Black Box LRA3000A User manual

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
CUSTOMER
SUPPORT
INFORMATION
MAY 2000
LRA3000A
LRA3001A
LRA3002A
LRA3003A
T1 and E1 Remote Access Concentrators
WIDE AREA 1
LNK
STS
ASYNC
LNK
STS
ENET
STS
CPU
PWR
PINOUT
RESET
WIDE AREA 2
LNK
STS
TELCO
Dual T1 Remote Access Concentrator

FCC, IC, AND VCCI RFI STATEMENTS; EU DECLARATION OF CONFORMITY
1
FEDERAL COMMUNICATIONS COMMISSION (FCC), INDUSTRY CANADA (IC), AND
VOLUNTARY CONTROL COUNCIL FOR INTERFERENCE (VCCI) RADIO-FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in
strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of
Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment
is operated in a commercial environment. Operation of this equipment in a residential area is likely to cause interference,
in which case the user at his own expense will be required to take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio Interference
Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la classe
A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.
EUROPEAN UNION DECLARATION OF CONFORMITY
This equipment has been tested and found to comply with the limits for a class A computing device in accordance with the
specifications in the European standard EN 55022. These limits are designed to provide reasonable protection against
harmful interference. This equipment generates, uses and can radiate radio-frequency energy, and if not installed and
used in accordance with the instructions, might cause harmful interference to radio or television reception. However,
there is no guarantee that harmful interference will not occur in a particular installation. If this equipment does cause
interference to radio or television reception, which can be determined by turning the equipment on and off, you can
correct the interference with one or more of the following measures:
(a) Reorient or relocate the receiving antenna.
(b) Increase the separation between the equipment and the receiver.
(c) Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
(d) Consult the supplier or an experienced radio/TV technician for help.
This equipment has also been tested and found to comply with European standard EN 50082-1:1992.

T1 AND E1 REMOTE ACCESS CONCENTRATORS
2
NORMAS OFICIALES MEXICANAS ELECTRICAL-SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano
mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de
operación. Todo otro servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato
eléctrico sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en
libreros o gabinetes que impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas
u otros aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de
operación, o como se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos
colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de
ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

FCC PHONE-EQUIPMENT STATEMENT
3
FCC REQUIREMENTS FOR TELEPHONE-LINE EQUIPMENT
1. The Federal Communications Commission (FCC) has established rules which permit this device to be directly
connected to the telephone network with standardized jacks. This equipment should not be used on party lines
or coin lines.
2. If this device is malfunctioning, it may also be causing harm to the telephone network; this device should be
disconnected until the source of the problem can be determined and until the repair has been made. If this is not
done, the telephone company may temporarily disconnect service.
3. If you have problems with your telephone equipment after installing this device, disconnect this device from the line
to see if it is causing the problem. If it is, contact Black Box.
4. The telephone company may make changes in its technical operations and procedures. If any such changes affect
the compatibility or use of this device, the telephone company is required to give adequate notice of the changes.
You’ll also be advised of your right to file an FCC complaint.
5. If the telephone company requests information on what equipment is connected to their lines, inform them of:
a. The telephone number that this unit is connected to.
b. The ringer equivalence number.
c. The USOC jack required: RJ-11C.
d. The FCC registration number.
Items (b) and (d) can be found on the unit’s FCC label. The ringer equivalence number (REN) is used to determine
how many devices can be connected to your telephone line. In most areas, the sum of the RENs of all devices on any
one line should not exceed five (5). If too many devices are attached, they may not ring properly.
6. In the event of an equipment malfunction, all repairs should be performed by Black Box. It is your responsibility
to tell us that your equipment needs to be serviced.

T1 AND E1 REMOTE ACCESS CONCENTRATORS
4
CERTIFICATION NOTICE FOR TELEPHONE-LINE EQUIPMENT USED IN CANADA
The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain
telecommunications-network protective, operational, and safety requirements. Industry Canada does not guarantee the
equipment will operate to your satisfaction.
Before installing this equipment, you should ensure that it is permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be installed using an acceptable method of connection. In some
cases, the company’s inside wiring associated with a single-line individual service may be extended by means of a certified
connector assembly (extension cord). Be aware that compliance with the above conditions may not prevent degradation
of service in some situations.
Repairs to certified equipment should be made by an authorized maintenance facility—in this case, Black Box. Any
equipment malfunctions, or any repairs or alterations you make to this equipment, may give the telecommunications
company cause to ask you to disconnect the equipment.
You should ensure for your own protection that the electrical ground connections of the power utility, telephone lines,
and internal metallic water-pipe system, if present at your site, are connected together. This precaution may be particularly
important in rural areas.
CAUTION!
Users should not attempt to make such connections themselves, but should contact the appropriate electric
inspection authority, or electrician, as appropriate.
The LOAD NUMBER (LN) assigned to each terminal device denotes what percentage of the total load to be connected
to a telephone loop is caused by the device. In order to prevent overloading, the termination on a loop may consist
of any combination of devices, subject only to the requirement that the sum of the load numbers of all the devices
does not exceed 100.

