Bauhn P61330 User manual

2.1 CHANNEL SOUNDBAR
WITH BUILT-IN SUBWOOFER
P61330
User Manual

Contents
3
Contents
About this user manual................................................................................... 5
Explanation of symbols ......................................................................................5
Proper use ....................................................................................................... 7
Safety information .......................................................................................... 8
Setting up the device safely ..............................................................................8
Power supply ..................................................................................................... 10
Handling batteries ............................................................................................ 10
Ambient temperature .......................................................................................12
Faults....................................................................................................................13
Package contents ...........................................................................................13
Device overview.............................................................................................14
Top........................................................................................................................14
Control buttons...................................................................................................14
Rear view.............................................................................................................15
Connections ........................................................................................................15
Remote control .................................................................................................. 16
Preparation for use ........................................................................................17
Inserting batteries into the remote control....................................................17
Setting up / mounting soundbar.................................................................... 18
Connecting external devices......................................................................... 20
Connecting external device via AUX................................................................21
Connecting an external device using the optical socket............................. 22
Connecting devices using HDMI ARC.............................................................. 23
Important information about HDMI CEC/HDMI ARC ...................................... 23
Connecting USB storage devices..................................................................... 24
Setting up the soundbar................................................................................25
Connecting the soundbar to mains power ...................................................25
Switching on the soundbar / switching to standby mode..........................25
Connecting an external device via Bluetooth®............................................ 26
Operation........................................................................................................27
Selecting the audio source .............................................................................. 27
Adjusting the volume ....................................................................................... 27
Muting the soundbar........................................................................................28

Contents
4
Setting the equaliser sound effects................................................................28
Setting the treble and bass .............................................................................28
Playback control in USB/Bluetooth® mode...................................................28
Maintenance.................................................................................................. 29
Cleaning......................................................................................................... 29
Storing the device when not in use.............................................................. 30
Troubleshooting............................................................................................ 30
Declaration of conformity ..............................................................................31
Trademark information .....................................................................................31
Disposal ..........................................................................................................32
Technical specifications..................................................................................33
Privacy statement ......................................................................................... 34
Service information....................................................................................... 35
Legal Notice ................................................................................................... 36
Warranty Details .............................................................................................37
Repair and Refurbished Goods or Parts Notice............................................ 38

About this user manual
5
About this user manual
Thank you for choosing our product. We hope you enjoy using it.
Read the safety instructions carefully before using the device for the first
time. Note the warnings on the device and in the user manual.
Always keep the user manual close to hand. If you sell the device or
give it away, please ensure that you also pass on this user manual. It is an essential
component of the product.
Explanation of symbols
If a block of text is marked with one of the warning symbols listed below, the hazard
described in that text must be avoided to prevent the potential consequences
described there from occurring.
DANGER!
This signal word indicates a hazard with a high level of risk which, if not avoided, will
result in death or serious injury.
WARNING!
This signal word indicates a hazard with a medium level of risk which, if not avoided,
could result in death or serious injury.
NOTICE!
This signal word warns of possible damage to property.
Additional information on using the appliance!
Read the user manual and observe its instructions.

About this user manual
6
Protection class II
Electrical appliances in protection class II are electrical appliances that
permanently have double and/or reinforced insulation and do not
have the option of connecting a protective earth.
Indoor use
Devices with this symbol are only suitable for use indoors.
Symbol for direct current
Symbol for alternating current
The Australian Regulatory Compliance Mark (RCM) is a single
compliance mark used by suppliers after establishing compliance with
all applicable regulations, including EMC, telecommunications, radio
communications, electromagnetic radiation (EMR) and electrical safety.
The HDMI logo and High-Definition Multimedia Interface are registered
trademarks of HDMI Licensing LLC.
• Check list/Provides information concerning an event that may occur
during use
− Instructions to follow
− Safety instructions to follow

Proper use
7
Proper use
The device is used to play back audio signals. The soundbar is
designed for connecting to televisions. Other devices such as
portable CD or MP3 players, computers/notebooks, smartphones
and stereo systems can also be connected.
The device is only intended for private use and not for industrial/
commercial use.
Please note that no liability will be accepted if the device is used
for an improper purpose:
− Do not modify the device without our explicit agreement and
do not use any accessories that have not been supplied or
approved by us.
− Only use replacement parts and accessories supplied or
approved by us.
− Observe all the information in this user manual, especially the
safety information. Any other use is deemed improper and may
cause personal injury or damage to property.

