Belarus 2022.6 User manual

BELARUS
2022.6
2022.6-0000010 OM
OPERATOR’S MANUAL
2014

This Operator's manual was composed by an engineer of the first Department of
Constructive and Experimental Works (DCEW-1), A.V. Runov, with participation of key
specialists of DCEW-1 of OJSC “Minsk Tractor Works”
Publication responsible person –Yu.M. Korotky, head of engineering office for de-
sign documentation of the DCEW-1.
Executive editor –N.I. Zezetko, chief designer of tractor production of OJSC
“MTW”.
Editor-in-chief –A.G. Stasilevich, OJSC “MTW” general designer.
Operator's manual contains brief description and specifications of tractors
“BELARUS-2022.6”produced by Minsk Tractor Works. The main operating rules for trac-
tors are set forth, the information about their adjustments and maintenance is provided.
Operator's manual is meant for tractor study, operation rules and maintenance of
tractors “BELARUS-2022.6”.
In view of Minsk Tractor Works policy directed to constant upgrading of produced
goods, the construction of some units and parts of Belarus tractor may undergo changes
which are not reflected in the present edition. The detailed information may be obtained
from “BELARUS” dealer.
©OJSC ”Minsk Tractor Works”, 2014
All rights reserved. No part of this book may be reproduced in any form without written
permission of OJSC “MTW”.

2022.6-0000010 OM
3
CONTENTS
1 TRACTOR DESCRIPTION AND OPERATION ..............................................................11
1.1 Tractor assignment ......................................................................................................11
1.2 Technical specifications ...............................................................................................12
1.3 Tractor composition .....................................................................................................15
1.4 Vibration level at the operator's working place of the tractor “BELARUS -2022.6”.......18
1.5 Noise level at the operator's working place of the tractor “BELARUS -2022.6” ...........18
1.6 Tractor and its components marking............................................................................18
2 CONTROLS AND INSTRUMENTS ................................................................................20
2.1 Layout of controls and instruments of the tractor .........................................................20
2.2 Switches of the instrument board.................................................................................21
2.3 Upper shield unit of button switches ............................................................................24
2.4 Conditioner control.......................................................................................................24
2.4.1 Conditioner control in the conditioning mode ............................................................24
2.4.2 Conditioner control in the heating mode ...................................................................25
2.4.3 Cab ventilation ..........................................................................................................26
2.5 Cooling liquid drain from heating system .....................................................................26
2.6 Instrument board..........................................................................................................27
2.7 Pilot lamps unit ............................................................................................................29
2.7.1 General information ..................................................................................................29
2.7.2 Functioning algorithm of pilot lamp to indicate operation of heating plugs................30
2.8 Integrated indicator and integrated indicator control panel ..........................................31
2.8.1 General information ..................................................................................................31
2.8.2 Assignment and operation principle of integrated indicator gauges..........................32
2.8.3 Pilot lamps of the integrated indicator .......................................................................35
2.8.4 Description of testing the integrated indicator performance ......................................36
2.8.5 The order of the integrated indicator programming...................................................36
2.9 Information display and engine control system panel ..................................................39
2.9.1 General information ..................................................................................................39
2.9.2 Adjustment of brightness and sharpness of the information display .........................39
2.9.3 Call-up of changeable images and parameters on the screen of the information
display................................................................................................................................39
2.9.4 Engine control system panel.....................................................................................42
2.10 Steering .....................................................................................................................42
2.10.1 General information ................................................................................................42
2.10.2 Steering wheel adjustments....................................................................................43
2.11 Parking brake control .................................................................................................43
2.12 Handle for fuel supply manual control........................................................................43
2.13 Tractor pedals............................................................................................................43
2.14 Switching of ranges and gears on GB........................................................................44
2.14.1 General information ................................................................................................44
2.14.2 Diagram of tractor velocity ......................................................................................45
2.15 Control panel for rear axle DL, FDA and FPTO drives...............................................46
2.15.1 General information ................................................................................................46
2.15.2 Front power take-off shaft control ...........................................................................47
2.15.3 FDA drive control ....................................................................................................47
2.15.4 Rear axle differential lock control............................................................................48
2.15.5 Annunciation of oil emergency temperature in the hydraulic lift linkage..................48
2.15.6 Indication of GB reduction unit actuated pass.........................................................48
2.16 Rear PTO control.......................................................................................................49
2.17 Control of lift linkages.................................................................................................50
2.17.1 General information on rules of RLL control ...........................................................50

