BEMIS PURE CLEAN 2000 User manual

BEMIS PURE CLEAN®2000
WASHING TOILET SEAT
ABATTANT LAVANT
Instruction manual
Notice d’installation
Important: Read instructions before use
Important: Lisez les instructions avant utilisation
!
A

2
A
I
II
III
3. Specications
14. Caractéristiques techniques
5. Safety precautions
16. Mesures de sécurité
8. Remote control and Side button functions
19. Fonctions de la télécommande et du bouton latéral
10. Removal and Cleaning instructions
21. Instructions de démontage et de nettoyage
11. Water lter and Nozzle cleaning
22.Nettoyage du ltre à eau et de la buse
12. Troubleshooting
23.Dépannage
25. /
27.
Installation instruction - Bottom xation
Instructions d’installation - Fixation par le bas
26. /
27
Installation instruction - Top xation
Notice d’installation - Fixation par le dessus
28.
Water connection
Raccordement à l’eau
31. Remote control wall xation
Fixation murale de la télécommande

3
Specificaon
Rated voltage and rated frequency 220 - 240V~ 50/60Hz
Length of wire
Posterior cleaning
Feminine cleaning
Swing cleaning
Drying temperature
Safety device
Temperature range
So-close control for seat
cover
Safety device
Room temperature~42℃󽙏3 grade sengs󽙐
Damper device
Temperature sensor & Temperature control switch & Temperature fuse
Anbacterial seat cover
Self-cleaning nozzle
Rated power Maximum power1070W
4℃~35℃
Temperature of
supplied-water
Ambient
temperature
Waterproofing
grade
1600W
3℃~40℃
IPX4
1󾙏 The rated power󾙏water pressure is 0.18MPa + 0.02MPa under the ambient temperature of 23℃±2℃󽙓
And under the condion of 15℃±0.5℃ water-inflow temperature󽙓heighten the water quanty󽙓
the seat temperature and the water temperature in turn󽙓 to stat the posterior cleaning in a average power.
2󾙏 Maximum power󾙏 water pressure is 0.18MPa+0.02MPa under the ambient temperature of 23℃±2℃󽙓
And under the condion of 5℃±1℃ water-inflow theperature󽙓heighten the water quanty󽙓
the seat temperature and the water temperature in turn󽙓 to start the feminine cleaning in a average power.
3󾙏󾙓󾙙󾙓󾙙󽘀󽘁
Pressure of
supplied-water 0.07MPa󽙏Dynamic󽙐~0.75MPa󽙏Stac󽙐
Treated arcle containing biocidal product with acve substance:
Inorganic silver CAS number: 7761-88-8
Self-cleaning
About 32℃~52℃󽙏Top Gear󽙐
Temperature control switch & Temperature fuse
Massage cleaning
Adjustment of the water
spray and nozzle
Water temperature
range
Safety device Liming the circuit by the soware of over-temperature fast
Temperature control switch & Temperature fuse
Interval cleaning, Powerful cleaning
3 grades
About 35℃~42℃󽙏Top Gear󽙐
Swing cleaning back and forth
Water
yield
Washing
equipment
Seat cover
Drying
device
Self-cleaning
About 0.4~0.7L/min(hydraulic pressure of 0.2Mpa)
About 1.5m
SPECIFICATIONS | EN

4




 

󾙔󾙒 
󾙕󾙒


󽘀
󽘀












F3/8 M3/8
M3/8
󽘀
󽘀


Model:
Bemis Pure Clean®
2000 S/n:
Bemis Manufactering Company
Made in China
Rated voltage ~ 220 V
Rated frequency 50 Hz
Rated power 900 W
Waterproof level IPX4
An�-electrical shock type I
Cer�fied EN 1717
EN | SPECIFICATIONS

