Becker C01 PLUS User manual

P5-16...R40-17
Model: C01 PLUS
en Assembly and Operating Instructions
Roller shutter drive with integrated radio
transceiver
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
2010 301 184 0d19/10/2023

Table of contents
General ............................................................................................................................................................................... 3
Warranty ............................................................................................................................................................................. 4
Safety instructions ............................................................................................................................................................... 4
Instructions for the user................................................................................................................................................... 4
Instructions for installation and commissioning.................................................................................................................. 4
Intended use ....................................................................................................................................................................... 6
Assembling and disassembling the plug-in connecting cable................................................................................................... 6
Assembly ............................................................................................................................................................................ 7
Compatible Centronic transmitters ........................................................................................................................................ 9
Commissioning with a CentronicPLUS transmitter ................................................................................................................ 10
Establish programming mode ........................................................................................................................................ 11
Programming the CentronicPLUS transmitter.................................................................................................................. 12
Adding additional transmitters to the installation .............................................................................................................. 13
Selection of the receiver for the setting mode.................................................................................................................. 13
Checking that the running direction is correct.................................................................................................................. 14
Intelligent installation management ................................................................................................................................ 15
Limit position status indicator ........................................................................................................................................ 15
Setting the limit positions............................................................................................................................................... 15
Upper stop to lower stop .......................................................................................................................................... 15
Upper point to lower point......................................................................................................................................... 16
Upper stop to lower point.......................................................................................................................................... 16
Upper point to lower stop.......................................................................................................................................... 17
Changing the set limit positions...................................................................................................................................... 17
Deleting the limit positions ............................................................................................................................................. 18
Intermediate positions I + II ............................................................................................................................................ 19
Restoring the wireless memory of the tubular drive to factory settings ............................................................................... 20
Commissioning with a Centronic transmitter......................................................................................................................... 22
Programming the master transmitter .............................................................................................................................. 23
Checking that the running direction is correct.................................................................................................................. 23
Intelligent installation management ................................................................................................................................ 24
Limit position status indicator ........................................................................................................................................ 24
Setting the limit positions............................................................................................................................................... 24
Upper stop to lower stop .......................................................................................................................................... 24
Upper point to lower point......................................................................................................................................... 25
Upper stop to lower point.......................................................................................................................................... 25
Upper point to lower stop.......................................................................................................................................... 25
Changing the set limit positions...................................................................................................................................... 25
Deleting the limit positions ............................................................................................................................................. 26
Intermediate positions I + II ............................................................................................................................................ 27
Programming additional transmitters.............................................................................................................................. 27
Deleting transmitters..................................................................................................................................................... 28
Overwriting the master .................................................................................................................................................. 28
Additional functions with CentronicPLUS/ Centronic ............................................................................................................ 29
Upper anti-freeze mechanism........................................................................................................................................ 29
Activating/ deactivating the upper anti-freeze mechanism with a CentronicPLUS transmitter......................................... 29
Activating/ deactivating the upper anti-freeze mechanism with a Centronic transmitter................................................. 29
Fly screen protection function........................................................................................................................................ 29
Programming the run times ........................................................................................................................................... 30
Deleting the run times with a CentronicPLUS transmitter .................................................................................................. 30
Deleting the run times with a Centronic transmitter .......................................................................................................... 31
Activating/ deactivating the run times with a CentronicPLUS transmitter ........................................................................... 31
Activating/ deactivating the run times with a Centronic transmitter ................................................................................... 31
Restoring the factory settings of the tubular drive ................................................................................................................. 31
Local operation with a single button..................................................................................................................................... 32
Obstacle detection............................................................................................................................................................. 32
Disposal ............................................................................................................................................................................ 33
Maintenance ..................................................................................................................................................................... 33
Technical data dia. 35 ........................................................................................................................................................ 33
Technical data dia. 45 ........................................................................................................................................................ 33
Error messages ................................................................................................................................................................. 34
What to do if...?.................................................................................................................................................................. 34
Sample wiring diagram ....................................................................................................................................................... 35
Declaration of conformity ................................................................................................................................................... 36
2-en

