SDC Excel E1200 Series User manual

P:\INSTALLATION INST\Electromagnetic Locks\EXCEL\INST-E1200.vsd REV A3 08-18 Page 1
Any suggestions or comments to this instruction or
product are welcome. Please contact us through
our website or email engine[email protected]m
INSTALLATION INSTRUCTIONS
E1200 SERIES MAGNETIC LOCK
Electrical Instructions:
Use properly fused U. L. Listed Power Supply
Do not install a diode in parallel with any magnetic lock. A diode
will cause a delay when releasing the door and residual magnetism
to occur.
Although SDC recommends the use of a DC power supply, a
transformer with an adjacent mounted full wave bridge rectifier
may be used. A significant drop will occur when using a full wave
bridge rectifier.
Any low voltage condition will cause erratic operation of the
optional board sensor.
When using a full wave bridge rectifier all access controls and/or
release contacts must be located between the EMlock and rectifier
to ensure quick release.
Electrical Specifications:
Dual Voltage 12 or 24VDC
Power Consumption .500mA@12VDC
250mA@24VDC
DS Door Status Sensor SPDT, 500mA@30VDC
LS Lock Status Sensor SPDT, 2A@30VDC
Outswing
Quick Mount
Interlocking
Mounting Assembly
Mounting Screws
Armature
Interlocking
Mounting Plate
Frame
801 Avenida Acaso, Camarillo, Ca. 93012 • [phone] •
www.sdcsecurity.com • E-mail: [email protected]

P:\INSTALLATION INST\Electromagnetic Locks\EXCEL\INST-E1200.vsd REV A3 08-18 Page 2
1. Inspect the frame header to determine if mounting accessories are required (refer to page 4).
2. Fold template as indicated on dotted line. For single doors locate template against the door and header on the
lock jamb side of the frame.
3. Mark and drill holes as indicated by the template.
4. Mount armature to door.
STEP 4
STEPS 2 & 3
5. Install magnet onto the header with the magnetic stripes towards the door side of the stop.
Assure that the magnet and armature line up properly, then tighten down ALL mounting screws.
STEP 5
HOLLOW METAL DOOR
From Sexnut side of door, drill exactly 1/2” hole thru one metal
thickness only. From Armature side of door, drill 5/8” hole to insert
reinforcement tube. Press in sexnut and reinforcement tube all the
way and mount armature to door using hardware provided.
REINFORCEMENT
TUBE 1-3/4“ HOLLOW
METAL DOOR
5/8“ DRILL
STEEL WASHER 2X
RUBBER WASHER
5/16-18 SOC HD
SCREW
WITH 3/16 (5MM)
ALLEN HEX
ARMATURE 1/2” DRILL
SEXNUT

P:\INSTALLATION INST\Electromagnetic Locks\EXCEL\INST-E1200.vsd REV A3 08-18 Page 3
6. Holding the magnet housing at each end, engage the entire length of the interlock detail, by pushing towards the
door. Tap with a soft hammer to ensure proper alignment and engagement.
CAUTION: The lock body must be held in place until secured with mounting screws. Secure socket head
screws provided inside the housing at each end. Start screws into threads carefully to avoid stripping the
threads. Check alignment and tighten screws. Pull wires through frame, mounting plate and magnet housing
STEP 6
7. Select jumper position for 12VDC or 24VDC. Connect power to magnetic lock.
A/C
MAINS
POWER
SUPPLY
12VDC
or
24VDC
SWITCH or
ACCESS
CONTROL
+
-
8. Test operation. When all is operating properly, tighten
all screws as shown. Install security pins and screws
as shown. Install anti-tamper plugs over socket head
screws using a soft hammer to avoid damage to the housing.
ATTACH THE RED SIDE OF THE CONNECTOR HERE
FOR A GREEN LED ENERGIZED & SECURE (RED=ENERGIZED & UNSECURE)
ATTACH THE GREEN SIDE OF THE CONNECTOR HERE
FOR A RED LED ENERGIZED AND UNSECURE (GREEN=ENERGIZED & SECURE)
COM
NC
NO
Door Position Sensor (Reed switch)
ORANGE (open with door closed)
YELLOW (closed with door closed)
WHITE
R G B
W
G B R
Door
Position
Sensor
Lock
Status
Switch
(Relay)
Power
Supply
Voltage Jumper
8
NC
7 C
6
NO
5
NC
4
C
3
NO
2 -
1
+
12VDC 24VDC
LED RED
GRN

P:\INSTALLATION INST\Electromagnetic Locks\EXCEL\INST-E1200.vsd REV A3 08-18 Page 4
To maintain surface plating from corrosion:
Do not touch the lock face with your hands.
Clean lock face with Scotch-Brite pad by 3M (do not use
sandpaper).
Apply a thin film of rust inhibitor (LPS-3) on lock face.
Repeat application on armature plate.
Supplied Mounting Hardware
ANGLE BRACKET
E12L
Inches: 10.5" L x 0.5" H x 1" D
STOP FILLER PLATE
FP15
Lock: 10-1/2" L x 2-7/8" H x 1-5/8" D
Filler Plate: 11" L x 1-1/4 H x 5/8" D
GLASS DOOR ARMATURE BRACKET
E12U
For use with Model E600 Series
Field adjustable for glass thickness
TOP JAMB MOUNTING BRACKET
E12Z
For use with Model E1200 Series
MOUNTING ACCESSORIES:
