Bender RCMA423 User manual

Manual EN
LINETRAXX® RCMA423
Residual current monitor
for monitoring AC- and (pulsed) DC-currents IΔ = 30 mA…3 A
in TN- and TT systems
RCMA423_D00063_04_M_XXEN/12.2023

2 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
Table of contents
1General information 5
1.1 How to use the manual.................................................................................................................................5
1.2 Indication of important instructions and information.......................................................................5
1.3 Signs and symbols...........................................................................................................................................5
1.4 Service and Support....................................................................................................................................... 5
1.5 Training courses and seminars...................................................................................................................6
1.6 Delivery conditions......................................................................................................................................... 6
1.7 Inspection, transport and storage.............................................................................................................6
1.8 Warranty and liability.....................................................................................................................................6
1.9 Disposal of Bender devices..........................................................................................................................7
1.10 Safety.................................................................................................................................................................... 7
2Function 8
2.1 Intended use......................................................................................................................................................8
2.2 Device features................................................................................................................................................. 8
2.3 Function...............................................................................................................................................................8
2.3.1 Connection monitoring.................................................................................................................................9
2.3.2 Fast response value query........................................................................................................................... 9
2.3.3 Automatic self test.......................................................................................................................................... 9
2.3.4 Manual self test................................................................................................................................................ 9
2.3.5 Functional faults...............................................................................................................................................9
2.3.6 Set the number of reload cycles................................................................................................................9
2.3.7 Assigning alarm categories to alarm relays K1/K2..............................................................................9
2.3.8 Time delays t, ton and toff...............................................................................................................................9
2.3.9 Residual current monitoring in window discriminator mode...................................................... 10
2.3.10 Password protection (on, OFF)................................................................................................................ 10
2.3.11 Factory setting FAC...................................................................................................................................... 10
2.3.12 Erasable history memory............................................................................................................................10
2.3.13 External, combined test/reset button T/R........................................................................................... 10
2.3.14 Fault memory..................................................................................................................................................10
3Installation, connection and commissioning 11
3.1 Wiring.................................................................................................................................................................11
3.2 Commissioning...............................................................................................................................................12
RCMA423_D00063_04_M_XXEN/12.2023 3

Table of contents
4Operation and setting 13
4.1 Display elements in use..............................................................................................................................13
4.2 Function of the operating elements......................................................................................................14
4.3 Menu structure...............................................................................................................................................14
4.4 Display in standard mode..........................................................................................................................16
4.5 Display in menu mode................................................................................................................................16
5Parameter settings 18
5.1 Response value setting for overcurrent............................................................................................... 18
5.2 Fault memory..................................................................................................................................................19
5.3 Alarm relays.....................................................................................................................................................19
5.4 Alarm categories............................................................................................................................................20
5.5 Set the time delays.......................................................................................................................................21
5.6 Changeover: overcurrent/undercurrent/window mode................................................................ 22
5.7 Password protection.................................................................................................................................... 22
5.8 Factory settings..............................................................................................................................................24
5.9 Device information query.......................................................................................................................... 24
5.10 History memory query................................................................................................................................ 24
6Technical Data 25
6.1 Factory settings..............................................................................................................................................25
6.2 Error codes.......................................................................................................................................................25
6.3 Tabular data.................................................................................................................................................... 25
6.4 Standards, approvals and certifications................................................................................................30
6.5 Ordering information...................................................................................................................................30
6.6 Document revision history........................................................................................................................ 31
4 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
1 General information
1 1 How to use the manual
ADVICE
This manual is intended for qualified personnel working in electrical engineering and electronics!
Part of the device documentation in addition to this manual is the enclosed supplement ‘Safety
instructions for Bender products’.
ADVICE
Read the operating manual before mounting, connecting and commissioning the device. Keep the
manual within easy reach for future reference.
1 2 Indication of important instructions and information
DANGER
Indicates a high risk of danger that will result in death or serious injury if not avoided.
WARNING
Indicates a medium risk of danger that can lead to death or serious injury if not avoided.
CAUTION
Indicates a low-level risk that can result in minor or moderate injury or damage to property if not
avoided.
ADVICE
Indicates important facts that do not result in immediate injuries. They can lead to malfunctions if the
device is handled incorrectly.
Information can help to optimise the use of the product.
1 3 Signs and symbols
Disposal Protect from moisture Protect from dust
Temperature range Recycling RoHS directives
1 4 Service and Support
Information and contact details about customer service, repair service or field service for Bender devices are
available on the following website: Fast assistance | Bender GmbH & Co. KG.
RCMA423_D00063_04_M_XXEN/12.2023 5

