Boneco H400 User manual

H400
MANUAL
Read and save these instructions
Lisez et enregistrez ces instructions
Lea y guarde estas instrucciones

EN Always observe all safety notes (included separately in delivery).
FR Veuillez respecter impérativement l’ensemble des consignes de sécurité
(fournies séparéme nt dans le contenu de la livraison).
ES Tenga en cuenta siempre todas las indicaciones de seguridad
(se suministran aparte junto con el producto).

EN Instructions for use 5
FR Mode d’emploi 25
ES Instrucciones de uso 45

5
en
INSTRUCTIONS FOR USE

6
en TABLE OF CONTENTS
Items included 8
Overview and part names 9
Technical data 10
Starting up 11
Manual handling 12
On manual handling 12
AUTO mode 12
Adapted AUTO mode 12
Switching on and off 12
Manual control 13
The various operating modes 14
Hybrid mode (“Hybrid”) 14
“Hybrid” LED operating mode 14
Humidification only (“Humidifier”) 14
“Humidifier” LED operating mode 14
Purification only 14
“Purifier” LED operating mode 14
Fragrance container 15
Basics 15
Use 15
The benefits of the BONECO app 16
About the BONECO app 16
Scope of services 16
Connecting to the app 17
Preparations 17
BONECO app for iOS 17
Pairing 17
BONECO app for Android 17
Meaning of the status LED 18
LED lighting up in WHITE, BLUE OR GREEN 18
LED pulsating in blue AND WHITE 18
LED ring flashing in blue 18
LED flashing in red 18
Notes on cleaning 19
About cleaning 19
Recommended cleaning intervals 19
Cleaning the appliance 20
Disassembly and cleaning 20
Cleaning the AW200 evaporator mat 21
About the AW200 evaporator mat 21
Cleaning in the washing machine 21
Cleaning by hand 21

7
en
Cleaning pre-filter 22
About the pre-filter 22
Cleaning pre-filter 22
Replacing the accessories 23
Replacing the AH300 pollen filter 23
Availability of accessories 23
Notes on operation and troubleshooting 24

8
en ITEMS INCLUDED
BONECO H400
ITEMS INCLUDED
Power supply
HEALTHY AIR IS A BASIC NEED.
There is little to which we react with greater sen-
sitivity than poor air. And yet many people do not
pay enough attention to air quality, which has con-
sequences for health and quality of life. This makes
us all the more pleased that you have chosen a TOP-
BONECO appliance to ensure that the basic need for
healthy room air is satisfied for you and the people
around you.
AVAILABILITY OF ACCESSORIES
You can obtain replacements for worn-out accesso-
ries as well as additional accessories from:
• Your BONECO specialist dealer,
• At www.shop.boneco.us
• Directly via the “BONECO healthy air” app.
Quick Manual Safety instructions

9
en
OVERVIEW AND PART NAMES
1
3
2
5
4
6 7 8 9 10
11
1On/O, performance level
2Status LED
3Hygrometer
4AH300 pollen filter
5Pre-filter
6Cover/air inlet
7Fragrance container*
8Drum*
9AW200 evaporator mat**
10 Water tank
11 Air outlet
12 Water base*
13 Water tank cover
* Washable in the dishwasher up to
122°F (50°C)
** Washable in the washing machine
up to 104°F (40°C)
12 13

10
en TECHNICAL DATA
Type designation BONECO H400
Mains voltage 100 –240 V ~ 50 /60 Hz
Power consumption 3.7 – 14.7 W
Humidity output up to 2.5 gal/day (400 g/h)**
Particle CADR 60 CFM (100 m3 / h
Recommended room size up to 600 sq ft (60 m2)
Water capacity max. 3.2 gallons (12 liters)
Dimensions L ×W× H 11×15.7×18.3 in. (280×400 ×465 mm)
Weight (empty) 14.9 lbs (6.8 kg)
Operating noise level 25 –55 dB(A)**
* subject to change
** at 120 V ~ 60Hz
TECHNICAL DATA*

11
en
STARTING UP
654
3
2
1
Fill the water tank with cold tap water. Insert the filled water tank.
Connect the power supply to the BONECO
appliance.
Remove the water tank.
Plug the power supply into a power outlet. Briefly press the output regulator to switch on
the appliance.
ON