2022.6-0000010 OM
4
2.17.2 RLL control panel....................................................................................................50
2.17.3 Remote buttons of RLL control system ...................................................................52
2.17.4 Troubleshooting of RLL electronic control system ..................................................53
2.17.5 Front lift linkage control...........................................................................................54
2.18 HLL pump control.......................................................................................................54
2.19 HLL valve group section control (remote cylinders) ...................................................55
2.20 Switching unit and electric cutout fuses .....................................................................56
2.20.1 General information ................................................................................................56
2.20.2 Switching unit and fuses for electrical equipment ...................................................56
2.20.3 Fuses for electronic systems of rear axle DL, FDA, GB reduction unit, FPTO and
RLL control ........................................................................................................................63
2.20.4 Fuses for engine electronic control system.............................................................64
2.21 Cab locks and handles...............................................................................................65
2.21.1 Cab door locks........................................................................................................65
2.21.2 Side window opening ..............................................................................................65
2.21.3 Rear screen opening...............................................................................................66
2.21.4 Cab hatch opening..................................................................................................66
2.21.5 Cab emergency exits ..............................................................................................66
2.22 Seat and its adjustments............................................................................................67
2.22.1 General information ................................................................................................67
2.22.2 Adjustments of “BELARUS” seat ............................................................................67
2.22.3 Adjustments of “Grammer” seat..............................................................................68
2.23 Control of the transmission hydraulic system pump drive ..........................................69
2.24 Control of the pneumatic system compressor............................................................69
2.25 Connector elements of the electrical equipment ........................................................70
2.25.1 Socket to connect coupled agricultural equipment..................................................70
2.25.2 Connection of additional electrical equipment of coupled machines.......................70
2.26 Fuel tanks ..................................................................................................................71
2.27 SCR system operation ...............................................................................................71
2.27.1 Tank for SCR system liquid ....................................................................................71
2.27.2 Indication of SCR system operation........................................................................72
3 INTENDED USE OF TRACTOR.....................................................................................75
3.1 Safety measures while preparing tractor for operation.................................................75
3.2 Tractor use...................................................................................................................76
3.2.1 Boarding the tractor ..................................................................................................76
3.2.2 Engine start and preparation for it.............................................................................76
3.2.3 Start of tractor movement, GB shifting ......................................................................78
3.2.4 Tractor stop...............................................................................................................79
3.2.5 Engine stop...............................................................................................................79
3.2.6 Leaving the tractor ....................................................................................................80
3.2.7 PTO use....................................................................................................................80
3.2.8 Selection of optimal inner pressure in tires depending on operational conditions and
load on tractor axles ..........................................................................................................83
3.2.8.1 Selection of optimal inner pressure in tires depending on operational conditions
and load on tractor axles....................................................................................................83
3.2.8.2 Tire inflation ...........................................................................................................85
3.2.9 Rear wheel track formation .......................................................................................86
3.2.10 Rear wheel twinning................................................................................................87
3.2.11 Front wheel track formation ....................................................................................88
3.3 Safety measures while tractor operation......................................................................90
3.3.1 General safety measures while tractor operation......................................................90
3.3.2 Fire safety measures ................................................................................................93
3.4 Tractor final assembly and run-in.................................................................................94

