Besam SW200i User manual

Besam Swing Door Operator
SW200i
Owners Manual
Original instructions
ASSA ABLOY, the global leader in door opening solutions

CONTENTS
3Congratulations on your new automatic door! ........................................................
3Electronic equipment reception interference ..........................................................
4Environmental requirements ..................................................................................
4Product liability .......................................................................................................
4Warranty .................................................................................................................
5Service ...................................................................................................................
5Intended use ...........................................................................................................
6How the SW200i works ..........................................................................................
6Technical specification ............................................................................................
7Regular safety checks ............................................................................................
11General accessories ...............................................................................................
11Safety accessories .................................................................................................
11Troubleshooting ......................................................................................................
12Maintenance plan ...................................................................................................
12Other products from Besam ...................................................................................
© All rights in and to this material are the sole property of Besam US Inc.. Copying, scanning, alterations or
modifications are expressly forbidden without the prior written consent of the applicable company within Besam
US Inc.. Rights reserved for changes without prior notice.
Backtrack information: folder: Library, version: a349, date: 2012-03-19, time: 14:47:29, state: Working
1007717-US-1.0Issue 2012-03-202

Congratulations on your new automatic door!
Besam has developed automatic doors for more than 40 years. State-of-the-art technology and
carefully tested materials and components provide you with a superior product.
As with all other technical products, your automatic door requires periodic maintenance and
service. It is essential that you know your automatic door (system) and that you recognize the
importance of maintaining it in compliance with applicable standards for safety.
Your local Besam-authorized representative is familiar with these standards, as well as all ap-
plicable local codes and Besam recommendations for power-operated pedestrian doors. Service
and adjustments performed by your Besam-authorized representative, will ensure safe and
proper operation of your automatic door unit.
WARNING!
Failure to observe the information in this manual may result in personal injury
or damage to equipment.
To reduce the risk of injury to persons - use this operator with single or double
pedestrian swinging or folding doors only.
Save these instructions for future reference.
Electronic equipment reception interference
The equipment complies with the European EMC directive (US market FCC Part 15), provided
installed according to Installation and Service manual.
The equipment may generate and use radio frequency energy and if not installed and used
properly, it may cause interference to radio, television reception or other radio frequency type
systems.
If other equipment does not fully comply with immunity requirements interference may occur.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•Re-orient the receiving antenna.
•Relocate the receiver with respect to the equipment.
•Move the receiver away from the equipment.
•Plug the receiver into a different outlet so that equipment and receiver are on different
branch circuits.
•Check that protective earth (PE) is connected.
If necessary, the user should consult the dealer or an experienced electronic technician for ad-
ditional suggestions.
3Issue 2012-03-201007717-US-1.0

Environmental requirements
Please act according to your local regulations and dispose of your unused product(s) and
packaging properly. The correct disposal will help prevent potential negative consequences
for the environment and human health.
Besam products are equipped with electronics and may also be equipped with batteries containing
materials which are hazardous to the environment. Remove this material from the operator
before it is scrapped and make sure that it is disposed of properly as was done with the packag-
ing.
This manual contains the necessary details and instructions for the installation, maintenance
and service of the Swing Door Operator Besam SW200i.
Product liability
According to regulations, the following are the responsibility of the owner or caretaker of the
equipment
•that the equipment operates correctly, so that it gives sufficient protection in regard to
safety and health
•that the equipment is operated and regularly maintained, inspected and serviced by someone
with documented competence in the equipment and in applicable regulations
•that a journal is kept of inspection, maintenance and service records including the provider
•that inspection covers the emergency opening function (when applicable)
•that the closing force is appropriate for the door size on fire-approved door systems (when
applicable)
Warranty
Besam warrants its products to be free from defects in material and workmanship under intended
use and service for a warranty time of 12 months, beginning at time of delivery. This warranty
extends only to the original buyer of the equipment.
Besam warrants that the software will operate substantially in accordance with its functional
descriptions and that it has been recorded on non-defective media.
The Besam warranty does not apply to
•That the software will be error-free or operate without interruption
•General wear and tear on the system
•Fuse, disposable batteries and glass damage
•System deviations caused by installer other than Besam
•System that has been altered or damaged by vandalism or misuse
•System that has been additionally equipped with non-Besam original branded parts and/or
spare parts
•Unrequired visits due to poor client communication (door working when our technician
arrives, reset, power discontinuation)
•Adjustments (closing and opening speed and also detection field radars) due to customer
requests (excludes operational adjustments thought to create a hazard)
•Water damage
•Adverse weather conditions
1007717-US-1.0Issue 2012-03-204