General
These tubular drives are high-quality products with the following features:
•Optimised for roller shutter operation
•Individual, group and central radio control
•No need to run wires to a switch or relay control device
•Any combination of drive and transmitter possible
•Simple to set the limit positions with the transmitter
•Installation without stops possible (from upper point to lower point)
•Two freely selectable intermediate positions can be set
•Flexible radio grouping; can be altered at any time with no need to install/uninstall
•Integrated memo function facilitates easy programming of one or two switching times on daily repeat.
•Automatic detection of the lower limit position when using springs in conjunction with the "drive adapter for obstacle detec-
tion"
•Automatic detection of limit positions thanks to intelligent electronic system with stop systems
•Obstacle detection, even when using rigid shaft connectors (axle shaft devices)
∙Slight pressure applied to the roller shutter curtain makes it difficult to raise or reach under it
∙Suitable for rigid aluminium, steel and wooden profiles
•The limit positions do not have to be reset: Changes in the shading solution are accommodated automatically when using stop
systems.
•Torque control in the up direction prevents damage to the roller shutter in the event of a frozen or blocked shutter
•Anti-freeze mechanism in the upper limit position can be enabled
•Considerably reduced stop load, and thus considerably reduced shading solution load
•Smooth operation of the system and the drive increases the service life
•For plug-in connecting cable
•Fly screen protection function
Please follow these Assembly and Operating Instructions when installing and setting up the device.
The date of manufacture comes from the first four digits of the serial number.
The numbers 1 and 2 indicate the year and the numbers 3 and 4 indicate the calendar week.
Example: 34th calendar week in 2020
Ser. No.: 2034XXXXX
Explanation of pictograms
CAUTION CAUTION indicates a hazardous situation which, if not avoided, could
result in injury.
ATTENTION ATTENTION indicates measures that must be taken to avoid damage to
property.
Denotes user tips and other useful information.
3-en

Warranty
Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in
serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current statutory, official and, in particular, EMC regu-
lations are adhered to during utilisation of our products, especially with regard to end product manufacture, installation and cus-
tomer advice.
Safety instructions
The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury.
Instructions for the user
General information
•The drive must be disconnected from its power source during cleaning and maintenance and when re-
placing parts.
•All work, including maintenance and cleaning, on electrical installations as well as other system parts
must always be performed by trained technicians, in particular qualified electricians.
•Children from the age of 8 years and persons with reduced physical, sensory or mental capabilities or
lack of experience and/or knowledge may use these devices, provided they are supervised or have
been instructed in the safe use of the device, and have understood the hazards involved. Children must
not play with the device.
•Systems have to be checked regularly by authorised specialists for wear and damage.
•Always put damaged systems out of operation immediately until they are repaired by an authorised
specialist.
•Do not operate equipment if people or objects are within the danger zone.
•Observe the danger zone of the equipment during operation.
•Ensure that there is adequate clearance (at least 40 cm) between moving parts and adjacent objects.
Caution
Safety instructions for avoiding serious injuries.
•Crushing or shearing points must be avoided or protected.
Instructions for installation and commissioning
General information
•Observe the safety instructions in EN 60335-2-97. Please note that this list of safety instructions is not
exhaustive, since it would be impossible for the standard to include all sources of danger. For example,
the design of the operated product, the way the drive works in the situation it is installed in or even the
way the end product is mounted in the end user’s place of use cannot be taken into consideration by
the drive manufacturer.
If any questions or uncertainties regarding the safety instructions contained in the standard arise,
please contact the manufacturer of the part or end product in question.
•All applicable standards and regulations for electrical installation must be complied with.
•All work, including maintenance and cleaning, on electrical installations as well as other system parts
must always be performed by trained technicians, in particular qualified electricians.
•Only use spare parts, tools and accessory devices which have been approved by the drive manufac-
turer.
Unapproved third-party products or modifications to the system and its accessories represent a risk to
your safety and the safety of others. This means that the use of unapproved third-party products, or
modifications which have not been agreed with or approved by us, are prohibited. We do not accept li-
ability for damage or injury arising from such actions.
•Position switch with OFF presetting within sight of the driven product, but away from moving parts, at a
height of over 1.5 m. This must not be publicly accessible.
•Permanently mounted control devices must be positioned where they can be seen.
•Rated torque and duty cycle must be suitable for the requirements of the driven product.
Technical data - rated torque and service life can be found on the type plate of the tubular drive.
4-en

