Galvin Specialised CliniLever Lead Safe TM-BASX Instruction sheet

Version 1, 14th April 2020, Page 1of 5
CliniLever®Lead Safe™SS Basin Mixer
PRODUCT CODES:
TM-BASX
TM-BASXD
SPECIFICATIONS
Lead Safe™stainless steel construction
Clean hygienic design
Low maintenance and easy to operate
Smooth round designs to facilitate easy cleaning and help reduce dirt and bacteria growth.
IMPORTANT: All CliniLever®Taps are tested in accordance with AS/NZS 3718 and leave our premises in
good working order.
As ‘lead free’ is not currently defined by low in Australia and New Zealand, we have based our definition of Lead Safe™ on the requirements of s1417 of the USA’s Safe Drinking Water Act (SDWA)
and the relevant US standards NSF61 / NSF372. The SDWA defines ‘lead free’ as “not more than a weighted average of 0.25% lead when used with respect to the wetted surface of pipes, pipe
fittings, plumbing fittings and fixtures”.
TECHNICAL DATA
Inlet
½” BSP –Female (Flexi-hoses)
Outlet
Aerator
Headwork
Ceramic Cartridge
Working Pressure Range (kPa)
Min
50
Max
500
Working Temperature Range (°C)
Min
5
Max
80
Nominal Flow Rate (LPM)
5.88
Construction
Stainless Steel
Finish
Stainless Steel
NOTE: Galvin Engineering continually strive to improve their products. Specifications may change without
notice.
DIMENSIONS –TM-BASX
TM-BASXD
TM-BASX
Rough-In Dimensions
Ø35mm

Version 1, 14th April 2020, Page 2of 5
DIMENSIONS –TM-BASXD
INSTALLATION
INSTALLATION COMPLIANCE: Galvin Engineering products must be installed in accordance with these
installation instructions and in accordance with AS/NZS 3500, the PCA and your local regulatory requirements.
Water and/or electrical supply conditions must also comply to the applicable national and/or state standards.
Failing to comply with these provisions shall void the product warranty and may affect the performance of the
product.
1. Fit Mounting Hardware and Hoses
Screw in and tighten flexi-hoses.
Fully screw in threaded rods as shown.
2. Fit Tap
Ensure the basin mounting hole for the tap is
as per the rough-in dimensions.
Ensure the O-ring is present underneath the
tap.
Carefully fit the flexible hoses and threaded
rods through the basin hole as shown.
O-Ring
Rough-In Dimensions
Ø35mm

Version 1, 14th April 2020, Page 3of 5
3. Secure Tap
Fit the mounting gasket and bracket as
shown.
Screw hex nuts on threaded rods finger
tight.
4. Tighten Installation
Tighten the hex nuts using the provided tool
as shown.
Ensure the tap body doesn’t move on the
basin once tightened.
5. Connect Water and Test
We recommend the use of wall mounted shut off valves (not included).
Ensure water supply lines are flushed before connecting.
Connect the flexible hoses to the mains water as shown ensuring the hot and cold connections are
correct.
Test the tap for leaks and correct operation.
Hot Water
Cold Water
Wall Valves
(Not Included)

Version 1, 14th April 2020, Page 4of 5
REMOVE & INSPECT FLOW REGULATING AERATOR
1. Remove Flow Regulating Aerator Housing
Using the supplied tool (pictured) remove the
flow regulating aerator housing as shown.
Ensure the flats on the outlet line up with the
flats on the tool and turn anti-clockwise.
2. Remove & Inspect
Remove the housing and flow regulating
aerator.
Inspect for debris and clean. Replace if
necessary.
3. Reassemble
Reverse steps 2 & 1 to reassemble ensuring correct orientation.
Test for leaks and correct operation
TROUBLESHOOTING
PROBLEM
CAUSE
RECTIFICATION
Tap is leaking
Headworks are worn or
damaged
Remove and inspect the headworks,
remove debris and/or replace parts if
damaged
Tap incorrectly installed
Follow the installation steps above when
fitting the tap.
Tap has inconsistent flow
Blocked flow regulating aerator
Follow the instructions above to remove
flow regulating aerator from the body and
check for debris. Install an inline strainer
to stop further blockages.
Tap moves on basin
Insufficiently tightened
Follow the steps above in relation to
tightening the installation.
Water temperature is opposite to
the handle markings
Inlet hoses connected
incorrectly
Connect the inlet hoses to the correct
inlets as shown above.
Supplied Tool
Flow Regulating
Aerator

Version 1, 14th April 2020, Page 5of 5
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty
Ltd. With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied.
Galvin Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including but
not limited to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download
from www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free
from operational defects in workmanship and materials for the warranty period as shown on the schedule in the
manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any defective
products manufactured by Galvin Engineering without charge, so long as the terms of the Manufacturer’s
warranty are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for
breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other
property which is damaged if this product does not work properly, other costs resulting from labour charges,
delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions,
chemical, electrical or any other circumstances over which Galvin Engineering has no control. This warranty
shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or
alteration of the product.
