CODA™3521/3522
OFFICE CHAIR
DESIGNED BY CLAUDIO BELLINI
LET’S GET STARTED.
INSTRUCTION MANUAL

BDIUSA.COM | 3NEED ASSISTANCE? [e-mail]
Congratulations on the purchase of your Coda Oce Chair 3521/3522 from BDI. Your
oce chair has been designed to provide a lifetime of enjoyment. This manual will
provide you with assembly instructions and other helpful information to ensure you get
the most out of your product. Please save it for future reference.
Your Coda Oce Chair has been engineered for simple assembly. Please follow these
directions carefully to prevent any damage.
Should you need further assistance, contact BDI at customerservic[email protected]om.
ENJOY!

4 | BDIUSA.COM CODA 3521/3522
Hex Screw w/ Washer (H1) QTY: 3
Backrest Assembly (C1) QTY: 1
Hex Screw x 2 1/4" (H2) QTY: 6
Seat Assembly (C2) QTY: 1
Pan Head Screw x 1/2" (H3) QTY: 2
4mm Hex Wrench (T2) QTY: 1
HARDWARE AND COMPONENTSHARDWARE AND COMPONENTS
Unpack and identify the parts listed below. The assembly workspace should be a non-marring
surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at
customerservic[email protected]om.
Do not use power tools for the assembly of this product.
For all other concerns, please contact your BDI retailer.
5mm Hex Wrench (T1) QTY: 1

BDIUSA.COM | 5NEED ASSISTANCE? [e-mail]
Armrest (Left & Right) (C3) QTY: 1 of each Lift Column (C4) QTY: 1
Wheel (C6) QTY: 5Base (C5) QTY: 1
Headrest (C7) QTY: 1
HARDWARE AND COMPONENTS

6 | BDIUSA.COM CODA 3521/3522
Using the box as a workbench, position the
Seat Assembly (C2) as shown. Lift and pull the
Backrest Assembly (C1) toward the Seat
Assembly (C2) so the mounting holes align.
Fasten using 3 Screws with Washers (H1).
Tighten with 5mm Hex Wrench (T1).
STEP 1. CONNECT SEAT MECHANISMASSEMBLY
C2
C2
C2
C1
C1
C1
H1
H1
H1
HEX WRENCH – T1 QTY
1
SCREW – H1 QTY
3

BDIUSA.COM | 7NEED ASSISTANCE? [e-mail]
ASSEMBLY
STEP 2. ATTACH ARMREST
Ensuring the R and L labels on the Left and
Right Armrests (C3) match the R and L labels
on the Seat Assembly (C2), attach the armrests
to the seat using 6 Screws (H2) and tighten with
5mm Hex Wrench (T1).
H2
H2
HEX WRENCH – T1 QTY
1
SCREW – H2 QTY
6
C3
C3

8 | BDIUSA.COM CODA 3521/3522
Position the Lift Column’s (C4) narrow end into the hole on
the bottom of the Seat Assembly (C2). Press into place.
STEP 3. INSTALL LIFT COLUMNASSEMBLY
ASSEMBLY STEP 4. INSTALL SWIVEL WHEELS
Position the Base (C5) upside down on the carpeted floor. Press the Swivel Wheels (C6) firmly
into the holes until they lock.
C4
C2
C6
C6
C6
C6
C6
C5

BDIUSA.COM | 9NEED ASSISTANCE? [e-mail]
ASSEMBLYSTEP 5. CONNECT THE BASE
Connect the Base (C5) to the chair either right side up (with base on the floor as shown) or
upside down on top of the box. Insert the Column (C4) into the hole and press to fit.
C5
C4

10 | BDIUSA.COM CODA 3521/3522
Attach the Headrest (C7) to the back of the chair
by inserting 2 Pan Head Screws x 1/2” (H3) from
the bottom. This is easiest to do if the Headrest is
in its highest position. Tighten with 4mm Hex
Wrench (T2).
STEP 6. CONNECT THE BASEASSEMBLY
HEX WRENCH – T2 QTY
1
SCREW – H3 QTY
2
C7
H3
H3
H3
C7

BDIUSA.COM | 11NEED ASSISTANCE? [e-mail]
FUNCTION
ADJUSTING HEADREST
To position the headrest, raise it completely to
release it, then move it to its lowest position. As
you slowly move it up, it will ratchet through
various stopping heights. Select the best height
for your comfort. To reposition, completely raise
and lower the headrest to reset it and start the
process again.
ADJUSTING SEAT DEPTH
To adjust the seat depth, lift
the lever under the left side
of the seat. Slide seat forward
or back and release lever to
lock it into position. Allow
2"-3"of space between the
back of your knees and the
edge of the seat.
ADJUSTING ARMRESTS
Lift the button under the arm to
adjust the height. Further, refine
your settings by grasping the top
of the arms and sliding in any
direction. For optimal ergonomic
positioning, elbows should stay
close to your sides and your
wrists should be straight.
SYNCHRO TILT
Rotate the left control knob to
lock and unlock the chair
recline. Lean back to the
desired position and turn the
same knob to lock the back into
one of four recline positions.
ADJUSTING SEAT HEIGHT
Height is adjusted using the
lever on the right-hand
control bar. Pull up on the
lever while lifting or lowering
your body weight in the chair;
the seat will adjust on its
pneumatic cylinder to reach
your desired height.
TILT TENSION CONTROL
Adjust the force needed to create a softer
or firmer recline motion. Pull out the lever
on the right-hand control bar and rotate it
several times. Turn clockwise for more
tension, counterclockwise for less tension.

These distinctive product configurations are protected by US and international patents, trade
dress, and/or copyright laws. Coda & BDI are trademarks of Becker Designed, Inc. All rights
reserved. ©2022, BDI | V.11.16.2022
Made in China.
WARRANTY
BDI warrants to the original purchaser that this product shall be free of defects in assembly, material,
or workmanship for five (5) years from the original date of retail purchase. In the event of a proven
defect in this product’s assembly, material, or workmanship within five (5) years from the original
date of purchase, BDI will replace any such defective part(s). This warranty coverage is based on an
8-hour shift by any user weighing up to 300 lbs. Claims under this limited warranty or any implied
warranty shall be limited to replacing 100% of the chair at BDI’s sole option and discretion.
This warranty does not apply to normal wear or damage from misuse, abuse, improper storage or
handling, installation, accident, repair or alteration, or other circumstances not directly attributable
to manufacturing or material defects.
