Bissell Select 23V8-EFGY Series User manual

USER'S GUIDE
23V8-EFGY SERIES
2Thank You
Safety Instructions
Product View
Assembly
Operations
Maintenance and Care
Consumer Care
Troubleshooting
3
4
5
7-8
9
12
9-10
Replacement Parts
Additional Accessories
Warranty
Product Registration
10
10
11
12

www.bissell.com
2
EN
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS
BEFORE USING YOUR STEAM MOP.
When using an electrical appliance, basic precautions should be
observed, including the following.
WARNING
ALWAYS CONNECT TO A PROPERLY EARTHED
ELECTRICAL SOCKET.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY:
» Unplug from electrical socket when not
in use and before servicing.
» This appliance can be used by persons
with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
» Children should be supervised to ensure
that they do not play with the appliance.
» If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
» Liquid or steam must not be directed
towards equipment containing
electrical components.
» The appliance shall not be left unattended while it is
connected to the supply mains.
» The appliance is not to be used if it has been dropped,
if there are visible signs of damage or if it is leaking.
» Keep the appliance out of reach of children when it is
energized or cooling down.
» The foot surfaces are liable to get hot during use.
» Do not modify earthed plug.
» To reduce the risk of electric shock: Use indoors only.
Do not expose to rain. Store indoors.
» Do not allow to be used as a toy.
» Use only as described in this user guide.
» Use only manufacturer’s recommended attachments.
» Do not use with damaged cord or plug.
» Do not immerse in water or liquid.
» If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into
water; do not attempt to operate it and have it
repaired at an authorized service center.
» Do not pull or carry by cord, use cord as a handle,
close door on cord, or pull cord around sharp edges
or corners.
» Do not run appliance over cord.
» Keep cord away from heated surfaces.
» To unplug, grasp the plug, not the cord.
» Do not handle plug or appliance with wet hands.
» Do not put any object into openings.
» Turn off all controls before unplugging.
» Use extra care when cleaning on stairs.
» Do not use appliance in an enclosed space
filled with vapors given off by oil base paint, paint
thinner, some mothproofing substances, flammable
dust, or other explosive or toxic vapors.
» Keep appliance on a level surface.
FOR OPERATION ON A 220-240 VOLT A.C. 50/60 HZ POWER SUPPLY ONLY.
This model is for household use only.
THIS SYMBOL MEANS
WARNING: DANGER OF SCALDING
WARNING
SURFACE MAY BE HOT. AVOID CONTACT.
SAVE THESE INSTRUCTIONS

Thanks for buying a BISSELL Steam Mop Select
We’re glad you purchased a BISSELL Steam Mop Select. Everything we
know about floor care went into the design and construction of this
complete, high-tech home cleaning system.
Your BISSELL Steam Mop Select is well made, and we back it with a
limited one year warranty. We also stand behind it with a knowledgeable,
dedicated Consumer Care department, so, should you ever have a problem,
you’ll receive fast, considerate assistance.
My great-grandfather invented the floor sweeper in 1876. Today, BISSELL
is a global leader in the design, manufacture, and service of high quality
homecare products like your BISSELL Steam Mop Select.
Thanks again, from all of us at BISSELL.
Mark J. Bissell
Chairman & CEO
3
WARNING AN ACTION OR ATTENTION IS NEEDED TO THIS AREA
IN ORDER TO REDUCE THE RISK OF ELECTRIC SHOCK,
FIRE, OR INJURY
STEAM DANGER OF SCALDING
GUIDE READ USER GUIDE FOR COMPLETE
SAFETY AND USER INSTRUCTIONS
WEEE DO NOT THROW THE APPLIANCE AWAY WITH THE
NORMAL HOUSEHOLD WASTE AT THE END OF ITS LIFE,
BUT HAND IT IN AT AN OFFICIAL COLLECTION POINT
FOR RECYCLING. BY DOING THIS YOU WILL HELP TO
PRESERVE THE ENVIRONMENT.
Symbol Definitions

www.bissell.com
4
Product view
Washable Mop
Pads-2 Pack
Strain Reliever
Handle™
Steam on
Demand Trigger
Lower Cord
Wrap
Mop Pad
Quick Release™
Cord Wrap
Power Cord
Steam Mop Scented
Water-Citrus Steam Mop Scented Water-Spring Fresh
Optional Accessories:
Removable
Water Tank
Indicator Light
Mop Head
EN

