Blue Tiger Storm User manual

THE BLUE TIGER STORM MANUAL
www.BlueTigerUSA.com

Our mission is to help
professional drivers be safe while
traveling on the road.
®
1

Volume levels are measured in decibels (dB). Exposing your ears to any noise
at or above 85 dB can cause gradual hearing loss.
According to the Occupational Safety and Health Administration (OSHA),
listening to volume levels over 100 dB for more than two hours at a time can
lead to hearing loss.
http://www.osha.gov/SLTC/noisehearingconservation/#loud
2

Table of Contents:
1. Product Overview --------------------------------------------------------------------------------------------------------------------------------------------------- 4
2. Basic Operations ---------------------------------------------------------------------------------------------------------------------------------------------------- 5
3. Bluetooth Pairing and Connection ---------------------------------------------------------------------------------------------------------------------------- 7
4. Connection with Two devices ----------------------------------------------------------------------------------------------------------------------------------- 8
5. LED Indicator --------------------------------------------------------------------------------------------------------------------------------------------------------- 9
6. Charging -------------------------------------------------------------------------------------------------------------------------------------------------------------- 10
7. TTS Tone -------------------------------------------------------------------------------------------------------------------------------------------------------------- 12
8. Product Specification -------------------------------------------------------------------------------------------------------------------------------------------- 13
9. Attention and Q & A ----------------------------------------------------------------------------------------------------------------------------------------------- 14
3

B
1. Product Overview:
Package Contents:
A. Bluetooth Mono Headset Blue Tiger Storm x1
B. USB-C Charging Cable x 1
C. Mic Windscreen x 1
D. FCC Certified DC (Vehicle Charger) x 1
E. Quick Start Guide
C
DE
AMute the microphone button
Volume-
Volume+
Type-C Charge Interface
MFB (Multi Function Button)
Microphone
4

2. Basic Operations:
Button Function Operation
In off status, hold MFB for 2 seconds to power on. Blue Tiger Storm will power on and enter pairing
mode automatically if it does not have a pairing record . ( it will enter reconnect mode
automatically if it has a pairing record)
In on status, hold MFB for 3 seconds to power off.
In off status, hold MFB for 2 seconds to power on and enter pairing mode. If the headset is not
paired within 10 minutes, it will power off automatically.
Press to play music.
In connected standby/playing music mode, double press MFB to dial the last call.
Incoming call during a call, press the MFB to answer the new call and hang up the current call;
Incoming call during a call, double press the MFB to answer the new call and keep the current call;
Incoming call during a call, hold the MFB for 2 seconds to reject the new call. When you are on a
three-party call, double press the MFB to switch audio between the current call and the other call.
In connected standby/playing music mode, hold MFB for 2 seconds then release.
Press MFB to answer an incoming call.
During a call, press MFB to end the call.
Multi-function
Button(MFB)
Power On
Power Off
Enter into Pairing Mode
Play / Pause
Redial A Call
Three-way calling function
Voice Dialing
Answer
Hang up
5

Multi-function
Button(MFB)
Volume +
Volume -
Press MFB for 1 second to ignore an incoming call.
In the paired state, hold MFB for 2 seconds to activate Siri and Google Assistant.
Press.
Hold for 1 second.
Press.
Hold for 1 second.
During a call, press button to mute, press again to cancel.
Reject a call
Activate Siri and Google Assistant
Volume Up
Next Song
Volume Down
Previous Song
Microphone Mute
Mute the microphone button
6

3. Bluetooth Pairing and Connection:
A. In off status, hold MFB for 2 seconds to enter pairing mode. LED will flash Blue and Red.
B. On your phone, access the Bluetooth menu and select Add New Device, or search for New Device.
C. Select Blue Tiger Storm.
D. LED changes to a Blue slow flash once connected, now you can begin using your headset.
Pairing: In off status, hold MFB for 2 seconds to enter
pairing mode. LED will flash Blue and Red.
Connection: Search and click to connect
“ Blue Tiger Storm” on your phone
Bluetooth lists.
2ConnectionPairing
Search and connect
7

4. Connection with Two devices:
A. Follow part 3 to connect with first phone, then turn off the Bluetooth function of first phone.
B. The headset will enter pairing mode automatically. LED will flash Blue and Red. Turn on the Bluetooth function of second phone to
search and connect “Blue Tiger Storm”, LED changes to a Blue slow flash after connected.
C. Turn on Bluetooth function of first phone, click to reconnect "Blue Tiger Storm" on Bluetooth lists. Headset is connected with two
phones now. Expect up to 5 seconds to switch between music.
Notes:
Music only can be played from one phone under two connections, when you want to play music from another phone, you
need to pause or close the music of the previous phone. The same operation during talking status.
8

5. LED Indicator:
Mode
Power on
Power off
Pairing mode
Unconnected standby mode
Connected standby mode
Playing Music
Talking
Delete pairing record
Low battery
Charging
Fully Charged
LED Indicator
LED Blue flashes 2 seconds
LED Blue flashes 2 seconds
LED Red & Blue flashes alternately
LED Blue flashes twice every 5 seconds
LED Blue flashes once every 10 seconds
LED Blue flashes once every 10 seconds
LED Blue flashes once every 10 seconds
Blue and Red LED flashes once at the same time
Solid LED Red
Solid LED Red
Blue LED Flash
9

