Boneco F210 User manual

READ AND SAVE THESE INSTRUCTIONS
F210
MANUAL

Instructions for use 3

3
en
INSTRUCTIONS FOR USE
BONECO F210

4
en TABLE OF CONTENTS
Technical data 5
Introduction 6
Scope of delivery 6
Overview and part names 7
Starting up 8
Operations 9
Operations 9
Head Positions 9
Positioning tips 10
Notes on performance 10
Air-conditioning system 10
Multiple floors 10
Fresh air 10
Rooms with high ceilings 10
Cleaning and maintenance 11
Care instructions 11
Cleaning the Housing 11
Cleaning the Fan Blades 11
ELECTRO DIAGRAM (CN version only) 12

5
en
Technical data*
Type
Mains voltage
Power consumption
Operation noise level
Airflow
(Air speed)
Dimensions
Net Weight
TECHNICAL DATA
* Subject to changes

6
en
SCOPE OF DELIVERY
BONECO F210 fan unit BONECO F210 fan head Fan supportive pole
Printed user manual
Congratulations on your purchase of the BONECO F210
fan. This high-performance fan seamlessly adapts to
meet your needs. When set to the lower fan levels, it
provides a gentle, pleasant breeze in your home. On the
other hand, if you use an air conditioning system, the
unit’s powerful fans distribute the cooled air throughout
the room, which enables a uniform temperature to be
reached.
Thanks to its unique deep pitch blade design, this
BONECO fan is the all-year-around user friendly climate
product which can provide you simplest and most effi-
cient solution to room climate control. Its elegant design
fits to all room style. It’s specially engineered to ensure
the lowest maintenance level.
We hope you enjoy your new BONECO fan!
INTRODUCTION

7
en
1F210 fan head incl. T-connector
2Control knob
3Power cable connector
4Supportive pole
5Base stand incl. power cable
1
2
4
5
3
OVERVIEW AND PART NAMES

8
en
1 2 3
STARTING UP
Take the fan unit out from package. Plug into the main power supply (ensure the ratings
matches).
Switch / control the fan by turning the control knob.
Plug the power cord into a power outlet.

9
en
OPERATIONS
The BONECO F210 fan has the simplest operation design
to the unit. It has only one control knob. By turning this
knob, you can switch on and off the fan or adjust the fan
speed from level 1 (lowest level) up to level 4 (highest
level).
HEAD POSITIONS
Depends on your interior construction of windows or air
conditioners, the fan head can be adjusted by 270 de-
grees manually.
OPERATIONS

10
en
NOTES ON PERFORMANCE
The BONECO F210 is equipped with a high-performance
fan that can move large quantities of air. Making use of
this feature: Move the air in a specific direction to achieve
a uniform room climate. The following examples illustrate
how you can do this.
AIR-CONDITIONING SYSTEM
Most air-conditioning systems are stationary. This means
that the temperatures will vary in different parts of the
room. Use the BONECO fan to move the warmer air to-
wards the air-conditioning system. This can be done di-
rectly or indirectly via air circulation, as shown in this
image.
FRESH AIR
The BONECO fan series helps you achieve better ventila-
tion indoors. If cross-ventilation does not build up, guide
the fresh air into the room from the window.
MULTIPLE FLOORS
In the summer, it can become uncomfortably hot and
muggy on the upper floors. The powerful fan moves the
cool air from the ground floor to the upper floors so that
a uniform temperature is achieved.
ROOMS WITH HIGH CEILINGS
In air-conditioned rooms with high ceilings, the cold air
sinks to the floor while the warm air rises to the ceiling.
Point the BONECO fan upwards to circulate the air and
achieve a uniform room climate.
POSITIONING TIPS

11
en
CLEANING AND MAINTENANCE
CARE INSTRUCTIONS
Always unplug the BONECO fan before you start
cleaning it! Failure to do so can result in electric
shock and fatal injury!
Do not use alcohol or corrosive cleaning agents for
cleaning.
CLEANING THE HOUSING
BONECO fans are designed for maintenance-free opera-
tion, even when used over many years. In most cases, a
dry cloth can be used for cleaning the housing. If stubborn
dirt is present, clean the housing using a damp cloth. Add
a small amount of dishwashing detergent to the water.
Household cloths and window cleaners can also be used.
CLEANING THE FAN BLADES
• Unscrew the security screw at the buttom side of the
fan head.
• Remove the front grid from the fan head by turning it
anti-clockwise.
• Unscrew the protection screw in the center of the fan
blade by turning it clockwise…
• Take out the fan blade and clean with a damp cloth or
sponge
• Put the Fan blade back into the housing, and fix the
protection screw fest.
• Put the front grid back onto the housing and fix the
security screw

12
en
ELECTRO DIAGRAM (CN VERSION ONLY)