Safety information
8
Safety information
WARNING!
Risk of injury due to improper handling.
− This device is not intended to be used by people (including
children) with reduced physical, sensory or mental capacity or
with a lack of experience and/or knowledge unless they use
the device under the supervision of a person responsible for
their safety or if they have been given instructions about how
to use the device safely.
− Do not allow children to play with electrical devices without
adult supervision. Children cannot always properly identify
possible hazards.
Setting up the device safely
WARNING!
Risk of injury due to electric shock!
There is a risk of electric shock due to live wires.
− Select a suitable location to set up the device and make
sure that you do not damage concealed electrical wires or
installation cables when drilling.
− Do not place any containers filled with liquid, such as vases, on
or near the device and power cord. The container may tip over
and the liquid may compromise electrical safety.
− Protect the device and all connected devices from moisture,
drips or splashes of water. Avoid dust, heat and direct sunlight
to prevent malfunctions.
− Do not place any sources of open flame, such as burning
candles, on or near the device.

Safety information
9
− Do not use the device in areas where there is a risk of explosion.
This includes e.g. fuel pumps, fuel storage areas or areas in
which corrosive agents are processed. This device should
also not be used in areas where the air is contaminated with
particles (e.g. flour or sawdust).
− Do not expose the device to extreme conditions; it is only
intended for use in indoor spaces.
Avoid:
• high humidity or wet conditions
• extremely high or low temperatures
• direct sunlight
• open flame
− To prevent overheating, do not cover the device with objects
(newspapers, blankets, etc.).
− Do not place any objects on the cords because this may
damage them.
− Place and operate all components on a stable, level and
vibration-free surface to prevent the device from falling over.
− All multimedia devices that are connected to the device must
meet the requirements of the EU Low Voltage Directive.
− Make sure there is enough space on the back of the devices for
the power cords and cable connections.
− Do not place anything on/near the soundbar that might
cover the cables or block the speaker openings. It may cause
malfunction.

Safety information
10
Power supply
WARNING!
Risk of injury due to electric shock!
There is a risk of electric shock due to live wires.
− The power points must be located near the device and be
easily accessible. Lay the cord in such a way that no-one can
step on it or trip over it.
− To disconnect your device from the power supply, switch off the
power point and unplug the device. Always hold on to the plug
itself when unplugging the device. To prevent damage, never
pull on the cord itself.
− Only operate the device from an earthed power point with a
voltage of 100–240V ~ 50/60Hz. If you are not sure about the
electricity supply at the location where you are setting up the
device, check with your local electricity supply company.
− Do not use the plug of the device if the housing or the cord to
the device are damaged.
− Do not under any circumstances open the housing of the
device. Any contact with live parts or modifications to the
electrical and mechanical assembly are dangerous and may
lead to device malfunctions.
− Disconnect the device from the mains power if there is a storm
or if you do not want to use it for an extended period.
Handling batteries
The remote control is battery-operated. Please observe the
following advice concerning the batteries:
− Keep new and used batteries away from children.
− Do not allow children to change batteries without supervision.
− Do not swallow batteries; there is the risk of chemical burns.

Safety information
11
WARNING!
Risk of chemical burns!
The remote control contains two AAA batteries. If these batteries
are swallowed, they can cause severe internal chemical burns
within 2 hours that may lead to death.
− If you suspect your child has swallowed a battery immediately
call the 24-hour Poisons Information Centre on 13 11 26 for fast,
expert advice.
− If the battery has been swallowed, medical attention should be
sought immediately.
− Remove flat batteries from the device immediately. Clean the
contacts before inserting new batteries. Avoid contact with
skin, eyes and mucous membranes. Rinse areas affected
by battery acid immediately with plenty of clear water and
immediately seek medical advice. There is a risk of chemical
burns due to battery acid!
− Dispose of used batteries immediately and safely in accordance
with local regulations.
− Do not use the remote control if the battery compartment no
longer closes securely and keep it away from children.
WARNING!
Explosion hazard!
Not replacing the batteries properly can create the risk of
explosion.
− There is a risk of explosion if batteries are not changed properly.
Only insert new batteries of the same type. Never use old and
new batteries together.
− Never attempt to recharge the batteries. There is a risk of
explosion!

