Body Solid GCEC-340 Installation guide

&
Assembly Instructions
OWNER’S MANUAL
by
by
®
®
v. 190822
by
by
®
®
GCEC-340
T able of Contents
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . p. 2
Reference Drawings. . . . . . . . . . . . . . . . . . . p. 3
Important Safety Instructions. . . . . . . . . . . p. 4
Before You Begin. . . . . . . . . . . . . . . . . . . . . . p. 5
Preparations. . . . . . . . . . . . . . . . . . . . . . . . . . p. 6
Assembly Instructions. . . . . . . . . . . . . . . . . p. 7-13
Warning, Safety & Maintenance. . . . . . . . . p. 14-15
Mainframe Parts List. . . . . . . . . . . . . . . . . . . p. 16
Hardware List. . . . . . . . . . . . . . . . . . . . . . . . . p. 17
Hardware (To Scale). . . . . . . . . . . . . . . . . . . p. 18-20
Exploded View Diagram. . . . . . . . . . . . . . . . p. 21
OWNER`S MANUAL
A s s e m b l y I n s t r u c t i o n s
ʹ
˚˖˘˖ˀˆˇ˃

Dimensions
2
The room layout diagram below will help you decide
the best placement for your GCEC-340.
The overall space needed for operation may be more depending on the user.
Minimum Usage Space – 3’ 1”W x 4’ 3” L x 3’ 1’ H
Suggested Usage Space – 4’ 5”W x 6’ 5” L
4' 3" 3' 1"
3' 1"
4' 5" 6' 5"
4' 3" 3' 1"
3' 1"
4' 5" 6' 5"
4' 3" 3' 1"
3' 1"
4' 5" 6' 5"
4’ 3” 3’ 1”
3’ 1”
4’ 5”
6’ 5”

3
R e f e r e n c e D i a g r a m s
by
by
®
®
Use the following diagrams as a point of reference when
assembling your GCEC-340.
Becoming familiar with the unit and the orientation of its components will help ease installation. Please
use the following diagrams to become more accustomed with your GCEC-340 and its applications.

Important Safety Instructions
4
Before beginning any tness program, you should obtain
a complete physical examination from your physician.
Il est conseille de subir un examen medical complet avant d’entreprendre tout programme d’exercise. Si vous avez
des etourdissements ou des faiblesses, arretez les exercices immediatement.
Antes de comenzar cualquier programma de ejercicios, deberias tener un examen sico con su doctor.
Whenusingexerciseequipment,you should
always take basic precautions, including
the following:
Read all instructions before using the GCEC-340.
These instructions are written to ensure your safety
and to protect the unit.
Do not allow children on or near the equipment.
Use the equipment only for its intended purpose as
described in this guide. Do not use accessory attach-
ments that are not recommended by the manufac-
turer. Such attachments might cause injuries.
Wear proper exercise clothing and shoes for your
workout, no loose clothing.
Use care when getting on or o the unit.
Do not overexert yourself or work to exhaustion.
If you feel any pain or abnormal symptoms, stop
your workout immediately and consult your physi-
cian.
Never operate the unit when it has been dropped or
damaged. Return the equipment to a service center
for examination and repair.
Never drop or insert objects into any opening in the
equipment.
Always check the unit before each use. Make sure
that all fasteners are secure and in good working
condition.
Do not use the equipment outdoors or near water.
Personal Safety During Assembly
It is strongly recommended that a qualied dealer
assemble the equipment.
Assistance is required.
Before beginning assembly, please take the time to
read the instructions thoroughly.
Read each step in the assembly instructions and
follow the steps in sequence. Do not skip ahead. If
you skip ahead, you may learn later that you have
to disassemble components and that you may have
damaged the equipment.
Assemble and operate the GCEC-340 on a solid, level
surface. Locate the unit a few feet from the walls or
furniture to provide easy access.
m
m
m
m
m
m
m
m
m
m
m
m
m
m
 m