1.544-MBPS/SUBRATE AFFIDAVIT
5
AFFIDAVIT FOR THE CONNECTION OF CUSTOMER EQUIPMENT TO 1.544-MBPS AND/OR
SUBRATE DIGITAL SERVICES
For the work to be performed in the certified territory of
Telco’s name: ________________________________________,
State/province of: _____________________________________,
Country of : __________________________________________,
I, _________________________, of _______________________,
(Name of Authorized Representative and Customer Name)
_____________________________________________________, _________________________,
(Customer’s Address and Telephone Number)
being duly sworn, state:
I have responsibility for the operation and maintenance of the terminal equipment to be connected to
_________________________ 1.544-Mbps and/or ___________________ Subrate digital services. The terminal equipment
to be connected complies with Part 68 of the Commission’s rules except for the encoded analog content and billing-
protection specifications. With respect to encoded analog content and billing protection:
• I attest that all operations associated with the establishment, maintenance, and adjustment of the digital CPE with
respect to encoded analog content and encoded billing information continuously complies with Part 68 of the FCC’s
Rules and Regulations.
• The encoded analog and billing protection is factory-set and is not under the control of the customer.
I attest that the operator(s)/maintainer(s) of the digital CPE responsible for the establishment, maintenance, and
adjustment of the encoded analog content and billing information has (have) been trained to perform these functions
by successfully completing at least one of the following (check all that apply):
a. A training course provided by the manufacturer/grantee of the equipment used to encode analog signals; or
b. A training course provided by the customer or authorized representative, using training materials and instructions
provided by the manufacturer/grantee of the equipment used to encode analog signals; or
c. An independent training course (at a trade school, technical institution, etc.) recognized by the manufacturer/
grantee of the equipment used to encode analog signals; or
d. In lieu of the proceeding training requirements, the operator(s)/maintainer(s) is (are) under the control of a
supervisor trained in accordance with letter ___ above.
I agree to provide ______________________________ (Telco’s Name) with proper documentation to demonstrate
compliance with the information provided in the preceding paragraph, if so requested.
______________________________________ (Signature)
______________________________________ (Title)
______________________________________ (Date)
Subscribed and sworn to me this ____ day of __________________ (month), ________ (year).
__________________________________
(Notary Public)
My commission expires:

T1 AND E1 REMOTE ACCESS CONCENTRATORS
6
DISCLAIMER
In no event shall the manufacturer or its suppliers or agents be liable for any damages whatsoever (including,
without limitation, damages for loss of business or profits; damages for business interruption; damages for loss
of business information; special, incidental, consequential, or reliance damages; or damages for other loss)
arising out of the use or inability to use this product, even if the manufacturer or its suppliers or agents have
been advised of the possibility of such damages. Because some states do not allow the exclusion or limitation
of liability for consequential or incidental damages, or on the duration or limitation of implied warranties,
in some instances the above limitations and exclusions might not apply to you.
TRADEMARKS USED IN THIS MANUAL
BLACK BOX and the logo are registered trademarks of Black Box Corporation.
AT&T is a registered trademark, and Definity is a trademark, of AT&T.
VT100 is a trademark of Compaq Computer Corporation.
K56flex is a trademark of Rockwell Telecommunications and Lucent Technologies.
MNP is a registered trademark of Microcom Systems, Inc.
Microsoft, Windows, and Windows NT are registered trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
Telnet is a trademark of Telnet Communications, Inc.
UL is a registered trademark of Underwriters Laboratories Incorporated.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

