BLUM AVENTOS HF User manual

AVENTOS HF
Subject to technical modifications without notice. © 2018 1
Telescopic arm set
▀ Telescopic arm (qty 2)
Cabinet heights Part no.
479 (18-7/8") — 558 (22") 20F3200.01
558 (22") — 686 (27") 20F3500.01
686 (27") — 889 (35") 20F3800.01
889 (35") — 1067 (42") 20F3900.01
Cover set
▀ Right and left cover plate
▀ Non-handed cover cap (qty 2) Part no.
Cover set 20F8000.NA
Lift mechanism set
▀ Lift mechanism (qty 2)
▀ #7 x 35 mm (1-3/8”) wood screw (qty 8)
Power factor Part no.
85 — 230 (1 lift mechanism req.) 20F2200.N5
231 — 470 20F2200.N5
471 — 880 20F2500.N5
780 — 1440 20F2800.N5
1401 — 2300 (3 lift mechanisms req.) 20F2800.N5
Narrow aluminum door hardware set
▀ 72T550A.TL — CLIP top free swing narrow alum. top door hinge (qty 2)
▀ 78Z550AT — CLIP top narrow aluminum bottom door hinge (qty 2)
▀ 175H3100 — Top door mounting plate (qty 2)
▀ 175H5A00 — Bottom door mounting plate (qty 2)
▀ 175H5B00 — Telescopic arm mounting plate (qty 2)
▀ 669.110 — Aluminum screw for the bottom door mounting plate, bottom hinge,
top hinge and telescopic arm mounting plate (qty 18)
NOTE: Three hinges and mounting plates are required for cabinet widths over 1219 (48”) or combined
door weight of 26.5 lb
Narrow aluminum door hardware set 78Z550ATA6
Installation screw for top mounting plate 606N or 606P
Narrow aluminum
frame door application
Part no.

Subject to technical modifications without notice. © 2018
2
Part no.
65.1051.02
192
Y
37
Top door height
TR
Ø5
TR = Top reveal
TDH = Top door ht.
Top door height
(TDH)Y
231 to 271 TDH x .6 - 28 + TR
272 to 531 TDH x .6 - 57 + TR
Universal individual template is available for pre-boring 5 mm locating pins
1Locating pin locations
Assembly
WARNING
Risk of injury from spring-loaded arm
▀ Do not push arm assembly down or leave in the down position
▀ Remove mechanism before installing or removing cabinet

3
Subject to technical modifications without notice. © 2018
WARNING: Risk of injury from spring loaded arm.
Attach telescopic arms by clipping
them on in the fully upright position.
2Attach the lift mechanism
3Attach the telescopic arms
Align the lift mechanism in the cabinet using the 5 mm locator pins and attach the mechanism with the four
wood screws provided.
#7 x 35 mm (1-3/8") wood screws (qty 4)
5min.
Ø5

Subject to technical modifications without notice. © 2018
4
19
1
.
7
21
66
15
66
3
21
Assembly
4Top door hinge planning
5Bottom door hinge planning
Part no.
Aluminum door hinge
72T550A
In-line mounting plate
175H3100
Part no.
Aluminum door bottom hinge
78Z550AT
Bottom door mounting plate
175H5A00

5
Subject to technical modifications without notice. © 2018
22
31
11.4
38
44
R4
19
‒
21
R4
7.5 1. 4
min.
90°
– 0.1
Ø7
1.1
38
X
17
min.
Top door height
NOTE: 3 hinges are
required for cabinet width
over 1219 mm (48") or 26.5
lb. combined door weight
Top door
height (TDH)X
231 to 271 TDH x .5 + 70
272 to 531 TDH x .5 + 47
6Frame preparation
7Bottom door planning
Part no.
Telescopic arm mounting plate
175H5B00

Subject to technical modifications without notice. © 2018
6
Determine the locations of
mounting plates and hinges
and attach the hardware to
cabinet doors. Attach top door
to the cabinet.
Attach bottom door to the top door and
attach the telescopic arms.
Assembly
8Attach the top door to the cabinet
9Attach the bottom door

7
Subject to technical modifications without notice. © 2018
Close and flush doors to cabinet. Open and close door to test closing force. Open door
and adjust tension screws on both lift mechanisms with a power drill. Test door again
and repeat until desired function is achieved.
Tension adjustment should be the same on both lift mechanisms.
21 Use #2x2 POZI bit
10 Finalize the tension adjustments
11 Finalizing the door adjustments
1. Adjust each top door hinge and mounting plate
to properly align the top door to the cabinet.
2. Adjust each bottom door hinge and mounting
plate to properly align doors to the cabinet and
to the top door.
± 2 mm ± 2 mm± 2.5 mm± 2 mm± 3 mm + 3/- 2 mm
1 2
NOTE: Although not illustrated here, telescopic arm mounting plates can also be adjusted horizontally ± 2
mm if needed.

Subject to technical modifications without notice. © 2018
8
Attach the left and right cover plates
to each lift mechanism then attach the
symmetrical cover caps.
Assembly
1. Close and flush doors to cabinet. While
pressing on the bottom of the top door, pull
the bottom door open one inch.
12
2. Slightly open door and lock the
telescopic arms into position using the
levers as shown.
Open door
enough to
lock levers
12 Adjust and lock telescopic arms
13 Attach cover caps

9
Subject to technical modifications without notice. © 2018
Release both arms and gently rest
the top door on the loose arms. The
tension will hold the doors up for the
next step.
WARNING
Removal
1Removing the covers
2Removing the door
Risk of injury from spring-loaded arm
▀ Do not push arm assembly down or leave in the down position
▀ Remove mechanism before installing or removing cabinet
1
2

Subject to technical modifications without notice. © 2018
10
1. Hold the bottom door while unclipping
the bottom hinge.
2. Hold the top door while detaching
the top hinges. Simply unclip them if
using the CLIP top hinges or unscrew
them if using COMPACT.
1
2
3Removing the doors
Using a screwdriver, depress the
release tabs to remove telescopic arms.
If transporting the cabinet to the jobsite,
stop here. Lift mechanisms can stay inside
the cabinet for easy transport.
1
2
4Removing the telescopic arms
1
2

Z
TDH
Z = TDH x .44 + 38
Blum, Inc.
800-438-6788
sales.u[email protected]
blum.com
Subject to technical modifications without notice. © 2018 INST-AVT03-04.15
Inch mm
1/32 .031 1
1/16 .063 1.5
3/32 .094 2
1/8.12 5 3
5/32 .156 4
3/16 .188 5
7/32 .219 5.5
1/4.25 6
9/32 .281 7
5/16 .313 8
11/32 .344 9
3/8.375 9.5
13/32 .406 10
7/16 .438 11
15/32 .469 12
1/2 .5 13
17/32 .531 13.5
9/16 .563 14
19/32 .594 15
5/8.625 16
21/32 .656 17
11/16 .688 17.5
23/32 .719 18
3/4.75 19
25/32 .781 20
13/16 .813 20.5
27/32 .844 21
7/8.875 22
29/32 .906 23
15/16 .938 24
31/32 .969 24.5
1 1 25.4
Other information
Door clearance above cabinet
