Treadmill Owner’s Manual
BH Fitness T10
BH FITNESS
20155 Ellipse Foothill Ranch CA 92610
Phone: [phone] Fax: [phone]
Email: f[email protected]
Web: www.bhnorthamerica.com and www.bhfitness.com
Issued: 18 July 2008 (v1)
Revised: 20 November 2008 (v2)

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
1
TABLE OF CONTENTS
SECTION PAGE
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Lubricating and adjusting the belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Removing and washing the bottle holder . . . . . . . . . . . . . . . . . . . . . . . . . 15
Fitness and Exercise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Computer Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
2
IMPORTANT SAFETY INSTRUCTIONS
User Safety
1. Users should pass a full medical examination before they begin an exercise program. Work at the
recommended exercise level. Do not over exert yourself. If you feel any pain or discomfort stop
exercising immediately and consult your doctor.
2. Do warm up stretching exercises before using the unit.
3. Verify that all of the parts are attached and that the nuts bolts pedals and bar are correctly
tightened before use.
4. Do not wear loose clothing or high heels. Tie up shoe laces.
5. The maximum weight of a user is 425 pounds (192 Kg).
6. Keep hands away from moving parts.
7. Supervise children invalids or disabled persons at all times. Children are curious and vulnerable to
accidents. Do not use the unit as a toy. Disabled people should not use the exercise equipment
without the assistance of a qualified person or doctor.
8. The owner is responsible for explaining safety instructions to each user.
9. The unit can only be used by one person at a time.
Unit Safety
1. For safety maintain a minimum clearance around the unit. Maintain 18 inches on the front and on
each side of the unit plus 24 inches at the rear of the unit.
2. Install and use the unit on a flat stable surface with some type of protection for the floor or carpet.
Do not place it alongside walls or furniture. Check the unit before each use.
3. Please read all of the instructions before assembling or using this unit.
4. To reduce the dangers and risk of electric shock always unplug the unit from its electrical power
immediately after using before cleaning opening disassembling or doing maintenance.
5. Do not place sharp objects near the exercise equipment.
6. Do not use the exercise equipment if it is not working correctly.
7. Do not lean against the computer console.
8. Do not start the treadmill when someone is standing on the running belt moving surface.
9. Connect this treadmill to a properly grounded 110-120V 15 or 20 Amp dedicated outlet only.
WARNING: To reduce the risk of fire electric shock injury to persons or inflicting the harm of a burn:
10. Turn all the controls to the off position prior to removing the electrical plug from the outlet.
11. The unit should never be left unattended when plugged in. Unplug the unit from the electrical power
before leaving the room when unused and before adding or removing parts.
12. Do not operate the unit under a blanket or pillow. Excessive heating can occur and cause fire
electric shock injury to persons or inflict the harm of a burn.
13. Use the unit only as described in this manual. Only use attachments recommended by the
manufacturer.
14. Never operate this unit if it has a damaged electrical cord or plug. Do not operate this unit if it is not
working properly. Do not operate this unit if it has been dropped or damaged. Do not operate this
unit if it has been immersed into water. Return the unit to a service center for examination and
repair.
15. Do not pull or carry the unit by the electrical cord. Do not use the cord as a handle.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
3
IMPORTANT SAFETY INSTRUCTIONS
16. Keep the electrical cord away from heated surfaces.
17. Never operate the unit when the air openings are blocked. Keep the air openings free of lint hair
and the like.
18. Do not drop or insert any objects into any openings.
19. Do not use outdoors or near water.
20. Do not operate where aerosol (spray) products are being used or where oxygen is being
administered.
Power Cord Safety
The power cord has a polarized plug (one blade is wider than the other) and grounding pin. This plug
will fit only one way into a polarized outlet. If the plug does not fully fit into the outlet then reverse the
plug. If it still does not fit then contact a qualified Electrician to install the correct outlet. Do not change
the plug in any way.
The unit must only be connected to a dedicated electrical circuit with an earth ground connection. If not
the user risks receiving an electric shock. Make sure that the outlet has the same pin layout as the plug
on the unit. See Fig. A.
GROUNDED
OUTLET
GROUNDING
PIN
Please save these instructions.
Fig A