TABLE OF CONTENTS
7
Contents
Chapter Page
1. Specifications .......................................................................................................................................... 9
2. Introduction ......................................................................................................................................... 12
3. Installation ............................................................................................................................................ 14
3.1 The Complete Concentrator Package ......................................................................................... 14
3.2 Arranging ISDN Service ............................................................................................................... 14
3.3 Setting the Pinout Switch for Your WAN Interface (T1 Models Only) ..................................... 15
3.4 Placement ...................................................................................................................................... 16
3.5 Rackmounting (Optional) ........................................................................................................... 16
3.6 Making Cable Connections .......................................................................................................... 19
3.6.1 Console (ASYNC) Connections ......................................................................................... 19
3.6.2 LAN (ENET) Connections ................................................................................................ 21
3.6.3 WAN (WIDE AREA) Connections ..................................................................................... 22
3.7 Connecting to AC Power .............................................................................................................. 23
4. Configuration ....................................................................................................................................... 24
4.1 The Information You’ll Need ....................................................................................................... 24
4.2 The Local Management Utility .................................................................................................... 26
4.3 Module Configuration .................................................................................................................. 28
4.3.1 IP Configuration ................................................................................................................. 30
4.3.1.A IP LAN Interface ................................................................................................... 31
4.3.1.B Default LAN Route ............................................................................................... 33
4.3.1.C Static LAN Routes ................................................................................................. 35
4.3.2 SNMP Community Names ................................................................................................. 37
4.3.3 Authentication Settings ...................................................................................................... 38
4.3.4 PPP Settings ........................................................................................................................ 40
4.3.5 Using a RADIUS Server as a Device Database .................................................................. 42
4.3.5.A RADIUS Authentication Servers .......................................................................... 43
4.3.5.B RADIUS Accounting Servers ................................................................................ 45
4.3.5.C RADIUS Client Support ....................................................................................... 47
4.3.6 CAS Configuration ............................................................................................................. 50
4.3.6.A R2 (for E1) ............................................................................................................ 50
4.3.6.B RBS (for T1) .......................................................................................................... 54
4.3.7 General Configuration ....................................................................................................... 58
4.3.8 Flash Download (Upgrading the Firmware) .................................................................... 60
4.4 Network Tools ............................................................................................................................... 62
4.5 Fault Records ................................................................................................................................. 63
4.6 Integrating the Concentrator Into Your Network ....................................................................... 65
4.6.1 Using Static Routes to Reach Subnets Through WAN Devices ....................................... 66
4.6.2 Integrating the Concentrator Into a Standard IP Network ............................................. 67
4.6.3 Integrating the Concentrator Into an IP Network as an Internet Gateway .................... 69
4.6.4 Integrating the Concentrator Into an IP Network with Multiple Subnets ...................... 70

T1 AND E1 REMOTE ACCESS CONCENTRATORS
8
Contents (cont’d)
Chapter Page
5. Basic CSM ............................................................................................................................................. 71
5.1 Overview of Installing CSM .......................................................................................................... 71
5.2 CSM Configuration ....................................................................................................................... 72
5.2.1 Establishing an IP-Address Pool ........................................................................................ 73
5.2.2 Setting Up the Concentrator as an Access Server ............................................................ 74
5.2.3 Setting Up CSM for Your Remote Devices ........................................................................ 75
5.3 Upgrading the Concentrator’s Firmware Through CSM ........................................................... 77
5.3.1 Using a TFTP Server .......................................................................................................... 78
5.3.2 Using a TFTP/BootP Server .............................................................................................. 80
6. Applications .......................................................................................................................................... 82
6.1 Windows 95/98/2000/NT Dial-up Networking .......................................................................... 82
6.1.1 Concentrator Configuration for Windows Dial-up Networking ...................................... 84
6.1.2 CSM Configuration for Windows Dial-up Networking (CSM Only) ............................... 85
6.1.3 Remote-Device Configuration for Windows Dial-up Networking ................................... 87
6.2 ISDN Router Running NAT ......................................................................................................... 89
6.2.1 Concentrator Configuration for NAT ............................................................................... 91
6.2.2 CSM Configuration for NAT (CSM Only) ........................................................................ 92
6.2.3 Remote-Router Configuration for NAT ............................................................................ 94
6.3 Standard ISDN IP Router ............................................................................................................. 95
6.3.1 Concentrator Configuration for Standard IP ................................................................... 97
6.3.2 CSM Configuration for Standard IP (CSM Only) ............................................................ 98
6.3.3 Remote-Router Configuration for Standard IP .............................................................. 100
6.4 ISDN Bridge ................................................................................................................................ 101
6.4.1 Concentrator Configuration for ISDN Bridging ............................................................ 103
6.4.2 CSM Configuration for ISDN Bridging (CSM Only) ..................................................... 104
7. Troubleshooting ................................................................................................................................. 105
7.1 Calling Black Box ........................................................................................................................ 105
7.2 Shipping and Packaging ............................................................................................................. 105