•Any damage caused, directly or indirectly, by a circumstance beyond the control of the
applicable company within Besam US Inc., such as industrial dispute, fire, natural disaster,
war, extensive military mobilization, insurrection, requisition, seizure, embargo, restrictions
in the use of power and defects or delays in deliveries by sub-contractors caused by any
such circumstances
Please note:
•Non-compliance with manufacturers care and maintenance recommendations may void
the warranty.
•Besam -authorized resellers shall extend this warranty to end-users only, but have no au-
thority to extend a greater or different warranty on behalf of Besam.
•A service agreement with Besam will help secure the availability of a fully operational
system and will give priority at call-out, thus minimizing the time that the equipment is
unusable.
Service
Regular inspections by a trained and qualified person, and the frequency of service
occasions, should at minimum be made according to national regulations or industry
standard, in the absence of a national regulation. Environmental aspects shall also be
considered. This is especially important when the installation concerns a fire-approved
door or a door with an emergency-opening function. To extend the life of your invest-
ment and ensure safe and reliable operation of the door, we recommend a minimum
of 2 visits per year or more, depending on usage and operating conditions. Talk to
your Besam representative for the best solution for your installation and to learn more
about Besam Pro-Active Care! For contact information, see last page of this manual.
Intended use
The door is designed to offer continuous use, a high degree of safety and maximum lifetime.
The Besam SW200i is an automatic swing door operator developed to facilitate entrances to
buildings and within buildings.
The SW200i is a combination of a Heavy Duty (HD) operator for large heavy doors as well as
an low energy electromechanical operator (LE), mainly suitable for almost all types of internal
swing doors - but also external doors. This operator will be mainly used in the health care
sector.
The operator itself is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the operator by a person responsible for
their safety.
This does not however prevent those persons to use the door where the operator is installed.
Do not let children play with the door or the fixed controls.
Keep remote controls away from children.
For installation and maintenance see Installation and Service manual 1007718.
5Issue 2012-03-201007717-US-1.0

How the SW200i works
The swing door operator SW200i uses a DC motor which is connected to the output shaft by
a combination of a bevel gear and spur gears. The arm system that is connected to the output
shaft opens the door in a wall mounted application.
There is also an adjustable spring mechanism connected to the output shaft. During opening
of the door, the clock spring is tensioned by the rotation of the output shaft. During the closing
cycle, the accumulated spring force is acting in the closing direction. The spring force can be
adjusted so there is appropriate force to close the door when it is operated manually or in case
of a power failure.
To activate the operator you can use a manual activator (elbow switch) or an automatic activator
(radar device). It is also possible –where local standards allow –to activate the operator by
just pushing the door, if Push & Go is selected.
After the door has been activated it will open and stay open for a specified Hold Open Time
(HOT). When the HOT has elapsed the door will close.
The SW200i can be set in three or four different modes, depending on programme selector
type, see table below.
In fully manual use (or in case of a power failure) the SW200i acts as a normal door closer.
FunctionPosition
The door is closed. The door cannot be opened with inner and outer activation
units. The door is locked if an electromechanical locking device has been
fitted. The door can be opened with a key switch (if fitted).
OFF
Passage from inside only. The door is normally locked if an electromechan-
ical locking device has been fitted. The door can only be opened with the
inner activation unit and with a key switch (if fitted).
EXIT
The door can be opened with the inner and outer manual and/or automatic
activators. The electric strike, if fitted, is open.
AUTO
Normal
position
The door is held permanently open by the motor.OPEN
Technical specification
Besam US Inc.Manufacturer:
1900 Airport Road, US-Monroe, NC 28110Address:
SW200iType:
120 V AC +10/-15%, 50/60 HzMains power supply:
Max. 300 WPower consumption:
The SW200i complies with ANSI/BHMA.Standards:
1007717-US-1.0Issue 2012-03-206