www.bissell.com
Assembly
5
Your Steam Mop Select assembles
quickly and easily. Your Steam
Mop Select is packaged with the
following items:
– Handle Assembly
– Lower Body
– Maneuverable Mop Head
– Removable Water Tank
– 2 Steam Mop Select Mop Pads
1. Attach lower body to mop head by
snapping it into place.
2. Slide handle assembly down into
lower body until it snaps into place.
3. Slide water tank onto lower body and
gently push tank into place.
Steam Mop Select assembly is now complete.
Handle Assembly
Maneuverable Mop Head
Removable
Water Tank
1
3
Lower Body
Triangular
Mop Pads
EN

www.bissell.com
Special features
6
Removable Water Tank
The water tank is located on the top of the
Steam Mop Select. It can be refilled with
water any time during use. Distilled or
demineralized water is recommended in
place of tap water.
Do not use chemicals with your
Steam Mop Select.
Indicator Light
The indicator light will glow when the
Steam Mop Select is plugged in.
Maneuverable Mop Head
This triangular mop head allows you to clean
in tight spaces and under cabinets.
Reusable Mop Pads
These reusable microfiber mop pads are
machine washable and safe for fully sealed
hard floor surfaces. The all-white "soft" pad
is best for everyday use on delicate flooring
like sealed hardwoods and laminate.
The gray and white striped pad can be
used for scrubbing heavily soiled floors and
tougher messes.
Steam on Demand Trigger
Press to release steam.
Tip:
Do not attempt to use
your Steam Mop Select
without water in the tank.
EN

www.bissell.com 7
Operations
1A 1B
Getting ready
The mop pad may have already
come attached to the mop head, if
not follow steps 1A and 1B below.
1. Attach mop pad
A. Set mop head in mop pad, making
sure toggle is located on the back.
B. Tighten mop pad by pulling on elastic
cord while pressing on toggle.
2. Fill the water tank
A. Remove tank by lifting straight up
and away from unit.
B. Unscrew cap at bottom of water tank.
C. Fill water tank with water. For best
results, water should be at
room temperature.
D. Replace the cap, tighten until snug.
E. Replace water tank by gently sliding
tank into place.
3. Twist the quick release cord wrap clock-
wise to unwrap the power cord completely
and plug into a 220-240 Volt outlet as
described on the Important Safety
Instructions, page 3.
4. The indicator light will illuminate when the
Steam Mop Select is plugged in.
2A
2D
2B
2E
Tip:
Use of distilled water is recommend-
ed to prolong the life of your Steam
Mop Select
EN

www.bissell.com
Operations
8
Before you clean
Thoroughly sweep or vacuum floor
prior to cleaning with the Steam
Mop Select.
Cleaning hard floors
Your Steam Mop Select is designed
to clean hard flooring such as
ceramic tile, vinyl, laminate, marble,
stone and sealed hard wood floors.
Use of your Steam Mop Select on
waxed or some unwaxed floors may
result in a diminished glossiness.
The Steam Mop Select is not for use
on unsealed wood floors. For best
results test in an inconspicuous area
and check the care instructions from
your flooring manufacturer.
1. Plug the unit in and wait 30 seconds for
it to heat up. Begin cleaning by slowly
passing over surface while pressing the
steam on demand trigger to emit steam
as needed.
2. To sanitize an area of your floor, (attack
invisible germs and bacteria) place the
Steam Mop Select over the spot for a
minimum of 15 seconds using continuous
steam, but no longer than 20 seconds
using continuous steam. For larger
areas, overlap swivel head placement.
Important: Sanitizing on timber floors
is not recommended as prolonged
application of steam in one area
increases the risk of damage to the
surface treatment on timber floors,
especially in areas with regular
foot traffic and direct sunlight,
which will wear down timber floor
surface treatments making it more
susceptible to steam damage. See
CAUTION to the right.
3. When the Steam Mop Select stops
emitting steam, unplug the unit. Simply
remove the water tank, refill, and
continue cleaning.
WARNING:
Never put descaling, alcoholic,
or detergent products into the
steam cleaner, as this may
damage it or make it unsafe for
use. Only use BISSELL authorized
aromatic products.
CAUTION:
Exercise extreme care when using
the Steam Mop Select on timber
flooring. Ensure the Steam Mop
Select an inconspicuous area
prior to mopping a large floor
area. The Steam Mop Select
generates hot steam, so when
depressing the trigger to apply
steam, ensure the Steam Mop
Select is moving continuously.
The trigger does not need to be
depressed at all times. Prolonged
application of steam in one area
increases the risk of damage to
the surface treatment on timber
floors. Check with your timber
floor treatment application
specialist prior to Steam Mop
Select operation. Regular foot
traffic and direct sunlight will
wear down timber floor surface
treatment making it more
susceptible to steam damage.
Exercise extreme care when
using the Steam Mop Select on
timber flooring.
EN

