No Description Qty No Description Qty
1 Frame 1 77 Adjustment Cover(Right) 2
2 Bronze Bushing 178 Tube End(PAT3210) 2
3 Bearing(6003ZZ) 279 Round Head Philips Self Tapping Screw(ST3x10) 4
4 Bealt Wheel 180 Handle End Cap 2
5 Crank Post + Iron Board 1 81 Plastic Elliptical Decoration Tube 2
6Flat Head Hex Screw (M6x16) 4 82 Foam Sticker 2
7M6 Nylon Nut(Galvanized) 7 83 Flex Part of Rocker 2
8 Magnet + Plastic Base 1 84 Plastic Washer 2
9 C Ring(∮17) 2 85 Allen Bolt(M8x56) 2
10 Bushihng(NBO22518) 1 86 Arc Washer(SCB2085)(Black) 2
11 Wave Washer∮22x∮17.5x0.3t 1 87 Washer∮20x∮9x2t 2
12 Grinding Wheel 1 88 M8 Nylon Nut 2
13 Washe
r
∮18x∮10x2.0t 2 89 Bearin
g
(6200ZZ) 4
14 Allen Flange Nut 3/8"x26,
Thickness 7mm 2 90 Bushing(NBO24245105) 2
15 Truss Hex Screw
(
M10x20
)
1 91 Left Handrail 1
16 Idler Fixing Plate 1 92 Right Handrail 1
17 Bushin
g
(
NBO551410
)
193
HDR Foam Grip(Ø31.8x3.0t) 2
18 Bearing(6203ZZ) 4 94 Hand Pulse Sensor 2
19 Lowr Control Wire 1 95 Round Head Philips Self Tapping Screw(ST3x15) 4
20 Sensor 1 96 Hand Pulse Pulse Wire 1
21 Truss Hex Screw
(
M10x42
)
197
318 Upper Galvanized End Cap 2
22 M10 N
y
lon Nut
(
17 Sides
)
198
318 Lower Galvanized End Cap 2
23 Bearing 6000ZZ 3 99 Wire Cap 2
24 Round Head Philips Screw(M5x12) 4 100 Compter Frame 1
25 Adjustment Motor 1 101 Fixed Handrail Plastic (Left) 1
26 Adjustment Screw(SAZ660) 1 102 Fixed Handrail Plastic (Right) 1
27 M6 Flange Nut 1 103 HDR Foam Grip(Ø25.4x3.0t) 2
28 Belt 1 104 254 Upper Galvanized Tube 2
29 Idler Flex Spring 1 105 255 Lower Galvanized Tube 2
30 Turnplate Frame 2 106 Front Stabilizer 1
31 Plasteic Turn Plate 2 107 Inner Front Stabilizer Cover (Left) 1
32 Turnplate Cover 2 108 Outer Front Stabilizer Cover (Left) 1
33 Truss Philips Self Taping Screw(ST4x15) 26 109 Plastic Wheel 2
34 Allen Flange
NutAd(M10)(SA
J
101511) 2 110 Truss Philips Screw(M4x15) 2
35 Adjustment Cable 1 111 Inner Front Stabilizer Cover (Right) 1
36 M10 N
y
lon Nut
(
14 Sides
)
1 112 Outer Front Stabilizer Cover (Right) 1
41 Round Shaped Sensor Fixing Plastic 1 113 Rear Stabilizer 1
42 Rouond Head Philips Self Tapping Screw(ST4x16) 3 114 Outer Rear Stabilizer Cover 2
43 Left Chain Guard 1 115 Adjusment Support 2
44 Right Chain Guard 1 116 Adjustment Knob 2
45 Left Front Frame Decoration Cover 1 117 Foot Pad 2
46 Right Front Frame Decoration Cover 1 119 Computer 1
47 Upper Front Decoration Cover 1 120 Truss Philips Screw(M5x10) 6
48 Small Decoration String (Left) 1 121 Upper Control Wire 1
EK80TBBBSN PART LIST
第 1 頁,共 2 頁
No Description Qty No Description Qty
EK80TBBBSN PART LIST
49 Middle Decoration String (Left) 1 122 TV Computer 1
50 Large Decoration String (Left) 1 123 Pedal Tube Cover(A) 2
51 Small Decoration String (Right) 1 124 Pedal Tube Cover (B) 2
52 Middle Decoration String (Right) 1 125 Plastc Pedal 2
53 Large Decoration String (Right) 1 128 Adaptor 1
54 Truss Philips Self Tapping Screw(ST4x20) 2 131 Tube End(PAA4520) 2
55 Truss Philips Screw(M4x12) 16 134 Newspaper older Iron String 1
56 Pedal Assemly (Left) 1 135
Truss Hex
Screw(M8x15)(SAE81546)(
Chromeplated)
4
57 Pedal Assemly (Right) 1 136 Spring Washer(M8x2.0t)(Chraomeplated) 4
58 Bearing(2203-2RS) 2 137 Arc Washer(SCB2085)(Chromeplated) 4
59 C Ring(∮40) 2 138 Allen Bolt(M8x15)(Nickelplated) 6
60 Upright 1 139 Spring Washer(M8x2.0t)(Nickelplated) 10
61 Hook Preventing Cover 2 140 Arc Washer(SCB2085)(Nickelplated) 6
62 Middle ontrol Wire 1 141 Allen Bolt(M10x60) 2
64 Rocker 2 142 M10 Nylon Nut 2
65 Wave Washer∮26x∮19.5x0.3t 2 143 Truss hex Screw(
M8x15)(SAE81546)( 2
66 Allen Screw (M8x15)(Black) 2 144 Washer∮22x∮9x2.0t 2
67 Spring Washer(M8x2.0t)(Black) 4 145 Round Head Philips Srew(M6x12) 10
68 Washer∮17x∮9x1.0t 2 146 Truss Hex Screw(M8x60) 4
69 Washer∮22x∮17.5x2.0t 2 147 Washer∮18x∮9x2.0t 4
70 Washer∮22x∮9x4.0t 2 148 CKS Hex
Screw(M8x42)(SAK812510) 4
71 Wave Washer∮26x∮17.5x0.3t 2 149 Screwdriver(Plastic Handle) 1
72 Handrail Cover(Front) 2 150 Lug Open Spanner 2
73 Handrail Cover(Rear) 2 151 Hex Wrench(6mm) 1
74 Truss Philips Self Tapping Screw(ST4x12) 4 152 Small Bottled Silicon 1
75 Counter Sink Philips Self Tapping Screw(ST4x20) 11 155 Hex Wrench(5mm) 1
76 Ajustment Cover (left) 2 156 Belt(4.8x300) 4
第 2 頁,共 2 頁