2022.6-0000010 OM
5
3.4.1 Tractor final assembly...............................................................................................94
3.4.2 Technical maintenance before tractor run-in.............................................................94
3.4.3 Tractor run-in ............................................................................................................94
3.4.4 Technical maintenance during tractor run-in.............................................................95
3.4.5 Technical maintenance after tractor run-in................................................................95
3.5 Emergency actions ......................................................................................................96
4 COUPLING OF IMPLEMENTS.......................................................................................97
4.1 General information .....................................................................................................97
4.2 Types of implements coupled with tractor “BELARUS -2022.6”...................................98
4.3 Lift linkage....................................................................................................................99
4.3.1 General information ..................................................................................................99
4.3.2 Three-point rear lift linkage .......................................................................................99
4.3.3 RLL components adjustment rules .........................................................................103
4.3.3.1 Buckles ................................................................................................................103
4.3.3.2 Lifting rods ...........................................................................................................104
4.3.3.3 Upper link.............................................................................................................105
4.3.3.5 Mounting of implements to the tractor RLL ..........................................................106
4.3.4 Three-point front lift linkage ....................................................................................107
4.3.5 The rules of agricultural implements coupling to FLL..............................................109
4.3.6 The rules of shifting FLL from operating to transport position .................................109
4.4 Drawbar hitches.........................................................................................................110
4.4.1 General information ................................................................................................110
4.4.2 Drawbar hitch DH-2V (short towing yoke)...............................................................111
4.4.3 Drawbar hitch DH-ЗV (long towing yoke)................................................................112
4.4.4 Drawbar hitch DH-2R (“python”) .............................................................................113
4.4.5 Drawbar hitch DH-1М-01 (draw bar) .......................................................................114
4.4.6 Drawbar hitch DH -1 (crossbeam)...........................................................................115
4.4.7 Coupling clevis KU2000/329NB33 and coupling clevis KU5410/329-33.................116
4.4.8 Piton-Fix coupling PB5329NNB33 ..........................................................................118
4.4.9 Coupling balls KI8329NB33 and KB8329NB33 ......................................................120
4.5 Usage patterns of tractor hydraulic system for drive of operating parts and other
elements of hydraulically-powered coupled machines and implements...........................123
4.6 Front ballast weight....................................................................................................125
4.7 Trailer brake drive......................................................................................................127
4.7.1 General information ................................................................................................127
4.7.2 Double-wire pneumatic drive for trailer brakes........................................................127
4.7.3 Single-wire pneumatic drive for trailer brakes .........................................................128
4.7.4 Hydraulic drive of trailer brakes ..............................................................................128
4.8 Determination of PTO shaft and cardan shaft applicability ........................................130
4.9 Peculiarities of PTO shaft and cardan shaft applicability ...........................................130
4.10 Ways of changing drawbar features and passing ability of the tractor .....................134
4.11 Features of tractor application in special conditions ................................................135
4.11.1 Tractor operation in areas with rugged topography. Possibility of tractor application
for haylage preparation....................................................................................................135
4.11.2 Application of substances for chemical treatment.................................................135
4.11.3 Operation in a forest .............................................................................................135
4.12 Determination of total weight, loads on front and rear axles, tires holding capacity and
the required minimum ballast...........................................................................................136
4.13 Possibility of front loader installation ........................................................................138
4.13.1 General information ..............................................................................................138
4.13.2 Safety measures while tractor “BELARUS-2022.6” operation with the loader
installed............................................................................................................................140
4.13.3 Information on tractor mounting holes...................................................................142

2022.6-0000010 OM
6
5 MAINTENANCE............................................................................................................144
5.1 General instructions...................................................................................................144
5.2 Providing access to the components for maintenance services.................................146
5.3 Maintenance procedure .............................................................................................147
5.4 Scheduled maintenance service operations ..............................................................150
5.4.1 Maintenance service on a shift basis (SBMS) in every 8 – 10 hours of operation or
per shift............................................................................................................................150
5.4.2 Maintenance service in every 125 hours of operation (MS-1).................................158
5.4.3 Maintenance services in every 250 hours of operation (2MS-1), in every 500 hours of
operation (MS-2), in every 1000 hours of operation (MS-3), in every 2000 hours of
operation (special maintenance) and maintenance service that does not coincide with
intervals of MS-1, 2MS-1, MS-2, MS-3 and special MS...................................................167
5.4.3.1 General instructions .............................................................................................167
5.4.3.2 Operation 35. Check / adjustment of clearances in steering joints ......................167
5.4.3.3 Operation 36. Check / adjustment of wheel toe-in ...............................................168
5.4.3.4 Operation 48. Check / adjustment of service brake control..................................169
5.4.3.5 Operation 49. Check / adjustment of parking brake control .................................172
5.4.4 General maintenance services ...............................................................................174
5.4.4.1 General instructions .............................................................................................174
5.4.4.2 Operation 80. Adjustment of GB centrifuge valves ..............................................174
5.4.4.3 Operation 81. Maintenance of the engine air cleaner ..........................................175
5.5 Seasonal maintenance services ................................................................................177
5.6 Safety measures while maintenance service and repair operations ..........................178
5.6.1 General safety requirements...................................................................................178
5.6.2 Safety precautions for exclusion of hazardous situations related to accumulator
batteries and a fuel tank...................................................................................................178
5.6.3 Guidelines for safe use of leveling jacks and statement of proper places for their
installation........................................................................................................................179
5.7 Instruments, work tools and measuring devices while maintenance services and repair
.........................................................................................................................................181
5.8 Filling and lubrication of the tractor with fuel and lubrication materials ......................182
6. POSSIBLE FAILURES AND INSTRUCTIONS FOR THEIR TROUBLESHOOTING ...186
6.1 Possible clutch failures and instructions for their troubleshooting..............................186
6.2 Possible failures in gearbox and instructions for their troubleshooting ......................189
6.3 Possible failures in the electronic control system for rear axle differential lock, front
driving axle drive, front power take off shaft, GB reduction gear and instructions for their
troubleshooting ................................................................................................................190
6.4 Possible failures in rear axle and instructions for their troubleshooting......................192
6.5 Possible failures in rear power take-off shaft and instructions for their troubleshooting
.........................................................................................................................................193
6.6 Possible failures in front power take-off shaft and instructions for their troubleshooting
.........................................................................................................................................194
6.7 Possible failures of brakes and instructions for their troubleshooting ........................195
6.8 Possible failures in the pneumatic system and instructions for their troubleshooting.197
6.9 Possible failures of trailer brake hydraulic actuator and guidelines for troubleshooting
.........................................................................................................................................199
6.10 Possible failures of the transmission hydraulic system and instructions for their
troubleshooting ................................................................................................................200
6.11. Possible failures of FDA and instructions for their troubleshooting .........................201
6.12 Possible failures of the hydrostatic steering control and instructions for their
troubleshooting ................................................................................................................203
6.13 Possible failures in the electronic control system of RLL and instructions for their
troubleshooting ................................................................................................................206

