AMQ ILINE Series User manual

ILINE installation guide

ILINE INSTALLATION GUIDE | 2 amqsolutions.com
CONTENTS
ILINE 180° (2-WAY) ASSEMBLY ............... 3
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Post, Beam Plate & Feet Assembly ...........5
Beam Assembly (3-Circuit) ............... 6-7
Beam Assembly (4-Circuit) ............... 8-9
Post, Beam Plate & Feet Assembly (cont.) . 10-14
ILINE 120° (3-WAY) ASSEMBLY .............. 15
Components . . . . . . . . . . . . . . . . . . . . . . . . 16-17
Post, Beam Plate & Feet Assembly ..........18
Beam Assembly (3-Circuit) ............. 19-20
Beam Assembly (4-Circuit) ............. 21-22
Footer & Base Plate Assembly .......... 23-24
Post & Beam Assembly ...................25
Entering Electric Base Feed................26
Cover and Trim Assembly .................27
Installing Caps & Covers — Post Sleeve......28
Extending the Configuration................29
ILINE 90°/180° (4-WAY) ASSEMBLY ........... 30
Components . . . . . . . . . . . . . . . . . . . . . . . . 31-32
Footer & Base Plate Assembly .......... 33-34
Beam Assembly (3-Circuit) ............. 35-36
Beam Assembly (4-Circuit) ............. 37-38
Post, Beam Plate & Feet Assembly ....... 39-40
Installing Jumpers .......................41
Installing Caps & Covers ..................42
Installing Caps & Covers — Post Sleve.......43
Installing Screens........................44
Final Adjustments........................45
Power Pole Retrofit .......................46

ILINE 180° (2-WAY)

ILINE INSTALLATION GUIDE | 4 amqsolutions.com
ILINE 180° (2-WAY)
2-Way Post
COMPONENTS
Vertical Post
Top Cap
Post Side Cover
Nuts
180° Post is for inline/2-way applications only
Base Plate
Feet Assembly
Horizontal Beam
Beam
Face Plate Cover
Sliding Clip Receptacle
Cover
Data Face Plate Data Adaptor
Junction Bracket
(3 circuit)
Junction Bracket
(4 circuit)
Bottom Beam Plate

ILINE INSTALLATION GUIDE | 5 amqsolutions.com
ILINE 180° (2-WAY)PHASE 1 | Post, Beam Plate & Feet Assembly
Step 1 Step 2

ILINE INSTALLATION GUIDE | 6 amqsolutions.com
ILINE 180° (2-WAY)PHASE 2 | Beam Assembly (3-Circuit)
Step 1
Place beam upside down on the floor to reveal the
beam canal.
Step 2
Insert the sliding clip into the beam from the top
and slide it to the sides. (Make sure the tab below
the clip goes into the slot on the beam.)
5
6
4
3
21

ILINE INSTALLATION GUIDE | 7 amqsolutions.com
ILINE 180° (2-WAY)
Beam Cut-Out Side
PHASE 2 | Beam Assembly (3-Circuit)
Step 3
Mount 2 receptacle on one side of the junction block. Insert the junction block slighfly tilted like in the
diagram with the junction block without the receptacles facing the beam cut-out.
Step 4
Clip on the receptacles to the junction block
through the beam cut-out.
Step 6
Place the face plate cover over the beam cut-
out. Position it like in the diagram.
Step 5
Take 2 junction bracket (3-circuit) and position
them as shown in the diagram below. Make sure
the base of the bracket is touching the beam. Now
take the 4 self-tapping screws which are supplied
with the bracket and screw them in.
Step 7
Slide-in the sliding clip till the tab locks into the
face plate cover.
wide
narrow

ILINE INSTALLATION GUIDE | 8 amqsolutions.com
ILINE 180° (2-WAY)PHASE 2 | Beam Assembly (4-Circuit)
Step 1
Place beam upside down on the floor to reveal the
beam canal.
Step 2
Insert the sliding clip into the beam from the top
and slide it to the sides. (Make sure the tab below
the clip goes into the slot on the beam.)
6
5
4
3
2
1

ILINE INSTALLATION GUIDE | 9 amqsolutions.com
ILINE 180° (2-WAY)
Step 3
Mount 2 receptacle on one side of the junction block. Insert the junction block slighfly tilted like in the
diagram with the junction block without the receptacles facing the beam cut-out.
Step 4
Clip on the receptacles to the junction block
through the beam cut-out.
Step 6
Place the face plate cover over the beam cut-
out. Position it like in the diagram.
Step 5
Take 3 junction block (4-circuit) and position it as
shown in the diagram. Push it down until it can go
no further.
Step 7
Slide-in the sliding clip till the tab locks into the
face plate.
PHASE 2 | Beam Assembly (4-Circuit)
Beam Cut-Out Side
wide
narrow