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
4
IMPORTANT SAFETY INSTRUCTIONS
SAFETY BREAKER
This model is equipped with an electronic circuit breaker to protect both the electronic and
electrical circuits. Figure B.
The circuit breaker will be automatically triggered if the unit is subjected to abnormal force or
heat.
Should this occur:
1. Set switch (L) located on the main body to the “0” (OFF) position.
2. Press the circuit button (C) to reset the unit.
3. Next set switch (L) to the “I” (ON) position and the unit will be ready for use again.
Should the circuit breaker trip repeatedly then the most probable causes are:
-Abnormal working conditions
-Treadmill belt in need of lubricant
-Solvent based lubricants used (use BH type)
-Belt is too tight.
Plug the unit into a dedicated 110-120V 15 or 20 Amp circuit with a ground terminal. Set switch
(L) to the “I” (ON) position.
Figure B

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
5
ASSEMBLY
ASSEMBLY INSTRUCTIONS
Take the unit out of the box and place it on the floor as shown in Figure 1. Verify that the parts
are undamaged and quantities are correct.
ATTENTION: The assistance of a second person is advisable for the assembly work.
Follow the assembly instructions step by step:
ITEM DESCRIPTION
Qty
A Computer Console 1
B Frame 1
C Handle/Holder Set 1
D Left Upright 1
E Right Upright 1
F Right Decoration Cover 1
G Left Decoration Cover 1
H Bottle Holder 2
J Bottle 1

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
6
ITEM Description Qty
a
Truss Hex Screw
M8xP1.25x80L
8
b Nylon Nut M8 4
c
Truss Philips Screw
M5xP0.8x10
6
d
Truss Hex Screw
M8xP1.25x45
2
e Plastic Handle 2
f
Hex Wrench 6mm x 80mm x
80mm
1
g
Hex Wrench 5mm x 80mm x
80mm
1
h Power Switch Cover 1
i T Shaped Wrench 8mm x 200mm 1
j
Sleeve Spanner (wrench) + Screw
Driver
1
k Bottle of SILICONE Lubricant 1
m Power Cord 1

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
7
1. As required use the fishing line inside
of uprights (D E) to bring wire up from
Frame throught upright to the top of
upright.
2. One assembler hold the upright.
3. Second assembler tighten the left and
right uprights (D E) on the frame with
screws (a). Be careful not to damage
wires.
4. Install Decoration Covers (F G) and
fasten with Screws (C).
5. Pass wire from Upright into
Handle/Holder Set (C) through cup
holder space to the rear of (C). See
small figure.
6. Fasten Handle/Holder Set (C) onto
uprights (D E) with Nylon Nut (b).
7. Verify wire appears at the rear of (C).
See small figure.
Bring wire to rear
of Holder (C)

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
8
8. Remove the fasteners and the cover
under the computer console (A)
according to the arrowhead in the
right drawing. Save fasteners for
reuse.
NOTE: Two Assemblers are required.
9. Connect the lower control wire of
Handle/Holder Set (C) and the upper
control wire of Computer Console (A).
10. Fasten the computer on Holder (C)
with screws (c).
11. Reinstall the cover under the
computer console (A). Reuse the
fasteners removed in step 8.
12. Tighten the computer console (A)
with plastic handles (d).

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
9
13. Put the bottle holders (H) into the
Holder (C) and turn to hold firmly.
14. As required install the Power Switch
Cover (h) over the Power cord (m).
15. As required insert the Power cord
into the Frame.
16. As required screw the Cover (h) to
the Frame.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
10
ASSEMBLY CONTINUED
POSITION THE TREADMILL
1 For safety maintain a minimum clearance around the treadmill. Maintain 18 inches on the
front and on each side of the treadmill plus 24 inches at the rear of the treadmill.
NOTE: Safe movement of the treadmills is explained in the MAINTENANCE section of this
manual.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
11
MAINTENANCE
LEVELING
Once the unit has been placed into its final position for doing exercise make sure that the
treadmill sits flat on the floor and that it is level. This can be achieved by doing the following:
A) - Switch the treadmill on to see if the console shows that the treadmill is at zero inclination
level.
B) – Once you have checked the inclination place a spirit level on the running belt
.
MOVEMENT & STORAGE
NOTE: Lift and roll the treadmill using two people.
NOTE: To prevent accidents DO NOT move the treadmill across uneven floors.
The treadmill is easier to roll if the incline is higher than zero. Unplug the power cord prior to
moving the treadmill. To move the treadmill tilt the treadmill so that the front wheels rest on
the floor.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
12
MAINTENANCE
LUBRICATION
Figure 7. Use the bottle of lubricant (h) to lubricate the inside of the belt in order to keep your
unit in top condition and to ensure that friction between the belt and the board is kept to a
minimum (due to different running styles always apply more lubrication to the area where you
place your feet during the exercise). It is advisable to lubricate the base of the belt every 3-12
months depending on how often it is used.
If the belt starts to slip after lubrication then check the tension of the belt. To tension the belt
Figure 8 take the Allen key (m) and with the machine set to 2.5 miles/hr (4 km/h) turn screws
(R & L) one full turn in a clockwise direction.
Table I
Operating Speed Recommended lubrication period
for home use. Lubricate monthly
for business use
1 to 3.7 miles (1 to 6 km) per hour 1 year
3.7 to 7.4 miles (6 to 12 km) per hour 6 months
7.4 to 9.9 miles (12 to 16 km) per hour 3 months
Do not use solvent based lubricants
Figure 7 Figure 8
m