Safety information
12
− Never expose the batteries to excessive heat (such as sunlight,
fire or similar).
− Store batteries in a cool and dry place. Extreme direct heat can
damage the batteries. Do not expose the device to extreme
sources of heat.
− Do not short-circuit batteries.
− Do not throw batteries into a fire.
− Do not disassemble or deform batteries.
− A lithium battery with a damaged case should not come into
contact with water.
− Ensure the correct polarity (+/-) when inserting the batteries.
− Remove flat batteries from the device and dispose of them in
accordance with local regulations.
− If you are not going to use the device for an extended period,
remove the batteries.
− Do not weld or solder directly to batteries.
− Do not encapsulate and / or modify batteries.
Ambient temperature
− The device can be operated in an ambient temperature of
between 0°C and +40°C.
− When the device is switched off, it can be stored at
temperatures of between -0°C and +45°C.
− Only use the appliance in dry indoor spaces.
DANGER!
Risk of electric shock!
In the event of significant fluctuations in temperature or humidity,
condensation may cause moisture to build up within the device,
which can cause an electrical short circuit.
− After transporting the device, wait until it has reached the
ambient temperature before operating it.

Package contents
13
Faults
− If the device or the power cord is damaged, turn off the power
point immediately and pull out the plug.
− Do not use the device or its accessories if they show signs
of damage or if you see smoke or hear abnormal noises
during operation. If this happens, switch off the power point
immediately and pull out the plug.
− Never try to open or repair the device yourself.
− If there are technical problems, please contact our Service
Centre.
Package contents
DANGER!
Risk of choking and suffocation!
There is a risk of choking and suffocation through swallowing or
inhaling small parts or plastic wrap.
− Keep packaging away from children.
− Do not allow children to play with the packaging material.
− Packaging material is not a toy!
− Take the product out of the packaging and dispose of all the packaging material.
− Please check your purchase to ensure that all items are included. If anything is
missing, please contact our Service Centre within 14 days of purchase.
− The device must be checked for damage before each use.
− If damage is present, please contact our Service Centre.
The following items are supplied with your product:
• Soundbar
• Mains power cord
• Remote control incl. 2 × AAA LR03 batteries
• Audio cable (3.5 mm jack)
• Wall mount kit
• User manual and warranty documents

Device overview
14
Device overview
Top
A1
2
1LED indicator light
• Red: In STANDBY mode
• Green: In AUX mode
• Flashing green: In USB mode
• Blue: In Bluetooth mode
• Orange: In Optical mode
• White: In HDMI ARC mode
2Rubber feet
Control buttons
B
3 4 5 6
3Switch on the soundbar / switch to standby mode
4Decrease volume
5Increase volume
6Select the audio source (BLUETOOTH / AUX / USB / HDMI ARC /
OPTICAL)

Device overview
15
Rear view
C
7
7Attachment points for mounting on wall
Connections
D
8 9 10 11 12
8AC~ Connection socket for power cord (100–240V 50/60Hz)
9AUX Socket for TV and other audio output devices (3.5mm jack)
10 USB USB port (5V 500mA) for playing MP3 files
11 HDMI ARC Output socket for ARC-capable TV and other audio output
devices
12 OPTICAL Optical input socket for TV and other audio output devices

Device overview
16
Remote control
E
14
15
16
17
13
19
20
18
24
23
21
22
25
26
27
28
13 Switch on the
soundbar / switch to
standby mode
14 PAIR In Bluetooth mode:
activate pairing mode
/ disconnect already
paired Bluetooth
device
15 USB Select USB operating
mode
16 OPTICAL Select Optical
operating mode
17 TREBLE +/- Increase / decrease
treble
18 Mute / unmute
soundbar
19 Pause playback
20 Start / resume
playback
21 Play next track
22 Play previous track
23 / Increase / reduce volume
24 BASS +/- Increase / decrease bass
25
MUSIC /
NEWS /
MOVIE
Set equaliser sound effect (music / news / movie)