•Hazardous moving parts of the drive must be installed at a height of over 2.5 m above floor level or any
other surface from which the drive can be accessed.
•To ensure safe operation of the system after commissioning, the limit positions must be correctly set/
programmed in.
•Drives with a H05VV-F connecting cable may only be used indoors.
•Drives with a H05RR-F, S05RN-F or 05RN-F connecting cable may be used both indoors and outdoors.
•To connect the drive to the driven part, solely mechanical accessory components made by the drive
manufacturer from the current product catalogue may be used. The components must be installed in
accordance with the manufacturer's instructions.
•If the drive is used for shading solutions in a specially marked area (e.g., escape routes, hazard zones,
safety areas), compliance with all applicable regulations and standards must be ensured.
•Once the drive has been installed, the fitter must mark the used tubular drive in the “Technical data”
chapter and make a note of the installation position.
Caution
Safety instructions for avoiding serious injuries.
•When electrical or electronic equipment and units are operated, certain components,
e.g., the power supply unit, are live. Physical injuries or damage to property can result in
the event of unauthorised interventions or failure to heed warnings.
•Be careful when touching the tubular drive, as it heats up during operation for technical
reasons.
•Before installation, shut down all lines and control devices that are not essential for op-
eration.
•Crushing or shearing points must be avoided or protected.
•When installing the drive, all-pole disconnection from the mains with a contact gap of at
least 3mm per pole must be provided (EN60335).
•If the mains connecting cable is damaged, it may only be replaced by the manufacturer.
If the drive has a plug-in connecting cable, it must be replaced with the same type of
mains connecting cable, which is available from the drive manufacturer.
Attention
Safety instructions for avoiding property damage.
•Ensure that there is adequate clearance between moving parts and adjacent objects.
•The drive must not be carried by the mains connecting cable.
•All latching connections and fastening screws on the brackets must be checked to en-
sure that they are secure.
•Ensure that nothing rubs against the tubular drive, such as shading solution attach-
ments, screws, etc.
•The drive must be fitted horizontally.
5-en

Intended use
The type of tubular drive described in these instructions is intended solely for the operation of roller shutters.
This type of tubular drive supports not only curtain attachment by means of springs but also rigid shaft connectors. These are de-
tected automatically.
If the springs or the top lath are screwed or riveted to the barrel, a point must be set in the lower limit position.
When mounting connection parts on the drive dia. 35 mm PXX/XX, only use screws EJOT Delta PT 40x12 WN 5454 Torx (9900 000
545 4).
For sun protection applications, please use only the types of tubular drive designed for this purpose.
This type of tubular drive is designed for use in single systems (one drive per barrel).
The tubular drive must not be used in potentially explosive areas.
The connecting cable is not suitable for transporting the drive. Always carry the drive by the housing tube.
Other applications, uses and modifications are not permitted in order to protect the safety of the users and others, since these ac-
tions can impair the system’s safety and carry the risk of personal injury and property damage. The drive manufacturer does not
accept liability for damages or injury arising from such actions.
Always observe the information in these instructions when operating or repairing the system. The drive manufacturer does not ac-
cept liability for damage or injury resulting from improper usage.
Attention
Only use rigid shaft connectors if the roller shutter laths are sufficiently strong. The closed
curtain must not project beyond the guide tracks or else there is a risk of the joint between
the top two laths being subjected to excessive strain and getting damaged.
Assembling and disassembling the plug-in connecting cable
Caution
The power supply to the connecting cable must be disconnected prior to assembly/disas-
sembly.
Assembling the plug-in connecting cable
Ø35/Ø45/Ø58 Insert the dead connecting cable into the drive head until the
locating lug clicks into place in the drive. If necessary, use a
suitable flathead screwdriver to assist with insertion. Set the
screwdriver into one of the two plug grooves provided for this
purpose.
Check that the cable is properly engaged.
1 = locating lug
6-en