CHAPTER 1: Specifications
9
1. Specifications
Compliance — EMI/RFI:
USA: FCC (47CFR) Part 15 Subpart J Class A;
Canada: IC Class/classe A, CSA C108.8;
EU: CE (EN 55022 class A, EN 50082:1-1992, 89/336/EEC);
Australia/New Zealand: AS/NZ 3548;
Japan: VCCI V-3 93.01;
PSTN connection: FCC Part 68/IC-03;
Electrical safety:
USA: UL®1950;
Canada: CSA C22.2 No. 950;
EU: IEC 950, EN 60950, 73/23/EEC;
Australia/New Zealand: TS 001
Standards — LAN: IEEE 802.3 Ethernet v. 2;
Modem:
Main data interchange: ITU-T V.90, V.34, V.32 bis, V.32, V.22 bis,
V.22 A/B, V.23, and V.21; proprietary K56flex™ and V.34+;
Bell 212A and 103;
Error correction: ITU-T V.42 LAP-M, MNP®1 through 4 and 10;
Data compression: ITU-T V.42 bis and MNP 5;
RFCs: 768 (UDP), 791 (IP), 793 (TCP), 1157 (SNMP), 1213 (MIB-II/UDP,
DS0, SNMP), 1321 (MD5 Message Digest), 1332 (IPCP), 1406 (DSX1
MIB), 1638 (BCP), 1650 (Ethernet), 1661 (PPP), 1676 (PPP/HDLC
framing), 1696 (modem MIB), 1757 (RMON), 1877 (DNS and NBNS
address negotiation), 1990 (MLP), 1994 (PPP authentication/
PPP-CHAP), 2011 (SNMP v2 MIB for IP using SMI v2), 2013 (SNMP v2
MIB for UDP using SMI v2), 2021 (RMON v2 for SMI v2),
2127 (ISDN), 2138 (RADIUS authentication), 2139 (RADIUS
accounting), 2233 (interfaces MIB);
MIBs: Modem MIB, MIB-II, DSX1 MIB, DS0 MIB, SNMP MIBs, RMON
MIBs, interfaces MIB
Interfaces — WAN:
LRA3000A, LRA3002A: ISDN T1 PRI (including CT1 if CAS is
enabled) through integral CSU and digital modems;
LRA3001A, LRA3003A: ISDN E1 PRI (including R2 if CAS is enabled)
through digital modems;
LAN: 10BASE-T;
Console: EIA/TIA RS-232 (proprietarily pinned on RJ-45)
Protocols — WAN: Unnumbered IP WAN, HDLC, ISDN, R2 (for E1) or RBS (for
T1/CT1), digital modem, PPP, Multilink PPP, Async-PPP, Sync-PPP,
PPP-IPCP, PPP-BCP, PPP trace;
Console: Asynchronous

T1 AND E1 REMOTE ACCESS CONCENTRATORS
10
T1 Characteristics
(LRA3000A, LRA3002A) — ISDN PRI Signaling (switch types): N1-2, AT&T®4ESS/5ESS/Definity™;
DMS500/250/100, SL100, INS1500 (Japan);
Framing: D4/SF, ESF;
Line coding: B8ZS;
Channel-associated signaling: Robbed-bit signaling (RBS) including E&M
Wink Start (B8ZS)
E1 Characteristics
(LRA3001A, LRA3003A) — ISDN PRI Signaling (switch types): ETSI - CTR4/NET5 (Euro-ISDN),
1TR6 (Germany); TS014/TS038 (Australia/New Zealand);
for other countries, call Black Box Technical Support;
Framing: Multi-framing with CRC4, double framing;
Line coding: HDB3;
R2 channel-associated signaling: ITU, Mexico (Telmex™), Brazil,
Indonesia, or India (for other countries, call Black Box Tech Support)
Routing — IP: Default route, static routes, RIP v1 and v2;
All other routing protocols are supported for bridging only
Authentication — RADIUS authentication, PAP, CHAP, CLID, PPP Call Back (CBCP), basic
IP-address pooling; with proprietary CSM software, also supports proxy
to NT domains and proxy to RADIUS
Authorization — All authorization options require CSM;
IP Layer 4 policy controls (per TCP/UDP port) based on remote user
and/or device; time-of-day, bandwidth, and maximum connect-time
restrictions; priority port reservation; policy violation logging; and
dynamic profile updates
Accounting — RADIUS accounting; with proprietary CSM software, also supports PPP
connection statistics, connection accounting, and IP Layer 4 flow accounting
based on TCP/UDP port
Advanced Connection
Management — Modem-inactivity timer;
All other connection-management options require CSM:
Advanced IP-address pooling, static IP addresses, dial-out (calling out),
device connection history, connection-problem logging, connection
accounting, and SQL-based reporting and statistics
Device Management — In-band: SNMP;
Out-of band: RS-232 console, Telnet™ server, TFTP client
Number of
Internal Modems — LRA3000A: (48);
LRA3001A: (30);
LRA3002A: (24);
LRA3003A: (60)

