BLUM AVENTOS HF User manual

AVENTOS HF
1
Dimensions in millimeters (inch equivalents as noted) © 2021
Telescopic arm set
▀ Telescopic arm (qty 2)
Cabinet heights Part no.
479 (18-7/8") - 558 (22") 20F3200.01
558 (22") - 686 (27") 20F3500.01
686 (27") - 889 (35") 20F3800.01
889 (35") - 1067 (42") 20F3900.01
Cover set
▀ Right and left cover plate
▀ Non-handed cover cap (qty 2)
Cover set 20F8020.NA
Lift mechanism set
▀ Lift mechanism (qty 2)
▀ #7 x 35 mm (1-3/8”) wood screw (qty 8)
Power factor Part no.
85 - 230 (1 lift mechanism req.) 20F2200.N5
231 - 470 20F2200.N5
471 - 880 20F2500.N5
780 - 1440 20F2800.N5
1401 - 2300 (3 lift mechanisms req.) 20F2800.N5
Wood or wide alum door hardware set
▀ CLIP top 120° hinge (qty 2)
▀ COMPACT 33° hinge (qty 2)
▀ CLIP top bottom door hinge (qty 2)
▀ COMPACT mounting plate (qty 2)
▀ Face frame adapter (qty 4)
▀ Telescopic arm mounting plate (qty 2)
NOTE: Three hinges and mounting plates required
for cabinet widths over 1219 (48").
Hardware set 78Z5530TA8
Inst. screw for wood doors 606N or 606P
Inst. screw for wide alum doors 7072A
Mounting plate with bracket set
▀ Left and right mounting plate with bracket
▀ For large overlay five-piece doors
Part no.
Mounting plate w/ bracket set 175H3F00
Wood/wide aluminum
frame door application
Part no.
▀ Colors: Light Gray, Dark Gray and Silk White
Part no.

Subject to technical modifications without notice. © 2021
2
1Locating pin locations
Frameless
TR = Top reveal
TDH = Top door height
Top door height
(TDH) Y
231 to 271 TDH x .6 - 28 + TR
272 to 531 TDH x .6 - 57 + TR
Face frame
T o p d o o r h e i g h t
(TDH) Y
231 to 271 TDH x .6 - 28 + TR
272 to 531 TDH x .6 - 57 + TR
TR = Top reveal
TDH = Top door height
192
Y
37
TDH
TR
Ø5
NOTE: Face frame cabinets must be blocked out flush with the frame or use
face frame mounting bracket 20F6001.
Assembly
Universal individual template is available for pre-boring holes for locating pins.
Part no.
65.1051.02
WARNING
Risk of injury from spring-loaded arm
▀ Do not push arm assembly down or leave in the down position.
▀ Remove mechanism before installing or removing cabinet.
192
Y
37
Top door height
TR
Ø5

3
Dimensions in millimeters (inch equivalents as noted) © 2021
Align the two locating pins on the lift mechanism with the two Ø5 x 5 holes bored in the side of
cabinet, and attach the mechanism with the five wood screws provided.
2Attaching the lift mechanism
#7 x 35 mm (1-3/8") wood screws (qty 4)
3Attach the telescopic arms
WARNING: Risk of injury from spring loaded arm.
Attach telescopic arms by clipping them on in the fully upright position.
min 5
5
Assembly

Subject to technical modifications without notice. © 2021
4
4Small overlay top door hinge planning CLIP top hinges
5Large overlay top door hinge planning COMPACT hinges
B
overlay
12.7
overlay
B
1/2"
Part no.
CLIP top hinge 70T5580.TL
Mounting plate 175H6000
Part no.
COMPACT hinge
32.4630
Mounting plate 130.1130.02
Overlay table
13 * 14 15 16 17
33456
B Bore distance
* Bore at 3 then adjust 1
Overlay table
1-1/4”
3
Bore distance
Assembly

5
Dimensions in millimeters (inch equivalents as noted) © 2021
reveal
B
12.7
Reveal table
6 5 4 3
3456
B Bore distance
Part no.
CLIP top hinge 78Z5530T
Mounting plate 175H6000
6Bottom door hinge planning
7a
NOTE: For five-piece door mounting
specifications, see page 6.
Attaching the telescopic arm mounting plates
12.5+Overlay
XTDH
17
min.
Top door
height (TDH) X
231 to 271 TDH x .5 + 70
272 to 531 TDH x .5 + 47
Part no.
175H3100
Telescopic arm mounting plate
Assembly