Charging with Charger
Charging with PC
6. Charging:
Please charge the Blue Tiger Storm headset at once when the Red LED flashes. Charging time is about 1.5 hours. Solid Red LED will
turn off when fully charged.
Charge Connections
Please connect to the Blue Tiger Storm charging port through the Type-C end of Type-C charging cable, USB end to the
charger, can be used as car charger, travel charger, computer USB, etc.
10

Notes:
1. Please charge your Blue Tiger Storm at least once every 2 months when not in use.
2. Charging when power on, it is normal that the charging indicator will be on at the same time as the Bluetooth indicator.
3. Make sure it's fully charged before the first use.
4. Charge the headset with the USB-C cable provided.
5. Charging when using headset: When your Blue Tiger Storm needs to be used for a long time, due to the limited working time of the
built-in battery, it is allowed to connect the charging power supply (DC 5V ≥ 500mA, low battery or poor power quality may cause
the current sound); Operation: connect the charging power first and then turn on the Blue Tiger Storm.
Please note: it is not recommended to use the headset frequently when charging, otherwise it may affect the life of the battery.
11

7. TTS Tone:
Power on
Enter pairing mode
Paired successfully
Connected successfully
Disconnect
Power off
Microphone mute on
Microphone mute off
Power on
Pairing
Paired
Your headset is connected
Your headset is disconnected
Power off
Mute on
Mute off
12

8. Product Specification:
Bluetooth Version
Bluetooth Chipset
Frequency Range
Operation Range
Bluetooth Protocols
CODEC Code
Standby Time
Working Time
Charging Time
Battery Capacity
Working Temperature
Headset Net Weight
Headset Dimension
V5.0, Class II
QCC3020
2.402GHz-2.480GHz
Up to 100 feet
HSP, HFP, AVRCP, A2DP
AAC, SBC
Approx. 85 hours
Approx. 32 hours (70% volume)
Approx. 1.5 hours
400mAh/3.7V
14 °F to 131°F
138.8g (approx 4.9 ounces)
188.72 x 150.03 x 59.68 mm (7.43 x 5.9 x 2.35 inches)
Notes: *Actual use time will differ from environment and music.
13

9. Attention and Q & A :
A. How to reconnect and operate when failed to reconnect?
When Blue Tiger Storm is connected with your mobile phone successfully the first time, it will search and reconnect the paired device
automatically when powered on, If failed, please pair and connect again. Blue Tiger Storm can be reconnected in 10 minutes, it will
power off if over 10 minutes. It will have a tone “Your headset is connected”
B. How to Delete paired records?
In pairing mode, hold the MFB and Volume - Button for 5 seconds to clear the pairing record. The indicator Blue and Red LED is on
for 1 second at the same time ; that means the pairing record has been cleared, and your Blue Tiger Storm will not connect the
connected device. When there are various connection problems, try clearing the pairing record first.
C. What devices could charge the headphone?
Any car charger, power bank, PC, etc, which meet DC 5V charging current at more than 500mA, could be used to charge this item.
D. What’s the password for pairing?
Some connection devices require a password for pairing, please try 0000 or 8888 or 1111 or 1234.
14

E. If there are some exceptions such as not being able to power on, abnormal connection and so on?
Please try charging to reset: press and hold the MFB, plug in charging cable to charge, this will reset the headset to power off, it can
be used normally after powered on.
F. Power off automatically.
Blue Tiger Storm will power off if it does not connect any devices for over 5 minutes, or battery voltage is less than 3.1V.
G. Three-way calling function operation.
Incoming call during a call, press the MFB to answer the new call and hang up the current call .
Incoming call during a call, double press the MFB to answer the new call and keep the current call .
Incoming call during a call , hold the MFB for 2 seconds to reject the new call.
When you are on a three-party call, double press the MFB to switch audio between the current call and the other call.
15

Industry Leading Customer Support
At Blue Tiger USA, we stand behind our products. We believe that our customer
service does not end when we process your payment, but it continues for as long
as you use our headset.
One-Year Manufacturer’s Warranty
(1) Blue Tiger USA warrants that your product will be free from defects in
material and workmanship for one year from the date of purchase. If, during
the first year from the date of purchase, your product fails to work due to a
defect in material or workmanship, Blue Tiger USA will repair or replace the
product, at its election, free of charge. Without proof of purchase, the warranty
period begins on the date of manufacture. Consumable components (for
example, cushions and battery) are not included in this one-year warranty.
16

(2) The foregoing limited warranty does not cover equipment failure attributable
to accident, improper operation, misuse, abuse, or any cause other than
defects in the materials or workmanship of Blue Tiger USA products.
(3) Blue Tiger USA obligations under this warranty are limited to repair or
replacement (at our option) of any defective part returned to Blue Tiger USA
at the customer’s expense. Returned products require a Return Authorization
that may be obtained by calling 800-935-1165 or visiting BlueTigerUSA.com.
Products returned to Blue Tiger USA for repair under this warranty will be
return shipped to the customer at Blue Tiger USA expense.
17
