Bosch B5512 User manual

Control Panels
B5512/B4512
en Owner's Manual

Table of contents
1Introduction 8
1.1 About documentation 9
2Keypads overview 11
3Points 14
3.1 What is a point? 14
3.2 Controlled points 14
3.3 24-hour points 15
4Areas 16
4.1 What is an area? 16
5Warning displays and tones 17
5.1 Keypad quiets for keystrokes 17
5.2 Silence the alarm tone 17
5.3 Entry delay tone and display 18
5.4 Exit delay tone and display 18
5.5 Keypress tones 19
6How the system reports events 20
7Alarm events 22
7.1 Priority of events 22
7.2 Fire alarms 22
7.3 Gas alarms 24
7.4 User and burglarly alarms 25
8Trouble events 27
8.1 Fire trouble events 27
8.2 Gas trouble events 27
Control Panels Table of Contents | en 3
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

8.3 User and burglary trouble events 28
8.4 System trouble events 28
9Cleared events are not lost 29
10 View faulted or bypassed points 30
11 B930 keypad operation 31
11.1 B930 keys overview 32
11.2 B930 display overview 34
11.3 B930 status LEDs overview 35
12 B930 Menu tree 37
13 B930 On/Off menu 41
13.1 All On menu 41
13.2 Part On menu 46
13.3 Off menu 49
13.4 Extend Closing 52
13.5 Bypass 54
14 B930 Status menu 56
14.1 View Area Status 56
14.2 View Point Status 57
14.3 Send Status Report 58
15 B930 Actions menu 59
15.1 Reset 59
15.2 Outputs 61
15.3 Test 62
15.4 RPS 67
15.5 Go to area 71
15.6 Firmware 72
15.7 Service bypass 73
4en | Table of Contents Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

16 B930 Users menu 74
16.1 Change Passcode 74
16.2 Add User 76
16.3 Edit User 82
16.4 Delete User 85
17 B930 Settings menu 87
17.1 Watch Mode 87
17.2 Date/Time 89
17.3 Schedule (SKEDs) 91
17.4 Keypad 93
18 B930 Shortcuts menu 96
19 B930 Events menu 97
19.1 View Event Memory 97
19.2 Clear Event Memory 98
19.3 View Log 99
20 B920 keypad operation 100
20.1 B920 keys overview 101
20.2 B920 display overview 103
20.3 B920 status LEDs overview 104
21 B920 Menu tree 106
22 B920 On/Off menu 110
22.1 All On menu 110
22.2 Part On menu 115
22.3 Off menu 118
22.4 Extend Closing 120
22.5 Bypass menu 122
Control Panels Table of Contents | en 5
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

23 B920 Status menu 124
23.1 View Area Status 124
23.2 View Point Status 125
23.3 Send Status Report 126
24 B920 Actions menu 127
24.1 Reset 127
24.2 Outputs 129
24.3 Test 130
24.4 RPS 136
24.5 Go to Area 139
24.6 Firmware 140
24.7 Service Bypass 141
25 B920 Users menu 142
25.1 Change Passcode 142
25.2 Add User 144
25.3 Edit User 150
25.4 Delete User 154
26 B920 Settings menu 155
26.1 Watch Mode 155
26.2 Date/Time 157
26.3 Schedule (SKEDs) 159
26.4 Keypad 161
27 B920 Shortcuts menu 164
28 B920 Events menu 165
28.1 View Event Memory 165
28.2 Clear Event Memory 166
28.3 View Log 167
6en | Table of Contents Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

29 Options 168
29.1 Two-man Rule 168
29.2 Early Ambush 169
29.3 Security system limitations 171
29.4 Cross points 173
29.5 Fire safety and evacuation 174
29.6 Multiple area systems 176
Glossary 184
Control Panels Table of Contents | en 7
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

Introduction
Security systems help to secure life, property, and
investments against fire, theft, and bodily harm. The
keypad is an advanced digital device that offers a variety
of features not available with other systems. Its highly
visible, back-lit display and built-in sounder alert you to
a number of system events. Stylish design and ease-of-
use make it ideal for property protection.
Your security company can program the system to meet
your individual needs. Your property is given its own
English language description that appears in the display.
Contact your security company should problems be
encountered during testing of the system.
Your alarm company is:
Call before test:
______________________________________________________
1
8en | Introduction Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