12
en MANUAL HANDLING
ON MANUAL HANDLING
Manual handling works conveniently by the knob
on the front side. The BONECO app oers additional,
extensive options for control and automation of the
BONECO appliance.
AUTO MODE
If you have never operated the BONECO appliance
with the BONECO app and switch it on for the first
time, it starts up in AUTO mode. The appliance is pre-
set to a target relative humidity of 50 percent. The
performance level is automatically adapted to the
current humidity: The drier the air, the higher the
performance level.
If the preset target humidity is exceeded, the appli-
ance switches to standby mode, which is indicated
by the pulsing LED.
If the humidity drops below the set level, the BONE-
CO appliance resumes operation.
ADAPTED AUTO MODE
If you have already operated the BONECO appliance
with the BONECO app and set a dierent humidity,
that value is automatically taken over when the ap-
pliance is switched on.
SWITCHING ON AND OFF
1. Briefly press the knob once to switch on the
BONECO appliance.
The appliance is always in AUTO mode when it is
switched on. You can identify active AUTO mode by
the small LED that lights up above the knob.
2. To switch o the BONECO appliance while it is in
AUTO mode, briefly press the knob once.

13
en
The selected performance level is indicated by the
number of LEDs that light up above the knob.
3. Briefly press the knob once to exit manual mode
and to reactivate AUTO mode.
4. Briefly press the knob once more to switch o the
BONECO appliance.
If you exit AUTO mode, the BONECO appliance
will continue at the selected performance
level until the water base is empty, regardless of
what the current level of humidity is.
MANUAL CONTROL
1. Briefly press the knob once to switch on the
BONECO appliance.
The appliance is always in AUTO mode when it is
switched on.
2. Adjust the output to your needs by setting the
knob to the desired level from 1 to 6. This action
exits AUTO mode (AUTO LED is o).

14
en THE VARIOUS OPERATING MODES
HYBRID MODE (“HYBRID”)
The BONECO appliance combines two functions.
The AH300 pollen filter cleanses breathing air by
removing pollen, household dust and fine particles.
The evaporator mat humidifies the room air.
You achieve the best results when the BONECO ap-
pliance is humidifying and purifying the air at the
same time. Nevertheless it is possible to use just
one of the two functions.
“HYBRID” LED OPERATING MODE
HUMIDIFICATION ONLY (“HUMIDIFIER”)
We recommend using the BONECO appliance with
inserted AH300 pollen filter even in the winter be-
cause, aside from pollen, it also filters household
dust out of the air. In order to operate the appliance
without the pollen filter, simply remove the filter
from its holder and use the BONECO app to switch to
“Humidifier” mode.
When you remove the AH300 pollen filter, the maxi-
mum humidifier performance increases because
you achieve a better air passage.
“HUMIDIFIER” LED OPERATING MODE
PURIFICATION ONLY
In summer, humidity is usually sucient, but pollen
gives people with allergies a dicult time. If you
only want to use the purifying eect of the AH300
pollen filter, switch the BONECO appliance to “Puri-
fier” operating mode using the BONECO app and re-
move the water and the drum from the appliance.
“PURIFIER” LED OPERATING MODE

15
en
FRAGRANCE CONTAINER
BASICS
Commercially available fragrances and essential
oils can be inserted into the fragrance container on
the rear side.
Never mix any additives into the water base
itself, since doing so can decrease the per-
formance of the BONECO appliance and even cause
damage. This damage is not covered by the war-
ranty.
The fragrance container can be cleaned in the
dishwasher. However, the temperature may
not exceed 122 °F (50 °C).
USE
1. Remove the water tank.
2. On the rear side, press down on the fragrance
container to take out the drawer.
3. Sprinkle the felt insert in the drawer with the fra-
grance of your choice.
4. Reinsert the fragrance container.
5. Reinsert the water tank.