Subject to technical modifications without notice. © 2021
6
less than 6
12.5
19
12.5
ü
Standard mounting plate works.
Attaching the telescopic arm mounting plate with bracket for five-piece doors
7b
more than 6
12.5
ü
Standard mounting plate does not work.
Use mounting plate with bracket when
panel is < 6 from screw.
Part no.
175H3F00
Telescopic arm mounting plate with bracket
Assembly

7
Dimensions in millimeters (inch equivalents as noted) © 2021
8Attach the top door to the cabinet
9Attach the bottom door
Attach bottom door to the top door and attach the telescopic arms.
1
ab
Assembly

Subject to technical modifications without notice. © 2021
8
11 Finalizing the door adjustments
1. Adjust each top door hinge and
mounting plate to properly align the top
door to the cabinet.
2. Adjust each bottom door hinge and
mounting plate to properly align doors to
the cabinet and to the top door.
± 2 mm± 2.5 mm ± 2 mm± 2 mm± 3 mm + 3/- 2 mm
1 2
10
2
1
NOTE: Although not illustrated here, telescopic arm mounting plates can also be adjusted
horizontally ± 2 mm if needed.
Assembly
Adjust tension of the mechanism
Use #2x2 POZI bit
1. Close and flush doors to cabinet. Open
and close door to test closing force.
2. Open door and adjust tension screws on
both lift mechanisms with a power drill. Test
door again and repeat until desired function
is achieved.
Tension adjustment should be the same on both lift mechanisms.

9
Dimensions in millimeters (inch equivalents as noted) © 2021
13 Attach covers
Attach the left and right cover plates to each lift mechanism.
Adjust and lock telescopic arms
12
1. Close and flush doors to cabinet. While
pressing on the top door, pull the bottom door
open one inch.
2. Slightly open door and lock the telescopic
arms into position using the levers as shown.
12
Open door
enough to
lock levers.
Assembly

Subject to technical modifications without notice. © 2021
10
Detaching the telescopic arms
1
2
Remove covers
WARNING
Release both arms and gently rest
the top door on the loose arms. The
tension will hold the doors up for the
next step.
Warning: Risk of injury
from spring-loaded
telescopic arm!
Maintain control of telescopic arm
while releasing the CLIP mechanism.
Removal
Risk of injury from spring-loaded arm
▀ Do not push arm assembly down or leave in the down position.
▀ Remove mechanism before installing or removing cabinet.
1
2
1
2
Remove left and right cover plates.

11
Dimensions in millimeters (inch equivalents as noted) © 2021
3Removing the doors
1. Hold the bottom door while unclipping the bottom hinges.
2. Hold the top door while detaching the top hinges. Simply unclip them if using the CLIP top
hinges or loosen them if using COMPACT.
2
1
4Removing the telescopic arms
Using a screwdriver, depress the release tabs to remove telescopic arms.
If transporting the cabinet to the jobsite, stop here. Lift mechanisms stay inside the cabinet for
easy transport.
1
2
1
2
Removal

Door clearance above cabinet.
Z
TDH
Z = TDH x .44 + 38
INST-AVT07.21
Inch mm
1/32 .031 1
1/16 .063 1.5
3/32 .094 2
1/8.125 3
5/32 .15 6 4
3/16 .18 8 5
7/32 .219 5.5
1/4.25 6
9/32 .281 7
5/16 .313 8
11/32 .344 9
3/8.375 9.5
13/32 .406 10
7/16 .438 11
15/32 .469 12
1/2 .5 13
17/32 .531 13.5
9/16 .563 14
19/32 .594 15
5/8.625 16
21/32 .656 17
11/16 .688 17. 5
23/32 .719 18
3/4.75 19
25/32 .781 20
13/16 .813 20.5
27/32 .844 21
7/8.875 22
29/32 .906 23
15/16 .938 24
31/32 .969 24.5
1 1 25.4
