MANUAL DRIVE SYSTEM: GO TO PG 13
FOR THE 12V ELEC. DRIVE SYSTEM: GO TO PG 14
12
QQ

15
ASSEMBLY INSTRUCTIONS
Upper Tower Assembly (Manual)
QTY 2: 3/8 nylock nut ("24")
QTY 4: 3/8 flat washer ("23")
QTY 1: 1/2 x 1-1/2 clevis pin ("29")
QTY 1: cotter pin ("30")
QTY 1: sheave ("33")
QTY 2: 3/8 x 1.5" bolt ("25")
33
18
ROUTE
BEHIND
PLATES
MM & NN
LL
NN
24
BB or CC
23
24 23
MM
NOTE: use a small amount of anti-seize on bolt threads
33 NN
MM
29
23 25
23
25
30
manual drive
These parts are not used
with the electric power head.
14
QTY 4: 3/8 x 1.25" bolts ("1")
QTY 4: 3/8 nylock nuts ("3")
QTY 8: 3/8 flat washers ("2")
KK
ASSEMBLY INSTRUCTIONS
Winch Bracket Installation
1
2
1
2
1
2
1
2
2
2
2
3
2
3
3
3
NOTE: use a small amount of anti-seize on bolt threads
QQ BB or CC

15
ASSEMBLY INSTRUCTIONS
Upper Tower Assembly (Manual)
QTY 2: 3/8 nylock nut ("24")
QTY 4: 3/8 flat washer ("23")
QTY 1: 1/2 x 1-1/2 clevis pin ("29")
QTY 1: cotter pin ("30")
QTY 1: sheave ("33")
QTY 2: 3/8 x 1.5" bolt ("25")
33
18
ROUTE
BEHIND
PLATES
MM & NN
LL
NN
24
BB or CC
23
24 23
MM
NOTE: use a small amount of anti-seize on bolt threads
33 NN
MM
29
23 25
23
25
30
manual drive
These parts are not used
with the electric power head.
14
QTY 4: 3/8 x 1.25" bolts ("1")
QTY 4: 3/8 nylock nuts ("3")
QTY 8: 3/8 flat washers ("2")
KK
ASSEMBLY INSTRUCTIONS
Winch Bracket Installation
1
2
1
2
1
2
1
2
2
2
2
3
2
3
3
3
NOTE: use a small amount of anti-seize on bolt threads
QQ BB or CC

JJ
28
28
PP
QTY 3: 1/4 x 0.50" bolt ("26")
QTY 3: 1/4 flat washer ("27")
QTY 3: 3/8-24 x 3/8 cut point set screw ("28")
26
26
26
ASSEMBLY INSTRUCTIONS
Final Tower Assembly
KK
LL
NOTE: use a small amount of anti-seize on bolt threads
27
27
27
17
SECURE CABLE:
With lift in fully lowered
position, wrap excess cable
around winch drum in
counter-clockwise direction
and secure as shown.
Carriage bolt is
inserted into
square hole. 32
(Electric hoist wraps in clockwise direction.)
16
QTY 3: 3/8 x 1.25" bolts ("34")
QTY 3: 3/8 nylock nuts ("24")
QTY 6: 3/8 flat washers ("23")
NOTE: use a small amount of anti-seize on bolt threads
ASSEMBLY INSTRUCTIONS
Winch Bracket Assembly 34
PP
23
23
24
23
24
23
24
LL
Secure cable
on this side
23
34
23
34
BB or CC