5
B e f o r e Y o u B e g i n
Retain this Owner’s Manual for future reference!
To maximize your use of the equipment please study this Owner’s Manual thoroughly. Please retain this
manual for future reference or parts information.
Thank you for purchasing the GCEC-340.
This gym is part of the Body-Solid line of quality
strength training machines, which let you target spe-
cic muscle groups to achieve better muscle tone
and overall body conditioning.
Unpacking the Equipment
The GCEC-340 is carefully tested and inspected be-
fore shipment. We have shipped the unit in several
pieces that require assembly. Ask for assistance dur-
ing the assembly process. Carefully unpack the boxes
and lay the pieces on the oor near the area where
you plan to use the equipment.
The GCEC-340 is designed for your enjoyment. By fol-
lowing these precautions and using common sense,
you will have many safe and pleasurable hours of
healthful exercise with your Body-Solid GCEC-340.
After assembly, you should check all functions to en-
sure correct operation. If you experience problems,
or if any items are missing, rst recheck the assembly
instructions to locate any possible errors made dur-
ing assembly. If you are unable to correct the prob-
lem, call the dealer from whom you purchased the
machine or call 1-800-556-3113 for the dealer near-
est you.
Obtaining Service
Please use this Owner’s Manual to make sure that all
parts have been included in your shipment. When
ordering parts, you must use the part number and
description from this Owner’s Manual. Use only Body-
Solid replacement parts when servicing this unit. Fail-
ure to do so will void your warranty and could result in
personal injury.
For information about product operation or service,
check out the ocial Body-Solid website at www.
bodysolid.com or contact an authorized Body-Solid
dealer or a Body-Solid factory-authorized service
company or contact Body-Solid customer service, M-F
8:30am-5:00pm CST, at one of the following:
*
Toll Free: [phone]
Local: [phone]
Fax: [phone]
:
E-mail: [email protected]
or write to:
+
Body-Solid, Inc.
Service Department
1900 S. Des Plaines Ave.
Forest Park, IL 60130 USA
Body-Solid continually seeks ways to improve the performance, specications and product manuals in order to ensure that only superior products are re-
leased from our factories. Please take the time to carefully read through this manual thoroughly. Instructions contained in this document are not intended
to cover all details or variations possible with Body-Solid equipment, or to cover every contingency that may be met in conjunction with installation,
operation, maintenance or troubleshooting of the equipment. Even though we have prepared this manual with extreme care, neither the publisher nor the
author can accept responsibility for any errors in, or omission from, the information given. Should additional information be required, or should situations
arise that are not covered by this manual, the matter should be directed to your local Body-Solid representative, or the Service Department at Body-Solid
Inc. in Forest Park, Illinois.
Any Questions?
Call [phone]

Preparations
6
CAUTION: To set up this unit, you will need assistance.
Do not attempt assembly by yourself.
You must review and follow the instructions in this Owner’s Manual. If you do not assemble and use the
GCEC-340 according to these guidelines, you could void the Body-Solid warranty.
Required Tools
The basic tools that you must obtain before assem-
bling the GCEC-340 include but are not limited to:
mStandard Wrench Set
mMetric Wrench Set
mAdjustable Wrench
mAllen Set
mRubber Mallet
mSilicone Spray Oil
mKnife
Installation Requirements
Follow these installation requirements when assem-
bling the GCEC-340:
Set up the GCEC-340 on a solid, at surface.
A smooth, at surface under the machine helps keep
it level. A level machine has fewer malfunctions.
Provide ample space around the machine.
Open space around the machine allows for easier ac-
cess and a more comfortable workout.
Insert all bolts in the same direction.
For aesthetic purposes, insert all bolts in the same di-
rection unless specied (in text or illustrations) to do
otherwise.
Leave room for adjustments.
Tighten fasteners such as bolts, nuts, and screws so
the unit is stable, but leave room for adjustments. Do
not fully tighten fasteners until instructed in the as-
sembly steps to do so.
Fill out and mail the warranty card.
To benet from the best and most comprehensible
warranty in the tness industry, completely ll out
and mail the warranty card enclosed with the unit.
CAUTION !
Obtain assistance! Do not attempt to assemble
the GCEC-340 by yourself. Review the Installa-
tion Requirements before proceeding with the
following steps.