About documentation
This owner’s manual covers basic and advanced
functions. This manual is designed to be an everyday
type of reference for system users. The functions
described in this manual are programmed by your
security company. Some of them might not be included
in your system. Some of the functions covered require
you to enter your personal passcode.
This manual offers instructions for both the B930 and
B920 keypads.
Manual organization
– Sections 2 through 10. Discuss security system
basics, including how to identify which keypad
model(s) you own.
– Sections 11 through 19. Cover how to use the B930
keypad.
– Sections 20 through 28. Cover how to use the B920
keypad.
– Section 29. Explains optional features and security
system recommendations and limitations.
1.1
Control Panels Introduction | en 9
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

Manual conventions
Throughout this manual the # symbol refers to a variable
numerical quantity, such as the number of points to test
or exit delay time.
Text that shows on the keypad’s display appears in this
manual in italics, unless it is referring to a softkey. Keys
to press appear in this manual in brackets [ ]. When
keys are softkeys, the softkey name appears in bold in
brackets [ ].
Copyright
This document is the intellectual property of Bosch
Security Systems, Inc. and is protected by copyright. All
rights reserved.
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and
must be treated accordingly.
10 en | Introduction Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

Keypads overview
The B930 ATM Style Alphanumeric Keypad (SDI2)
features a bright five-line display with four ATM style
softkeys on either side of the display.
The B920 Two-line Alphanumeric Keypad (SDI2)
features a bright two line display and 8 function keys.
Both keypad models have user-adjustable volume and
display brightness, and a [HELP] key that opens on-
display instructions.
The overview figure shows the B930 keypad in the top
half, and the B920 keypad in the bottom half. Take note
of which keypad you own so that you can read the
appropriate instructions.
2
Control Panels Keypads overview | en 11
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

GAS
1
4
7
ESC
GHI
PQRS
0CMD
9WXYZ
6MNO
3DEF
2
5JKL
8TUV
ABC
1
4
7
ESC
GHI
PQRS
0CMD
9WXYZ
6MNO
3DEF
2
5JKL
8TUV
ABC
NEXT
HELPPREV
Area 1 Off
A1 Lobby
Ready to turn on
<Shortcuts Menu>
1 2
3
7
4
5 6
3
7
GAS
A1 Lobby
Ready to turn on
1
2
3
9
5 6
8
10
11
4
12 en | Keypads overview Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

Descriptions of callouts for B930 and B920 overview
figure (previous page)
Callout
Number
Description
1 Alphanumeric display
2 HELP key
3 PREV and NEXT keys
4 Status LEDs
5 ESC key (Escape)
6 CMD key (Command)
7 Softkeys (B930 only)
8 Programmable function keys (B920 only)
9 ALL, PART, and BYPASS keys (B920 only)
10 ENTER key (B920 only)
11 MENU key (B920 only)
Control Panels Keypads overview | en 13
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

Points
What is a point?
The term point refers to a detection device, or group of
devices connected to your security system. Points show
individually at the keypad with name. The point name
can describe a single door, motion sensor, smoke
detector, or an area such as Upstairs or Garage. There
are two basic types of points, controlled and 24-hour.
Controlled points
Controlled points respond to alarm conditions
depending upon whether the system is turned on
(armed) or turned off (disarmed). Controlled points are
programmed to respond instantly to alarm conditions or
to provide a delay for you to reach the keypad and turn
your system off. There are two types of controlled
points, part points and interior points.
Part points
Part points often include the exterior doors and
windows of the building (the perimeter of the building).
When you turn your system Part On, you only turn on
(arm) the part points.
3
3.1
3.2
3.2.1
14 en | Points Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