5
SAFETY PRECAUTIONS | EN
READ ALL INSTRUCTIONS BEFORE INSTALLATION AND USE
Strictly follow the user manual during assembly.
Please keep the user manual aer assembly.
Indicates potenally hazardous situaon which, if not avoided, may result
in minor or moderate injury or in damage to the product or other property.
Indicates potenally hazardous situaon which, if not avoided,
could result in death or serious injury.
WARNING
Indicates an imminently hazardous situaon which, if not avoided,
will result in death or serious injury.
DANGER
CAUTION
DANGER- To reduce the risk of electrocuon
WARNING- To reduce the risk of burns, electrocuon, fire, or injury to persons
PLEASE OBSERVE THE FOLLOWING PRECAUTION BEFORE USING THIS PRODUCT
Do not open the product to repair or remodel.
Only qualified service personnel should service this product.
Do not use aachments not recommended by the manufacturer.
Do not modify the product yourself or with another person.
Do not dismantle
Connect this product to cold water supply pipe carrying potable water.
Do not connect to an industrial water supply line that
does not carry water of drinking quality.
This will negavely effect hygiene and performance.
Prohibited
About Low Temperature Burns:
A burn occurs when the skin has been exposed to high temperatures.
However, a low temperature burn may occur when the skin has been in contact with an
object at relavely low temperature (about 40ºC). Close supervision is necessary when
this product is used by children or adults with sensive skin.
Prohibited
Do not use benzene, any acid chemical based detergent,
puy powder or non neutral detergent / cleanser to clean the plasc
parts like toilet seat cover, inner ring or other plasc components.
Only neutral detergent permied.
Do not use a nylon brush or other harsh tools to clean the plasc parts
like toilet seat cover, inner ring or other plasc components.
Only a so cloth or sponge is permied.
Prohibited
Do not plug in the power cable before connecng the water supply hose.
It is prohibited to connue using the product if the product has
a breakdown:
Product is very hot to touch
Product has smoke coming from the back side or the cable part.
Product has an abnormal sound or burning smell.
Product is broken, leaking or damaged
Toilet pan is blocked by water or another foreign object etc.
Prohibited
Persons (including children) with physical, perceptual, intellectual disabilies or lack of
experience and common sense need to use the product under the guidance or
supervision of someone else, or they may cause electric shock, injury or fire to
themselves or others.
Observe at all mes
The following terms are used in this manual to indicate hazards of varying degrees of severity.

6
This product must be grounded.
An approved & adequately installed EU electricity plug must be used.
Grounding
Do not splash water on this product.
Please provide adequate venlaon to avoid high levels of humidity
which can damage the electronic components.
It is necessary to provide adequate venlaon with a fan,
open door or open window when bathing.
Do not spray water
Do not touch the power cable with wet hands.
Do not reach for a product that has fallen into water.
Unplug immediately!
Wet hands prohibited
This product must be connected to a standard EU voltage power source.
Do not connect the power cable if the cable is damaged or broken.
Do not plug the power cable into a loose electric outlet.
Observe at all mes
Please disconnect the power cable when you clean this product or
detach it from toilet bowl.
Do not supply electrical power to the unit unl the plumbing work
has been completed.
Observe at all mes
Keep the electrical cable away from heated surfaces to prevent a fire hazard.
Also, keep any flammable materials away from this product at all mes.
Use of fire prohibited
Never operate this product if it is not
working properly, if it has been
dropped or damaged, or dropped into
water. Return the product to a service
center for examinaon and repair.
Prohibited
Do not obstruct or put
anything into the dry air
outlet. Do not apply
excessive force to the
shower nozzle.
Prohibited
Do not strain or push the connected hose and tube connecter;
it may cause water leakage.
Never drop or insert any object into any opening or hose.
Use proper plumbing supplies if any modificaon is to be made.
Prohibited
Drain the water from unit and unplug the power if this product is
not going to be used for an extended period of me.
Observe at all mes
Do not stand or sit on
the seat cover lid.
It is not designed to
support a user’s
body weight.
Prohibited
Allow the seat
and lid to close
automacally.
Do not force the
lid closed.
Prohibited
Must install the electric bidet seat with a water proof electrical socket (minimum IPX4).
The locaon of electric plug socket must be 0.5m above the floor and 1.5m away from
shower or bathtub, otherwise it might cause electricity leakage.
Observe at all mes
Indicates potenally hazardous situaon which, if not avoided, may result
in minor or moderate injury or in damage to the product or other property.
Indicates potenally hazardous situaon which, if not avoided,
could result in death or serious injury.
WARNING
Indicates an imminently hazardous situaon which, if not avoided,
will result in death or serious injury.
DANGER
CAUTION
DANGER- To reduce the risk of electrocuon
WARNING- To reduce the risk of burns, electrocuon, fire, or injury to persons
PLEASE OBSERVE THE FOLLOWING PRECAUTION BEFORE USING THIS PRODUCT
Do not open the product to repair or remodel.
Only qualified service personnel should service this product.
Do not use aachments not recommended by the manufacturer.
Do not modify the product yourself or with another person.
Do not dismantle
Connect this product to cold water supply pipe carrying potable water.
Do not connect to an industrial water supply line that
does not carry water of drinking quality.
This will negavely effect hygiene and performance.
Prohibited
About Low Temperature Burns:
A burn occurs when the skin has been exposed to high temperatures.
However, a low temperature burn may occur when the skin has been in contact with an
object at relavely low temperature (about 40ºC). Close supervision is necessary when
this product is used by children or adults with sensive skin.
Prohibited
Do not use benzene, any acid chemical based detergent,
puy powder or non neutral detergent / cleanser to clean the plasc
parts like toilet seat cover, inner ring or other plasc components.
Only neutral detergent permied.
Do not use a nylon brush or other harsh tools to clean the plasc parts
like toilet seat cover, inner ring or other plasc components.
Only a so cloth or sponge is permied.
Prohibited
Do not plug in the power cable before connecng the water supply hose.
It is prohibited to connue using the product if the product has
a breakdown:
Product is very hot to touch
Product has smoke coming from the back side or the cable part.
Product has an abnormal sound or burning smell.
Product is broken, leaking or damaged
Toilet pan is blocked by water or another foreign object etc.
Prohibited
Persons (including children) with physical, perceptual, intellectual disabilies or lack of
experience and common sense need to use the product under the guidance or
supervision of someone else, or they may cause electric shock, injury or fire to
themselves or others.
Observe at all mes
EN | SAFETY PRECAUTIONS