2022.6-0000010 OM
7
6.14 Possible failures of the hydraulic lift linkage and guidelines for troubleshooting ......213
6.14.1 General information ..............................................................................................213
6.14.2 Instructions for troubleshooting in HLL.................................................................213
6.15 Possible failures in the electrical equipment and instructions for their troubleshooting
.........................................................................................................................................216
6.16 Possible failures of air-conditioning and cab heating systems and instructions for
troubleshooting ................................................................................................................218
6.17 Possible engine failures and instructions on their troubleshooting...........................219
7. TRACTOR STORAGE .................................................................................................220
7.1 General instructions...................................................................................................220
7.2 Requirements for inter-shift storage of machines ......................................................220
7.3 Requirements for short-term tractors storage ............................................................220
7.4 Requirements for outdoors long-term storage ...........................................................221
7.5 Preservation...............................................................................................................222
7.6 Depreservation and represervation............................................................................222
7.7 Putting tractor into operation after long-term storage.................................................222
7.8 Safety requirements for preservation.........................................................................223
8. TRACTOR TOWING....................................................................................................223
Service bulletins...............................................................................................................224

2022.6-0000010 OM
8
Introduction
The present manual is designed for studying the structure, operation rules and mainte-
nance of tractors “BELARUS-2022.6”.
Scrutinize this manual. It will help you to study the rules of correct operation and main-
tenance.
Failure to follow these instructions can lead to operator's injury or a tractor breakdown.
Tractor operation, its maintenance and repair shall be carried out only by employees,
familiar with all of its parameters and characteristics and informed about necessary safety re-
quirements to prevent casualties.
Due to constant tractor development, some changes which are not specified in the pre-
sent manual can be introduced in the structure of certain units and parts.
Any arbitrary changes made by a consumer release the manufacturer from responsibil-
ity for possible further injuries to the operator and a tractor breakdown.
Adopted abbreviations and conventional notations:
ADL – automatic differential lock;
AB – accumulator battery;
DL – differential lock;
RADL – rear axle differential lock;
PLU – pilot lamps unit;
FB – fuse block;
FC – fast coupling;
PTO – power takeoff shaft;
PRS – power reception shaft;
HSC – hydrostatic steering control;
HLL – hydraulic lift linkage;
HS – hydraulic system;
FFVS – frequency fuel volume sensor;
STM – shift-time maintenance;
RPTO – rear power take-off shaft;
SPTA – spare parts, tools and accessories;
RA – rear axle;
RLL – rear lift linkage;
II – integrated indicator;
GB – gearbox;
MI – multifunction indicator;
MTU – machine and tractor unit;
CC – coupling clutch;
LL – lift linkage;
CL – coolant;
IAC – inlet air cooler;
FDA – front driving axle;
FPTO – front power take-off shaft;
FLL – front lift linkage;
VC – voltage converter;
FDAD – front driving axle drive;
CM – control module;
IICP – integrated indicator control module;
HPH – high pressure hoses;
HP – heating plugs;
SM – seasonal maintenance;
MS – maintenance service;
MS1 – maintenance service No1;
MS2 – maintenance service No2;
MS3 – maintenance service No3;
DH – drawbar hitch;
ECS – electronic control system;
EECS – engine electronic control system;
EE – electrical equipment.