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
13
MAINTENANCE
ADJUSTING THE BELT
If your unit is not seated evenly on the four contact points this may cause the belt shown on
Figure 8 area (X) to shift sideways. Rigorous quality control adjusts and checks the running
belt. However due to weight differences and individual styles of running the belt may be prone
to shift sideways.
If the belt does shift to the left or right stop the machine and adjust the belt.
NOTE: Over tightening of the belt can lead to a loss of speed on the machine and even stretch
the belt itself. Bear In mind that one turn of the right screw (R) in a clockwise direction has the
same effect on the position of the belt as one turn of the left screw (L) in a counterclockwise
direction. Consequently in the event of excessive belt movement you can use either of the two
screws in order to avoid over tightening the belt.
BELT SHIFTED TO THE RIGHT (Figure 8)
1. Turn off and unplug the treadmill each time before using the hex wrench.
2. Use the hex wrench to turn the right hexagonal head socket a 1/4 turn clockwise.
3. Turn on treadmill for a few minutes at a speed of 2.5 mph (4 km/h) and check belt location.
4. If the belt is not centered then turn the left hexagonal head socket a 1/4 turn
counterclockwise.
5. If the belt is not centered then repeat steps.
BELT SHIFTED TO THE LEFT (Figure 8)
1. Turn off and unplug the treadmill each time before using the hex wrench.
2. Use the hex wrench to turn the left hexagonal head socket a 1/4 turn clockwise.
3. Turn on treadmill for a few minutes at a speed of 2.5 mph (4 km/h) and check belt location.
4. If the belt is not centered then turn the right hexagonal head socket a 1/4 turn
counterclockwise.
5. If the belt is not centered then repeat steps.
TREADMILL CLEANING
Switch the unit off and unplug the power cable. Use a damp cloth or towel to clean the dust off
the treadmill especially the side bars and the electronic console. Do not use solvents.
NOTE: Unplug the treadmill before using a vacuum near the treadmill.
Use a vacuum cleaner to carefully vacuum around the visible components (belt structure
etc.). You can increase the INCLINE in order to vacuum the underside of the unit. You can
vacuum the inside of the motor housing by removing the cover that protects the motor (be
careful with the wires).
NOTE: Press STOP to lower the INCLINE.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
14
MAINTENANCE
TIGHTENING THE FASTENERS
Check the connections and tighten all the parts on your unit every three months
Use of this machine with worn parts e.g. the drive belt running belt or rollers may cause the
user injury. If you are unsure about the condition of any part we recommend that you replace it
with original spare parts. The use of other spare parts may cause injuries or affect the
performance of the machine.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
15
MAINTENANCE CONTINUED
REMOVING & WASHING THE BOTTLE HOLDER
To check if the Bottle Holder is held loosely gently push the Bottle Holder up from beneath. If
this does not release the Bottle Holder then remove as follows:
RIGHT BOTTLE HOLDER REMOVAL OR INSTALLATION:
Gently grasp the Bottle Holder from beneath or on the rim. Turn it clockwise to unfasten.
Once the Holder is loosened lift the Holder up and out of the hole.
To install a Bottle Holder into the right hole:
Move away the wires.
Insert the Holder into the hole and gently turn counterclockwise to fasten.
LEFT BOTTLE HOLDER REMOVAL OR INSTALLATION:
Gently grasp the Bottle Holder from beneath or on the rim. Turn it counter-clockwise to
unfasten.
Once the Holder is loosened lift the Holder up and out of the hole.
To install a Bottle Holder into the left hole:
Move away the wires.
Insert the Holder into the hole and gently turn clockwise to fasten.
BOTTLE HOLDER WASHING
Please wash the Bottle Holders by hand only. The Bottle Holders cannot be placed into the
dishwasher or microwave.
Left Bottle Holder hole
Right Bottle Holder hole
Bottle Holder
Bottle Holder

