Basta Boatlifts Over-Center 4.5k37 User manual

COPYRIGHT 2022
BASTA INC.
3/22
L392-0088C
BASTA BOATLIFTS
OVER-CENTER HYDRAULIC ALUMINUM LIFT
4,500 lb Capacity Boat Lift
Models 4.5k 37 / 4.5k 53
866-GoBasta GoBasta.com

PAGE 2
Basta Boatlifts are protected by one or more US Patents
www.gobasta.com/patents
DANGER
• Do not exceed the maximum weight capacity specified for the lift. Maximum weight
capacity can be found on the cover of this manual and on the H frame of the lift.
Improper use or failure to follow this instruction can cause property damage,
serious injury, or death.
• Never use for lifting humans or animals. Improper use or failure to follow this
instruction can cause property damage, serious injury, or death. The lift should only
be used for lifting boats & watercraft.
• Always avoid being under, and maintain adequate clearance from, the lift. Failure to
follow this instruction can cause serious injury or death.
• Always use AGM batteries and follow battery manufacturer’s warnings and instructions.
Improper use, or use of other batteries, have the potential to produce flammable hydrogen
gas which can result in serious injury or death.
• Visually inspect all parts and assemblies for damage or defects prior to assembling lift.
• Install the lift on firm and level ground.
• Verify the lower frame of the lift is level before each use.
• Do not play on or near the lift.
• Do not service the unit with the watercraft on the lift.
• High pressure hydraulics can penetrate skin. Oil injected into the skin from
high pressure systems can cause severe injury. In the case of injury, seek
medical attention immediately.
WARNING
• Do not install the lift alone.
• The lift should only be used for lifting boats & watercraft.
• Passengers should stand clear of the lift when the lift is in operation.
CAUTION

TABLE OF CONTENTS
PAGE 3
PRODUCT INFORMATION
Model #:
Serial #:
Purchased From:
Date of Purchase:
Contact Name:
Phone #:
Notes:
SAFETY ............................................................................................... P 2
PARTS LIST AND DIAGRAMS ................................................................. P 4-5
ASSEMBLY INSTRUCTIONS .................................................................... P 6-18
OPERATIONAL INSTRUCTIONS ............................................................... P 19
REMOTE CONTROL FOB INFORMATION ................................................... P 20
TROUBLESHOOTING / FAQ .................................................................... P 21
MAINTENANCE ..................................................................................... P 22
WARRANTY ......................................................................................... P 24
IMPORTANT!
WARRANTY MUST BE
REGISTERED WITHIN 30 DAYS
OF INSTALLATION.
TO REGISTER, SCAN HERE OR VISIT
WWW.BASTABOATLIFTS.COM/SUPPORT