7
SAFETY PRECAUTIONS | EN
Waterproof socket
(minimum IPX4)
ground electrode
Min 500 mm
∙ If the power cord length is not long
enough, please choose the
professional extension line which is
made by manufacturers!
∙ Only for reference.
This product must be grounded.
An approved & adequately installed EU electricity plug must be used.
Grounding
Do not splash water on this product.
Please provide adequate venlaon to avoid high levels of humidity
which can damage the electronic components.
It is necessary to provide adequate venlaon with a fan,
open door or open window when bathing.
Do not spray water
Do not touch the power cable with wet hands.
Do not reach for a product that has fallen into water.
Unplug immediately!
Wet hands prohibited
This product must be connected to a standard EU voltage power source.
Do not connect the power cable if the cable is damaged or broken.
Do not plug the power cable into a loose electric outlet.
Observe at all mes
Please disconnect the power cable when you clean this product or
detach it from toilet bowl.
Do not supply electrical power to the unit unl the plumbing work
has been completed.
Observe at all mes
Keep the electrical cable away from heated surfaces to prevent a fire hazard.
Also, keep any flammable materials away from this product at all mes.
Use of fire prohibited
Never operate this product if it is not
working properly, if it has been
dropped or damaged, or dropped into
water. Return the product to a service
center for examinaon and repair.
Prohibited
Do not obstruct or put
anything into the dry air
outlet. Do not apply
excessive force to the
shower nozzle.
Prohibited
Do not strain or push the connected hose and tube connecter;
it may cause water leakage.
Never drop or insert any object into any opening or hose.
Use proper plumbing supplies if any modificaon is to be made.
Prohibited
Drain the water from unit and unplug the power if this product is
not going to be used for an extended period of me.
Observe at all mes
Do not stand or sit on
the seat cover lid.
It is not designed to
support a user’s
body weight.
Prohibited
Allow the seat
and lid to close
automacally.
Do not force the
lid closed.
Prohibited
Must install the electric bidet seat with a water proof electrical socket (minimum IPX4).
The locaon of electric plug socket must be 0.5m above the floor and 1.5m away from
shower or bathtub, otherwise it might cause electricity leakage.
Observe at all mes