Disassembling the plug-in connecting cable for tubular drives
Ø35 Insert a suitable flathead screwdriver between the locating lug
and the snap-in pin, so that the snap-in pin releases the locat-
ing lug from the plug.
Now you can pull out the connecting cable along with the flat-
head screwdriver.
1.
2.
3.
A
A = snap-in pin
Ø45/Ø58 Insert a suitable flathead screwdriver right into the recess of the
locating latch, so that the latch releases the locating lug from
the plug.
Now you can pull out the connecting cable along with the flat-
head screwdriver.
A
1. 2.
A = locating latch
Assembly
Assembling the drive
Attention
To connect the drive to the driven part, solely mechanical accessory components made by
the drive manufacturer from the current product catalogue may be used.
Prior to mounting, the fitter must ensure that the masonry and the system being motorised are sufficiently robust (drive torque plus
weight of the shading solution).
Caution
Electrical connections may only be carried out by a qualified electrician. Prior to assembly,
the power supply must be disconnected and secured. Please give the enclosed connection
information to the responsible electrical contractor.
If you want the roller shutter curtain to open to the upper stop, proceed as follows: The
roller shutter curtain must be prevented from being drawn into the shutter box with a
mechanical stop or an angled end strip. With face-fixed elements, we recommend con-
cealed stops in the guide tracks.
Calculate the space required at the side (M) by measuring the drive head (1) and wall bracket (2). The
clear dimension of the box (X) minus the space required at the side (M) and idler (G) gives the length
(L) of the barrel: L=X-M-G.
The space required at the side (M) varies depending on the combination of drive and wall bracket.
Then mount the wall bracket and idler. Ensure that the barrel is aligned at right angles to the wall and that sufficient axial play is al-
lowed for the mounted system.
Attention
When using rigid shaft connectors, closed brackets must be fitted. The tubular drive
presses the closed curtain down to make it difficult for people to reach under it or raise it.
Only use curtains made of sufficiently strong material, such as aluminium, steel or wood.
To prevent damage to the curtain it must run in guide tracks from top to bottom.
7-en

Assembling and disassembling the mounting pin
Ø45
When pushed in, the mounting pin (2) locks automatically. To undo the mounting pin (2), push the tab
washer (1) upwards and pull out the mounting pin (2).
If you wish to use the "obstacle detection" function, you must use the "drive adapter for
obstacle detection".
Assembling and disassembling the drive adapter
Fitting the ring onto the thrust ring
Assembling the drive adapter with safety catch on the
drive shaft
Disassembling the drive adapter with safety catch on the
drive shaft
Assembling and disassembling the drive adapter with drive adapter safety catch or screw connection
Assembling and disassembling the drive
adapter with separate drive adapter
safety catch
Assembling and disassembling the drive
adapter with screw connection
Mounting the drive in the tube
For profile shafts:
In the case of some drive adapters, tolerances of the groove widths in different barrels can be offset by
rotating the drive adapter into a different groove recess. These groove recesses have different sizes
and allow the drive to fit exactly.
Y
X
For round shafts:
Measure the lug of the thrust ring (X, Y). Then notch the tube on the motor side, so the lug of the thrust
ring can also be pushed into the shaft. There must be no play between the lug of the thrust ring and the
shaft.
-10 mm
To ensure secure torque transmission for round shafts, we recommend screwing the drive adapter to
the shaft (see the table below).
Attention!When drilling into the barrel, never drill near the tubular drive!
8-en