Regular safety checks
To help you fulfil the national/international requirements and to avoid malfunction and risk
for injuries, we have provided the following checklist.
Do not use if repair or adjustment is necessary.
If problem
occurs
Daily Action
Activate your operator and check visually, fastening of
•operator
1
•arm system
2
•position switch
3
•hinges
4
•door and glass
5
Also inspect your operator and check visually for
•sharp edges on the door leaf and door frame (if any)
6
•condition of door seals
7
•finger protection
8
•and finally that the complete door runs properly and closes slowly in a smooth way
Set the programme selector in OFF mode and check that the operator and lock work together. Also
check that the lock really secures the door
9
.
Activate the manual activation units
10
if any, and walk towards the door. Check that the door has
opened sufficiently while you pass the entrance/exit.
Then proceed with the automatic activation units
11
in the same way.
Check the non-monitored safety sensors
12
if any, by standing in the swing path and activate the
operator. The door must not hit you when opening nor when closing. If you are unsure of which type
of sensor you have, please contact your Besam representative.
Set the programme selector in AUTO mode. Push the door manually
in escape direction and make sure that no object or function will prevent
the door from opening. Also make sure the escape route is free for use.
By law, these tests must be performed regu- larly by trained personnel.
Escape
doors
Let the door close after an impulse and make sure that no object will
prevent the door from closing and locking (if demanded).
Fire
doors
Contact your Besam representative. For contact information, see last page.=
Take appropriate measures.=
7Issue 2012-03-201007717-US-1.0

FUNCTION AND VISUAL INSPECTION
CLEANING
The best way to remove dust and dirt from the SW200i is to use water and a soft cloth or a sponge. A gentle de-
tergent may be used. To maintain the quality of the enamel layer, the surfaces should be cleaned once/four months
period. The cleaning should be documented. To avoid damages to the profiles the brushes/weather stripping must
be vacuum-cleaned weekly.
•Do not expose windows, doors or profiles to alkalis. Both aluminium and glass are sensitive to alkalis.
•Do not clean with high pressure water. Operator, programme selector and sensor may be damaged and water
may enter the profiles.
•Do not use polishing detergent.
•Do not scrub with materials like Scotch-brite, as this will cause mechanical damage.
1007717-US-1.0Issue 2012-03-208

SIGNAGE according to ANSI /BHMA A 156.19 (Low energy)
50±12"
50±12"
34-48"
50±12"
C
L
Apply to both sides of the door.
When using a wall switch,
apply to both sides of the door.
Apply the push decal to the push
side and the pull decal to the pull
side of the door.
Push plate
PRESS
TO OPEN
21-24-005
21-24-005
PUSH TO
OPERATE
21-24-006
PUSH TO
OPERATE
21-24-006
PULL TO
OPERATE
21-24-008
ACTIVATE
SWITCH TO
OPERATE
21-24-007
ACTIVATE
SWITCH TO
OPERATE
21-24-007
A
B
E
PRESS
TO OPEN
C
D
AUTOMATIC
DOOR
CAUTION
75-20-102
AUTOMATIC
DOOR
CAUTION
75-20-102
If problem
occurs
Action
Check that all required signage is applied and intact. Mandatory indicates that the signage is required
by European directives and equivalent national legislation outside the European Union.
Dual Side “AUTOMATIC DOOR / CAUTION”
A
Operator designed for disabled people:
Recommended, if applicable (applied to both sides of the door)
B
Dual Side “Activate Switch to Operate”
C
Push side “PUSH TO ACTIVATE”
Pull side “PULL TO ACTIVATE”
D
Activation by disabled people: Recommended, if applicable
E
Contact your Besam service representative. For contact information, see last page.=
9Issue 2012-03-201007717-US-1.0