General information
1 5 Training courses and seminars
Regular face-to-face or online seminars for customers and other interested parties:
www.bender.de > know-how > seminars.
1 6 Delivery conditions
The conditions of sale and delivery set out by Bender GmbH & Co. KG apply. These can be obtained in printed
or electronic format.
The following applies to software products:
Die Elektroindustrie
‘Software clause in respect of the licensing of standard software as part of deliveries,
modifications and changes to general delivery conditions for products and services in the
electrical industry’
1 7 Inspection, transport and storage
Check the shipping and device packaging for transport damage and scope of delivery. In the event of
complaints, the company must be notified immediately, see ‘www.bender.de > service & support.’.
The following must be observed when storing the devices:
1 8 Warranty and liability
Warranty and liability claims for personal injury and property damage are excluded in the case of:
•Improper use of the device.
•Incorrect mounting, commissioning, operation and maintenance of the device.
•Failure to observe the instructions in this operating manual regarding transport, commissioning, operation
and maintenance of the device.
•Unauthorised changes to the device made by parties other than the manufacturer.
•Non-observance of technical data.
•Repairs carried out incorrectly.
•The use of accessories or spare parts that are not provided, approved or recommended by the
manufacturer.
•Catastrophes caused by external influences and force majeure.
•Mounting and installation with device combinations not approved or recommended by the manufacturer.
This operating manual and the enclosed safety instructions must be observed by all persons working with the
device. Furthermore, the rules and regulations that apply for accident prevention at the place of use must be
observed.
6 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
1 9 Disposal of Bender devices
Abide by the national regulations and laws governing the disposal of this device.
For more information on the disposal of Bender devices, refer to
www.bender.de > service & support.
1 10 Safety
If the device is used outside the Federal Republic of Germany, the applicable local standards and regulations
must be complied with. In Europe, the European standard EN 50110 applies.
DANGER Risk of fatal injury due to electric shock!
Touching live parts of the system carries the risk of:
•Risk of electrocution due to electric shock
•Damage to the electrical installation
•Destruction of the device
Before installing the device and before working on its connections, make sure that the installation
has been de-energised. The rules for working on electrical systems must be observed.
RCMA423_D00063_04_M_XXEN/12.2023 7