Size of drive
[mm]
Drive adapter Torque
max. [Nm]
Fastening screws
(4 units)
dia. 35-dia. 45 All Up to 50 Self-tapping screw
dia. 4.8 x 9.5 mm
We also recommend screwing the idler to the barrel.
Attention
Do not hammer the tubular drive into the tube or drop it into the barrel! The curtain can only
be secured using springs or rigid shaft connectors. We recommend at least three pieces
per metre of barrel.
2
1
Assemble the tubular drive with the relevant ring (1) and drive adapter (2). If the ring has several
grooves, select the groove which is a perfect fit and push the ring (1) onto the thrust ring.
Insert the tubular drive with the pre-assembled ring (1) and drive adapter (2) into the tube to achieve a
form fit. Ensure that the ring and drive adapter are secure in the tube.
Mount the assembled unit comprising shaft, tubular drive and idler on the box and secure the drive with
a splint or spring pin according to the type of wall bracket fixing.
Position the barrel so that the roller shutter curtain can be attached with springs or fit the rigid shaft connectors in accordance with
the manufacturer's instructions.
Lay the connecting cable
Lay the connecting cable up to the tubular drive, and fix. The connecting cable must not project into the
winding chamber. Cover any sharp edges.
The exterior antenna, if present, must not be shortened or damaged under any circumstances and also
must not project into the winding space.
Caution!Mains voltage may be present at a damaged or cut antenna. There is acute danger
to life in the event of contact! Systems with a damaged antenna must be immediately discon-
nected and repaired.
Compatible Centronic transmitters
All CentronicPlus receivers can be operated with the Centronic transmitters listed in the Centronic/CentronicPlus compatibility
table at
www.becker-antriebe.com/downloads
As two fundamentally different radio technologies are linked in this case, the full performance of the CentronicPlus radio control
system is not available in this combination. When using the Centronic transmitter with CentronicPlus receiver, the range perform-
ance may be reduced under certain circumstances. A Centronic transmitter cannot process feedback from the CentronicPlus re-
ceiver. The full performance of CentronicPlus is only achieved in combination with CentronicPlus transmitters, receivers and
sensors, as only then will an intelligent, bidirectional system be automatically created.
9-en

Commissioning with a CentronicPLUS transmitter
Explanation of symbols
UP button
STOP button
DOWN button
Programming button (on the transmitter)
Function button (on the transmitter)
LED ring on the transmitter
Receiver confirms once or multiple times by “clicking” or “shifting”
1 = direction switch
2 = radio switch
Operating modes
Normal mode Control of selected receiver/ channel
Receiver selection Selection of the required receiver and channel allocation
Setting mode Commissioning and administration of selected receivers
Attention
The tubular drives are designed for short-time operation. An inbuilt thermal protection
switch prevents overheating of the tubular drive. During commissioning (long drop dis-
tance or long running time), the thermoswitch may trigger. The drive will switch off. After a
short cooling-down period, the system is ready for operation again.
The drive does not achieve its full duty cycle until it has cooled to ambient temperature.
Avoid a situation where the thermal protection switch cuts in repeatedly.
10-en

Connecting the tubular drive
N1
2
1
2
4
3
4
230V AC / 50 Hz
L1
PE
Connect the tubular drive to the power supply.
1 = blue 3 = black
2 = brown 4 = green/ yellow
Switch on the power.
► The tubular drive confirms.
Establish programming mode
This step is only necessary if one of the devices to be programmed is not yet part of the in-
stallation. This is the case for brand new products, for example, or devices from another
installation or products that have been restored to factory settings.
Readying the tubular drive for programming by switching on the power
Switch on the power.
▻ The tubular drive confirms.
► The tubular drive is ready to program for 15 minutes.
If several tubular drives are to be connected in parallel, you can deactivate the program-
ming mode on one tubular drive by switching the radio switch to the outside position after
turning the power on.
Readying the tubular drive for programming with the radio switch
Switch the radio switch to the inside position. If the radio switch is already in this posi-
tion, switch it to the outside and back to the inside position.
► The tubular drive is ready to program for 15 minutes.
11-en