www.bissell.com 9
Maintenance and care
CAUTION:
Upright storage of the Steam
Mop Select with a wet mop
pad may result in the formation
of white marks on your floor. To
remove the white marks, clean
area with vinegar.
When you're done
1. Unplug power cord from outlet.
2. Carefully remove mop pad from flip
head, as mop pad and lower assembly
may be hot.
3. Any water remaining in the water tank
should be emptied prior to machine
storage.
4. Mop pad can be machine washed in
warm water. Use only liquid detergents.
Do not use fabric softeners. For best
results, air dry.
5. Wrap power cord around quick release
cord wrap on side of Steam Mop Select.
6. Wipe all surfaces of Steam Mop Select
with a soft cloth. Store upright in a
protected, dry area.
Troubleshooting
Reduced steam or no steam.
Possible Causes Remedies
1. Water tank empty 1. Fill tank
Other maintenance or service not included in the manual should
be performed by an authorized service representative.
Thank you for selecting a BISSELL product.
Please do not return this product to the store.
For any questions or concerns, BISSELL is happy to be
of service.
EN

www.bissell.com
10
Item Part No. Part Name
1 203-7738 Handle Assembly
2 203-7734 Water Tank with Cap and Insert
3 203-7735 Cap and Insert Assembly
21 3
23
1
Additional Accessories
Item Part No. Part Name
1 203-2271 Replacement Mop Pads - 2 pack
2 1393 Steam Mop Scented Water Citrus 32 FL oz
3 203-2168 Storage Hook with Screws
4 1394 Steam Mop Scented Water Spring Fresh 32 FL oz
Replacement parts- BISSELL Steam Mop Select
EN
4

www.bissell.com 11
Warranty
For UK inquiries:
Telephone: [phone]
Monday – Thursday 9am - 5pm
Friday 9am - 4pm
BISSELL Homecare (Overseas)
Inc.
Ground Floor
226 Berwick Avenue
Slough
Berkshire, SL1 4QT
United Kingdom
For Australian inquiries:
Telephone: 1.800.811.183
Monday – Friday
9 am – 5 pm
BISSELL AUSTRALIA
PTY LIMITED
42 Rocco Dr.
Scoresby 3179
Victoria
Australia
For New Zealand
inquiries:
Telephone: [phone]
Monday – Friday
9 am – 5 pm
For South Africa inquiries:
Telephone:
27 (0) 86.177.8888
Monday – Friday
9 am – 5 pm
Tevo (PTY) Ltd.
P.O. Box 25234
Gateway 4321, South Africa
Or email:
ser[email protected]
For Middle East & Africa
inquiries:
Telephone: [phone]
Sunday – Thursday
8 am – 5 pm
P.O. Box 61286
Jebel Ali Free Zone
Dubai
United Arab Emirates
For all other inquiries:
www.bissell.com
Website or E-mail:
www.BISSELL.com
This warranty gives you specific legal rights, and you may also have other rights which may vary from
country to country. If you need additional instruction regarding this warranty or have questions regarding
what it may cover, please contact BISSELL Consumer Services by E-mail, telephone, regular mail as
described below, or contact your local in country distributor.
Limited One Year Warranty
Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL will repair or replace
(with new or remanufactured components or products), at BISSELL’s option, free of charge from the
date of purchase by the original purchaser, for one year any defective or malfunctioning part due
to manufacturer defect.
This warranty applies to product used for personal, and not commercial or rental service. This
warranty does not apply to fans or routine maintenance components such as filters. Damage or
malfunction caused by negligence, abuse, neglect, unauthorized repair, or any other use not in
accordance with the User's Guide is not covered.BISSELL recommends that the original packaging
be kept for the duration of the warranty period in case such need arises within the warranty period
that the item need re-packing and transportation.
BISSELL Consumer Care:
If your BISSELL product should require service or if you need information about repairs, authorized service
centers in your area, replacement parts or your warranty, please contact BISSELL Consumer Care, as
indicated below, or contact your local in-country distributor.
*EXCEPTIONS AND EXCLUSIONS FROM THE TERMS OF THE LIMITED WARRANTY
BISSELL AND ITS IN-COUNTRY DISTRIBUTORS ARE NOT LIABLE FOR INCIDENTAL OR ONSEQUENTIAL DAMAGES OF ANY NATURE
ASSOCIATED WITH THE USE OF THIS PRODUCT. BISSELL’S LIABILITY WILL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCT.
THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY OTHER WARRANTIES EITHER ORAL OR WRITTEN. ANY IMPLIED WARRANTIES
WHICH MAY ARISE BY OPERATION OF LAW, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE ONE YEAR DURATION FROM THE DATE OF PURCHASE AS DESCRIBED ABOVE.
FOR AUSTRALIAN CONSUMERS ONLY: OUR GOODS COME WITH GUARANTEES THAT CANNOT BE EXCLUDED UNDER
THE AUSTRALIAN CONSUMER LAW. YOU ARE ENTITLED TO A REPLACEMENT OR REFUND FOR A MAJOR FAILURE AND FOR
COMPENSATION FOR ANY OTHER REASONABLY FORESEEABLE LOSS OR DAMAGE. YOU ARE ALSO ENTITLED TO HAVE THE GOODS
REPAIRED OR REPLACED IF THE GOODS FAIL TO BE OF ACCEPTABLE QUALITY AND THE FAILURE DOES NOT AMOUNT TO A MAJOR
FAILURE.
THIS WARRANTY IS IN ADDITION TO OTHER RIGHTS OR REMEDIES UNDER LAW. NOTHING IN THIS WARRANTY EXCLUDES,
LIMITS OR MODIFIES ANY LIABILITY OF BISSELL WHICH IS IMPOSED BY LAW, OR LIMITS OR MODIFIES ANY REMEDY AVAILABLE
TO THE CONSUMER WHICH IS GRANTED BY LAW. TO MAKE A CLAIM UNDER THIS WARRANTY CONTACT BISSELL AUSTRALIA
PTY LTD (DETAILS ABOVE). CONTACT BISSELL PRIOR TO RETURNING ANY GOODS. WHERE AGREED, BISSELL WILL REIMBURSE
REASONABLE POSTAGE / HANDLING COSTS (IF ANY) FOR RETURNING GOODS TO BISSELL.
EN