2022.6-0000010 OM
9
The manufacturer uses standard international symbols regarding application of in-
struments and control units.
Given below are the symbols with indication of their meanings.
see the manual;
control manipulations;
brake;
fast;
handbrake;
slowly;
audible beep;
forward;
alarm signaling;
reverse;
fuel; accumulator charging;
coolant;
cab dome light;
heating plugs; parking lights;
engine speed; tractor turn indicator;
oil pressure in the engine;
tractor trailer turn indicator;
upper beam;
temperature of engine coolant;
low beam;
off / stop; working lights;
on / start;
differential lock;
gradual adjustment;
PTO engaged;

2022.6-0000010 OM
10
front screen wiper; front driving axle drive;
rear screen wiper and washer; fan;
brake fluid level in main cylin-
der tanks;
air filter clogged;
oil pressure in HSC engine start;
beacon — road-train
oil pressure in gearbox — external cylinder – retracting
braking of gearbox
— external cylinder – protracting
air pressure in pneumatic sys-
tem — external cylinder – floating
— swivel lever – up engine stop
— swivel lever – down — linkage control system
— instrument illumination — instrument supply
— +12V supply — battery disconnection lock
— starter — starter lock
— from working lights on hand-
grips and on roof

2022.6-0000010 OM
11
1. TRACTOR DESCRIPTION AND OPERATION
1.1 Tractor assignment
Tractor “BELARUS-2022.6” is intended for performance of various general–purpose
agricultural operations, primary cultivation and pre-sowing tillage, cereal and other crop
sowing if coupled with wide-span and multi-purpose mounted, semi-mounted and trailed
machines and implements, for forage conservation, grain crop harvesting as well as for
loading-unloading and transportation work if combined with highly productive harvest com-
plexes.
Tractor “BELARUS-2022.6” is a general-purpose wheeled tractor of traction class 3
with the wheel arrangement 4X4.
Physical configuration of tractor “BELARUS-2022.6” in basic configuration is shown
in figure 1.1.1.
Physical configuration of tractor “BELARUS-2022.6” equipped with FPTO and FLL
is shown in figure 1.1.2.
Figure 1.1.1 – Basic configuration of tractor “BELARUS -2022.6” in basic configuration
Figure 1.1.2 – Tractor “BELARUS-2022.6” equipped with FLL and FPTO (for the
rest, see figure 1.1.1)

2022.6-0000010 OM
12
1.2 Technical specifications
Main parameters and specifications of tractor “BELARUS -2022.6” are given in table
1.2.1.
Table 1.2.1
Parameter
(specification) designation
Parameter value for tractor
“BELARUS -2022.6”
1 Traction class according to GOST 27021 3
2 Rated traction force, kN 30
3 Engine 1)
а) model D-260.4 S4
b) engine type 2) turbocharged with intercooling of inlet
air
c) number and arrangement of cylinders 2) six, in-line, vertical
d) cylinder displacement, l 2) 7,120
e) engine power, kW:
1) rated 2) 155,9
2) operating 150,0±3,0
f) crankshaft rated speed, rpm 2) 2100
g) specific fuel consumption at operating
power, g/(kW·h) 224±11
h) rated factor of torque backup, at least, %
2)
30
i) max torque, N·m 2)
920
4 Number of gears:
а) for forward travel 24
b) for reverse travel 12
5 Tractor travel speed (design) at crankshaft
rated speed, km/h:
a) for forward motion:
1) least 1,9
2) highest 39,6
b) for backward motion:
1) least 2,6
2) highest 18,7
6 Tractor weight, kg:
a) tare weight 6850±100
b) operating with ballast 7300±100
c) max operating 10000 (11500 3))
d) ex-works 4) 7100±100
7 Distribution of operating weight on axles,
kg:
а) on front 2960±40 5)
b) on rear 4340±60 5)