CHAPTER 1: Specifications
11
User Controls — All models: (1) Front-mounted recessed RESET switch;
LRA3000A, LRA3002A only: (1) Front-mounted PINOUT switch
(affects pinout of WIDE AREA 1 port);
Firmware-resident terminal-based Local Management utility
for configuration and system management;
All advanced functions are software-controlled
Indicators — Front-mounted LEDs:
(1) for main power, labeled PWR;
(1) for self-test, labeled CPU;
(2) for the console (ASYNC) port, labeled LNK and STS;
(1) for the LAN (ENET) port, labeled STS;
(2) for each WAN (WIDE AREA) port, labeled LNK and STS;
All other indications are firmware- and software-based
Connectors — All front-mounted:
(1) RJ-45 female console port, labeled ASYNC;
(1) RJ-45 female LAN port, labeled ENET;
(1) RJ-48C female WAN port, labeled WIDE AREA 1;
LRA3000A, LRA3003A only: (1) RJ-48C female WAN port,
labeled WIDE AREA 2
MTBF — 50,000 hours (calculated estimate)
Temperature Tolerance — Operating: 32 to 104˚F (0 to 40˚C);
Storage: –22 to +194˚F (–30 to +90˚C)
Humidity Tolerance — 5 to 95% noncondensing
Power — From utility-power (mains) outlet(s), through included detachable power
cord(s), rear-mounted IEC 320 inlet(s), and internal transformer(s):
Input: 100 to 125 VAC (~300 mA) or 200 to 240 VAC (~150 mA) at
50 or 60 Hz (autosensing);
Current: Rated for 55 watts;
Inlets: Dual (redundant) IEC 320 male;
Consumption: 35 watts maximum
Size — 1.8"H (1U) x 15.5"W x 17"D (43.2 x 39.4 x 4.5 cm)
Weight — 13 lb. (5.9 kg)

T1 AND E1 REMOTE ACCESS CONCENTRATORS
12
2. Introduction
NOTE
This manual is intended to help you get your Remote Access Concentrator up and
running. It isn’t a detailed reference on the Concentrator’s operation; for more
complete information, use a standard browser to page through the HTML
documentation included on CD with the Concentrator. Also, you might want to check
our Black Box Web site (www.blackbox.com) for material that might be more up-to-
date than what you received, including software or firmware updates, updated MIBs,
and revised HTML documentation.
Enterprises seeking increased productivity and communication are extending dial-up access to their
telecommuting employees and business partners, and service providers are searching for ways to differentiate
their dial-up services to retain existing customers and attract new ones.
But this expansion in access is creating new challenges in the areas of security, accounting, and network
management. Our T1 and E1 Remote Access Concentrators (the LRA3000 series of product codes) directly
address these challenges by delivering the lowest-cost dial solutions with support built in for using RADIUS
for remote device authentication.
The Concentrators support high-density ISDN/V.90 concentration of dial-up traffic in a compact, rack-
mountable form factor. The Concentrators’ architecture supports universal dial access (ISDN or modem) on
every port, yielding excellent price/performance in a slender design that’s only 1U (1.8", 4.4 cm) high. Both
T1 and E1 versions are available, supporting two ISDN Primary Rate Interfaces (PRIs) and either 48 (T1)
or 60 (E1) DS0 connections; the DS0s can be any combination of V.90 (56K) modem and ISDN calls.
All Concentrators have redundant power supplies for added protection in mission-critical applications.
We also offer Connection Services Manager (CSM) software (our product code LRA300SW) for use with the
Concentrators. It performs remote device authentication, supports robust connection management, and gives
you real-time control over remote user authentication, policy definitions, and accounting from a centralized
server. More information about CSM is available in the HTML documentation on the CD that came with
your Concentrator.
The table below summarizes each Concentrator model’s options.
Model WAN Telco Interface(s) Number of V.90
Access Digital Modem Ports
LRA3000A T1 Dual ISDN T1/PRI 48
LRA3001A E1 Single ISDN E1/PRI 30
LRA3002A T1 Single ISDN T1/PRI 24
LRA3003A E1 Dual ISDN E1/PRI 60
NOTE
The T1 models support ISDN Primary Rate Interface (PRI) in Canada, the United
States, and Japan. The E1 models support ISDN Primary Rate Interface (PRI) in
Europe, the Asia-Pacific region (excluding Japan), and Latin America.