8
Stop
Press the buon to turn all funcons o. Night
light could be o or on by holding the“stop”
buon more than 2 seconds.
Rear cleaning
Press the buon to start rear cleaning funcon.
Auto o aer 2 mins use or stop by pressing
stop or another funcon. Funcon will stop
when user leaves.
Bidet cleaning
Press the buon bidet funcon on aer sounded
auto o aer 2 mins or o by pressing the stop
buon. Funcon will stop when user leaves.
Dry (warm air drying)
Press the dry buon to begin the warm air drying
funcon. Auto o aer 2 mins or by pressing the
stop buon. Funcon will stop if user leaves.
TEMP °C
Massage
The massage cleaning mode can only be turned on aer the rear / bidet cleaning
mode has been turned on rst. You can switch from rear /bidet mode to massage
mode by pressing the massage buon. the massage mode works by varying water
pressure along to mimic interval massage movements.
Swing
The swing funcon can only be turned on aer the rear /bidet cleaning mode has
been turned on rst. Aer pressing the bidet /rear cleaning mode - press the swing
buon to start the back and forth cleansing. Cleaning mode stops by pressing the
stop buon.
Temp ºC (water temperature levels)
Under rear and bidet cleaning mode - the
pre-set water temprature level is 3 (the
hoest). To decrease the water temper-
ature, press the - buon below TEMP.
There are 3 water temperature levels - hot
(top) / medium / luke warm (boom). The
corresponding light will indicate which
level has been chosen.
Dry (warm air drying levels)
The Dry (warm air drying) funcon has 3
levels of wind speed; high, medium and
low. The inial pre-set level is 3 - high. The
drying speed can be adjusted by pressing
the - sign to reduce the speed and + sign
to increase the speed.
Posion
(adjust spray posion)
Under rear and bidet cleaning
mode - the pre-set spray
posion is 3 (nozzle further
out). To adjust the posion of
the spray nozzle - press the
arrows top or down. There
are 3 levels (further out /
middle and further back), the
corresponding light indicates
the level chosen.
EN | REMOTE CONTROL

9
REMOTE CONTROL & SIDE BUTTON FUNCTIONS | EN
Flow (adjust water ow)
The water ow can be adjusted under the rear / bidet clean-
ing mode. The pre-set ow is high water ow pressure. To
decrease the water ow intensity - press the - buon to the
side of the ow buon. There are 3 water ow pressure set-
ngs - high pressure / medium pressure and low pressure. The
corresponding light indicates the chosen opon.
Seat (adjust temperature)
The heated seat funcon starts when you sit down and press
any cleaning mode. The pre-set temperature level is high. To
decrease the seat temperature level - press the - buon to the
side of the seat icon. There are 3 temperature levels - high /
medium / low. The corresponding light indicates your chosen
opon.
Important note
For children and adults with sensive skin - Please adjust the
seat temperature to medium or low temperature. To prevent
user scalding - the system will automacally decrease the seat
temperature aer being seated for longer than 15 mins.
Side buon funcons:
Cleaning modes
Press the rear / bidet cleaning funcon buons to start. To
stop funcon - press buon again.
Press the drying buon to start. To stop funcon - press the
buon again.
Automac cleaning mode (preset program)
Slide & hold the rear / bidet cleaning funcon buon for more
than 2 seconds to begin a preset cleaning mode. This preset
regime has the following steps; Back and forth rear /bidet
cleaning mode - 30 seconds. Back and forth powerful massage
- 60 seconds. The preset cleaning mode stops when the last
step is nished aer 3 minutes 30 seconds.
Night light
The night light is preset and will automacally turn on when
the bathroom has no light. To turn o this funcon - slide and
hold the rear cleaning funcon for more than 5 seconds to
turn o the preset night light. To turn the night light back on -
repeat the above.
Under rear/front cleaning mode push the side buon forward
to adjust the posion of the nozzle or water volume. Hold the
drying buon more than 2 seconds to switch between nozzle
posion or water volume adjustments. When you hear the
sound you have successfully switched modes.
Under the drying mode push the side buon forward to set
the temperature lower or higher.
Slide button back and forward
Rear cleaning function
Bidet cleaning function
Drying function

10
1. Pull out the power supply cord(A). Make
sure to close the water connec on. Detach
the water inlet hose (B) and drain the water.
2. Press the water ou low bu on on the
back of the seat to drain any excess water
out of the toilet seat.
3. Press the take o bu on to unlock the
hinges, slide the seat backwards to take the
toilet cover of the ceramic.
4. Use warm soapy water (e.g. washing-up
liquid) and a so cloth to clean the surface
& hinges. Do NOT use harsh abrasives or
cleaners containing bleach or alcohol to
clean your toilet seat (e.g. general bathroom
cleaners and wipes), as this can damage the
surface of the seat and the hinge and is not
covered by warranty.
EN | REMOVAL & CLEANING INSTRUCTIONS
A
B
