Baumatic BO988BL User manual

1
BO988BL 60 cm Built in electric double
oven
BO992SS 60 cm Built in electric double
oven
BO996SS 60 cm Built in electric double
oven

User Manual for your Baumatic
BO988BL 60cm Built in double electric oven
BO992SS 60 cm Built in double electric oven
BO996SS 60 cm Built in double electric
multifunction oven
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 09/07/10
2

3
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 – 12
Product and aperture dimensions (all models) 8
BO988BL/BO992SS 9
BO996SS 10
Coolingfans 11
Controlpanel 11
Ovenprogrammer/timer 12
Initial set up of your oven 12 – 13
Setting the time of day 12
Before first use 13
Timerfunctions 14 – 18
The minute minder function (main oven and top oven) 14
The semi-automatic cooking function (main oven only) 15
The end of cooking function (main oven only) 16
The automatic cooking function (main oven only) 17 – 18
Cancelling the semi-automatic and automatic function 18
Cancelling the minute minder function 18
Adjusting the volume of the audible signal 18 - 19
Changingthetimeofday 19
Using your oven 19-23
Selecting an oven function 19 – 20
Main oven functions (all models) 19
Additional main oven functions (BO996SS) 20
Top oven functions (all models) 20
Thermostat control knob (main and top oven) 20
Oven operating light (main and top oven) 21
Cooking guidelines 21 - 22
Warnings 22-23
Cleaning and maintenance 23 – 27
Removing the side racks 24
Replacing the oven bulb (main oven) 25
Replacing the oven bulb (secondary oven) 25 - 26
Removing the oven door for cleaning 26 - 27
Installation 27 - 32
Electrical connection 27 – 28
Connecting the mains supply cable 28 – 29
Replacing the mains supply cable 29
Positioning the appliance 30
Ventilation requirements 31
Installing the oven into the housing unit 31
My appliance isn’t working correctly 32 - 33
Contact details 34

Environmental note
4
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Information
oThis appliance is designed for domestic household use and can
be built into a standard kitchen cabinet or housing unit.
oIMPORTANT: The adjacent furniture or housing and all
materials used in the installation must be able to withstand a
minimum temperature of 85°C above the ambient temperature
of the room it is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic Ltd.
will invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
oRepairs may only be carried out by Baumatic service
engineers or their authorised service agent.
Warning and safety instructions
oThis appliance complies with all current European safety
legislation. Baumatic do wish to emphasise that this compliance
does not remove the fact that the appliance surfaces will
become hot during use and retain heat after operation.
5

6
Child Safety
oBaumatic strongly recommend that babies and young children
are prevented from being near to the appliance and not allowed
to touch the appliance at any time.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
General Safety
oDo not place heavy objects on the oven door or lean on the
oven door when it is open, as this can cause damage to the oven
door hinges.
oDo not leave heated oil or fat unattended, as this is a fire risk.
oDo not place pans or baking trays directly on the base of the
oven cavity, or line it with aluminium foil.
oDo not allow electrical fittings or cables to come into contact
with areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in or to
dry clothing.
oDo not install the appliance next to curtains or soft furnishings.
oDo not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance
or result in injury to the person lifting the appliance.
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.

Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
oBaumatic Ltd. declines any responsibility for injury or
damage, to person or property, as a result of improper
use or installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
oPlease consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
Declaration of conformity.
oIn the parts destined to come into contact with foodstuffs, this
appliance is in accordance with the requirements of the EC
directive 89/109 transposed in the Italian Legislative Decree No.
108 of 25/01/92.
oCE: Appliance conforming to the European directives
89/336/EEC, 93/68/EEC, 73/23/EEC and subsequent revisions
and “RoHS” directive 2002/95/CE.*
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.
*The RoHS directive stands for “the restriction of the use of
certain hazardous substances in electrical and electronic
equipment”. This directive bans the placing on the EU market of
new electrical and electronic equipment containing more than
the agreed levels of lead, cadmium, mercury, hexavalent
chromium, polybrominated biphenyl (PBB) and polybrominated
diphenyl ether (PBDE) flame retardants.
7

Specifications
Product and aperture dimensions (all models)
Product Dimensions
Height: 885 mm
Width: 596 mm
Depth: 547 mm
Aperture Dimensions
Height: 800 - 882 mm
Width: 562 - 565 mm
Depth: 560 mm (min)
8

9
BO988BL/BO992SS
Product specifications
oEnergy efficiency class: A/A
oLED full programmer (main oven only)
o2 x cooling fans
oTriple-glazed removable doors
oTop oven: static oven with grill
oGross oven capacity: 36 litres
oNet oven capacity: 30 litres
o4 functions
oMain oven: fan oven with grill
oGross oven capacity: 60 litres
oNet oven capacity: 54 litres
o4 functions
Standard accessories
o2 x Enamelled baking trays with handle
o2 x Safety shelves
o2 x Trivets
oRemovable side racks
Optional extras
oBPS2 Pizza stone
oSCL.1KIT Stay clean liners (main oven only)
Electrical details
Rated Voltage: 220 - 240 V~ 50/60 Hz
Supply Connection: 20 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 4.41 kW
Mains Supply Lead: 3 x 2.5 mm²
Oven Light Bulb: 25 W/300°C screw type pigmy

10
BO996SS
Product specifications
oEnergy efficiency class: A/A
oLED full programmer (main oven only)
o2 x cooling fans
oTriple-glazed removable doors
oTop oven: static oven with grill
oGross oven capacity: 36 litres
oNet oven capacity: 30 litres
o4 functions
oMain oven: multifunction oven
oGross oven capacity: 60 litres
oNet oven capacity: 54 litres
o9 functions
Standard accessories
o2 x Enamelled baking trays with handle
o2 x Safety shelves
o2 x Trivets
oRemovable side racks
oStayclean liners
Optional extras
oBPS2 Pizza stone
Electrical details
Rated Voltage: 220 - 240 V~ 50/60 Hz
Supply Connection: 30 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 4.92 kW
Mains Supply Lead: 3 x 2.5 mm²
Oven Light Bulb: 25 W/300°C screw type pigmy
