BluDot Open Plan Desk Quick start guide

Open Plan Desk
DESIGNED IN 2020
ASSEMBLY NOTES | REV 00
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
@BLUDOT
We design all our pieces in our Minneapolis studio. Follow
along on Instagram for some sneak peeks into the process.

1 | 844.425.8368 OPEN PLAN DESK
8041
An�-�p Bracket
8042
An�-�p Strap
Pt. 1217
Pt. 8054 Pt. 8053 Pt. 5013
2
2 4 4
QTY
QTY QTY QTY
Pt. 1218
Pt. 4022
Pt. 3002
Right Side Frame
Pt. 1613
Left Side Frame
2
4
2
1
2
1
QTY
QTY
QTY
QTY
QTY
QTY
Pt. 8041
Pt. 1690
Stretcher
QTY
QTY
QTY
Pt. 8042
Pt. 9016
Desk Top
1
1
1
QTY
QTY
QTY
2
8
1
Parts & HardwareParts & Hardware

[e-mail] |2ASSEMBLY NOTES
PT. 5013 x 4PT. 1613 x 2PT. 3002 x 2PT. 9016 x 1PT. 4022 x 4
Pt. 5013
Wooden
Dowel
Step 01
ATTACH STRETCHER TO SIDE FRAMES.
Assemble the desk on soft surface.
Assemble stretcher to side frames using the provided
hardware as shown. Do not fully tighten bolts.
Thread adjustable glides into place as shown.

3 | 844.425.8368 OPEN PLAN DESK
PT. 8053 x 4PT. 1690 x 8PT. 9016 x 1
Step 02
ATTACH DESK TOP.
Attach the side frames to the desk top using the provided
hardware as shown.Tighten bolts in the stretcher and all four
corners before use.

[e-mail] |4ASSEMBLY NOTES
PT. 1217 x 2
8041
An�-�p Bracket
PT. 8041 x 1
Step 03
ATTACH ANTI-TIP BRACKET TO DESK.
Brackets must be installed to the back rail of the desk.
In order to prevent damage, it is recommended that
3/32” pilot holes be drilled prior to installation.
Note: Ensure that the depth of the pilot hole does not
exceed 1/2”. A deeper pilot hole may be visible on the
opposite side.

5 | 844.425.8368 OPEN PLAN DESK
PT. 1218 x 2PT. 8054 x 2
8041
An�-�p Bracket
PT. 8041 x 1
1” lower than
desk top
OR
wall
wall
Step 04
ATTACH ANTI-TIP BRACKET TO WALL.
Wall anchors and fasteners are included for installation
into drywall. Please consult your local hardware
professional to determine the hardware best suited for
your wall type.
If the mounting locations are positioned on a stud, the
installation of wall anchors may be skipped. Instead,
drill 7/64” pilot holes in the marked positions and install
anti-tip bracket with provided hardware as shown.
If the mounting locations are not positioned on a stud,
drill 15/64” holes into the marked locations and press
wall anchors into the drilled holes and install anti-tip
bracket with provided hardware as shown.

[e-mail] |6ASSEMBLY NOTES
8042
An�-�p Strap
PT. 8042 x 1
Step 05
SECURE DESK.
Install and tighten wall strap prior to using the product.
Ensure the desk is level prior to use.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use quality cleaners formulated for
wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