Programming the CentronicPLUS transmitter
With brand new products, devices from another installation or products that have been re-
stored to factory settings, programming mode must be established beforehand (see Es-
tablishing programming mode).
Bring the transmitter as close as possible to the receiver to be programmed.
3s Press the programming button for 3 seconds when it is ready to program. The trans-
mitter performs a search and the LED ring continuously changes colour. The trans-
mitter then switches to receiver selection and selects the receiver with the best con-
nection quality.
▻ The receiver confirms.
If you do not receive confirmation from the required receiver, you can press the /
button to toggle between the available receivers until the required receiver confirms.
Pressing the button for 3 seconds confirms the receiver with the best connection
quality.
▻ The transmitter displays the current assignment status of the receiver via the
LED ring.
Assignment status
Lights up yellow: The receiver is not yet part of the installation or is in the as-delivered condition.
Lights up blue: The receiver is not assigned to the selected channel.
Lights up green: The receiver is assigned to the selected channel.
Lights up white: Centronic PLUS sensor selected.
Lights up purple Centronic PLUS transmitter selected.
Lights up red: No receiver located.
Select the desired channel by pressing the function key on the multi-channel hand-
held transmitter.
or
Press the STOP button to change the assignment status of the selected receiver. If
the receiver is not yet part of the installation, it will be added and assigned to the se-
lected channel.
▻ The receiver signals once to confirm the channel assignment, or signals
twice to cancel the channel assignment.
▻ The transmitter lights up accordingly to confirm the new assignment status.
► The receiver is now part of the installation with the required channel assignment.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
12-en

Adding additional transmitters to the installation
If installation data already exists for the transmitter being programmed, the procedure will
be terminated. Termination is indicated by the red flashing of the LED ring. In this case, the
transmitter will need to be restored to factory settings (see corresponding transmitter in-
structions).
3s Press the programming button on an already programmed transmitter for 3 seconds.
The transmitter performs a search and the LED ring continuously changes colour. The
transmitter then switches to receiver selection and selects the receiver with the best
connection quality.
▻ The receiver confirms.
Now press and hold the programming button for a new transmitter.
▻ After 5 seconds, the LED rings on both transmitters start to fill in green.
Continue pressing and holding the programming button.
▻ Once the new transmitter has been added successfully, both transmitters
flash green to confirm.
► The transmitter has been added successfully.
The programming process can be terminated at any time by pressing the
STOP button on the transmitter that has already been programmed or by re-
leasing the programming button.
Selection of the receiver for the setting mode
Bring the transmitter as close as possible to the required receiver.
3s Press the programming button for 3seconds. The transmitter performs a search and
the LED ring continuously changes colour. The transmitter then switches to receiver
selection and selects the receiver with the best connection quality.
▻ The receiver confirms.
If you do not receive confirmation from the required receiver, you can press the /
button to toggle between the available receivers until the required receiver confirms.
Pressing the button for 3 seconds confirms the receiver with the best connection
quality.
▻ The transmitter displays the current assignment status of the receiver via the
LED ring.
Assignment status
Lights up yellow: The receiver is not yet part of the installation or is in the as-delivered condition.
Lights up blue: The receiver is not assigned to the selected channel.
Lights up green: The receiver is assigned to the selected channel.
Lights up white: Centronic PLUS sensor selected.
Lights up purple Centronic PLUS transmitter selected.
Lights up red: No receiver located.
Briefly press the programming button to change to the setting mode.
▻ The receiver confirms.
▻ The LED ring of the transmitter slowly pulses light blue.
▻ The receiver now enters dead-man mode.
► The setting mode is now active.
If a receiver has not yet been added to the installation (LED ring lights up
yellow), it will not be possible to select it in this way. The receiver must be ad-
ded to the installation beforehand. See chapter “Programming Centron-
icPLUS transmitters”.
13-en

Checking that the running direction is correct
The direction of rotation can only be changed if no limit position has been set.
There are several ways to change the direction of rotation:
•Changing direction of rotation via the direction switch
•Changing direction of rotation via the transmitter
Changing direction of rotation via the direction switch
Press the or button.
▻ The shading solution runs in the desired direction
► The running direction is OK.
If the shading solution runs in the wrong direction, the running direction must be changed. Proceed as follows:
Switch the direction switch (1) to the opposite position.
▻ The running direction will now have changed.
► Check the running direction again.
Changing the direction of rotation with a CentronicPLUS transmitter
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Press the or button.
▻ The shading solution runs in the desired direction.
► The running direction is OK. Now change back to normal mode, as described in the previous step.
If the shading solution runs in the wrong direction, the running direction must be changed. Proceed as follows:
3s
First, press the programming button, then within 3seconds also press the and
button for 3seconds.
▻ The receiver confirms.
▻ The transmitter confirms with a red/blue rotation of the LED ring.
Check the running direction again.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
14-en