ITEM PART NO. DESCRIPTION QTY.
Inner Arm Weldment
Bunk Rail Assembly, Left
Bunk Rail Assembly, Right
Bunk Rail Weldment, Left (part of MM)
Bunk Rail Weldment, Right (part of NN)
Bunk Board Assembly (part of MM, NN)
LL
MM
NN
N/A
N/A
N/A
(4)
1
1
(1)
(1)
(2)
W102-0046
A427-0017
A427-0018
W114-0013
W114-0014
W410-0069
PART NO. DESCRIPTION QTY. ITEM
K200-0001 Leg AA
BB
CC
DD
EE
FF
GG
W117-0001
W105-0010
W111-0016
A431-0044
A431-0043
SEE PG. 10
Foot Pad
Side Rail
Base Crossmember
H-frame, Forward
H-Frame, Aft
Hydraulic Cylinder
4
4
2
2
1
1
1
HH
JJ
KK
W107-0001
K200-0072
M621-1002
Stop Block
Pivot Block
Base Pivot Bushing
2
2
8
Washer, flat 5/16 SS (part of MM, NN)
Washer, lock 5/16 SS (part of MM, NN)
Nut, 5/16-18 SS (part of MM, NN)
N/A
N/A
N/A
(6)
(6)
(6)
S313-0007
S322-0007
S342-0007
4
7
5
12
15
11
9
10
8
11
22
6
1
2
6
3
13
14
16
17
[4.5k37 only]
[4.5k53 only]
PAGE 4
PART NO. DESCRIPTION QTY. ITEM
S362-0008 Nut, 3/8-16 Nylock SS 1
2
3
4
5
6
7
S313-0008
S503-0013
S503-0012
S314-0032
S103-0516
S522-0801
Washer, Flat 3/8 SS
Clevis Pin, 3/4 x 3.5 SS
Base Pivot Pin SS
Washer, Flat 3/4 Nylon
Bolt, Hex Head 3/8-16 x 3.75 SS
Ring Cotter Pin .091 x 3/4 SS
18
32
2
4
2
18
10
8
9
Y356-0003
S532-1801 P Pin, SS
1
4
PART NO. DESCRIPTION QTY. ITEM
S503-0019 Bunk Pin, SS 10
11
12
13
14
15
16
S520-1706
F730-0021
S103-0338
S322-0006
S103-0705
S503-0011
Cotter Pin 3/16 x 2.0 SS
Plastic Cap for 2-1/2” OD SQ Tube
Bolt, Hex Head 1/4-20 x 1.75
Washer, Lock 1/4 SS
Bolt, Hex Head 1/2-13 x 1.0 SS
4
4
4
4, [8]
4, [8]
4
4
L129-0001
Extension Arm Pin
2
Anti-Seize Grease Packet
N/A Key Flob Floats
17 S313-0013 Washer, Flat 3/4 SS 8
PARTS LIST - BOAT LIFT

POWER PACKAGE
#H653-0018
R812-0011
PART NO.
R283-0002
R310-0001
R310-0002
Remote Control Master Unit
DESCRIPTION
Solar Controller
On/Off Switch
Up/Down Switch
1
QTY.
1
1
2
ITEM
A1
B1
C1
D1
A1
B1
C1
D1
E1
F1
R281-0004
C243-0003
Solar Panel Assembly
Enclosure
1
1
F1
E1
MM
LL
13&14
16
13&14
10
3
5
8
NN
13&14
16
13&14
10
KK
GG
KK
HH
HH
EE
FF
11
4
6
6&2
6&2
11
6
4
1&2
1&2
3
4
6
11
CC
JJ
11
6
4
7
1&2
1&2 6&2
6&2
CC
AA
AA
12
1&2
12
DD
BB
BB
9
15
6&2
9
6&2
15
1&2
12
9
1&2 1&2
12
9
15
1&2
1&2
6&2
6&2
15
AA
BB
BB
DD
AA
PAGE 5
Symbol Glossary for the following pages:
indicates an illustration for a procedure.
indicates a major part described in the parts list
on pages 4 and 5.
or indicate hardware items shown above and
described in the parts list on pages 4 and 5.
Tools needed for the job:
• Tape measure
• Level
• 9/16 ratchet
• 9/16 box-end wrench
• Large slip joint pliers
• Medium sized adjustable wrench
AA
a
1
c+d

NOTE: The 3 different holes
shown can be used for pin
‘9’ to allow fine height
adjustment during installation.
Pictured: Steps 1-3
QTY 4: 3/8 x 3.75” bolts (“6”)
QTY 4: 3/8 nylon insert lock nuts (“1”)
QTY 8: 3/8 flat washers (“2”)
QTY 4: leg P pins (“9”)
QTY 4: 1/2 x 1.0” bolts (“15”)
AA
BB 15
6+2
1Feet & Legs (4 Places)
Do not tighten bolt ‘15’
until step 16.
Do not tighten any
hardware until step 12.
1
2
1
1
1
3
DD
9
1+2
ASSEMBLY INSTRUCTIONS
Use a small amount of
‘moly’ lube on bolt
threads through the
assembly process.
PAGE 6