JJ
28
28
PP
QTY 3: 1/4 x 0.50" bolt ("26")
QTY 3: 1/4 flat washer ("27")
QTY 3: 3/8-24 x 3/8 cut point set screw ("28")
26
26
26
ASSEMBLY INSTRUCTIONS
Final Tower Assembly
KK
LL
NOTE: use a small amount of anti-seize on bolt threads
27
27
27
17
SECURE CABLE:
With lift in fully lowered
position, wrap excess cable
around winch drum in
counter-clockwise direction
and secure as shown.
Carriage bolt is
inserted into
square hole. 32
(Electric hoist wraps in clockwise direction.)
16
QTY 3: 3/8 x 1.25" bolts ("34")
QTY 3: 3/8 nylock nuts ("24")
QTY 6: 3/8 flat washers ("23")
NOTE: use a small amount of anti-seize on bolt threads
ASSEMBLY INSTRUCTIONS
Winch Bracket Assembly 34
PP
23
23
24
23
24
23
24
LL
Secure cable
on this side
23
34
23
34
BB or CC

Slide in the battery and attach the battery cables - red to positive & black to
negative.
Temporarily plug the 6 pin connectors from the
cover assembly and the power head assembly
together and use the buttons on the
39
40
41
D
19
Battery Installation
ALWAYS have a MINIMUM of
four wraps of the cable around
the hoist drum.
Cable routing is different for the
manual hoist QTY 2: 1/4 x 0.75" bolts ("41")
QTY 2: 1/4 flat washers ("40")
QTY 2: 1/4 lock washers ("39")
QTY 2: 1/4 - 20 nuts ("38")
38
remote to unspool enough cable from
the hoist drum to string it.
at least 4 wraps
wrap starts
behind drum
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
12V ELECTRIC DRIVE
NOTE: use a small amount of anti-seize on bolt threads
Install the power head on the tower with 4 bolts
(“1”).Each bolt has a washer (“2”) under its head and
under the locknut (“17”).
Power Head Installation
QTY 4: 3/8 x 1.25" bolts ("1")
QTY 4: 3/8 nylock nuts ("3")
QTY 8: 3/8 flat washers ("2")
2
12
12
2
3
17
3
18
RR
FFF
RR
SS

Slide in the battery and attach the battery cables - red to positive & black to
negative.
Temporarily plug the 6 pin connectors from the
cover assembly and the power head assembly
together and use the buttons on the
39
40
41
D
19
Battery Installation
ALWAYS have a MINIMUM of
four wraps of the cable around
the hoist drum.
Cable routing is different for the
manual hoist QTY 2: 1/4 x 0.75" bolts ("41")
QTY 2: 1/4 flat washers ("40")
QTY 2: 1/4 lock washers ("39")
QTY 2: 1/4 - 20 nuts ("38")
38
remote to unspool enough cable from
the hoist drum to string it.
at least 4 wraps
wrap starts
behind drum
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS
12V ELECTRIC DRIVE
NOTE: use a small amount of anti-seize on bolt threads
Install the power head on the tower with 4 bolts
(“1”).Each bolt has a washer (“2”) under its head and
under the locknut (“17”).
Power Head Installation
QTY 4: 3/8 x 1.25" bolts ("1")
QTY 4: 3/8 nylock nuts ("3")
QTY 8: 3/8 flat washers ("2")
2
12
12
2
3
17
3
18
RR
FFF
RR
SS

ASSEMBLY INSTRUCTIONS
Upper Tower Assembly (12V)
QTY 2: 3/8 nylock nut ("44")
QTY 4: 3/8 flat washer ("43")
QTY 2: 3/8 x 2.75" bolt ("42")
QTY 1: tensioner block ("DDD")
QTY 1: up mag. plate ("BBB")
NOTE: use a small amount of anti-seize on bolt threads
at least 4 wraps
wrap starts
behind drum
INSIDE TOWER
42
43 BBB
43 44
AAA DDD
21
AA
QTY 1: 1/2 x 2-1/2 clevis pin ("5")
QTY 1: ring type cotter pin ("6")
QTY 1: sheave ("18")
QTY 1: lift cable ("AAA")
QTY 1: low mag. plate ("CCC")
ASSEMBLY INSTRUCTIONS
Cable Installation (12V)
5
6
PIN
IN FRONT
OF PIN BEHIND PIN
NOTE: use a small amount of anti-seize on bolt threads
18
AAA
CCC
TOP DOWN VIEW
20