Interior points
These points often include interior forms of burglary
detection devices, such as motion sensors or interior
doors, for example. When you turn your system All On,
you turn on (arm) both part points and interior points.
24-hour points
24-hour points are always on (armed), even when your
security system is turned off (disarmed). There are two
types of 24-hour points, fire points and non-fire points.
Fire points
Fire points exclusively monitor fire detection devices.
They are always on (armed) and cannot be turned off
(disarmed). You can clearly distinguish fire points from
other non-fire points at the keypad.
Non-Fire points
Non-fire 24-hour points are always on (armed) and you
cannot turn them off (disarm). Panic buttons, hold up
buttons, low temperature sensors, and water sensors
are examples of devices that are typically monitored by
non-fire 24-hour points.
3.2.2
3.3
3.3.1
3.3.2
Control Panels Points | en 15
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

Areas
What is an area?
An area is a number of points that are grouped together
so that you can control them together as one unit. For
example, if a security system protected a building with
three sections – an office, a laboratory, and a cafeteria –
the points in each of those sections could be grouped
together as an area. With each section being its own
area in your security system, you can turn them on
(arm) and off (disarm) individually, in groups (office and
laboratory, for example), or all together.
4
4.1
16 en | Areas Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

Warning displays and tones
The keypads emit several distinct tones and shows text
to alert you to system events. Additional bells or sirens
may also be connected to your system. Bells or sirens
mounted on the exterior of the premises alert neighbors
to emergencies and provide an audible guide for police
and fire fighters.
The keypads have five status LEDs that indicate the
status of the system and some alarms. For more
information, refer to the status LED overview section for
your keypad.
Keypad quiets for keystrokes
Pressing any key on the keypad lights the keys and
quiets any warning tones. If you do not press another
key within 20 seconds, the keypad lights go out and the
warning tones resume.
Silence the alarm tone
The audible alarm sounds for a specific period of time
before it automatically shuts off. To silence the siren
before the time expires, simply enter your personal
passcode and press [Enter] or [ENTER].
5
5.1
5.2
Control Panels Warning displays and tones | en 17
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

Entry delay tone and display
When you enter a system that is on (armed) through a
point programmed for entry delay, the keypad emits the
entry delay tone as a reminder to turn off the security
system.
Failure to turn off your security system before the entry
delay time expires might sound the burglary tone and
could result in an alarm report being sent to your
security company.
Your security company programmed the entry delay
times for you:
My entry delay time is: _______________________________
Exit delay tone and display
When you first turn on (arm) your system (using your
keypad or keyfob), the keypad emits the exit delay tone,
shows Exit Now!, and counts down the exit delay time.
The tone pulsing rate increases during the last 10 sec of
exit time.
If you exit and re-enter before exit time expires, the exit
delay timer restarts the countdown. The restart only
applies once.
5.3
5.4
18 en | Warning displays and tones Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.

Your security company programmed the exit delay times
for you:
My exit delay time is: _______________________________
Keypress tones
The keypad sounds the keypress tone (a short beep)
when you press any key. Use the Settings menu to
enable/disable the keypress tone.
Invalid entry (error tone)
The invalid entry tone follows the keypress tone when
the keypress completes a invalid entry.
Sometimes an entry is one keypress. Other times it is a
series of two or more keypresses.
5.5
5.5.1
Control Panels Warning displays and tones | en 19
Bosch Security Systems, Inc. Owner's Manual 2012.12 | 03 | F.01U.265.453

How the system reports
events
Your security system makes repeated attempts to send
reports to your security company. In the event your
security system fails to communicate, the keypad
sounds the trouble tone and the keypad shows a
communication failed message. Notify your security
company of the communications failure.
If your telephone, internet, or cellular service is
interrupted, your security system cannot send reports
to the security company unless an alternate means of
transmitting the reports exists.
For telephone communication, your security company
can program your security system to automatically
disconnect the telephones when sending reports to the
security company. Once the report finishes, the security
system returns the telephones to normal operation
(check with your security company).
Consult with your installer to determine if your security
system is configured with a communicator delay. A
communicator delay aborts reports to the central
6
20 en | How the system reports events Control Panels
2012.12 | 03 | F.01U.265.453 Owner's Manual Bosch Security Systems, Inc.