Function
2 Function
2 1 Intended use
The AC/DC sensitive residual current monitor RCMA423 is designed for use in earthed systems (TN and TT
systems) where DC and AC fault currents may occur.
These are in particular loads containing six-pulse rectifiers or one way rectifiers with smoothing, such as
converters, battery chargers, construction site equipment with frequency-controlled drives. Two separately
adjustable response ranges allow to distinguish between prewarning (IΔn1 = 50…100 % of the set response
value IΔn2) and alarm (IΔn2). Since the values are measured with measuring current transformers, the RCMA423 is
nearly independent of the nominal voltage and the load current of the system being monitored.
In order to meet the requirements of the applicable standards, customised parameter settings must be made
on the equipment in order to adapt it to local equipment and operating conditions. Please heed the limits of
the range of application indicated in the technical data. Any use other than that described in this manual is
regarded as improper.
2 2 Device features
•AC/DC sensitive residual current monitor Type B according to IEC 62020 and IEC 60755
•Two separately adjustable response ranges (prewarning, alarm)
•Adjustable switching hysteresis
•R.m.s. value measurement
•Starting delay, response delay and delay on release
•Measured value display via multi-functional LC display
•Alarm indication via LEDs (AL1, AL2) and changeover contacts (K1, K2)
•N/C operation or N/O operation selectable
•Password protection against unauthorized parameter changing
•Fault memory function can be switched off
•CT connection monitoring
2 3 Function
Once the supply voltage US is applied, the starting delay is activated. Measured values changing during this
time do not influence the switching state of the alarm relays.
Die Differenzstrommessung erfolgt über einen externen Messstromwandler CTUB101- CTBC20…210(P)
The currently measured value is shown on the LC display. In this way any changes, for example when circuits
are connected to the system, can be recognized easily.
If the measured value exceeds one or both response values, the response delays ton1/2 start running. Once the
response delay ton1/2 has elapsed, the K1/ K2 alarm relays switch and the alarm LEDs AL1/AL2 light up.
If the residual current falls below the release value (response value minus hysteresis), the delay on release toff
begins. Once the release delay toff has elapsed, the alarm relays return to their original state and the alarm LEDs
AL1/AL2 go out. If the fault memory is activated, the alarm relays remain in the alarm state and the LEDs light
until the reset button is pressed or until the supply voltage is interrupted.
The device function can be tested using the test button. The parameterization of the device can be carried out
via the LC display and the function keys integrated in the front plate and can be password-protected.
8 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
2 3 1 Connection monitoring
The CT connections are continuously monitored. In the event of a fault, the alarm relays K1 / K2 switch without
delay, the alarm LEDs AL1 / AL2 / ON flash (Error Code E.01). After eliminating the fault, the alarm relays
automatically return to their initial position, provided that the fault memory M is deactivated. With the fault
memory activated, K1/K2 return to their initial position by pressing the reset button R. A second cascaded
measuring current transformer will not be monitored.
2 3 2 Fast response value query
With the display in standard mode, the currently measured response values IΔn1 and IΔn2 can be queried
pressing the Up and Down keys ( < 1.5 s). Switchover to the Menu mode is not required. If you want to exit the
fast response value query, press the enter key.
2 3 3 Automatic self test
The device automatically carries out a self test after connecting to the system to be monitored and later every
24 hours. During the self test internal functional faults will be detected and appear in form of an error code on
the display.
The alarm relays are not checked during this test.
2 3 4 Manual self test
After pressing the test button for > 1.5 s, the device carries out a self test. During this test, internal functional
faults are detected and will be displayed in form of an error code. The alarm relays are not checked during this
test.
While the test button T is pressed and held down, all device-related display elements appear on the display.
2 3 5 Functional faults
If an internal functional fault occurs, all three LEDs flash. An error code will appear on the display (E01…E32). In
such a case please contact the Bender Service.
2 3 6 Set the number of reload cycles
If faults occur only temporarily, but recurrently, in the system being monitored, with the fault memory M
deactivated, the alarm relays would switch synchronously to the error status. RL in the out menu can be
used to limit the number of these changeover processes. As soon as the preset number of switching cycles is
exceeded, the fault memory will come on and an activated alarm remains stored.
2 3 7 Assigning alarm categories to alarm relays K1/K2
The alarm categories device error, residual current IΔn1, residual current IΔn2 or alarm by device test can be
assigned to the alarm relays via the ‘out’ menu.
2 3 8 Time delays t, ton and toff
The times t, ton and toff described below, delay the output of alarms via LEDs and relays.
Starting delay t
After connection to the supply voltage, the alarm indication is delayed by the preset time t (0…10 s).
Response delay ton1/2
RCMA423_D00063_04_M_XXEN/12.2023 9

Function
If the residual current increases above or falls below the response value the response time tan expires. After the
expiry of the response time an alarm is signalled. A set response delay ton1/2 (0…10 s) adds up to the device-
related operating time tae and delays alarm signalling (total delay time tan = tae + ton).
If the residual current fault changes from a value above the response value to a value below the response
value, an alarm will not be signalled.
Delay on release toff
When no alarm exists after deactivating the fault memory, the alarm LEDs go out and the alarm relays switch
back to their initial position. After activating the delay on release (0…99 s), the alarm state is continuously
maintained for the selected period.
2 3 9 Residual current monitoring in window discriminator mode
Change the measuring principle by selecting the window mode (SEt / In). In the window discriminator mode,
the threshold values I1 and I2 represent the upper and the lower value. If the measured value is not within this
area, an alarm is initiated by the device.
2 3 10 Password protection (on, OFF)
When the password protection is activated (on), settings are only possible after entering the correct password
(0…999).
2 3 11 Factory setting FAC
After activating the factory setting, all settings previously changed are reset to delivery status.
2 3 12 Erasable history memory
The first alarm value that occurs will be saved in this memory. The memory can be cleared via the menu HiS.
2 3 13 External, combined test/reset button T/R
Reset = Pressing the external button < 1.5 s
Test = Pressing the external button > 1.5 s
2 3 14 Fault memory
The fault memory can be activated, deactivated or set to continuous mode (con). If the fault memory is set to
‘con’ mode, the alarm parameters remain stored even on failure of the supply voltage. Stored alarms can be
reset by means of the reset button R.
10 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
3 Installation, connection and commissioning
Only skilled persons are permitted to carry out the work necessary to install, put into service and run a
device or system.
DANGER Risk of fatal injury due to electric shock!
Touching live parts of the system carries the risk of:
•Risk of electrocution due to electric shock
•Damage to the electrical installation
•Destruction of the device
Before installing the device and before working on its connections, make sure that the installation
has been de-energised. The rules for working on electrical systems must be observed.
Dimension diagram, drawing for screw mounting, push-wire terminal connection
36
93
74.5
90 45 70.5
47.5
31.1
Click
107
100
M4
M4
B98060008
All dimensions in mm.
The front plate cover is easy to open at the lower part marked by an arrow.
Mounting
DIN rail mounting
Snap the rear mounting clip of the device into place in such a way that a safe and tight fit is ensured.
Screw fixing
Use a tool to move the rear mounting clips (a second mounting clip required, see ordering information) to a
position that it projects beyond the enclosure. Then fix the device using two M4 screws.
3 1 Wiring
Connect the device according the wiring diagram.
Observe the manuals of the respective measuring current transformer.
RCMA423_D00063_04_M_XXEN/12.2023 11

