BluDot Open Plan Tall Bookcase Quick start guide

Open Plan Tall Bookcase
DESIGNED IN 2019
ASSEMBLY NOTES | REV 02
NEED A HAND?
Contact us at [email protected] or
844.425.8368 for assistance.
@BLUDOT
We design all our pieces in our Minneapolis studio. Follow
along on Instagram for some sneak peeks into the process.

1 | 844.425.8368 OPEN PLAN TALL BOOKCASE
8041
An�-�p Bracket
8042
An�-�p Strap
Front Upright
2QTY
Rear Left Upright
1QTY
Rear Right Upright
1QTY
Pt. 1217
Pt. 8054
Pt. 8053
2
2
8
QTY
QTY
QTY
Pt. 1218
Pt. 4022
Back Panel
2
4
2
QTY
QTY
QTY
Pt. 8041
Pt. 1690
Top Panel
QTY
QTY
QTY
Pt. 8042
Pt. 9016
Shelf Panel
1
1
5
QTY
QTY
QTY
2
24
1
Parts & Hardware
pin holes
pin holes
Parts & Hardware

[e-mail] |2ASSEMBLY NOTES
PT. 1690 x 12 PT. 9016 x 1
front upright
rear right upright
pin holes in
rear right upright
Step 01
ATTACH TOP PANEL AND SHELF PANELS.
Attach the top and shelf panels to the rear right upright
and front upright using the provided hardware as shown.
Ensure that the correct rear upright part is used by
matching the orientation of the pin holes shown below.

3 | 844.425.8368 OPEN PLAN TALL BOOKCASE
PT. 8053 x 8
Step 02
ATTACH BACK PANEL TO REAR UPRIGHT.
Place metal pins in the rear right uprights and align with
back panel pieces as shown.

[e-mail] |4ASSEMBLY NOTES
PT. 4022 x 4
PT. 1690 x 12 PT. 9016 x 1
front upright
rear left upright
Step 03
ATTACH REMAINING UPRIGHTS.
Attach the remaining rear left upright and
front upright using the provided hardware
as shown. Ensure that the back panel pins
align with the rear left upright.
Step 04
INSTALL ADJUSTABLE GLIDES.
Install adjustable glides to the bottom of
the uprights as shown. Ensure that the
uprights are level prior to using the product.

5 | 844.425.8368 OPEN PLAN TALL BOOKCASE
PT. 1217 x 2
8041
An�-�p Bracket
PT. 8041 x 1
Step 05
ATTACH ANTI-TIP BRACKET TO BOOKCASE.
Brackets must be installed to the back rail of the shelf
panel. In order to prevent damage, it is recommended
that 3/32” pilot holes be drilled prior to installation.
Note: Ensure that the depth of the pilot hole does not
exceed 1/2”. A deeper pilot hole may be visible on the
opposite side.

[e-mail] |6ASSEMBLY NOTES
PT. 1218 x 2PT. 8054 x 2
8041
An�-�p Bracket
PT. 8041 x 1
1” lower than
shelf panel
OR
wall
wall
Step 06
ATTACH ANTI-TIP BRACKET TO WALL.
Wall anchors and fasteners are included for installation
into drywall. Please consult your local hardware
professional to determine the hardware best suited for
your wall type.
If the mounting locations are positioned on a stud, the
installation of wall anchors may be skipped. Instead,
drill 7/64” pilot holes in the marked positions and install
anti-tip bracket with provided hardware as shown.
If the mounting locations are not positioned on a stud,
drill 15/64” holes into the marked locations and press
wall anchors into the drilled holes and install anti-tip
bracket with provided hardware as shown.

BLU DOT DESIGN & MANUFACTURING, INC. DESIGNED IN MINNEAPOLIS, MN
8042
An�-�p Strap
PT. 8042 x 1
Additional Information
CLEAN
Clean with a slightly damp, soft cloth. To remove dirt and fingerprints, use quality cleaners formulated for
wood furniture. Wipe completely dry with a soft cloth in the direction of the wood grain.
Step 07
SECURE BOOKCASE.
Install and tighten wall strap prior to using the product.
