Bretford QUATTRO Computer Table User manual

AssemblyInstructions
QUATTRO TABLES
Parts List
Qty.PartNo. Description
4 010-3511 CornerTies
4 017-0686 Bottom Legs
4 017-1026 Top Legs
4 015-0084 3/8-16Glides
2 010-3520 Bin Mounting Bracket
(ForComputerTablesOnly) Hardware List
Qty.Part No. Description
8 030-0396 3/8-16 x 1/2" Set screw
2 030-0357 #10-32Flanged Hex SerratedNut
(ForComputerTablesOnly)
2 030-0402 #10-32 x 5/8" Black Combo Head Screw
(ForComputersTablesOnly)
4 030-0852 5/16-18x1-1/4"HexFlangeCap Screw
Tools Required
PhilipsScrewdriver
AllenWrench
AdjustableWrench
Computer Table
Work Table
Round Work Table
Square Work Table

Laywoodtoponacarpeted surface with holes facing upward. Insert
the legs into each corner with holes facing in as shown.
Step 1
SAFETY WARNING
Note: TWO PERSON
ASSEMBLY REQUIRED
Attach legs with 5/16-18 x 1-1/4" Hex Flange Cap screws
(030-0852)andcorner ties (010-3511).Tightenall screws.
Step 2
Cornertie
010-3511 5/16-18 x 1-1/4"
030-0852
AllLegHolesFace Inward

Screwglides(015-0084) into bottomlegs(017-0686).
Glides should be fully installed into legs so that the
entire stem is inside of leg.
Step 3
Position holes in legs so that they face each other. Insert
bottom legs into top legs. Set desired height and insert 3/8-
16 x 1/2" (030-0396) Set screws into legs and tighten with
Allen wrench. Stand the unit upright.
Step 4
3/8-16 x 1/2"
Set screw
030-0396
Slide cord bin in between table legs. Slide the cord bin up on the
legs until it hooks onto apron's lip underneath working surface.
Step 5
(For tables with cord bin only)
Glide
015-0084
Cordbin
Bottom leg
017-0686
Cordbin
hook
Apron
hook

Part#031-4207
Rev. 01.04.10 CZ
Attach brackets to the cord bin as shown using #10-32 x 5/8" Combo screw (030-0402) and #10-32
Flangedhexnut (030-0357). Tighten allscrews
#10-32x5/8"Comboscrew
030-0402
Binmountingbracket
010-3520
#10-32 Flangedhexnut
030-0357
Cordbin
Working
surface
Step 6
(For tables with cord bin only)