Installation, connection and commissioning
Wiring diagram
Us
+12V
–12V
T
GND
S1(k)
S2(l)
CTUB101-
CTBC...
–12V k
T
lGND
+12V
1
CTX...
AL1
AL2
T/R
1
T/R
A1
1411 12
2421 22
A2
Terminal Connections
A1, A2 Connection for supply voltage Us
1 Socket for the connecting cable CTX… to the easuring current transfor er
T/R Connection for co bined test and reset button
11, 12, 14 Alar relay K1
21, 22, 24 Alar relay K2
3 2 Commissioning
Prior to commissioning, check proper connection of the residual current monitor.
12 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
4 Operation and setting
4 1 Display elements in use
A detailed description of the meaning of the display elements in use is given in the table below.
on off
Hys M
t
%
RI. n12
s
k
mA
>
<
Display-Elemente
Element Function
RL Reload function with e ory = off (L = I.)
I2 Response value IΔn2 as A (Alar 2, ain alar )
I1 Response valueIΔn1 as % of IΔn2 (Alar 1, prewarning)
r1, 1
r2, 2
Alar relay K1
Alar relay K2
I Hys, % Response value hysteresis as %
ton1
ton2
t
toff
Response delayton1 (K1)
Response delay ton2 (K2)
Starting delay t
Delay on release toff (K2)
M Fault e ory active
Relay operating ode K2
Password protection enabled
RCMA423_D00063_04_M_XXEN/12.2023 13

Operation and setting
4 2 Function of the operating elements
Operating elementes
AL1
AL2
Element Function
ON, green LED ON lighting continuously: Power On
Flashing LED ON: Syste fault or connection onitoring fault
AL1, yellow LED AL 1 lights: Response value 1 reached (IΔn1)
AL2, yellow LED AL 2 lights: Response value 2 reached (IΔn2)
TTest button (> 1.5 s): To indicate the available display ele ents,
to start a self test
R Reset button (> 1.5 s): Deleting the fault e ory
Up/Down key (< 1.5 s): Menu ite s/values
MENU MENU key (> 1.5 s): Starting the enu ode
Enter key (< 1.5 s): Confir enu ite , sub enu ite and value.
Enter key (> 1.5 s): Back to the next higher enu level.
4 3 Menu structure
All adjustable parameters are listed in the columns ‘menu item’ and ‘adjustable parameters’. A display-like
representation is used to illustrate the parameters in the column menu item. Different alarm categories can
be assigned to the alarm relays K1, K2 via the submenus r1, r2. This is done by activation or deactivation of the
respective function.
Menu Sub menu Menu item Activation Adjustable parameter
>I2 - (HI) IΔn2 (alar 2, ain alar )
>I1 - (HI) IΔn1 as % of IΔn2 (alar 1, prewarning)
AL
(response
values)
Hys - Hysteresis IΔn1 / IΔn2
14 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
Menu Sub menu Menu item Activation Adjustable parameter
M ON Fault e ory
1- Operating ode K1 (n.c.)
2 - Operating ode K2 (n.c.)
RL - Reload function ( e ory = off )
1 Err ON Device error at K1
r1 I1 ON PrewarningIΔn1 at K1
r1 I2 OFF Main alar IΔn2 at K1
r1 (K1: assign ent
alar category)
1 tES ON Device test
2 Err ON Device error at K2
r2 I1 OFF PrewarningIΔn1 at K2
r2 I2 ON Main alar IΔn2 at K2
out
(output
control)
r2 (K2: assign ent
alar category)
2 tES ON Device test
t on 1 - Response delay K1
t on 2 - Response delay K2
t - Starting delay
t
(ti ing check)
t off - Delay on release K1/K2
I 12 HI
Selectable para eters:
High (HI),
window function (In),
low (Lo)
OFF Para eter setting via password
FAC - Restore factory settings
Set
(device
control))
SYS - Function blocked
InF - Display hardware and software version
HiS Clr - History e ory for the first alar
value, erasable
RCMA423_D00063_04_M_XXEN/12.2023 15