Intelligent installation management
Completion of installation following automatic setting of limit positions
The drive saves the limit position permanently once the upper limit position is reached 3 times in succession. Installation is then
complete. If the limit position is set above a point, this is stored permanently.
Limit position status indicator
A brief stopping and restarting indicates that no limit position has been set in that direction of movement.
Setting the limit positions
The running direction must be correct. When setting the limit positions, the tubular drive
runs in dead-man mode with the limit position status indicator. The upper limit position
must always be set first. When setting the upper limit position, ensure that the roller shut-
ter curtain is not pulled out of the guide tracks.
When first installing using springs and adjusting the limit position "...to lower stop", the
barrel in the lower limit position turns approx. 1/4 of a turn further than usual. This allows
the tubular drive to automatically detect the use of rigid shaft connectors or springs. The
tubular drive switches off automatically.
Attention
When operating the tubular drive without the drive adapter for obstacle detection, if using
springs a point must be set in the lower limit position.
There are several ways to set the limit positions:
•Upper stop to lower stop
•Upper point to lower point
•Upper stop to lower point
•Upper point to lower stop
The limit position becomes fixed after the tubular drive has turned off automatically in the desired position three times.
Upper stop to lower stop
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open to the permanent upper stop.
▻ The tubular drive switches off automatically.
Then close to the permanent lower stop.
▻ The tubular drive switches off automatically.
► The limit positions are now set.
This type of limit position adjustment also works when using springs, rigid
shaft connectors are not required.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
15-en

Upper point to lower point
There is no shading solution length adjustment with this limit position setting.
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open to the desired upper limit position.
Press the programming button and, within 3seconds, also press the button and
hold the two buttons down.
▻ The tubular drive confirms.
▻ The transmitter confirms by lighting up the upper third of the LED ring.
Then close to the desired lower limit position.
Press the programming button and, within 3seconds, also press the button and
hold the two buttons down.
▻ The tubular drive confirms.
▻ The transmitter confirms by lighting up the lower third of the LED ring green.
► The limit positions are now set.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
Upper stop to lower point
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open to the permanent upper stop.
▻ The tubular drive switches off automatically.
Then close to the desired lower limit position.
Press the programming button and, within 3seconds, also press the button and
hold the two buttons down.
▻ The tubular drive confirms.
▻ The transmitter confirms by lighting up the lower third of the LED ring green.
► The limit positions are now set.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
16-en

Upper point to lower stop
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open to the desired upper limit position.
Press the programming button and, within 3seconds, also press the button and
hold the two buttons down.
▻ The tubular drive confirms.
▻ The transmitter confirms by lighting up the upper third of the LED ring.
Then close to the permanent lower stop.
▻ The tubular drive switches off automatically.
► The limit positions are now set.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
Changing the set limit positions
1) Shortening the range of travel (the desired limit position is located inside the current range of
travel)
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open/close to the desired new limit position.
or
First press and hold the programming button, then within 3 seconds also press and
hold the button for the lower limit position, or the button for the upper limit posi-
tion. Hold the two buttons down.
▻ The tubular drive confirms.
▻ The transmitter confirms by lighting up the upper/lower third of the LED ring.
► The new limit position is now saved.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
17-en

2) Extending the range of travel (the desired limit position is located outside the current range of
travel)
Attention
When both or individual limit positions are deleted, all the other set functions (intermediate
position I, intermediate position II, upper anti-freeze mechanism, obstacle detection, run
times, fly screen protection function) are deleted as well.
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open/close to the limit position in the direction in which you wish to extend the range
of travel.
3s
Press the programming button and, within the next 3seconds, press the STOP button
at the same time and hold the two buttons down for 3seconds.
▻ The tubular drive confirms.
▻ The transmitter confirms with red pulsing of the LED ring.
► The limit position is now deleted.
Open/close to the desired new limit position.
or
First press and hold the programming button, then within 3 seconds also press and
hold the button for the lower limit position, or the button for the upper limit posi-
tion. Hold the two buttons down.
▻ The tubular drive confirms.
▻ The transmitter confirms by lighting up the upper/lower third of the LED ring.
► The new limit position is now saved.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
Deleting the limit positions
Attention
When both or individual limit positions are deleted, all the other set functions (intermediate
position I, intermediate position II, upper anti-freeze mechanism, obstacle detection, run
times, fly screen protection function) are deleted as well.
Deleting individual limit positions
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open/close to the limit position to be deleted.
3s
Press the programming button and, within the next 3 seconds, press the STOP button
at the same time and hold the two buttons down for 3 seconds.
▻ The tubular drive confirms.
▻ The transmitter confirms with red pulsing of the LED ring.
► The limit position is now deleted.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
18-en