Preparation for use
17
26 HDMI ARC Select HDMI ARC operating mode
27 AUX Select AUX operating mode
28 Select Bluetooth operating mode
Preparation for use
Inserting batteries into the remote control
Before first use or if the device no longer responds to the remote control, or only
responds poorly, the batteries must be inserted or changed.
To do so, proceed as shown in Fig. 1 and as described below:
− Depress the battery compartment lid slightly and then push it downwards. Pull
the battery compartment lid upwards to remove it.
− Remove old batteries if present and dispose of them as required by law.
− Insert two new AAA LR03 batteries. Pay attention to the correct polarity when
inserting the batteries.
− Replace the lid on the battery compartment and push it upwards until you hear it
click into place.
1
AB C

Preparation for use
18
Setting up / mounting soundbar
You have the option of using
the soundbar either on a
horizontal surface (Fig. 2
Version A) or mounted on a
wall using the supplied wall
brackets (Fig. 2 version B).
2
A B
Version A – using soundbar on a horizontal surface
NOTICE!
Risk of damage!
There is a risk that the devices may be damaged if not set up
correctly.
− Place and operate all components on a stable, level and
vibration-free surface to prevent devices from falling.
− Some types of aggressive furniture varnish can attack the
rubber feet of the device. If necessary, place the device on an
anti-slip underlay.
− Position the soundbar on a stable and level surface near a readily accessible
power point.

Preparation for use
19
Version B – fixing soundbar onto a wall
WARNING!
Risk of injury due to electric shock!
There is a risk of electric shock due to live wires.
− Select a suitable location to set up the device and make
sure that you do not damage concealed electrical wires or
installation cables when drilling.
NOTICE!
Risk of damage!
Danger of damage to the device and/or property due to improper
assembly.
− Before mounting the soundbar on the wall, check if the wall
has the necessary load-bearing capacity. MEDIONAG does not
assume any liability for damage that occurs due to incorrect or
improper mounting.
− Use only the supplied wall brackets for wall mounting.
− Do not overtighten the screws.
Proceed as described below and as shown in Fig. 3 to mount the soundbar onto an
internal wall:
− Drill 2 parallel holes into the wall.
Use a drill bit suitable for the material you are drilling into (diameter 5–6 mm,
depending on the wall type). The distance between the holes should be 796 mm
(A).
− If necessary, insert a wall plug into the holes.
− Screw the two supplied wall brackets to the wall.
Make sure that the slots for hanging the soundbar are pointing up (B).
− Unscrew and remove the screws at the attachment points 7on the back of the
soundbar.
− Replace the removed screws with the supplied wall attachment screws and
screw them into the attachment points (C).

Connecting external devices
20
− Hang the soundbar with the wall attachment screws onto the mounting slots on
the wall brackets (D).
3
796 mm
A
B
CD
Connecting external devices
You can connect a range of different audio output devices to the soundbar, such as a
television, an MP3 or CD player, a receiver, a computer, a USB stick, etc.
− Switch all devices off before connecting them to one another.
Also refer to the user manual for the device you want to connect to the
soundbar.

Connecting external devices
21
Connecting external device via AUX
4
A B
Audio cable with 2 × 3.5mm diameter jacks
To connect an audio output device to the soundbar using the device’s headphone
output socket (see Fig. 4,A), you need an audio cable with 2 × 3.5mm diameter jacks
(included).
− Set the volume on the audio output device to a moderate level, and then turn it
off.
− Insert the jack into the AUX socket 9on the soundbar.
− Insert the other jack into the headphone output socket of the audio output
device.
Audio cable with RCA connectors
To connect an audio output device to the soundbar using the device’s RCA outputs
(see Fig. 4,B), you need an audio cable with RCA plugs, 1 × 3.5mm diameter jack -> 2
× RCA plugs (not included).
− Set the volume on the audio output device to a moderate level, and then turn it
off.
− Insert the jack into the AUX socket 9on the soundbar.
− Insert the red and the white plugs on the other end of the cable into the
corresponding colour-marked output sockets of the audio output device.
Devices such as stereo receivers or televisions usually have a red and a
white audio out jack. These are generally labelled OUT, AUDIO OUT, LINE
OUT or similar. Please also refer to the user manual of your audio output
device.
