ASSEMBLY INSTRUCTIONS
ATLAS 4' BED
www.birlea.com
Page 1 of 4
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR
ATLAS 4' BED FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY :
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all
legs to stop the bed frame from moving. If this is not adhered to there is no guarantee if the bed
frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
Vendor: S000053
Birlea
Suppliers of Inspiration

Vendor: S000053
Part List
A 8
B 4
C 10
D 6
E11
F22
G
H
I
4
2
2
Description
Headend M6 x 16mm JCBC Screw
Footend M6 x 50mm JCBC Screw
Side Support M6 Nut
Side Frame M6 x 35mm JCBC Screw
Mid Support Double Slat Cap
Base Leg Single Slat Cap
Slat Finial
M8 x 50mm JCBC Screw
M8 Nut
Description Qty
Hardware List (found in box 1)
Part
**M4 Allen Key & M5 Allen Key provided
Step 1: Fix the Side Support (3) to the Headend (1) and Footend (2) using hardware part (A).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
1
2
4
Small Allen Key
A
A
1
3
IMPORTANT: Do not tightly secure the screws before completing Step 2.
Page 2 of 4
Part
1
2
3
4
5
6
7
1
1
2
2
1
3
22
QtyBox
1
1
2
2
2
1
3
5
367

Vendor: S000053
Step 2: Place the Side Frames (4) at the bottom of the Side Supports (3) and secure with hardware parts (B) and (C).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 3: Place the Mid Supports (5) ON TOP both Side Frames (4) and secure using hardware parts (H) and (I)
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 4: Attach the Base Legs (6) to the Mid Supports (5) using hardware parts (C) and (D)
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
B
C
Small
Allen Key
1
43
D
D
C
Small Allen
Key
Base Leg
C
5
6
Page 3 of 4
H
Big Allen
Key
45
I
TOP

Vendor: S000053
Birlea
Suppliers of Inspiration
Step 5: Place the Double Slat Caps (E) into position on the Mid Supports (5) then place the Single Slat Caps (F) onto each
Slats (7). Firmly press into the Side Supports (3) then insert hardware part (G) to the Headend (1) and Footend (2)
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
GG
G
G
E
5
5
7
E
F
1
73
Page 4 of 4
Additional Information :
For complete product information, images and dimension diagrams please visit the website www.birlea.com.
If you have any issues with your item please contact the retailer directly you purchased it from who will be able
to resolve any issues with Birlea.
