Belkin TuneBase F8Z049 User manual

User Manual
TuneBase™ FM for iPod®

iPod Version of Firmware
iPod mini 1.4 and above
iPod photo 1.1 and above
iPod 4G 3.1 and above
iPod nano 1.0 and above
iPod video 1.0 and above
Note: iPod 3G is not supported.
Introduction | 01
Introduction
Congratulations and thank you for purchasing the innovative TuneBase FM from Belkin.
This product is designed to mount, stabilize, charge, power, and play your iPod as you
drive. Please review this User Manual carefully so that you can be sure to get the most
from your iPod, virtually anywhere you go.
Firmware Required
For complete compatibility, confirm your iPod has the following version of firmware.
To check your iPod’s firmware, select the “Settings” menu and then select the “About”
menu. Your iPod’s version is listed under “Version”. If your firmware is out of date,
consult the manufacturer’s website to download an updated version.

Setup Instructions
1. Turn your car stereo volume down.
2. Connect the Belkin TuneBase FM to your cigarette-lighter adapter in your car. The
LED on the TuneBase FM indicates proper connection.
Warning: Avoid excessive force when rotating the connector in the cigarette-lighter
adapter. If you experience resistance, unplug the connector from the outlet and
reinsert it in the desired position. Failure to do so may result in damage to the car’s
cigarette-lighter adapter or power outlet.
Note: The exact dimensions of power outlets vary by make and model of the car.
In some cases, the fit might be improved by pressing the collar (included with the
product) into the power outlet before inserting the connector in order to ensure a
tight fit. However, the collar will not be necessary in most cars (note: when it is not
necessary, it will not fit in the power outlet).
A. Be sure to position the ring securely around the metal contact to ensure proper
electrical connection within the power outlet.
B. Power source (cigarette-lighter outlet)
C. Fit ring
D. Connector
Setup Instructions | 02
(B)
(A)
(D)
(C)

Setup Instructions
3. Bend and position the flexible-steel neck to a
desired position for your iPod.
4. The TuneBase FM for iPod includes eight
adapters for all supported iPod models (4G
iPod 20GB/40GB, iPod photo 30GB/60GB, iPod
video 30GB/60GB, mini, nano). Choose the
adapter that fits your iPod and carefully insert
the adapter firmly into the top of the cradle.
5. Carefully slide your iPod into the cradle at the
top of the TuneBase FM. The iPod will power
on if the car battery is on.
Note: The iPod automatically pauses playback
when power is removed from the cigarette
lighter or the car is turned off.
Note: To avoid damage to the iPod, please be
sure to disconnect it from the TuneBase FM’s
cradle before disconnecting the TuneBase FM
from the power outlet of the car.
Setup Intructions | 03





The TuneBase FM transmitter function automatically turns on when the iPod is
connected and car power is available. It automatically turns off when the iPod is
removed or car power becomes unavailable.
1. Tune your car stereo frequency to a channel with a weak broadcast signal. The ideal
channel is one that is not broadcasting a radio program, or is doing so weakly.
2. Insert your iPod into the TuneBase FM. The iPod backlight will turn on and the
current transmitter frequency will be displayed on the iPod screen.
3. Press the ”▲” or “▼” button on the TuneBase FM to
select the transmission frequency chosen in step 1. The
frequency will be visible on the iPod’s screen. Pressing
and holding either button will provide faster tuning.
4. After displaying the current frequency for five seconds,
the iPod screen will return to the iPod Main Menu. This
will happen after making any changes to the TuneBase
FM’s settings. All settings—including transmission
frequency, volume control setting, and stereo/mono
control setting—are permanently stored in memory at
this time.
Note: iPod playback will pause momentarily when
entering and exiting the TuneBase FM control menu.
Playback will quickly resume.
5. Adjust the volume of your FM radio to the desired
listening level.
Using the TuneBase FM Transmitter
Using the TuneBase FM Transmitter | 04




Frequency
display
Frequency
selector

Storing and Using Presets
1. To store a preset, select the desired frequency using ”▲” or “▼” buttons. Press and
hold the desired preset button (1, 2, 3, or 4) for two seconds. An audible beep sounds
when the new frequency is programmed*. The iPod display reflects the change
when the memory button is released by showing which memory button was pressed
followed by the frequency saved in that memory position.
* Do NOT remove the iPod from the cradle until it returns to the Main Menu screen or
new settings may not be saved.
2. To select a preset frequency, momentarily press “1”, “2”, “3”, or “4”. This instantly
tunes the FM transmitter to the frequency stored in that preset.
Storing and Using Presets | 05
Frequency display
Frequency selector
Memory station display
Memory stations 1 - 4