1+2
DD
6+2
1+2
6+2
DD
CC
2Forward Crossmember
3Aft Crossmember
QTY 4: 3/8 x 3.75” bolts (“6”)
QTY 8: 3/8 flat washers (“2”)
QTY 4: 3/8 nylon insert lock nuts (“1”)
QTY 4: 3/8 x 3.75” bolts (“6”)
QTY 8: 3/8 flat washers (“2”)
QTY 4: 3/8 nylon insert lock nuts (“1”)
3
Assemble lift on level
ground and adjust legs
so that lift base frame
is level during lift
assembly.
PAGE 7

4
Pictured: Steps 4-6
4
Stop Blocks
Use a small amount of
‘moly’ lube on bolt
threads through the
assembly process.
PAGE 8
6
4
5
6
4
KK
KK
6+2
1+2
1+2
6+2
QTY 2: 3/8 nylon insert lock nuts (“1”)
QTY 4: 3/8 flat washers (“2”)
QTY 2: 3/8 x4 bolts (“6”)
JJ
JJ
6
ASSEMBLY INSTRUCTIONS

H-frame Bushings (fwd & aft)
H-frame Bushings (fwd & aft)
Forward H-frame is
shown. Aft H-frame
installation is the same.
KK
KK
EE
64
11
Bushings are pre-
installed - remove cable
ties used for shipping.
QTY 8: plastic bushings (“KK”)
1+2
QTY 4: 3/8 nylon insert lock nuts (“1”)
QTY 4: 3/8 flat washers (“2”)
QTY 4: 3/8 x 3.75 bolts (“6”)
QTY 4: cotter pins (“11”)
QTY 4: base pivot pins (“4”)
5
6
PAGE 9

Install cylinders with lift
in ‘down’ position.
Cylinder
Pictured: Steps 7-9
Use a small amount of
‘moly’ lube on bolt
threads through the
assembly process.
7
9
7
89
8
5
7+3
5
5
QTY 2: 3/4 x 3.5” clevis pin (“3”)
QTY 2: 3/4 ring type cotter pin (“7”)
QTY 2: 3/4 nylon flat washers (“5”)
7+3
ASSEMBLY INSTRUCTIONS
7
PAGE 10

Inner Arms
QTY 4: extension pins (“16”)
QTY 4: 1/4 x 1.75” bolt (“13”)
QTY 4: 1/4 lock washer (“14”)
Pictured: Step 8
8
8
6
16
IMPORTANT
Install cylinder with hose
fittings facing down!
LL
13+14
* Model 4.5k 53 only
* Model 4.5k 53 only
ASSEMBLY INSTRUCTIONS
8
PAGE 11

Pictured: Step 9
Bunk Rail Assembly
QTY 4: bunk pivot pins (“10”)
9
10
10
MM
NN
Model 4.5k 37 only:
Remove black bunk
bushings and replace
with shorter white bush-
ings before proceeding
with this step.
The angles and
directions of
bunk rail
assemblies MUST
face the direc-
tions show.
ASSEMBLY INSTRUCTIONS
9
PAGE 12

Step 1: Slide the Hydraulic Hose Assembly through the
access hole in the side of the fiberglass enclosure and
attach the ends to their corresponding Quick Couplers.
Ensure each Quick Coupler is fully seated, tight and
with no gap at the connection joint.
Step 2: Remove shipping plug in hydraulic reservoir and
replace with breather plug before first use.
Step 3: Install Battery as shown. Connect the Red Battery
Cable to the positive terminal (+) and the Black
Battery Cable to the negative terminal (-).
Step 4: Before moving into the water, test the lift on dry
ground using the Up/Down Switch and the Key Fob
Transmitters. Inspect the system for leaks.
10
NEGATIVE BATTERY CABLE (BLACK)
BREATHER CAP
POSITIVE BATTERY CABLE
(RED)
HOSE ASSEMBLY
Complete Power Unit Package
IMPORTANT
ONLY ADD FLUID WITH LIFT IN
DOWN POSITION
Hydraulic fluid shown with lift in the
DOWN position
one
inch
1”
ON/OFF
SWITCH
UP/DOWN
SWITCH
PAGE 13
FEMALE
QUICK COUPLER
MALE
QUICK COUPLER
CONNECT POWER UNIT

