Billion BiPAC 7402(G)X(L) Series User manual

BiPAC 7402(G)X(L) Series
3G/ ADSL2+ (802.11g) (VPN)
Firew ll Router
Quick St rt Guide

Quick St rt Guide

Billion BiPAC 7402(G)X(L) Series ADSL2+ Router
1
P ck ge Contents
BiPAC 7402(G)X(L) Series ADSL2+ Router
CD cont ining the on-line m nu l
RJ-11 ADSL/telephone c ble
Ethernet (CAT-5 LAN) c ble
One 2dbi det ch ble ntenn (Wireless model only)
Power d pter
RJ-45 to RS-232 Console Kit
Quick St rt Guide
Splitter/ Micro-filter (Option l)
Attention
Warning
PLEASE READ THE QUICK START GUIDE AND FOLLOW THE
STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU
INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.
IF YOU NEED MORE INFORMATION ON THIS SOFTWARE
CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON
CD-ROM.

Do not use the
router
in high humidity or high temper tures.
 Do not use the s me power source for the router s other
equipment.
 Do not open or rep ir the c se yourself. If the router is too hot,
turn off the power immedi tely nd h ve it rep ired t qu lified
service center.

Avoid using this
product
nd ll
ccessories
outdoors.

Pl ce the router on st ble surf ce.
 Only use the power d pter th t comes with the p ck ge. Using
different volt ge r ting power d ptor m y d m ge the router.

Quick St rt Guide
2
H rdw re Overview
The Front LEDs
The Re r Ports
* Note: For WPS configur tion, ple se refer to the WPS section of User M nu l.
Connect the supplied
power d pter to this
j ck.
Connect the supplied RJ
-
11
(“telephone”) c ble on this
port when connecting to the
ADSL/ telephone network.
Connect your computer
to LAN port, using
UTP Ethernet c ble.
Connect the
ntenn .
Lit when connected to n
Ethernet device. Green for
100Mbps; Or nge for 10Mbps.
Blinking when d t is
Tr nsmitted / Received.
Lit green when IP
connected.
Fl shes green when IP connected
nd IP tr ffic is p ssing thru the
device. Lit red when device
ttempted to become IP connected
nd f iled. Lit off in bridged mode or
when connection WAN is bsent.
Lit
o
r nge red
when
power is ON. Lit red
me ns system is f il.
Lit green when the
system is re dy.
Lit green when the wireless
connection is est blished.
Fl shes when the device
sending /receiving d t . Fl sh
once per second while wi-fi
protected setup is in progress
Lit green when
successfully connected
to n ADSL DSLAM
(“Line sync”)
Lit
green
when there
re em ils in
the inbox.
Press it to reset the
device or restore to
f ctory def ult settings.
Push WPS button to
trigger Wi-Fi Protected
Setup function*.
BiPAC 7402X(L) does not support 802.11g and WPS fun tions.
Power ON/
OFF switch
Connect the
USB
c ble on this port.
Lit
when the USB
device is re dy.
Fl shes when
sending /
receiving d t .

Billion BiPAC 7402(G)X(L) Series ADSL2+ Router
3
H rdw re Connection
H rdw re Inst ll tion
1. Power Connection
Plug the supplied power adapter to the wall jack and
the other side to the router.
Please note that the plug type may differ according to different country.
2. LAN Connection
Connect the supplied RJ- 5 Ethernet cable to one of the Ethernet ports, and the
other side to the PC’s Ethernet interface.

Quick St rt Guide
3. USB Connection
The USB 2.0 port supports 3G/ HSDPA modem connectivity: users can
conveniently access Internet via 3G, eliminating the limitations of the wired
network. This solution also employs an auto fail-over feature to ensure always-on
connectivity for SOHO users.
4. ADSL Connection
Connect the supplied RJ-11 phone cable to the router’s ADSL port, and the other
side to the phone jack on the wall.
5. EWAN Connection
Connect RJ- 5 Ethernet cable to the Ethernet port # 1 (EWAN), and connect the
other side to another alternative broadband device, such as Cable Modem, VDSL,
Fibre Modem or PON optic lines. Please refer to User Manual for detail instruction.

Billion BiPAC 7402(G)X(L) Series ADSL2+ Router
5
6. Splitter/ Micro-filter Connection
The Splitter / Micro-filter are important for ADSL installation,
they help direct
high-
frequency signals to the ADSL modem & low frequency signals to the
telephone or other analogue device to prevent inter-
modulation distortion & get
good speed/stable ADSL sync rate.
a) Splitter connection
If the installation has only a
single telephone and a single ADSL modem, then a
splitter can be employed.
b) Micro-filter connection
If the installation has several
telephones or other analog devices, then an internal
micro-filter can be employed at each analog device.
Setup Utility
After you complete the hardware installation insert CD into the CD Drive to run the setup utility.
The setup utility will auto-run. Follow the step-by-step configuration wizard & it will guide you to
setting up the basic network configuration.

Quick St rt Guide
6
Connecting to the Router
1. Open the web browser and type http://192.168.1.254 in the browser's address box. This
number is the default IP address for this router. Press Enter.
2. A username and password window will appear. The def ult usern me is “ dmin”, nd
p ssword is “ dmin”. Press OK to proceed.
3. You will get a status report web page and main menu screen.
Ple se see the relev nt sections of user m nu l for det iled instructions on how to
configure your router.
Troubleshooting
1. None of the LEDs re on when you turn on the router.
Check the connection between the adapter and the router. If the error persists, you may have
a hardware problem. In this case you should contact technical support.
2. C n’t ping ny PCs on the LAN.
Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC
connected. If it is off, check the cables between your router and the PC. Make sure you have
uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet
mask are consistent between the router and the workstations.
3. Frequent loss of ADSL linesync (disconnections).
Ensure that all other devices connected to the same telephone line as your router (e.g.
telephones, fax machines, analogue modems) have a line filter connected between them and
the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified
and licensed electrician), and ensure that all line filters are correctly installed and the right
way around. Missing line filters or line filters installed the wrong way around can cause
problems with your ADSL connection, including causing frequent disconnections. If you have
a back-to-base alarm system you should contact your security provider for a technician to
make any necessary changes.
Product Support nd Cont ct Inform tion
Most problems can be solved by referring to the Troubleshooting section in the User Manual. If
you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer
where you purchased this product.
Cont ct Billion
WORLDWIDE
http://www.billion.com
Billion Product Registr tion
Billion is committed to before and after sales customer services. You will get the most out of your Billion's products
after registration. Please register online at http://www.billion.com/register to receive valuable services and support
from us.
