Birlea WINCHESTER NEST OF TABLES User manual

Assembly Instructions
Thank you for
purchasing a
Birlea product.
Forachancetowina Love 2 Shop voucher
simplypostapictureofyournewproduct
onyourpreferredsocialchannelstagging
Birlea Furniture and using the hashtag
#ShareYourStyle and #Birlea .Onewinner
willbeselectedatrandomeachmonth.
To view our full terms and conditions please visit our website. www.birlea.com
Are you happy with your purchase?
Yes: That’sgreat,wewouldlovetohearmorefromyou.Pleaseleaveusareviewon
oursocialmediachannelsorTrustpilot.Yourfeedbackwillbegreatlyappreciated.
No: Ifforanyreasonthereissomethingmissing,indifferentorincorrectwith
yourorder,pleasecontacttheretaileryoupurchasedtheitemfrom.Wewill
workwiththeretailertoresolveyourissueasquicklyaspossible.
www.birlea.com

ASSEMBLY INSTRUCTIONS
WINCHESTER NEST OF TABLES
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLING OR USING YOUR WINCHESTER NEST OF TABLES.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this item if any parts are missing, damage or
worn.
DO NOT use this item unless all fixings are secured.
Please keep small parts out of reach of
children. Always use on a level, even
surface.
It is recommended that two people handle and assemble the item.
CARE & MAINTENANCE:
Assemble in the room of use.
To avoid damages assemble the item on a soft, clean
surface Periodically check all screws & fixings to ensure
they are secure. DO NOT push the item as this will
damage the base.
Always lift the item with two people to
reposition. Keep any sharp objects away
from the item.
This product is manufactured in pine which is a wood with natural characteristics including knots,
grains, clusters or indentations.
On unpacking the item you may notice an odour due to production processes but this will disappear
after a period of time.
DO NOT place the item next to a radiator or direct sunlight – this item is susceptible to temperature
change. It is recommended an even room temperature be maintained with no sudden fluctuations.
DO NOT place hot or cold items directly onto the surface of the item as marking will occur
For general cleaning use a duster or damp cloth (almost dry) not wet - do not use soap and water ,
detergents, aerosol sprays or any polish as use of these would invalidate any claims.
DO NOT place the item onto wet or damp flooring as staining may occur to the floor.
Page 1 of 5
www.birlea.com
Vendor: S000401
457mm
480mm
330mm 330mm
290mm250mm
480mm
370mm
290mm
307mm
382mm

Page 2 of 5
Vendor: S000401
Hardware List
Part Item Qty
A Wooden dowel 12
B 25mm Screw 12
C 40mm Screw 18
D Tack 12
E Slip Shoe 12
F 14mm Screw 24
G 25mm Screw 12
H Sticker 12
I 'L' Bracket 12
J Allen Key 1
012345678 9 1 0 1 1 1 2 1 3 1 4 1 5 1 6
mm
Parts List
Part Item Qty
1 Larger Top 1
2 Larger Column 4
3 Larger Front Traverse 3
4 Larger Side Traverse 2
5 Larger Bottom Side Traverse 2
6 Smaller Top 1
7 Smaller Column 4
8 Smaller Front Traverse 3
9 Smaller Side Traverse 2
10 Smaller Bottom Side Traverse 2
11 Top 1
12 Column 4
13 Front Traverse 3
14 Side Traverse 2
15 Bottom Side Traverse 2
1
2
2
2
2
3
3
34
5
5
4
6
7
7
7
7
8
8
9
9
10 10
8
11
12
12
12
12
13
13
13
14
15
15
14

Page 3 of 5
Vendor: S000401
Step 1: Insert hardware (A) into the larger top (1), smaller top (6) and top (11).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
A
AA
A
A
A
111 6
3
3
4
4
C
C
C
C
Step 2: Attach the Larger front traverse (3) to the Larger side traverse (4), the front traverse (13)
to the side traverse (14) and the smaller front traverse (8) to the smaller side traverse (9) using
hardware (C) and a screwdriver (not included).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
C
C
C
C
C
C
C
C
8
8
9
9
13
13
14
14
LARGE
MEDIUM SMALL

Page 4 of 5
Vendor: S000401
3
5
5
C
C
Step 3: Attach the larger front traverse (3) to the larger bottom side traverse (5), the front
traverse (13) to the bottom side traverse (15) and the smaller front traverse (8) to the smaller
bottom side traverse (10) using hardware (C) and a screwdriver (not included).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
G
G
G
G
B
B
BB
2
2
2
2
4
5
Step 4: Attach the Larger column (2) to the larger bottom side traverse (5) and the larger side
traverse (4), the column (12) to the bottom side traverse (15) and the side traverse (14) and the
smaller column (7) to the smaller bottom side traverse (10) and the smaller side traverse (9) using
hardware (B), (G) and (J).
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
Upper alignment
13
15
15
C
C
810
10
C
C
G
G
G
G
B
B
BB
12
12
12
12
14
15
G
G
G
G
B
B
BB
7
7
7
7
9
10
LARGE MEDIUM
SMALL
LARGE
MEDIUM
SMALL
J
J
J
BJ

Page 5 of 5
Vendor: S000401
Step 5: Fix the Larger top (1) to the larger column (2), the top (11) to the column (12) and the smaller
top (6) to the smaller column (7) using hardware (A), (F) and (I).Then attach the hardware (E) and (D)
to the bottom of the larger column (2), the column (12) and the smaller column (7). Insert hardware
(H) over the holes shown below.
Do NOT use any power tools are this may damage the frame and will invalidade any claim.
D
E
Additional Information:
• For complete product information, images and dimension diagrams
please visit the website www.birlea.com
• If you have any issues with your item please contact the retailer
directly you purchased it from who will be able to resolve any
issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [e-mail]
to be shared in our #birleahome feature on Instagram.
F
F
I
1
H
D
E
11
H
D
E
6
H
LARGE MEDIUM
SMALL
LARGE MEDIUM SMALL
2
2
2
2
12
12
12
1212
7
77
7
2
2
2
212
12
12
12
7
7
7
7