BISSELL consumer care
www.bissell.com
12
For information about repairs or replacement parts, or questions about your
warranty, call: BISSELL Consumer Care
Or visit the BISSELL website - www.bissell.com
When contacting BISSELL, have model number
of cleaner available.
Please record your Model Number: ________________
Please record your Purchase Date: _________________
NOTE: Please keep your original sales receipt. It provides
proof of purchase date in the event of a warranty claim.
See Warranty on page 11 for details.
©2015 BISSELL Homecare, Inc
Grand Rapids, Michigan
All rights reserved.
Printed in China
Part Number 160-6636
Rev 07/15
Visit our website at:
www.bissell.com
Registering is quick, easy and offers you benefits over the lifetime of your product.
You’ll receive:
Faster Service
Supplying your information now saves you time should you need to contact us with
questions regarding your product.
Product Support Reminders and Alerts
We’ll contact you with any important product maintenance reminders and alerts.
Special Promotions
Optional: Register your email to receive notice of offers, contests, cleaning tips and more!
Visit www.bissell.com/registration now!
Don't forget to register your product!
For UK inquiries:
Telephone: [phone]
Monday – Thursday 9am - 5pm
Friday 9am - 4pm
BISSELL Homecare (Overseas)
Inc.
Ground Floor
226 Berwick Avenue
Slough
Berkshire, SL1 4QT
United Kingdom
For Australian inquiries:
Telephone: 1.800.811.183
Monday – Friday
9 am – 5 pm
BISSELL AUSTRALIA
PTY LIMITED
42 Rocco Dr.
Scoresby 3179
Victoria
Australia
For New Zealand
inquiries:
Telephone: [phone]
Monday – Friday
9 am – 5 pm
For South Africa inquiries:
Telephone:
27 (0) 86.177.8888
Monday – Friday
9 am – 5 pm
Tevo (PTY) Ltd.
P.O. Box 25234
Gateway 4321, South Africa
Or email:
ser[email protected]
For Middle East & Africa
inquiries:
Telephone: [phone]
Sunday – Thursday
8 am – 5 pm
P.O. Box 61286
Jebel Ali Free Zone
Dubai
United Arab Emirates
For all other inquiries:
www.bissell.com
Website or E-mail:
www.BISSELL.com
EN