7
Assembly Instructions
Assembly of the GCEC-340 takes professional installers
about 1 hour to complete.
Professional installers are highly recommended!
If this is the rst time you have assembled this type of equipment, plan on signicantly more time. How-
ever, if you acquire the appropriate tools, obtain assistance, and follow the assembly steps sequentially,
the process will take time, but is fairly easy.
Assembly Tips
Read all “Notes”on each page before beginning each
step.
While you may be able to assemble the GCEC-340 us-
ing the illustrations only, important safety notes and
other tips are included in the text.
Some pieces may have extra holes that you will not
use. Use only those holes indicated in the instruc-
tions and illustrations.
IMPORTANT!
Before you begin you should look at the quick refer-
ence guide that shows all hardware parts (in actual
size) along with the corresponding component num-
bers in the assembly instructions.
To nd out the length of a particular bolt, measure its
shank (the long, narrow part beneath the head) using
the ruler below. Refer to the following diagram:

8
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE: Finger tighten all hardware in this step.
Do Not wrench tighten until the end of Step 3.
A. Slide both Foot Caps (12) into Multi-Hip Vertical Frame (K).
B. Slide both Foot Caps (12) into Rear Base Frame (H).
C. Attach both Rubber Clips (25) onto Main Base Frame (A) as shown.
D. Slide Foot Cap (12) into Leg Extension Frame (B).
E. Attach Rubber Clip (25) onto Leg Extension Frame (B).
F. Insert Multi-Hip Vertical Frame (K) into Leg Extension Frame (B) and secure using:
One 4 (M10x65 hex head bolt)
Two 9 (M10 washer)
One 7 (M10 nylon nut)
G. Connect Leg Extension Frame (B) to Main Base Frame (A) using:
Two 2 (M12x75 hex head bolt)
Two 8 (M12 washer)
Two 6 (M12 nylon nut)
H. Connect Rear Base Frame (H) to Main Base Frame (A) using:
Two 2 (M12x75 hex head bolt)
Two 8 (M12 washer)
Two 6 (M12 nylon nut)

9
STEP
1
Above shows Step 1 assembled and completed.
STEP
Above shows STEP 1
assembled and completed
1
2
2
8
8
12
12
6
6
25
H
K
12
12
4
9
7
9
25
25
6
6
2
2
8
8
B
12
A
STEP
Above shows STEP 1
assembled and completed
1
2
2
8
8
12
12
6
6
25
H
K
12
12
4
9
7
9
25
25
6
6
2
2
8
8
B
12
A

10
STEP
2
Be careful to assemble all components
in the sequence they are presented.
NOTE: Finger tighten all hardware in this step.
Do Not wrench tighten until the end of Step 3.
A. Connect Leg Hold Down (C) to Leg Extension Frame (B) using:
Two 2 (M12x75 hex head bolt)
Two 8 (M12 washer)
Two 6 (M12 nylon nut)
B. Connect Leg Hold Down (C) and Left Leg Hold Down (J) to Main Base Frame (A) using:
Two 1 (M12x80 hex head bolt)
Two 6 (M12 nylon nut)
C. Insert Round End Cap (22) into Left Leg Hold Down (J).
D. Insert Round End Cap (22) into Leg Hold Down (C).
E. Connect two Plates (M) to Main Base Frame (A) as shown using:
One 3 (M10x80 hex head bolt)
Two 9 (M10 washer)
One 7 (M10 nylon nut)
F. Connect the remaining two Plates (M) to Main Base Frame (A) as shown using:
One 3 (M10x80 hex head bolt)
Two 9 (M10 washer)
One 7 (M10 nylon nut)
G. Attach Seat Pad (N) to Plate (M) using:
Four 5 (⁄” x 1 ¼hex head bolt)
Four 11 (⁄” spring washer)
Four 10 (⁄” washer)
H. Insert both Nylon Bushings (19) into Main Base Frame (A).
I. Insert both End Caps (14) into Adjustable Tube (I).
J. Insert Adjustable Tube (I) into Main Base Frame (A) and secure using T-Shaped Pop Pin (31).
K. Slide Roller Bar (P) into Adjustable Tube (I).
L. Slide Foam Roller (23) onto both sides of Roller Bar (P).
M. Slide Nylon Washer (27) onto both sides of Roller Bar (P).
N. Insert Round End Cap (26) onto both sides of Roller Bar (P).