2022.6-0000010 OM
13
Table 1.2.1 continued
Parameter
(specification) designation
Parameter value for tractor
“BELARUS -2022.6”
8 Permissible load on axles, kN:
а) on front 50
b) on rear 85
9 Max weight of the trailer, kg
а) without brakes 3500
b) with independent brake 3500
c) with overrunning brake 12000
d) equipped with a brake system (trailer
brakes are interconnected with tractor
brakes) 25000
10 Road clearance under drawbar hitch
bracket, mm (on tires of basic configura-
tion), mm, at least: 410
11 Track dimensions (on tires of basic con-
figuration), mm:
а) for front wheels 1725±20, 1790±20, 1890±20,
1940±20, 2040±20, 2105±20, 2205±20
b) for rear wheels from 1800 to 2010 and from 2230 to 2500
12 Least radius of turning circle (with brak-
ing), m 5,3
13 Tractor base, mm 2920±20
14 Maximum fordable depth, m 0,85
15 Service life, years 12
16 Overall dimensions, mm:
a) length with loads and rear lift linkage in
transport position
5230±50
b) width along the ends of rear wheel semi-
axles 2400±20
c) cab height 3120±30
17 Tires (basic configuration):
а) front wheels 420/70R24
b) rear wheels 580/70R42
18 Electrical equipment according to GOST
3940:
а) rated supply voltage in on-board power
system, V
12
b) rated ignition voltage, V 24

2022.6-0000010 OM
14
End of table 1.1
Parameter
(specification) designation
Parameter value for tractor
“BELARUS -2022.6”
19 Hydraulic system:
а) pump displacement under crankshaft
rated speed, l/min, at least
b) safety valve operating pressure, МPа
c) nominal volume factor, at least
53
20-2
0,7
20 Operating equipment:
а) rear power take-off shaft: In subsection 3.2.7 “PTO use”
b) front power take-off shaft: In subsection 3.2.7 “PTO use”
c) rear lift linkage:
1) load-lifting capacity of rear lift linkage on
the suspension axle, kg, at least 6500
2) rear lift linkage lifting time from lower-
most to uppermost position with test load
on the suspension axle, s, at least
5
d) drawbar hitch: In section 4 “Coupling of implements”
_____________________________________________________________________
________________________________________
1) Engine parameters, not specified in table 1.2.1, shall comply with 260 S4 – 0000100
OM document.
2) For referential use.
3) When operating in a traction driven mode with implements on front and rear lift link-
ages and limiting speed to 15 km/h.
4) To be specified depending on configuration.
5) With ballast mounted.

2022.6-0000010 OM
15
1.3 Tractor composition
Tractor framework is semi-frame.
Undercarriage – front and rear wheels are driving, with pneumatic tires of low pres-
sure. Front wheels are steering. Rear wheels can be twinned by means of a spacer.
The tractor is equipped with a 4-stroke piston six-cylinder inner combustion engine
with in-line vertical arrangement of cylinders, with direct injection of diesel fuel and com-
pression ignition, corresponding to environmental requirements of Stage 4.
The system of engine lubrication is combined, some parts are lubricated under pres-
sure, some – by spattering. The lubrication system consists of an oil sump, oil pump, liq-
uid-oil heat exchanger, centrifugal oil filter and oil filter with paper filtering element.
The engine fuel supply system consists of the following parts:
- accumulator system of fuel supply Common RAIL, including a high-pressure fuel
pump, injectors, a fuel accumulator under high pressure, sensors of the engine working
environment condition (pressure and temperature of fuel and air), electromagnetic actuat-
ing mechanisms (fuel governor, electromagnetic injection valves), electronic unit of control
and communication check circuits, low-pressure pipelines, high-pressure pipelines;
- fuel fine filters;
- fuel coarse filters.
The system of engine start-up is an electric starter. A means of start-up facilitation
under low environmental temperatures are heating plugs.
The system of air delivery consists of a turbocharger, an air pipeline and a system of
inlet air cooling.
The turbocharger is executed as follows: a radial centripetal turbine and a centrifugal
single-stage compressor with a cantilever arrangement of wheels in relation to supports.
The system of air purification consists of a dry-type air cleaner with a built-in unit
“monocyclone” and two paper filtering elements. Air ingress with an air-cleaner is per-
formed through the “monocyclone” unit which provides preliminary inertial air cleaning at
the expense of tangential inflow and centrifugal forces, arising at spiral air rotation in rela-
tion to the axis of many small separate slots of “monocyclone” unit, discharging large-size
dust particles.
The cooling system for inlet air is of a radiator type. The CAC radiator is intended for
cooling the air, charged into the inlet collector.
The cooling system is closed-type with coolant compulsory circulation carried out by
a centrifugal pump. The water pump is driven by a V-belt from the crankshaft pulley. Two
thermostats TC-107 mounted at the delivery line are provided for acceleration of engine
warming-up after start-up and for automatic control of a temperature mode at various load-
ings and ambient temperatures.
To provide the required chemical composition of exhaust fumes, corresponding to
ecological requirements of Stage 4, the exhaust fumes system is additionally equipped
with two stages of selective catalytic reduction (SCR1, SCR2).
The coupling clutch is frictional, dry, two-disk, spring-loaded. The clutch pads are ce-
ramic-metal. The coupling control drive is hydrostatic with a hydraulic booster.
The gearbox is 24Fх12R, mechanical, step-by-step, with constant-mesh gears, shift-
ing of gears within the ranges is carried out by means of synchro-mesh units; switching
between ranges is carried out by toothed clutches.
Shifting of GB reduction unit ranges is electrohydraulic.