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
16
FITNESS AND EXERCISE
FITNESS
All doctors agree that regular exercise is a good way to control our weight make us more fit
and help us to relax. Before starting any exercise program it is advisable to consult your
doctor. You will achieve better results based on his/her advice or suggestions. Exercise
programs vary depending on age and physical condition.
ADVANTAGES OF EXERCISE
Regular exercise below a certain level for 15/20 minutes becomes aerobic. Aerobic exercise is
basically exercise that uses oxygen. Normally this is a continuous exercise without pauses. In
addition to sugars and fats the body also needs oxygen. Regular exercise improves the body’s
ability to supply oxygen to all of the muscles and at the same time improve lung function the
heart’s pumping capacity and better blood circulation. In short the energy produced during
exercise burns kilocalories (known as calories).
EXERCISE & WEIGHT CONTROL
The food we eat is transformed into among other things energy (calories) for our body. If we
take in more calories than we burn then the result is an increase in weight and vice versa if we
burn more calories than we eat we lose weight. When resting the body burns around 70
calories per hour to keep our vital functions active. The table shows approximate energy use
for an average person doing various activities.
Table II
ACTIVITY CALORIES USED PER HOUR
Walking moderate pace 140
Housework 150
Swimming (400 m/h) 300
Dancing 350
Walking brisk (6 km/h) 370
Tennis 420
Cycling (30 km/h) 500
Squash 690
EXERCISE PROGRAM
Regardless of whether your goal is to become more fit control your weight or for
physiotherapy always remember that your exercise should be gradual planned varied and
not too demanding. We recommend that you should exercise 3 to 5 times per week.
Before beginning a session it is important to do a warm-up for 2-3 minutes at low speed. This
will help protect your muscles and prepare your cardio respiratory system.
The next stage will last 15-20 minutes at a pulse rate of between 65 to 75% or between 75 to
85% for those already accustomed to exercise. At a later stage once we have become fit we
can divide this time between both levels but always remembering that the pulse rate must not
exceed 85% (aerobic area) and never reach the maximum heart rate limit that corresponds to
our age.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
17
FITNESS AND EXERCISE
When you have finished it is important to relax the muscles. This can be done by walking at a
low speed for 2-3 minutes until the heart rate drops below the 65% line. This will prevent
muscle pain especially after an intense session. It is also advisable to finish the program with
some relaxation exercises on the floor.
FINAL NOTE
We hope that you enjoy your unit. You will soon notice the benefits of your controlled exercise
program. You will feel better have more energy and suffer less stress. You will see for yourself
that it is worth staying in shape with BH Fitness.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
18
TROUBLESHOOTING
Table III
PROBLEM CHECKS SOLUTIONS
1 The console does
not switch on
1a) Make sure that the
machine is plugged in and the
ON/OFF switch is in
position I.
1b) Verify that the console
electric supply cable is
connected.
1a) Plug the machine into the
power supply. Set the switch
to position I.
1b) Connect the console
electric supply cable.
2 The treadmill does not
work
Check if the electrical outlets
fuse or circuit breaker has
shut off.
Repair fuse or circuit breaker.
Contact a qualified electrician
if required. Plug the treadmill
into a dedicated 110-120V 15
or 20 Amp outlet to ensure the
treadmill receives the
appropriate amount of current
to function correctly. The
outlet must not supply
electricity to any other device.
3 Walking motion is jerky
on the treadmill
3a) Check if the belt is
lubricated.
3b) Check the tension on the
running belt.
3c) Check the tension on the
AC motor drive belt drive belt.
3a) Lubricate the sliding belt.
3b) Adjust the belt tension.
3c) Adjust the drive belt
tension.
4 The treadmill belt skews
off center
4a) Check if the machine is
level on the floor.
4b) Check if the machine
wobbles.
4c) Check alignment of the
front and rear rollers.
4a 4b) Level the machine.
Check if the feet are
adjustable.
4c) Align the front and rear
rollers.

T10 Treadmill
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhfitness.com • Phone [phone] • Fax [phone]
19
CONSOLE OPERATION