11
STEP
2
Above shows Step 2 assembled and completed.
STEP
Above shows STEP
assembled and completed
2
2
N
1
C
22
6
2
8
B
3
9
M
10
5
11
A
22
J6
19
14
19
I
14
P
26
27
23
7
9
31
STEP
Above shows STEP
assembled and completed
2
2
N
1
C
22
6
2
8
B
3
9
M
10
5
11
A
22
J6
19
14
19
I
14
P
26
27
23
7
9
31

12
STEP
3
Be careful to assemble all components
in the sequence they are presented.
NOTE: Finger tighten all hardware until the end of this step.
A. Insert both Nylon Bushings (19) into Main Base Frame (A).
B. Insert End Cap (14) into Back Pad Frame (E).
C. Connect Back Pad (O) to Back Pad Frame (E) using:
Four 5 (⁄” x 1 ¼ ” hex head bolt)
Four 11 (⁄” spring washer)
Four 10 (⁄” washer)
D. Slide Back Pad Frame (E) into Main Base Frame (A) and secure using T-Shaped Pop Pin (31).
E. Insert both Round End Caps (15) into Leg Extension Arm (D).
F. Insert End Cap (13) into Leg Extension Arm (D).
G. Insert End Cap (14) into Multi-Hip Arm (F).
H. Insert Rubber Donut (18) onto Multi-Hip Arm (F).
I. Insert both Round End Caps (16) into Multi-Hip Arm (F).
J. Slide Foam Roller (24) onto Leg Extension Arm (D).
K. Slide Shaft Collar (21) onto Leg Extension Arm (D) and secure using Allen Screw (29).
L. Slide Nylon Washer (20) onto Multi-Hip Adjuster (G).
M. M6 Machine Key (28) is pressed into the cut slot on the end of the shaft of the Multi-Hip
Adjuster (G). Remove it. Then slide Multi-Hip Adjuster (G) into Leg Extension Arm (D), Leg
Extension Frame (B) and Multi-Hip Arm (F).
N. Insert M6 Machine Key (28) into Multi-Hip Adjuster (G) then secure Multi-Hip Adjuster (G) by
tightening four Allen Screws (29) on Multi-Hip Arm (F).
O. Insert Round End Cap (17) onto Shaft (L).
P. Insert Shaft (L) into Leg Extension Frame (B).
Q. Congratulations, the GCEC340 installation is complete.
R. When not in use, Adjustable Tube (I) may be placed in the rest spot as shown in Diagram 1.

13
STEP
3
Above shows Step 3 assembled and completed.
STEP
Above shows STEP
assembled and completed
3
3
19
A
19
14
E
5
11
10
O
G
21
24
15
29
D
15
20
13
16
18
14
F
28
29
17
L
B
31
STEP
Above shows STEP
assembled and completed
3
3
19
A
19
14
E
5
11
10
O
G
21
24
15
29
D
15
20
13
16
18
14
F
28
29
17
L
B
31
I
A
H
I
H
A
GCEC340
Diagram 1

Warning, Safety & Maintenance
14
Warning, Safety & Maintenance
Be sure that all users carefully read and understand all
warning, safety and maintenance labels on the machine
before each use. Failure to do so may result in serious injury.
It is imperative that you retain this Owner’s Manual and be
sure all warning labels are legible and intact. Replacement
Owner’s Manuals and labels are available from your local
Body-Solid dealer. If you have any questions about the
operation, set up or maintenance of this machine please call
our customer service department at 1 [phone].
#DWRULE-4
Warning Label for Rules
#DWSM-5
Warning Label for Maintenance
Warning, Safety & Maintenance
Be sure that all users carefully read and understand all
warning, safety and maintenance labels on the machine
before each use. Failure to do so may result in serious injury.
It is imperative that you retain this Owner’s Manual and be
sure all warning labels are legible and intact. Replacement
Owner’s Manuals and labels are available from your local
Body-Solid dealer. If you have any questions about the
operation, set up or maintenance of this machine please call
our customer service department at 1 [phone].
#DWRULE-4
Warning Label for Rules
#DWSM-5
Warning Label for Maintenance
It is imperative that the user becomes familiar and
understands all warnings posted on the unit.
To minimize the risk of injury, follow all safety guidelines provided with the unit and owner’s manual.
Be sure that all users carefully read and under-
stand all warning, safety and maintenance la-
bels on the machine before each use. Failure to
do so may result in death or serious injury.
It is imperative that you retain this Owner’s
Manual and be sure all warning labels are leg-
ible and intact. Replacement Owner’s Manuals
and warning labels are available from your local
Body-Solid dealer.
If you have any questions about the operation,
set up or maintenance of this machine please
call our customer service department at (800)
556-3113.