ILINE INSTALLATION GUIDE | 10 amqsolutions.com
ILINE 180° (2-WAY)PHASE 1 | Post, Beam Plate & Feet Assembly (cont.)
Step 1
Once complete, lay each beam assembly between
each foot assembly.
NOTE:
Make sure the Outer-to-Inner beams are mounted
to the ends while the Inner-to-Inner beams go in
between them.
Step 2
Place (do not fasten) the vertical posts on each of
the footer assemblies.
Step 3
Slide the beam assemblies onto each of the
vertical posts and fasten each side of the beam
using 2 screws.
* Use phillip head screw to mount
beams on vertical posts.
NOTE:
Inner-to-Inner beams are slightly
longer than Outer-to-Inner beams.
NOTE:
L-shaped configurations must use
Inner-to-Inner beam.
4
Oute -to-Inner Beamr Outer-to-Inner Beam
Inne -to-Inner Beamr
4
4
4
2
1

ILINE INSTALLATION GUIDE | 11 amqsolutions.com
ILINE 180° (2-WAY)
Step 4
Take the exposed end of the power entry and
feed through the desired end of the beam and
into the adjacent post-opening.
Continue to feed the power entry until the
exposed end is out through one of the base
plate’s openings.
Step 5
Secure the post to the footer assembly using a 7/16” spanner.
PHASE 1 | Post, Beam Plate & Feet Assembly (cont.)

ILINE INSTALLATION GUIDE | 12 amqsolutions.com
ILINE 180° (2-WAY)PHASE 2 | Post, Beam Plate & Feet Assembly (cont.)
Step 1
Connect power entry plug to the junction block.
Step 2
Feed the jumper through the beam canal and
into the vertical post opening into the next beam
assembly.
Step 3
Connect the jumper to each junction block.
Step 4
Repeat Steps 1-3 until the last jumper is connected
the last junction block.
The remaining installation of
electrical must be installed by
a professional electrician.
STOP
3
2
2
1

ILINE INSTALLATION GUIDE | 13 amqsolutions.com
ILINE 180° (2-WAY)PHASE 3 | Post, Beam Plate & Feet Assembly (cont.)
Step 1
Insert side covers into all exposed openings of
each vertical posts.
Step 3
Take two data adapters/face plates and snap
them onto each end of the underside of the beam
assembly. Snap on data face plates.
Step 2
Place top caps on all vertical posts.
Step 4
Insert the bottom beam plates between each data
adapter on the underside of the beam assembly.
Step 5
Repeat Steps 1-4 for all beam assemblies.

ILINE INSTALLATION GUIDE | 14 amqsolutions.com
ILINE 180° (2-WAY)PHASE 4 | Post, Beam Plate & Feet Assembly (cont.)
Step 1
Check the horizontal alignment of the beams
Step 2
If not aligned, please rotate the foot to adjust each post’s elevation until leveled.
NOTE:
Use a leveling guide for accuracy.
Completed ILINE 180° (2-Way Post)

ILINE 120° (3-WAY)

ILINE INSTALLATION GUIDE | 16 amqsolutions.com
ILINE 120° (3-WAY)
3-Way Post
COMPONENTS
4-Way Post
Hex Nuts
Hex Nuts
Glide,OEM
Base Place Kit
Foot SRC Foot DRE Foot DRCVertical Post
Vertical Post
Top Cap
Top Cap
Post Side Cover
Post Side Cover
Base Plate
Foot SRE
Post Sleeve

ILINE INSTALLATION GUIDE | 17 amqsolutions.com
ILINE 120° (3-WAY)
Beam
COMPONENTS
Horizontal Beam
Face Plate Cover Sliding Clip
Bottom Beam Plate
Junction Bracket
(4 circuit)
Receptacle Cover
Data Face Plate Data Adaptor Junction Bracket
(3 circuit)

ILINE INSTALLATION GUIDE | 18 amqsolutions.com
ILINE 120° (3-WAY)PHASE 1 | Post, Beam Plate & Feet Assembly
Step 1 Step 2

ILINE INSTALLATION GUIDE | 19 amqsolutions.com
ILINE 120° (3-WAY)PHASE 2 | Beam Assembly (3-Circuit)
Step 1
Place beam upside down on the floor to reveal the
beam canal.
Step 2
Insert the sliding clip into the beam from the top
and slide it to the sides. (Make sure the tab below
the clip goes into the slot on the beam.)
6
5
4
3
21

ILINE INSTALLATION GUIDE | 20 amqsolutions.com
ILINE 120° (3-WAY)
Beam Cut-Out Side
PHASE 2 | Beam Assembly (3-Circuit)
Step 3
Mount 2 receptacle on one side of the junction block. Insert the junction block slighfly tilted like in the
diagram with the junction block without the receptacles facing the beam cut-out.
Step 4
Clip on the receptacles to the junction block
through the beam cut-out.
Step 6
Place the face plate cover over the beam cut-
out. Position it like in the diagram.
Step 5
Take 2 junction bracket (3-circuit) and position
them as shown in the diagram below. Make sure
the base of the bracket is touching the beam. Now
take the 4 self-tapping screws which are supplied
with the bracket and screw them in.
Step 7
Slide-in the sliding clip till the tab locks into the
face plate cover.
wide
narrow