2022.6-0000010 OM
16
Rear axle:
- with the main drive – a pair of bevel pinions with circular teeth;
- with the hub drive – a pair of cylindrical gears;
- with final drives – of planetary type;
- with a differential – with mechanical blocking, and electrohydraulic control.
Brakes: operating brakes are multi-disk, oil-lubricated, located on drive pinion shafts
of hub drive. Operating brakes control is interlocked with pneumatic drive of trailer brakes.
Operating brakes control drive is hydrostatic.
Parking brake is combined with operating brakes, with independent manual me-
chanical control. Parking brake control is interlocked with pneumatic drive of trailer brakes.
Trailer brakes control drive is either double-wire pneumatic, or single-wire pneumatic
or hydraulic, interlocked with tractor operating brakes control. Against order, tractor can be
not equipped with pneumatic drive of trailer brakes – tire inflation shall be carried out
through a valve in the pneumatic compressor.
The rear power take-off shaft is continuous, four-speed, with smooth start, having two
modes – standard and economic.
The direction of rotation is clockwise as viewed from the side of the shaft end exten-
sion butt end.
The first variant of supply:
The tractor is equipped with PTO 3 shaft end extension (20 splines) according to
GOST 3480.
PTO 1c shaft end extension (8 splines) according to GOST 3480 and PTO 2 shaft
end extension (21 splines) according to GOST 3480 and ISO500 are included into tractor
SPTA.
The second variant of supply:
The tractor is equipped with PTO 2 (21 splines) according to GOST 3480 and ISO
500.
PTO 1 (6 splines) according to ISO500 and PTO 3 shaft end extension (20 splines)
according to ISO500 are included into tractor SPTA.
Front PTO (against order) is continuous, one-speed. PTO 2 shaft end extension (21
teeth) complies with GOST 3480. The direction of rotation is clockwise as viewed from the
side of the shaft end extension butt end.
The transmission hydraulic system provides the following:
- switching of GB reduction unit passes, RPTO drive, FPTO drive (against order),
FDA drive, differential lock;
- filtration of transmission oil;
- pressure feed lubrication of gearbox bearings, RA planetary gear reducer, FDA
bearings;
- operation of the clutch hydraulic booster.
The steering is hydrostatic. The feed pump is gear-type, the direction of rotation is
left. The dosing pump is gerotor-type with open center, without steering response. The
type of rotation mechanism is two hydraulic cylinders (Ц50x250) of bidirectional action and
a steering linkage.
The front driving axle is portal-frame, with planetary-cylindrical final gears. The main
drive is a pair of bevel gears with circular teeth. The differential is self-locked, with in-
creased friction. The FDA is driven from the gearbox through the frictional hydraulically-
operated clutch and the crankshaft. The FDA control is electro-hydraulic.

