Boneco P400 User manual

S.V.P. lire et conserver ces instructions
Please read and save these instructions
P400
MANUAL

Instructions for use 6
Instructions d’utilisation 14
Instrucciones de uso 22

4
en INSTRUCTIONS FOR USE FOR BONECO P400
DEAR CUSTOMER,
Congratulations on your purchase of the BONECO P400.
The highly efficient air purifier is equipped with a triple
filter system that rids the air of odors as well as dust,
pollen and contaminants. The filter also effectively allevi-
ates many forms of discomfort caused by allergies. This
includes hay fever or allergic reactions to dust mites and
household dust.
The BONECO P400 is designed for convenient, fully auto-
mated operation. The smart control system ensures that
the noise level remains as low as possible.
We hope you enjoy your new BONECO P400
air purifier!
SCOPE OF DELIVERY
BONECO P400 with country-
specific power cable
“ALLERGY”, “BABY” or
“SMOG” filter
Printed manual
TECHNICAL SPECIFICATIONS*
Type designation BONECO P400
Power supply voltage 120 V, 60 Hz
Power consumption 27 W
Operation noise level 30–58 dB(A)
Suitable for room size by
air exchange per hour
“ALLERGY” Filter “BABY” Filter “SMOG” Filter
Cleaning output (CADR) 221 m³/h | 131 cfm 211 m³/h | 124 cfm 248 m³/h | 146 cfm
Air flow 280 m³/h | 167 cfm
Dimensions L×W×H 224 × 420 × 562 mm | 8.8 × 16.5 × 22.1 in.
Weight (empty) 7.2 kg / 7.9 kg | 15.9 lbs / 17.4 lbs (with “ALLERGY” filter)
* Subject to change
1.5 x
3 x
5 x
600 sq ft (56 m2)
300 sq ft (28 m2)
175 sq ft (16 m2)
562 sq ft (52 m2)
281 sq ft (26 m2)
174 sq ft (16 m2)
668 sq ft (62 m2)
334 sq ft (31 m2)
189 sq ft (18 m2)

5
en
OVERVIEW AND PART NAMES
* Depending on the model, a “ALLERGY”, “BABY” or “SMOG” filter type is included in standard delivery
1 2 3
4 5
6
1Front cover
2Pre-filter
3Filter*
4BONECO P400
5Touch display
6Fragrance container
7Power cable
7

6
en PUTTING INTO OPERATION
6
31
4
2
5
Take out the filter and remove the protective foil.
Remove the magnetically attached front cover.
Insert the filter back into the holder
(note the markings).
Take off the pre-filter.
Reattach the front cover.
Put the pre-filter back on.

7
en
FRONT COVER AND FILTER TYPES
MAGNETIC FRONT COVER
The BONECO P400 front cover is held on by magnets. The
air purifier does not switch on if the front cover is missing
or positioned incorrectly.
NOTES ON THE FILTERS
Your BONECO P400 was shipped from the factory with
the “ALLERGY”, “SMOG” or “BABY” filter. However, the
appliance is compatible with all three filter types. The
delivered filter can be replaced by another model at any
time if your requirements change.
REPLACEMENT FILTERS
You can get the replacement filters at your BONECO
specialist dealer or at the online store at www.shop.
boneco.com. The filters are identified by these labels:
A401
ALLERGY
A403
SMOG

8
en
BRIGHTNESS OF THE DISPLAY
The brightness of the display depends on the ambient
light. The display is dimmed automatically if the BONECO
P400 is used in a dark room (such as a bedroom).
CLEARING THE FILTER WARNING
The symbol does not go out automatically after the
filter has been replaced. Press and hold the button
for five seconds to hide the symbol. This also resets the
counter for the new filter at the same time.
INDICATORS ON THE DISPLAY
Overview of all indicators on the display
Symbol Meaning
Fan level 9
Filter used up, replace 10

9
en
The BONECO P400 can easily be adapted to suit your
needs. Whenever you switch off the unit, all settings are
saved until the next use. However, the settings are reset
whenever the unit is disconnected from the power supply.
BASIC FUNCTIONS
MANUALLY CONTROLLING THE FAN LEVEL
The fan level of the BONECO P400 can be controlled
manually, such as if you want the air to be thoroughly
purified in the shortest possible time.
Push the button repeatedly until the desired fan set-
ting is achieved.
POWER LEVEL
“Power Level” (P) can be achieved by pressing the
button. The fan is working at its maximum output under
Power Level (P).
USING FRAGRANCES
The fragrance container for adding fragrances is on the
backside of the BONECO P400.
1. Briefly push on the fragrance container to unlock it and
then remove the compartment.
2. Insert the fragrance into the fragrance container.
3. Push the fragrance container into the air purifier until
it clicks into place.

10
en
REPLACING THE FILTER
The filter is worn out if the symbol is illuminated. The
filter must be replaced at this point to continue to ensure
optimal air purification.
The filter must be replaced as soon as possible after the
reminder is displayed but after one year at the latest.
The procedure for replacing the filter corresponds to the
figures on page 6.
1. Replace the filter in accordance with the instructions
on page 6.
2. Hold the button for 5 seconds to the hide the symbol
.
CLEANING THE PRE-FILTER
The pre-filter prevents excessive dust accumulation from
getting inside the BONECO P400.
1. Clean the pre-filter under running water or using a
vacuum cleaner.
2. Allow the pre-filter to dry completely before re-insert-
ing it.
CLEANING AND MAINTENANCE
