BDI Format 6307 User manual

1
C - 5/32" x 12mm
Phillips Screw
x 20
E - Center Caster x 1
I - Letter File Bar x 2
D - Brake Caster x 4
B - Cabinet x 1
F - M4 x 37mm
Phillips Screw
x 2
G - M4 x 25mm
Phillips Screw
x 2
H - Pull x 2
FORMAT
6307
Format is engineered for easy assembly. Carefully follow this
procedure to prevent any damage.
Do not use power tools for assembly of this product.
Placement and Maintenance
Format™ Office furniture is designed for indoor use on level floors.
Clean steel parts and wood veneer with a moist cloth.
Step 1
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the cabinet. The assembly
workspace should be a non-marring surface such as carpet. For
missing hardware pieces, please contact BDI Customer Service
at [email protected]. For all other concerns, please
contact your BDI Retailer.
Step 2
Install Casters
Carefully position Cabinet (B) on its back side so that bottom side
is accessible, then attach a Caster at each of the five (5) exposed
installation plates using 5/32" x 12mm Phillips Screw (C) and a
Phillips Screwdriver.
Component List
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and
international patents, trade dress, and/or copyright laws.
BDI and Format are trademarks of Becker Designed, Inc.
All Rights reserved. ©2012, BDI
Made in Taiwan. 6307REV022312v1
A - Phillips Screwdriver
x 1 (not provided)
C x 4
E x 1
C x 16
D x 4
ASSEMBLY INSTRUCTIONS
BDIUSA.COM [email protected]

FORMAT
6307 2ASSEMBLY INSTRUCTIONS
BDIUSA.COM [e-mail]
H x 1
I
Step 3
Install Drawer Pulls.
Install Pulls.
Carefully turn pedestal upright and then install Pull (H) to top drawer
using the M4 x 37mm Phillips Screw (F) and a Phillips Screwdriver. Install
Pull (H) to bottom drawer using the M4 x 25mm Phillips Screw (G) and a
Phillips Screwdriver.
Step 4
File Folders
Users who wish to use legal-length files may install Letter File Bars(I) into
place near front and back of file drawers.
F x 2
H x 1
G x 2