CHAPTER 2: Introduction
13
The figure below shows the Concentrator’s front panel, where most of its connectors and indicators are.
The connectors are discussed in more detail in the next chapter of this manual, and the LED indicators
are discussed in the Concentrator’s HTML documentation.
WIDE AREA 1
LNK
STS
ASYNC
LNK
STS
ENET
STS
CPU
PWR
PINOUT
RESET
WIDE AREA 2
LNK
STS
TELCO

T1 AND E1 REMOTE ACCESS CONCENTRATORS
14
3. Installation
CAUTION!
Only qualified personnel should attempt to install this equipment.
3.1 The Complete Concentrator Package
You should have received these things with your Remote Access Concentrator:
• The Concentrator itself.
• (1) Console cable for connections to the Concentrator’s ASYNC port.
• (1) RJ-45 M to DB9 F adapter for use with the console cable.
• (1) or (2) Cross-pinned WAN cable(s) for connections to the Concentrator’s WIDE AREA port(s).
• (1) Standard 10BASE-T cable for connections to the Concentrator’s ENET port.
• A grounding wrist strap for installers and maintenance people to wear, to prevent static discharges
that might damage the Concentrator.
• (4) Adhesive rubber feet for placing the Concentrator on a desk, counter, etc.
• A rackmount kit for mounting the Concentrator in a 19" rack.
• (2) Power cords.
• (1) CD of HTML documentation.
• This manual.
If anything is missing or arrives damaged, please call Black Box right away.
3.2 Arranging ISDN Service
Before you install your Remote Access Concentrator, we recommend that you contact your telco or service
provider and arrange for ISDN service compatible with the Concentrator:
1. Make sure that they use a type of ISDN central-office switch that the Concentrator supports.
2. Order an ISDN PRI line if you haven’t done so already.
3. Ask them for the ISDN line’s phone number, any prefix necessary for dialing, and the specs for line
encoding, framing, and (for T1 models) the T1 LBO.
For more details, see the “ISDN Line Ordering,” “ISDN PRI Line Information,” and “Telephone Switch
Support” sections in the Concentrator’s HTML documentation.

CHAPTER 3: Installation
15
3.3 Setting the Pinout Switch for Your WAN Interface (T1 Models Only)
The T1 models of the Remote Access Concentrator have a PINOUT switch on their front panels. This switch
allows you to make WAN-interface adjustments based upon country of usage for the Concentrator’s WIDE
AREA 1 port. (For instructions on connecting cables to this port, see Section 3.6.3.) For North American
installations, this switch should be set to the left (the default setting). For use in Japan, this switch should
be set to the right. The switch positions translate to the following WAN-connector pinout settings:
Switch set to the left for use in North America:
pin number 1245
polarity +–+–
direction receive receive transmit transmit
Switch set to the right for use in Japan:
pin number 3456
polarity ++––
direction transmit receive receive transmit
NOTE
As stated above, the PINOUT switch adjusts the pinout setting for the WIDE AREA 1
port only. The default pinout for both ports (WIDE AREA 1 and WIDE AREA 2) is for
North American use. If the LRA3000A or LRA3002A is used in Japan, a ModTap™
adapter is required for the WIDE AREA 2 port to have a correct pinout.
E1 models of the Concentrator don’t have a PINOUT switch; they use this unchangeable, international-
standard WAN-connector pinout:
pin number 1245
polarity +–+–
direction receive receive transmit transmit