Raise lift to install 1/4
x 1.75” bolts (“17”).
Bunk Rail Assembly
QTY 4: 1/4 x 1.75” bolts (“15”)
QTY 4: 1/4 lock washers (“16”)
15+16
15+16
15+16
15+16
Pictured: Step 11
MM
Use a small amount of
‘moly’ lube on bolt
threads through the
assembly process.
Placement may need
to be modified based
on watercraft draft and
weather conditions.
11
11
NN
ASSEMBLY INSTRUCTIONS
11
PAGE 14

Test lift on dry ground for leaks, remote control function and correct operation before moving into
water. Tighten all hardware.
Lower the lift completely, then raise it slightly. Disconnect the Hydraulic Hose Quick Couplers in the
Power Unit box to separate it from the lift.
Move the lift to nal destination. Use this diagram to help place the lift. Lift placement should be so
that the top of the aft end of the bunks are one foot above the high-water mark when the lift is in the
full up position, and one foot below the low water mark, when the lift is in the down position.
USE THIS DIAGRAM TO HELP PLACE THE 4.5k 37 LIFT
PLACEMENT INSTRUCTIONS
12
13
14
PAGE 15

USE THIS DIAGRAM TO HELP PLACE THE 4.5k 53 LIFT
PAGE 16

IMPORTANT: The leveling process must be completed to ensure stability of the lift frame
and Over-Center safety lock.
Level the lift following these instructions while referencing image below:
Step 1: Use a tape measure (reference image on right) to determine that the lower
frame is level.
Step 2: If the lower frame needs to be raised start with the lowest corner first then
work your way around the lift in a circle, corner to corner. Adjust the lift legs as needed.
Step 3: To make adjustments, first make sure the lift is properly supported.
Then, loosen the anti-sway bolts, remove the P-pin and raise or lower
the lift crossmember on the leg. Level the lift one corner at a time,
while making sure not to have more than 5” of difference in height
between the corners to prevent binding.
LEVEL
NOT LEVEL
MUST BE LEVEL
FORWARD AFT
FWD
CROSS-
MEMBER AFT
CROSS-
MEMBER
+ 4.5”
12”
Surface of Water
Leveling requires a second person to support the crossmember while making adjustments.
If the lift is too heavy for two people, a ratchet strap or winch system will be required to
raise/lower the frame corners.
Contact Basta at 866-GO-BASTA for additional help.
15
PAGE 17

16
17
18
Re-connect the Hydraulic Hose Quick Couplers inside the Power Unit box.
Fully raise lift and finish adjusting the legs so that the base frame is level side-to-side and
forward-to-aft. After the lift is assembled and installed, all fasteners should be checked for
proper tightness and reinspected periodically.
Load the boat onto the lift using the following
operational instructions:
1. Align the boat so it is centered between
the bunks side-to side.
2. Move the boat forward to position its center of
gravity near the bunks’ centers.
Perform the following adjustments to finalize
the lift installation:
1. Disembark and raise the boat.
If more than two inches of settling occurs, STOP,
carefully lower the lift to remove the boat and
re-level the lift. Continue repeating this
step until the lift can be raised into the full
Over-Center™ position without settling.
2. Remove the boat. Verify that the lift
frame is level. Re-level the framework if necessary.
3. Check all bolts for proper tightness.
OPTIONAL
The lift legs can be cut off above the leg sockets after installation for a cleaner
look. First, make sure that the lift has fully settled and has been re-leveled.
NOTE: If you plan to add a canopy, relocate the lift into deeper water, or load a
heavier vessel in the future, you must keep the existing leg length.
Shown: examples of fore and
aft placement of the boat
on the boat lift, which varies
based on engine location.
I/O & Outboard
Engine
V-Drive
Direct Drive
Center of Gravity
Center of Gravity
Engine
Center of Gravity
Engine
PAGE 18