Although the default volume setting will be ideal for most conditions, you
may be able to improve the performance of the TuneBase FM by adjusting
the volume of the transmitted audio signal. The TuneBase FM allows you to
select one of five volume levels. You may wish to decrease the volume if you
experience distorted audio.
You can access the transmission volume menu by pressing the “1” and “2”
buttons simultaneously. TuneBase FM displays the current volume setting
on the iPod, which is represented by “VOL 1” (low), “VOL 2”, “VOL 3” (default),
“VOL 4”, and “VOL 5” (high).
You can then change the volume level by using the up and down arrows. To
accept your volume selection, press one of the memory preset buttons, or
simply wait for the iPod screen to return to the iPod Main Menu.
Note: The iPod nano has a lower audio output level than other iPod models,
so a volume setting of “VOL 4” or “VOL 5” works best for iPod nano.
Stereo/Mono Selection
Transmitting music in stereo generally gives you the highest-quality listening
experience. However, you may get better FM signal reception by changing
the transmission to mono. TuneBase FM transmits in stereo mode by default.
We suggest that you switch from stereo to mono transmission only if your
car stereo is NOT receiving a clear signal from the TuneBase FM, or if you are
listening to mono recordings such as audio books.
You can access the stereo/mono transmission menu by pressing the “1”
and “3” buttons simultaneously. The TuneBase FM then displays the current
mode setting, which is represented by “MONO” or “ST”.
You can change the mode by pressing the up or down arrows.
Either arrow will change between the two modes. The new setting takes
effect immediately.
To accept your mode selection, press one of the memory preset buttons, or
simply wait for the iPod screen to return to the iPod Main Menu.
Transmission Volume Setting
Transmission Volume Setting | 06










Troubleshooting
Issue - My iPod does not seem to be charging.
Solution 1 - Make sure that the TuneBase FM is correctly connected to your car’s power
outlet. The green indicator light on the cigarette-lighter adapter portion of the product
should be lit at all times.
Solution 2 - Check to see that the iPod is pushed all the way into the cradle.
Solution 3 - Ensure that your car’s power outlet is receiving power. Some cars are designed so
that power is not provided to the power outlet unless the car is in ignition mode or the engine
is running. If none of these solutions solves the problem, the fuse of the TuneBase FM might be
burned out. In order to replace the fuse, please carefully follow these steps:
Troubleshooting | 07
SPRING
(NOT PICTURED)
FIG. A
FUSE
CONTACT
FRICTION WASHER
METAL WASHER
NUT
NOTE: DO NOT ATTEMPT TO DO
THIS IN THE CAR. Use a clean, level
surface or table for disassembly so
that components do not get lost.
The contact piece at the front end
of the cigarette-lighter adapter is
spring-loaded. With pliers, carefully
and slowly remove the nut at the
front end so that the spring inside the
cigarette-lighter adapter does not get
lost. The fuse will be easily accessible
now. Purchase a new fuse at any auto-
supply store.
Please refer to Fig. A for correct order
of assembly. Be sure to tighten the nut
firmly with pliers.

Issue - The audio is distorted.
Solution 1 - Decrease the TuneBase FM volume setting. Setting the volume setting to “VOL 4”
or “VOL 5” increases the likelihood of audio distortion, except when using iPod nano.
Solution 2 - Make sure that your iPod EQ setting is “Off” or “Flat”. Some EQ settings cause the
audio to clip.
Solution 3 - Tune your car stereo and the TuneBase FM to a different frequency.
Issue - The audio is too quiet.
Solution 1 - Increase the transmission volume setting, especially when using an iPod nano. If
your hear distortion in the audio, decrease the volume setting. The default setting of “VOL 3” is
ideal for most conditions.
Issue - I am unable to get clear FM reception.
Solution 1 - Tune your car stereo and the TuneBase FM to a different frequency.
Solution 2 - In some instances, lowering the car antenna (available in some cars) will improve
the clarity of the TuneBase FM’s signal.
Solution 3 - Change the stereo/mono setting to mono mode. This may improve signal
reception, but the audio will be monaural instead of stereo.
Issue - iPod playback stays paused after I’ve changed a setting on the TuneBase FM.
Solution - Simply press the “Play/Pause” button on your iPod to resume playback.
Issue - When I remove my iPod from the TuneBase FM cradle or turn off my car, iPod
playback does not automatically pause.
Solution - If you remove the iPod from the TuneBase FM cradle within 12 seconds of adjusting
the TuneBase FM settings, or remove power to the TuneBase FM during this time, the iPod may
not automatically pause. Simply press the “Play/Pause” button on your iPod to pause playback.
Issue - When returning to the iPod Main Menu after adjusting the TuneBase FM
settings, the iPod stays on the “OK to disconnect” screen.
Solution - Remove your iPod from the TuneBase FM and reconnect it. If you are no longer using
the TuneBase FM, simply remove and then reset your iPod by pressing the “select” and “menu”
buttons simultaneously for 10 seconds.
Troubleshooting
Troubleshooting | 08