Warning, Safety & Maintenance
15
Precision craftsmanship assures Body-Solid’s ability
to consistently deliver products of the highest stan-
dards. Our products have been carefully designed to
ensure safe, ecient long term operation.
However, it must be realized that safe use of this
equipment requires that owners carefully read and
follow the Body-Solid use recommendations, warn-
ings, and maintenance guidelines in this Owners
Manual.
Routine inspection and maintenance is of critical
importance to ensure maximum safety and perfor-
mance. Body-Solid uses the highest quality materials
available, but wear is inevitable. Therefore, you must
carefully inspect your equipment as outlined in the
Maintenance Schedule.
Be advised that dangerous conditions can arise even
during a warranty period. A warranty does not ne-
gate the owner’s responsibility to thoroughly, care-
fully and daily inspect the machine.
Including maintaining the equipment, the owner’s
responsibility is also to:
Be sure to always provide adequate supervision to all
end-users.
Be sure to instruct all end-users of proper usage.
Be sure all supervisors and personal trainers who
instruct end-users on equipment use are properly
trained and know the function and importance of
every adjustment and setting.
Also, be sure these trainers provide proper instruc-
tion to end-users on the fundamentals of strength
training.
CABLES:
While the machine is not in use, carefully run your
ngers along the cable to feel for thinning or bulg-
ing areas. Replace cables immediately at the rst
sign of damage or wear. Do not use the equipment
until the damaged cable has been replaced.
Visually inspect the cables for fraying, cracking,
peeling or discoloration.
Check slack in cables and re-adjust cable tension if
needed.
Check that the jam nut on the selector rod top bolt
is tight.
UPHOLSTERY:
Wipe down and sanitize after every workout.
Periodically take the time to use a mild soap or a
mild vinyl upholstery cleaner. Avoid using any abra-
sive cleaner not intended for use on vinyl.
Keep sharp or pointed objects out of your pockets
and clear of all upholstery.
NUTS/BOLTS/FASTENERS:
Periodically inspect all nuts and bolts. Tighten if
needed. If bolts seem to loosen periodically, use
Loctite 242 for a long-term cure.
Go through a re-tightening sequence periodically to
ensure that all hardware is properly tensioned.
GUIDE RODS:
Wipe clean with a dust free rag. Lubricate with a
Silicon or Teon based lubricant.
ADJUSTMENTS / LOCKING PINS /
TIGHTENING KNOBS:
Check all pieces for signs of visible wear or damage.
Check springs in Snap Links and Pop Pins for proper
tension and alignment.
If the spring sticks or has lost its rigidity, replace it
immediately.
ANTI-SKID SURFACES:
Replace if they appear worn or become slippery.
WARNING INSTRUCTION LABELS:
Inspect and familiarize yourself with all safety
warnings and other user information on decals.
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
It is imperative that the user becomes familiar and
understands all warnings posted on the unit.
To minimize the risk of injury, follow all safety guidelines provided with the unit and owner’s manual.

16
Mainframe Parts List
Part numbers are required when ordering parts.
Part# Qty Description
A 1 MAIN BASE FRAME
B 1 LEG EXTENSION FRAME
C 1 LEG HOLD DOWN
D 1 LEG EXTENSION ARM
E 1 BACK PAD FRAME
F 1 MULTI-HIP ARM
G 1 MULTI-HIP ADJUSTER
H 1 REAR BASE FRAME
I 1 ADJUSTABLE TUBE
J 1 LEFT LEG HOLD DOWN
K 1 MULTI-HIP VERTICAL FRAME
L 1 SHAFT (8220-017)
M 4 PLATE (8331-018)
N 1 SEAT PAD (9122-021)
O 1 BACK PAD (9112-008)
P 1 ROLLER BAR
45x1.8x405L
F25.4x108L
38x6x125
F1”x1.6x473L