PAGE 19
IMPORTANT:
• If you purchase a new vessel, make sure does not exceed the weight capacity limits of the lift.
Maximum weight capacity can be found on the cover of this manual and on the H frame of the lift.
• Always turn power unit OFF when not in use.
• Keep inside of power unit box dry.
• To prevent unauthorized use lock box using padlock through the latch hasp.
• Securing your mooring line to the dock may provide additional security should the lift be lowered
inadvertently.
• Leaving your bilge pump on the automatic setting may prevent the accumulation of rainwater in
your vessel and overloading of the lift.
• Service your lift according to recommended Maintenance (page 19).
• Only use Basta Boatlifts approved fluid in lift. Contact Basta Boatlifts or authorized dealer for
approved biodegradable hydraulic fluid.
• When not in use, store the lift in the upright position to prevent it from being an unknown hazard
underwater.
• Store with the power off.
Step 1: Power on. Using the manual switch on the control panel, switch the On/Off switch to the
“On” position.
Step 2: Lower the Lift. Using the Key Fob, unlock the Fob by pressing and releasing the lock button.
Next, press the down button to lower the lift.
Step 3: Carefully guide the watercraft off the lift. Repeat in reverse order upon return.
For more questions or troubleshooting, consult your Authorized Dealer, the FAQs page on
Bastaboatlifts.com or give us a call at 425-641-8911.
OPERATIONAL INSTRUCTIONS

PAGE 20
FOB POWER-UP
After turning on the ON/OFF switch in the dock box, the fob
receiver requires a 5 second delay before the fob is enabled.
FOB OPERATION
Depress the unlock button (lower right), this will allow normal
operation of the fob. The lockout is re-enabled after 60
seconds without a button press. Lift operation using the fob
is limited to 120 seconds of continuous operation. If a longer
cycle is needed it is necessary to release button and then
re-depress.
FOB PROGRAMMING
1. Turn off the ON/OFF switch.
2. Wait 20 seconds.
3. Turn power back on, and within 5 seconds of
power on, press both the UP and DOWN buttons
on the fob simultaneously for 1 second then
release.
4. Repeat steps 1-3 for additional Fobs. Up
to four fobs may be enrolled. If a fifth fob
is enrolled, the first enrolled fob will fall off the list.
BATTERY REPLACEMENT
Fob uses CR2032, 3 volt battery, commonly found online or at
drug / hardware stores. Part numbers vary by manufacturer.
LOW BATTERY LOCKOUT
The remote control contains a low voltage lockout which
is intended to protect the lift’s battery from over-discharge.
When the battery drops below the low battery threshold
during operation, further use of the fob is not allowed. The
manual UP/DOWN switches will allow the lift to operate
when sufficient battery power is present. The lift should
be checked and charged prior to further operation.
TROUBLESHOOTING
If fob worked previously, but
does not currently, replace fob
battery or verify fob battery
has greater than 3v. If fob does
not work after replacement
of fob battery, load test lift
battery ensuring voltage does not drop below 11v while
in use. If you have questions, contact your local dealer or
Basta Boatlifts.
UNDERWATER LIGHTS
The underwater lights are activated whenever the
lift is operated. The lights stay on for 2 minutes
after the lift is operated. The lights may be
manually turned on or off by depressing the lower
left button on the remote fob. When manually enabled the
lights will automatically turn off after
4 minutes. This prevents accidental battery discharge.
REMOTE CONTROL FOB INFORMATION