2022.6-0000010 OM
17
The hydraulic lift linkage is remote-cylinder, providing draft, position, combined and
depth adjustment for agricultural machinery position, and suppression of vertical oscillation
of agricultural implements in traveling position; with electrohydraulic system (EHR) of rear
lift linkage automatic control. The system has three pairs of independent outlets.
Free drain is available at the back for tractor operation with hydraulic units with con-
stant delivery, for example, with hydraulic motors.
The rear lift linkage is a three-point linkage of category 3 under ISO 730 and a link-
age 3 under GOST 10677. There are two cylinders Ц90x250.
Bushings are included into tractor SPTA to provide an opportunity for coupling of im-
plements of category 2 according to ISO 730 and lift linkage 2 according to 10677 to RLL.
The front lift linkage (against order) is a three-point linkage of category 2 under ISO
730 and a linkage 2 according to GOST 10677. There are two cylinders Ц90x250.
Drawbar hitches of a lift type:
- short towing yoke DH 2V – for coupling with semi-trailers and semi-trailed imple-
ments;
- long towing yoke DH 3V – for coupling with trailers and trailed implements;
- pin DH-2R (“Python”) – for coupling with semi-trailers and semi-trailed machines
(against order);
- towing bar DH-1M-01 –for coupling with semi-trailed and trailed agricultural ma-
chines (against order);
- cross member DH-1 – for coupling with trailed and semi-trailed machines (against
order).
Drawbar hitches of a lift type, purchasing and mounting of which onto “BELARUS-
2022.6” tractors is allowed to be carried out by a customer individually, are as follows:
- automated yokes KU2000/329NB33 or KU5410/329-33 (manufactured by company
“Walterscheid”) with a spherical pin – for coupling with trailers and semi-trailers, as well as
with agricultural machines based on trailers and semi-trailers;
- coupling device “python” PB5329NNB33 (manufactured by company “Walter-
scheid”) – for coupling with agricultural machines having a tail piece with an ear on the
towing beam;
- ball coupling devices KI8329NB33 and KB8329NB33 (manufactured by company
“Walterscheid”) – for coupling with agricultural machines having a tail piece with a spheri-
cal seat on the towing beam.
In coordination with “MTW”, a customer is allowed to purchase and mount onto the
tractor an automated yoke, coupling device “python” and ball coupling device manufac-
tured by other companies if parameters and coupling dimensions of the above mentioned
devices correspond to parameters and coupling dimensions, specified in corresponding
tables 4.4.6, 4.4.7, 4.4.8, 4.4.9, 4.4.10 of subsection 4.4 “Drawbar hitches”.
The cabin is a one-seated with a protective rigid framework, having thermal, noise
and vibration insulation, equipped with a sprung seat adjustable for operator's height and
weight, with rear-view mirrors, with a sun visor, with electrical wipers for front and rear
screens, with front and rear screen washers, with a roof lamp and a place to install a radio
set, with a system of air-conditioning and heating. Against order, the tractor can be
equipped with an additional seat. The cab doors have got locks, there are keys for the left
door. The right door is for emergency exit. The cab complies with category 2 under EN
15695-1:2009.
The electrical equipment complies with GOST 3940. The rated power supply voltage
for on-board network is 12V. The rated voltage for the start-up is 24V.
Instruments are a combination of devices; an integrated indicator; informational dis-
play; pilot lamps (glow lamps and light emitting diodes), located on the block of pilot lamps,
on the control panel of the rear axle differential lock and FDA drive, on the engine control
system board.

2022.6-0000010 OM
18
1.4 Vibration level at the operator's working place of the tractor “BELARUS -2022.6”
Vibration level at the operator's seat complies with the Council Directive
78/764/ЕEС. Values for vibration level are given in the EU type approval on each type of a
seat.
1.5 Noise level at the operator's working place of the tractor “BELARUS -2022.6”
Noise level at the operator's workplace conforms to Directive 2009/76/ЕС, Appendix
2, and does not exceed the value 86 dB (A). External noise level conforms to Directive
2009/63/ЕС and does not exceed the value 89 dB (A).
1.6 Tractor and its components marking
A metal nameplate is fixed at the rear of the cab on the right side, as shown in fig-
ure 1.6.1.
Additionally, the tractor serial number is applied by means of percussion on the right
side member and duplicated on the right plate of the front ballast weight.
Figure 1.6.1 – The place of the tractor nameplate application
Engine number and numbers of its components are given in engine operation man-
ual.
Nameplate for tractors ex-
ported to countries not in-
cluded into the EU
Nameplate for tractors exported
to countries included into the
EU

2022.6-0000010 OM
19
Numbers of tractor components are given in table 1.6.1.
Table 1.6.1 – Numbers of tractor components
Number of clutch casing
(to the left along tractor
movement)
Number of gear box
(to the left along tractor
movement)
Transmission and rear axle
serial number (at front low-
er pad on the right side of
rear axle housing)
FDA number
(on the tube of the bar)
Cab serial number
Serial number
GB configura-
tion number
Serial numbe
r
Housing version
number
Version number of
clutch housing
assembly
GBRA serial number
week
year number
version

2022.6-0000010 OM
20
2. CONTROLS AND INSTRUMENTS
2.1 Layout of controls and instruments of the tractor
Controls and instruments located in the tractor cab are shown in figure 2.1.1.
Figure 2.1.1 – Tractor controls and instruments