Operation and setting
4 4 Display in standard mode
By default, the currently measured residual current is displayed. The current response values I1 (prewarning)
and I2 (alarm) can be displayed using the Up and Down key. Press the Enter key to return to the measured
value.
M
m
A
I2
mA
>
M
I1
m
A
>
In the standard mode, the currently set response values I1 and I can be displayed using the Up and Down
keys.
4 5 Display in menu mode
AL
out
t
SEt
InF
HiS
ESC
M
m
A
t > 1,5 s
t > 1,5 s
t > 1,5 s
t < 1,5 s
t < 1,5 s
ESC
Parameter query and setting: overview
Menu item Adjustable parameter
AL
Response values query and setting
•Residual currentI2 (IΔn2) (AL2)
•Residual currentI1 (IΔn1) (AL1)
•Hysteresis of the response: % Hys
16 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
Menu item Adjustable parameter
UT
Configuration of the fault e ory and the alar relays
•Activate/deactivate the fault e ory or assign continuous ode (on/off/con)
•Select N/O operation (n.o.) or N/C operation (n.c.) individually for each K1/K2
•Specify the nu ber of the reload cycles
•Assign the alar category I1 (IΔn1) or I2 (IΔn2), relay test or device error individually to K1/K2 (1, r1/
2, r2).
T
Set delays
•Response delay ton1 /ton2
•Starting delay t
•Delay on release toff (LED, relay)
SEt
Device control para eter setting
•Select the appropriate para eter for response values: overcurrent ode (HI), undercurrent ode
(Lo) or window ode (In).
•Enable or disable password protection, change the password.
•Restore factory settings.
•Service enu SyS blocked
InF Query hard and software version
HiS Query the first stored alar value
ESC Move to the next higher enu level (back)
RCMA423_D00063_04_M_XXEN/12.2023 17

Parameter settings
5 Parameter settings
An example is given here on how to change the alarm response value I1 (IΔn1). It is presumed that the option
overcurrent (HI) has been selected in the SEt/I 12 menu (factory setting). Proceed as follows:
1. Press the MENU/Enter key for more than 1.5 seconds. The flashing short symbol AL appears on the display.
2. Confirm with Enter. The parameter response value > I2 flashes, in addition the associated overcurrent
value > 30 mA appears.
3. Use the Down key to select the parameter response value I1. The parameter > I1 flashes, in addition the
associated percentage value for prewarning 50 % of I2 appears.
4. Confirm with Enter. The current value for prewarning appears on the flashing display.
5. Use the Up or Down key to set the appropriate prewarning value. Confirm with Enter. I1 flashes.
6. You can exit the menu by:
– pressing the Enter key for more than 1.5 seconds or
– selecting the menu item ESC and confirming with Enter
to reach the next higher level.
The currently active segments are flashing! In the figures below, the segments where device settings can be
carried out are highlighted by an oval. The menu mode can be reached by pressing the MENU key for more
than 1.5 seconds.
5 1 Response value setting for overcurrent
Increasing the response value I2 (main alarm overcurrent IΔn2)
I
2
m
A
>
I2
mA
>
I2
mA
>
I2
mA
>
Increasing the response value I1 (prewarning overcurrent IΔn1)
I
2
m
A
>
%
I
1
>
%
I
1
>
I1
%
>
I1
%
>
1x
18 RCMA423_D00063_04_M_XXEN/12.2023

LINETRAXX® RCMA423
Setting the hysteresis of the response values IΔn1, IΔn2
I
2
mA
>
Hys
%
I
Hys
%
I
Hys
%
I
Hys
%
I
2x
5 2 Fault memory
Setting the fault memory to con mode
M M
M
M M
5 3 Alarm relays
Setting the alarm relay K1 to N/O operation (n o )
M
1 1
1 1
RCMA423_D00063_04_M_XXEN/12.2023 19

Parameter settings
Setting the number of reload cycles
M
RI. RI.
RI. RI.
3x
> 1,5 s
2x
5 4 Alarm categories
Overcurrent, undercurrent and device-related errors of the residual current monitor can be assigned to the
alarm relays K1 (r1, 1) and K2 (r2, 2). By default, the alarm relays K1 and K2 signal prewarning and alarm in case
of overcurrent and device-related errors.
Alarm relay K1: Deactivating the category device error
M
on
1
on
1
off
1
off
1
> 1,5 s
4x
3x
Alarm relay K1: Deactivating the category response value I1
M
on
1
on
1
I
on
1
I
off
1I
off
1I
> 1 5 s
4x
3x
20 RCMA423_D00063_04_M_XXEN/12.2023
