Bosch DS3MX-E-U User manual

7 | Bypass a zone
A user can bypass a zone during the arming sequence if it was
programmed at installation to allow bypass. You can bypass a zone if the
zone is either faulted or normal.
Bypassing a zone:
1. Enter the User code or the Master code.
2. Press [Bypass].
3. Enter the zone number to bypass (such as, Zone 1, Zone 2, or Zone 3, or
any combination of Zones 1, 2, or 3).
For example, to enter Zone 1, press [1], then press [On] to begin the
arming cycle and exit delay, if programmed. All bypassed zones clear and
automatically restore to normal mode the next time the system disarms.
Once a zone is bypassed, the zone’s LED indicates bypass status by
flashing twice every 2 seconds. Refer to Table 10.1.
8 | Fire alarm reset
Resetting the fire alarm:
Use the Fire Reset for power interrupt, and to reset the smoke detectors.
9 | Door unlock code/Request to Exit
Activate Request to Exit (REX) function:
If enabled, entering the Door Un-lock User code and pressing [*] activates
the REX function. This function releases any connected door lock.
NOTICE!
Your system must be programmed at installation to use this
function.
Activating Quick Arm:
If your system is programmed by the installer to allow Quick Arm, press
and hold [On] for 3 seconds to start the arming mode.
To disarm, refer to Section 2.
3 | Quick Arm
Disarming the system:
1. Enter a Master PIN code or a User PIN code.
2. Press [Off].
If a delay zone is triggered first, a code must be entered before the
expiration of the entry delay time. The red Armed indicator LED stops
flashing and turns off, indicating the system is disarmed. Refer to Table
10.1.
Canceling an alarm:
1. Enter a Master PIN code or a User PIN code
2. Press [Off] to immediately stop the alarm output.
4 | Cancel alarm
Using the panic function:
During an emergency, simultaneously press [*] and [#] for 3 seconds to
produce an alarm.
Entering a User code resets the panic alarm condition.
5 | Panic key
Clearing alarm history:
While in the disarmed mode, press [#] for 3 seconds to cancel all flashing
alarm history zone indicators.
If an alarm occurs while the system is armed, the zone’s LED stays on
continuously. Refer to Table 10.1.
When the system is disarmed, the LED of the zone causing the alarm
flashes.
While in the disarmed mode, press [#] for 3 seconds reset the indicator.
6 | Clear alarm history
2 | Disarm the system
NOTICE!
Your system must be programmed at installation to use this
function.
Only the Master code user can perform this function.
Arming the system:
1. Enter a Master PIN code or a User PIN code.
2. Press [On]. If the code was entered correctly, the red Armed indicator
flashes and the system arms.
If your system has an exit delay zone, the sounder beeps during the exit
period. The exit sounder beeps faster during the last 20 seconds of the
programmed exit delay time.
After the exit delay time expires, the red Armed indicator stays on
continuously. A violation on a zone, not programmed as a delay zone,
immediately activates a system alarm.
1 | Arm the system

© 2016 Bosch Security Systems, Inc. F.01U.072.326 | 05 | 2016.06
en Operation Guide
Alarm Control Panel
DS3MX-E-U
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450
USA
www.boschsecurity.com
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
Copyright
This document is the intellectual property of Bosch Security Systems, Inc. and
is protected by copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to
be registered trademarks and must be treated accordingly.
Bosch Security Systems, Inc. product manufacturing dates
Use the serial number located on the product label and refer to the Bosch
Security Systems, Inc. website at
http://www.boschsecurity.com/datecodes/.
10 | Zone status
Table 10.1: Zone status descriptions
LED Function Status
Zone 1 On Zone 1 alarmed/violated
Off Zone 1 normal
Flashing Zone 1 alarm history
(0.5 seconds on, 0.5 seconds off) Zone 1 bypassed
Flashes twice every 2 seconds
Zone 2 On Zone 2 alarmed/violated
Off Zone 2 normal
Flashing
(0.5 seconds on, 0.5 seconds off) Zone 2 alarm history
Flashes twice every 2 seconds Zone 2 bypassed
Zone 3 On Zone 3 alarmed/violated
Off Zone 3 normal
Flashing
(0.5 seconds on, 0.5 seconds off) Zone 3 alarm history
Flashes twice every 2 seconds Zone 3 bypassed
Armed Flashing
(0.5 seconds on; 0.5 seconds off) Exit delay
On System armed
Off System disarmed
Power On Power supply normal
Off No power supply