SIGNAGE according to ANSI / BHMA A 156.10
58±5"
C
L
Apply to the approach side of the door.
AUTOMATIC
DOOR
75-20-100
DO NOT
ENTER
AUTOMATIC
DOOR
AUTOMATIC
DOOR
CAUTION
75-20-102
AUTOMATIC
DOOR
CAUTION
75-20-102
DO NOT
ENTE R
AUTOMATIC
DOOR
AUTOMATIC
DOOR
75-20-100
A
B
C
Shall be visible from the side of doors that
swings towards pedestrians attempting to
travel in the wrong direction.
Apply on the swingside of the door.
If problem
occurs
Action
Check that all required signage is applied and intact. Mandatory indicates that the signage is required
by European directives and equivalent national legislation outside the European Union.
Back Side “AUTOMATIC DOOR / DO NOT ENTER”
No entry, identifying one-way traffic: Mandatory, if applicable.
Used in combination with label
C
.
A
Dual Side “AUTOMATIC DOOR / CAUTION”
B
Front Side “AUTOMATIC DOOR”–In
Used in combination with label
A
.
C
Contact your Besam service representative. For contact information, see last page.=
1007717-US-1.0Issue 2012-03-2010

General accessories
Your SW200i can be further improved with the following add-ons (please contact your local
Besam company for detailed description).
•Position switch
3
, see page 8
•Electrical lock
9
, see page 8
•Key switch
10
, see page 8
•Elbow switch
10
, see page 8
•Radar
11
, see page 8
•Wireless transmitters (not illustrated)
•Access control (not illustrated)
•Door stop (not illustrated)
Safety accessories
Even though the SW200i is installed to comply with all applicable safety regulations, it is
possible to enhance safety/comfort with the following add-ons (please contact your local Besam
company for detailed description).
•Safety sensors
12
, see page 8
•Finger protection
8
, see page 8
Troubleshooting
RemediesWhat's wrong?
The door does not open
Change the setting of the program selector (see page 6).The motor does not start
Check that there are no objects in the detection zone if a sensor
is fitted.
Check the mains switch and fuse in the building.
Unlock the mechanical locks.The motor starts but
door(s) will not open Check that nothing is jammed beneath the door.
Change the setting of the program selector (see page 6).The door does not close
Check that there are no objects in the detection zone if a safety
sensor is fitted.
Check that nothing is jammed beneath the door.
Check that there are no moving objects within 39"-59" (1-1.5 m)
from the door if an automatic activation unit is fitted.
The door opens and closes
continuously
If the problem continues, please contact your Besam representative.
11Issue 2012-03-201007717-US-1.0

Maintenance plan
As mentioned earlier in this manual, service and adjustments performed by your Besam-autho-
rized representative will ensure safe and proper operation of your automatic door unit. The table
below shows the recommended interval in months, when to replace parts during preventive
maintenance. Talk to your Besam representative to learn more about Besam Pro-Active Care!
Abusive
Environ-
ment
Cycles/hour in operationPart numberPart
>100<100<10
High
traffic
Medium
traffic
Low
traffic
661224330000271 SI/BKPUSH arm service kit
661224330000272 SI/BKPULL arm service kit
661224330000276Stop arm kit
661224330000275Micro switch kit
661224330000270Adaptor kit
60606060331007291Transmission unit
60606060331007504Connection box kit
60606060331007752CU-200 control unit
60606060331003557EXU-SA
60606060331003554EXU-SI
Other products from Besam
•Door Systems
•Balanced doors
•Air curtains
•Rollershutters
•Revolving doors
•Sliding doors
•Swing doors
•Automatic and manual activation units
•Service such as preventive maintenance and upgrade programs, emergency repairs, service
advice and door management
1007717-US-1.0Issue 2012-03-2012