Part numbers are required when ordering parts.
17
H a r d w a r e L i s t
Part# Qty Description
1 2 M12x80
2 6 M12x75
3 2 M10x80
4 1 M10x65
5 8 ⁄” x 1 ¼”
6 8 M12
7 3 M10
8 6 M12
9 6 M10
10 8 ⁄”
11 8 ⁄”
12 5 2” x 2” (9211-024)
13 1 2” x 2” (9211-087)
14 4 1 ¾” x 1 ¾” (9211-091)
15 2 F50 (9211-074)
16 2 F1” (9211-016)
17 1 F31x65 (9212-004)
18 1 F2 ½” (9310-012)
19 4 60x45 (9211-032)
20 1 F 1” (9214-001)
21 1 F2” (8130-065)
22 2 F1” (9260-021)
23 2 F4” x 8” (9161-054)
24 1 F6” x 16” (9161-057)
25 3 2” x 2” (9210-010)
26 2 F1” (8341-033)
27 2 F3” (9214-008)
28 1 6x45L (8890-060)
29 5 M8x8
30 1 ½” x 65L (8250-067)
31 2 3” (8250-012)
32 1 1 ½” OD x 14 ¾” L (9162-023)
33 1 1 ½” OD x 6 ¾” L (9162-004)
34 2 1” ID x 1 ¾” OD (8520-004)
35 3 (9440-104)
36 1 (9440-105)
37 1 (9440-103)
38 1 (9440-027)
39 1 (9440-217)
40 1
HEX HEAD BOLT
HEX HEAD BOLT
HEX HEAD BOLT
HEX HEAD BOLT
HEX HEAD BOLT
NYLON NUT
NYLON NUT
WASHER
WASHER
WASHER
SPRING WASHER
FOOT CAP
END CAP
END CAP
ROUND END CAP
ROUND END CAP
ROUND END CAP
RUBBER DONUT
NYLON BUSHING
NYLON WASHER
SHAFT COLLAR
ROUND END CAP
FOAM ROLLER
FOAM ROLLER
RUBBER CLIP
ROUND END CAP
NYLON WASHER
M6 MACHINE KEY
ALLEN SCREW
POP PIN
T-SHAPED POP PIN
FOAM GRIP
FOAM GRIP
OILITE BUSHING POP
PIN STICKER
WARNING STICKER
MAINTENANCE LABEL
BODYSOLID LOGO
WARNING STICKER
BODYSOLID PLATE (9440-199)
Part numbers are required when ordering parts.

18
H a r d w a r e (To Scale)
Part# 1 M12x80 Hex Head Bolt Qty. 2
H a r d w a r e (T o S c a l e)
1.M12X80 HEX HEAD BOLT----------------------------------------2PCS
2.M12X75 HEX HEAD BOLT----------------------------------------6PCS
3.M10X80 HEX HEAD BOLT----------------------------------------2PCS
4.M10X65 HEX HEAD BOLT----------------------------------------1PCS
5.5/16"X1 1/4" HEX HEAD BOLT-----------------------------------8PCS
29.M8X8 ALLEN SCREW ---------------------------------------------5PCS
mm
inch
060
10 30 50
40
20 60 130120
110
10090
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 2 M12x75 Hex Head Bolt Qty. 6
H a r d w a r e (T o S c a l e)
1.M12X80 HEX HEAD BOLT----------------------------------------2PCS
2.M12X75 HEX HEAD BOLT----------------------------------------6PCS
3.M10X80 HEX HEAD BOLT----------------------------------------2PCS
4.M10X65 HEX HEAD BOLT----------------------------------------1PCS
5.5/16"X1 1/4" HEX HEAD BOLT-----------------------------------8PCS
29.M8X8 ALLEN SCREW ---------------------------------------------5PCS
mm
inch
060
10 30 50
40
20 60 130120
110
10090
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 3 M10x80 Hex Head Bolt Qty. 2
H a r d w a r e (T o S c a l e)
1.M12X80 HEX HEAD BOLT----------------------------------------2PCS
2.M12X75 HEX HEAD BOLT----------------------------------------6PCS
3.M10X80 HEX HEAD BOLT----------------------------------------2PCS
4.M10X65 HEX HEAD BOLT----------------------------------------1PCS
5.5/16"X1 1/4" HEX HEAD BOLT-----------------------------------8PCS
29.M8X8 ALLEN SCREW ---------------------------------------------5PCS
mm
inch
060
10 30 50
40
20 60 130120
110
10090
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 4 M10x65 Hex Head Bolt Qty. 1
H a r d w a r e (T o S c a l e)
1.M12X80 HEX HEAD BOLT----------------------------------------2PCS
2.M12X75 HEX HEAD BOLT----------------------------------------6PCS
3.M10X80 HEX HEAD BOLT----------------------------------------2PCS
4.M10X65 HEX HEAD BOLT----------------------------------------1PCS
5.5/16"X1 1/4" HEX HEAD BOLT-----------------------------------8PCS
29.M8X8 ALLEN SCREW ---------------------------------------------5PCS
mm
inch
060
10 30 50
40
20 60 130120
110
10090
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 5 5/16” x 1 ¼” Hex Head Bolt Qty. 8
H a r d w a r e (T o S c a l e)
1.M12X80 HEX HEAD BOLT----------------------------------------2PCS
2.M12X75 HEX HEAD BOLT----------------------------------------6PCS
3.M10X80 HEX HEAD BOLT----------------------------------------2PCS
4.M10X65 HEX HEAD BOLT----------------------------------------1PCS
5.5/16"X1 1/4" HEX HEAD BOLT-----------------------------------8PCS
29.M8X8 ALLEN SCREW ---------------------------------------------5PCS
mm
inch
060
10 30 50
40
20 60 130120
110
10090
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0