Deleting both limit positions
Select the required receiver as described in the chapter Selection of the receiver for
the setting mode [}13].
Open/close the shading solution to a point between the limit positions.
3s
Press the programming button and, within the next 3 seconds, press the STOP button
at the same time and hold the two buttons down for 3 seconds.
▻ The tubular drive confirms.
▻ The transmitter confirms with red pulsing of the LED ring.
► The limit positions are now deleted.
3s Then press the programming button for 3seconds to change to normal mode.
► The LED ring goes out.
Intermediate positions I + II
The intermediate positions I + II are freely selectable positions for the shading solution
between the two limit positions. Each travel button can be assigned one intermediate posi-
tion. Both limit positions must be set before an intermediate position is set.
Setting/modifying the desired intermediate position
Open/close the shading solution to the desired intermediate position.
or
Press the STOP button and, within 3 seconds, also press the desired travel button
and hold the two buttons down.
▻ The receiver confirms.
▻ The transmitter confirms by lighting up the upper/lower third of the LED ring
light blue.
► The intermediate position is now saved.
If several receivers are operated on the same channel, a specific receiver can also be se-
lected beforehand. You can select the required receiver beforehand by following the de-
scription in the chapter Selection of the receiver for the setting mode [}13].
Travelling to the desired intermediate position
2x
or
2x
Press the travel button for the desired intermediate position twice within one second.
▻ The transmitter confirms with a rotational movement of the LED ring from
blue to turquoise.
► The shading solution travels to the intermediate position assigned to the travel
button.
19-en

Deleting the desired intermediate position
2x
or
2x
Move the shading solution to the intermediate position that is to be deleted.
or
Now press the STOP button and, within 3 seconds, also press the travel button as-
signed to the intermediate position and hold the two buttons down.
▻ The receiver confirms.
▻ The transmitter confirms by lighting up the upper/lower third of the LED ring
light blue.
► The intermediate position is now deleted.
Deleting the intermediate positions
5s Press the STOP button twice within 1 second and then press and hold for 5 seconds.
▻ The receiver confirms.
▻ The transmitter confirms with red pulsing of the LED ring.
► The intermediate positions have now been deleted.
Restoring the wireless memory of the tubular drive to factory settings
There are a number of options:
•Using a programmed CentronicPlus transmitter
•Using the universal programming unit (item no. 4935 000 001 0)
The set limit positions and all of the other set functions (intermediate position I, intermedi-
ate position II, upper anti-freeze mechanism, obstruction detection, fly screen protection
function) are retained.
Using a programmed CentronicPlus transmitter
Bring the transmitter as close as possible to the required receiver.
3s Press the programming button for 3seconds. The transmitter performs a search and
the LED ring continuously changes colour. The transmitter then switches to receiver
selection and selects the receiver with the best connection quality.
▻ The receiver confirms.
If you do not receive confirmation from the required receiver, you can press the /
button to toggle between the available receivers until the required receiver confirms.
Pressing the button for 3 seconds confirms the receiver with the best connection
quality.
▻ The transmitter displays the current assignment status of the receiver via the
LED ring.
Assignment status
Lights up yellow: The receiver is not yet part of the installation or is in the as-delivered condition.
Lights up blue: The receiver is not assigned to the selected channel.
Lights up green: The receiver is assigned to the selected channel.
Lights up white: Centronic PLUS sensor selected.
Lights up purple Centronic PLUS transmitter selected.
Lights up red: No receiver located.
20-en