T1 AND E1 REMOTE ACCESS CONCENTRATORS
16
3.4 Placement
Installation sites must be within reach of the network cabling and must meet the following requirements:
• A properly grounded AC power receptacle must be within 7 feet (2.1 m) of the location.
• Temperatures at the installation site must remain between 32 and 104˚F (0 and 40˚C), with fluctuations of
less than 18˚F (10˚C) per hour.
• If you are placing the Concentrator on a shelf, the shelf must be able to firmly support 13 lb. (5.9 kg) of
static weight for each Concentrator on the shelf.
• If you are placing the Concentrator in a rack, there must be at least two inches (5 cm) of clearance on each
side of and behind the Concentrator for adequate ventilation.
3.5 Rackmounting (Optional)
CAUTION!
Before installing the Concentrator in a rack, make sure that the rack can hold the
Concentrator securely without toppling, warping, breaking, etc. Otherwise, personal
injury and equipment damage might result.
Do not use screws other than those included with the Concentrator’s Rackmount
Kit to attach the Kit’s rackmount brackets to the Concentrator’s chassis. Wrong-sized
screws can cause electrical shorts and can physically damage the Concentrator.
To mount a Remote Access Concentrator in a 19" rack, you’ll need to attach the brackets from its included
rackmount kit to the Concentrator, then attach the bracketed assembly to your rack. You’ll need both a flathead
and a Phillips screwdriver to do this.
Take these steps:
1. Decide which way you want the Concentrator to face. The standard installation is with the front of the
Concentrator facing the front of the rack; the rest of the directions in this section assume that orientation.
But you can install the Concentrator with its rear panel facing the front of the rack instead. If you do so,
you’ll have to install the brackets upside down, so that they screw onto the bottom edge of the
Concentrator’s side. You’ll also have to substitute “rear of the Concentrator” for “front of the
Concentrator” in the following steps.
Rear flanges
Front end Front end
Rear flanges

CHAPTER 3: Installation
17
2. With the Concentrator’s faceplate (the front of the unit) towards you, take the Rackmount Kit’s brackets
and place one on either side of the Concentrator, so that the front end of each bracket lines up with the
faceplate.
3. There are slots in each side of the Concentrator that are made to accept the brackets’ rear flanges, as
shown below. Swing the front of each bracket outward, insert the flanges in these slots, and swing the front
back in. (If, after you do this, the front of a bracket doesn’t line up with the Concentrator’s faceplate, or
the screwholes along the top of the side a bracket don’t line up with the screwholes on the side of the
Concentrator’s chassis, swing the bracket back out and adjust how the flanges are seated in the slots.)
4. Using the four included 6⁄32 x 1⁄4-inch flathead screws, attach each bracket to the Concentrator along the top
of the Concentrator’s chassis, as shown below.
Front panel of Concentrator
Bracket screw holes
Insert flanges...
...then swing inward
Bracket
Bracket
Screws
Screws

T1 AND E1 REMOTE ACCESS CONCENTRATORS
18
5. Fasten the bracketed Concentrator assembly to the vertical frame of a 19" rack using your own mounting
screws, bolts, cage nuts, etc., as shown below.
Concentrator in 19" rack
Mounting
screws
Mounting
screws

CHAPTER 3: Installation
19
3.6 Making Cable Connections
3.6.1 CONSOLE (ASYNC) CONNECTIONS
The Remote Access Concentrator’s RJ-45 female RS-232 console port (labeled ASYNC) is the gateway to the
Concentrator’s local management (configuration) utility. It’s proprietarily pinned out this way:
Pin Function
1 Transmit Data (TD)
2 Carrier Detect (CD)
3 Data Set Ready (DSR)
4 Receive Data (RD)
5 Signal Ground (SGND)
6 Data Terminal Ready (DTR)
7 Request To Send (RTS)
8 Clear to Send (CTS)
(Refer to the Concentrator’s HTML documentation for complete information about this port and its two
associated LEDs.)
To attach a console to this port, use the included RJ-45 male-to-male console cable to make the following
connection:
1. Plug one end of the cable into the Concentrator’s console (ASYNC) port.
2. Plug the other end of the cable into the RJ-45 to DB9 adapter that’s included with the Concentrator in its
“console cabling kit.”
3. Plug the adapter into the serial port of a terminal or of a PC running a communications package that can
do VT100™ emulation.
PC
Console
connection
RJ-45 to DB9
Adapter
RJ-45 console
cable
Serial ports
Front panel
of
Concentrator