H a r d w a r e (To Scale)
19
Part# 29 M8x8 Allen Screw Qty. 5
H a r d w a r e (T o S c a l e)
1.M12X80 HEX HEAD BOLT----------------------------------------2PCS
2.M12X75 HEX HEAD BOLT----------------------------------------6PCS
3.M10X80 HEX HEAD BOLT----------------------------------------2PCS
4.M10X65 HEX HEAD BOLT----------------------------------------1PCS
5.5/16"X1 1/4" HEX HEAD BOLT-----------------------------------8PCS
29.M8X8 ALLEN SCREW ---------------------------------------------5PCS
mm
inch
060
10 30 50
40
20 60 130120
110
10090
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 8 M12 Washer Qty. 6
Hardware (T o S c a l e)
C1.M12 (I.D) WASHER---------6PCS C2.M10 (I.D) WASHER---------6PCS
C3.5/16" (I.D) WASHER---------8PCS C4.5/16" SPRING WASHER------8PCS
B1.M12 NYLON LOCK NUT-----8PCS B2.M10 NYLON LOCK NUT-----3PCS
mm
inch
060
10 30 50
40
20 60 130120110
100
90
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 10 5/16” Washer Qty. 8
Hardware (T o S c a l e)
C1.M12 (I.D) WASHER---------6PCS C2.M10 (I.D) WASHER---------6PCS
C3.5/16" (I.D) WASHER---------8PCS C4.5/16" SPRING WASHER------8PCS
B1.M12 NYLON LOCK NUT-----8PCS B2.M10 NYLON LOCK NUT-----3PCS
mm
inch
060
10 30 50
40
20 60 130120110
100
90
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 9 M10 Washer Qty. 6
Hardware (T o S c a l e)
C1.M12 (I.D) WASHER---------6PCS C2.M10 (I.D) WASHER---------6PCS
C3.5/16" (I.D) WASHER---------8PCS C4.5/16" SPRING WASHER------8PCS
B1.M12 NYLON LOCK NUT-----8PCS B2.M10 NYLON LOCK NUT-----3PCS
mm
inch
060
10 30 50
40
20 60 130120110
100
90
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0

20
H a r d w a r e (To Scale)
Part# 11 5/16” Spring Washer Qty. 8
Hardware (T o S c a l e)
C1.M12 (I.D) WASHER---------6PCS C2.M10 (I.D) WASHER---------6PCS
C3.5/16" (I.D) WASHER---------8PCS C4.5/16" SPRING WASHER------8PCS
B1.M12 NYLON LOCK NUT-----8PCS B2.M10 NYLON LOCK NUT-----3PCS
mm
inch
060
10 30 50
40
20 60 130
120110
100
90
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 7 M10 Nylon Nut Qty. 3
Hardware (T o S c a l e)
C1.M12 (I.D) WASHER---------6PCS C2.M10 (I.D) WASHER---------6PCS
C3.5/16" (I.D) WASHER---------8PCS C4.5/16" SPRING WASHER------8PCS
B1.M12 NYLON LOCK NUT-----8PCS B2.M10 NYLON LOCK NUT-----3PCS
mm
inch
060
10 30 50
40
20 60 130
120110
100
90
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
Part# 6 M12 Nylon Nut Qty. 8
Hardware (T o S c a l e)
C1.M12 (I.D) WASHER---------6PCS C2.M10 (I.D) WASHER---------6PCS
C3.5/16" (I.D) WASHER---------8PCS C4.5/16" SPRING WASHER------8PCS
B1.M12 NYLON LOCK NUT-----8PCS B2.M10 NYLON LOCK NUT-----3PCS
mm
inch
060
10 30 50
40
20 60 130
120110
100
90
8070 140 150
10
1" 6"
4"
3" 5"
2"
0
0