Republic of Ireland:
Besam Ltd,
unit 39, Navan Enterprise Centre,
Trim Road
Navan, Co. Meath
Tel: [phone]
Fax: [phone]
[email protected]
Germany:
Besam GmbH,
Lagerstraße 45,
64807 Dieburg
Tel: [phone]
Fax: [phone]
[email protected]
Hungary:
Besam Kft.,
Nagytétényi út 112,
1222 Budapest
Tel: [phone]
Fax: [phone]
[email protected]
Australia:
Besam Australia Pty Ltd.,
235 Huntingdale Road,
Oakleigh Victoria,
Australia 3166
Tel: [phone]
Fax: [phone]
[email protected]
Austria:
Besam Austria GmbH,
Hütteldorferstraße 216c,
1140 Wien
Tel: [phone]
Fax: [phone]
[email protected]
Russia:
Besam Export AB (Russian office)
Box 120, Ovchinnikovskaya nab. 22/24, building 1
Moscow 115035 Russia
Tel: [phone]
Fax: [phone]
[email protected]
Italy:
Besam S.p.A.,
Via Monzoro 142,
20010 S
Pietro all’Olmo (MI)
Tel: [phone]
Fax: [phone]
[email protected]
Belgium:
Besam Belgium NV,
Centrum-Zuid 3042,
3530 Houthalen
Tel: [phone]
Fax: [phone]
[email protected]
Singapore:
Besam (Mfg) Pte Ltd.,
No 33 Ubi Ave. 3 #03-52 Vertex
Singapore 408868
Tel: [phone]
Fax: [phone]
[email protected]
Netherlands:
Besam Nederland BV,
Postbus 8155
6710 AD Ede
Tel: [phone]
Fax: [phone]
[email protected]
Canada:
Besam Canada, Inc.,
4090 Ridgeway Dr. Unit #16,
Mississauga, Ontario
L5L 5X5 Canada
Tel: [phone]
Fax: [phone]
[email protected]
Slovak Republic:
Besam, spol. s.r.o.,
Kapitulská 15,
811 01 Bratislava
Tel: [phone]
Fax: [phone]
[email protected]
Spain:
Besam Ibérica S.A.,
Sepúlveda, 7A
28108 Alcobendas (Madrid)
Tel: [phone]
Fax: [phone]
[email protected]
New Zealand:
Doorman Besam Ltd.,
10 Haultain St.,
PD Box 15 784 New Lynn,
Auchland 1232
Tel: [phone]
Fax: [phone]
[email protected]
China:
Besam Automatic Door Systems Trading
(Shanghai) Co. Ltd.,
Suite 1903,
Modern Communication
Commercial Tower
218, Hengfeng Road,
Shanghai, PRC 200070
Tel: [phone]
Fax: [phone]
[email protected]
Sweden:
Besam Sverige AB,
Box 353
261 23 Landskrona, Sweden
Tel: [phone]
Fax: [phone]
[email protected]
Besam Export AB
Box 669,
261 25 Landskrona
Tel: [phone]
Fax: [phone]
[email protected]
Northern Ireland:
Tel: [phone]
Fax: [phone]
info@besam .co.uk
Norway:
Besam Norge AS, Brobekkveien 80
Postboks 25 Tveita,
0617 Oslo, Norway
Tel.: [phone]
Fax: [phone]
[email protected]
Czech Republic:
Besam spol. s r.o.,
Košarova 23,
197 00 Praha - Kbely
Tel: [phone]
Fax: [phone]
[email protected]
Denmark:
Besam A/S,
Marielundvej 20,
2730 Herlev
Tel: [phone]
Fax: [phone]
[email protected]
United Kingdom:
Besam Ltd.,
Washington House,
Brooklands Close,
Sunbury on Thames,
Middlesex TW16 7EQ
Tel: [phone]
Fax: [phone]
[email protected]
Poland:
Besam Polska Sp. z.o.o.,
ul. J. Olbrachta 94
PL-01-102 Warszawa
Tel: [phone]
Fax: [phone]
[email protected]
Portugal:
Besam Portugal,
Av. Marechal Gomes da Costa,
Fracção AD, 1º Piso, Cabo Ruivo
1800-255 Lisboa
Tel: [phone]
Fax: [phone]
[email protected]
Finland:
Besam OY,
Agronominraitti 2,
00790 Helsinki
Tel: [phone]
Fax: [phone]
[email protected]
France:
Besam S.A.S,
10 Rond Point du Général de Gaulle,
94864 Bonneuil s/Marne Cedex
Tel: [phone]
Fax: [phone]
[email protected]
US:
Besam US Inc.,
1900 Airport Road,
Monroe, NC 28110
Tel: [phone]
Fax: [phone]
[email protected]
Besam US Inc., 1900 Airport Road, US-Monroe, NC 28110
Tel: [phone] • Fax: [phone]
Tel: [phone] (service) • Tel: [phone] (sale)
[email protected] • www.besam.com
ASSA ABLOY is the global leader in door opening solutions, dedicated to satisfying end-user needs for security, safety and convenience.