16
en THE BENEFITS OF THE BONECO APP
ABOUT THE BONECO APP
The “BONECO healthy air” app is used for enhanced
control of the BONECO appliance and lets you take
full advantage of its potential. The app includes
functions such as a timer, a humidity preset and the
option to switch between various programs. In ad-
dition, it provides reminders for the cleaning inter-
vals and other recurring tasks.
SCOPE OF SERVICES
Operating
modes
“Hybrid” The air is cleaned and humidified at the same time
“Purifier” The air is cleaned, but not humidified
“Humidifier” The air is humidified, but not cleaned
Programs Predefined settings for frequent situations
AUTO mode The appliance uses all fan levels from 1 to 5 and has a preset target
humidity of 50%
SLEEP mode The appliance uses fan level 1 only and increases the
target humidity to 45%
BABY mode The appliance uses fan level 1 through 4 and increases the
humidity to 60%
Hygrostat Defining the desired humidity
Dimmer Setting the brightness of the status LED
Weather Displays the current weather and outside temperature
ON timer The appliance switches on after a set time
OFF timer The appliance switches o after a set time
Accessories and consumables Provides support in replacement orders and further information

17
en
CONNECTING TO THE APP
BONECO APP FOR IOS
Search the App Store for “BONECO healthy
air” or scan the QR code below.
BONECO APP FOR ANDROID
Search the Google Play Store for “BONECO healthy
air” or scan the QR code below.
PREPARATIONS
Make sure that Bluetooth is activated on your smart-
phone. During pairing, make sure that the smart-
phone is in the same room as the BONECO appliance.
Once paired successfully, you can control the BONE-
CO appliance with your smartphone from the same
room or even from an adjacent room. However,
the maximum distance between smartphone and
BONECO appliance depends on the specific struc-
tural conditions.
PAIRING
1. Make sure that Bluetooth is activated on your
smartphone.
2. Start the BONECO app.
3. Follow the instructions in the app.

18
en MEANING OF THE STATUS LED
LED FLASHING IN RED
The red LED flashes when the water tank is empty.
Fill the water tank with fresh, cold tap water.
LED RING FLASHING IN BLUE
When the 6 ring-shaped LEDs are flashing in blue,
the BONECO appliance is ready for pairing with a
smartphone via Bluetooth.
LED LIGHTING UP IN WHITE, BLUE OR GREEN
In normal operation, the status LED lights up in the
color of the current operating mode continuously.
The performance level is indicated by the number of
the illuminated ring LEDs.
LED PULSATING IN BLUE AND WHITE
A pulsating LED indicates that the target humidity
has been exceeded in AUTO mode; the appliance is
now in stand-by mode. Operation resumes as soon
as the humidity drops below the set level.

19
en
NOTES ON CLEANING
ABOUT CLEANING
Regular maintenance and cleaning are necessary
for trouble-free and hygienic operation.
Recommended cleaning and maintenance intervals
vary depending on air quality, water quality and
operating time.
A soft cloth, dish detergent and a scrub brush are
recommended for cleaning by hand.
Always unplug the BONECO appliance from
the power outlet before you begin cleaning.
Failure to do so can result in electric shock and fatal
injury!
In the case of cleaning the drum and the wa-
ter base in the dishwasher, a temperature of
122 °F (50 °C) may not be exceeded, as tempera-
tures higher than this can cause the plastic parts to
deform.
RECOMMENDED CLEANING INTERVALS
Interval Action
After the third day without operation Empty water base and water tank and fill with fresh water
Every 2 weeks Clean water base, drum and AW200 evaporator mat
Clean the pre-filter
Annually Clean the fan and the inner area of the appliance

20
en CLEANING THE APPLIANCE
6. Clean the inside of the water tank by hand or with
a suitable cleaning brush using a commercially
available dish detergent.
7. Clean the water tank cover with a commercially
available dish detergent and a cleaning brush.
8. Put the appliance back together by following the
steps in reverse order.
4. Remove the AW200 evaporator mat from the
drum.
5. Clean the water base and the drum either by
hand or in the dish washer at a max. temperature
of 122 °F (50 °C).
DISASSEMBLY AND CLEANING
1. Take o the upper part of the BONECO appliance.
2. Remove the drum with the AW200 evaporator
mat.
3. Twist both drum discs to release them. When do-
ing so, note the markings on the outer side of the
disc.
122 °F
