Bosch DS12R Operating instructions

EN
Installation and Operation Guide
Self-Contained Control
Panel
DS12R

DS12R |Installation and Operation Guide | Trademarks
2 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
Trademarks
Microsoft®is a registered trademark of Microsoft
Corporation in the United States and/or other
countries.

DS12R |Installation and Operation Guide | Contents
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 3
Contents
1.0 Overview.............................................................................................................................................................4
1.1 Multi-Tenant System (MTS) Overview..............................................................................................................4
1.2 MTS Device Address...........................................................................................................................................4
1.3 DS12R Overview .................................................................................................................................................4
2.0 Installation........................................................................................................................................................... 6
2.1 Mounting the DS12R...........................................................................................................................................6
2.2 Wiring the DS12R................................................................................................................................................7
2.2.1. System Wiring ...............................................................................................................................................7
2.2.2. Input Wiring.................................................................................................................................................. 8
2.2.3. Output Wiring ...............................................................................................................................................9
2.2.4. Wireless Receiver..........................................................................................................................................9
3.0 Programming....................................................................................................................................................10
3.1 Entering Programming Mode ...........................................................................................................................10
3.2 Changing Programming Values........................................................................................................................10
3.3 Exiting Programming Mode .............................................................................................................................10
3.4 Checking Programmed Data.............................................................................................................................10
3.5 Programming Wireless Devices........................................................................................................................16
3.6 Resetting Default Values ...................................................................................................................................17
3.6.1. Reset the Master Code ...............................................................................................................................17
3.6.2. Reset Programming Default Values..........................................................................................................17
3.7 Configuring the Working Mode .......................................................................................................................17
3.7.1. Configure as a Stand-alone System ...........................................................................................................17
3.7.2. Configure for use in an MTS system ........................................................................................................17
4.0 Wireless Maintenance.....................................................................................................................................18
4.1 Wireless Device Test Mode ..............................................................................................................................18
4.2 Low Battery Trouble..........................................................................................................................................18
4.3 Supervisory Trouble ..........................................................................................................................................18
5.0 Specifications....................................................................................................................................................18
6.0 RS-485 Bus Address .........................................................................................................................................19

DS12R |Installation and Operation Guide | Overview
4 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
1.0 Overview
1.1 Multi-Tenant System (MTS) Overview
MTS is a distributed security system for monitoring
and controlling a large number of small sites. Examples
include apartment and condominium complexes, retail
plazas, office buildings, and educational and hospital
campuses.
A typical MTS installation consists of the following
components:
•MTSW Security Station Software: MTSW is an
application based on Microsoft®Windows that is
installed on a PC and monitored by guard station
personnel.
•MTR Communication Receiver: The MTR
receives and handles alarm events from devices
connected to the CAN RS-485 bus. MTR monitors
and reports CAN bus status and other system
internal events, and interfaces with MTSW to
synchronize system data.
•MTGW CAN RS-485 Bus Gateway: The MTGW
converts data back and forth from an RS-485
format to a Controller Area Network (CAN) bus
format. The system supports up to 100 MTGWs on
each CAN bus. The MTGW provides three
RS-485 loops that support a total of 120 RS-485
devices spread across the three loops.
•RS-485 Bus Devices: Refer to Table 1 for a list of
supported RS-485 devices.
Table 1: MTS RS-485 Bus Devices
RS-485 Device Description
DS6R2 6-zone self-contained control panel
DS12R 12-zone self-contained control panel
MT1-1 Single-zone input device
MT1-2 Two-zone input device
MT1-8 8-zone input device
MT2-8 8-output device
MT3-1 Single-zone input/output device
Controller Area Network (CAN) wiring requirements
are as follows:
•CAN Bus Interface: Connect the CAN bus to the
MTR Communication Receiver with at least
1.5 mm (16 AWG) shielded twisted-pair wire;
maximum length: 2000 m (6500 ft).
•RS-485 Buses 1-3: Use at least 1.0 mm (20 AWG)
shielded twisted-pair wire for the RS-485 bus;
maximum length: 1200 m (3900 ft). RS-485 bus
wiring status is supervised.
1.2 MTS Device Address
You must assign an address to each device in the
system. The address consists of at least four segments.
For example, in the address 1.2.5.3.6 :
1 = This segment identifies the number assigned to
the MTR central receiver (01 to 99).
2 = This segment identifies the CAN bus number
occupied by the MTGW (1 or 2).
5 = This segment identifies the MTGW’s CAN bus
address (1 to 100).
3 = This segment identifies the device’s RS-485
address (1 to 120).
6 = This segment identifies the zone number of an
input or output device connected to the RS-
485 device.
To set the DIP switch address on this device, refer to
Section 6.0 RS-485 Bus Address on page 19.
1.3 DS12R Overview
The DS12R is a self-contained, 12-zone control panel.
Use it as a stand-alone security system, or connect it to
a Multi-Tenant System (MTS). MTS combines
individual apartment housing units into a single
monitoring system.
The DS12R supports:
•12 alarm input zones
•1 alarm relay output
•2 solid-state outputs
•1 keyswitch input
•1 master code
•3 user PIN codes
•1 duress code
•1 door unlock code
•RF3212 and RF3212e Wireless Receiver
•RF3332 and RF3334 Key Fobs
•RF3332e and RF3334e Key Fobs

DS12R |Installation and Operation Guide | Overview
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 5
Figure 1: MTS System Overview
1- MTSW Security Station Software
2- MTR Communication Receiver
3- CAN Bus 1
4- CAN Bus 2
5- MTGW CAN RS-485 Bus Gateway
6- RS-485 Device (DS12R is shown)
7- RS-485 Device (DS6R2 is shown)

DS12R |Installation and Operation Guide | Installation
6 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
2.0 Installation
Install the DS12R as described in this
document to avoid damage to the device.
When installation is complete, perform a
full system test.
2.1 Mounting the DS12R
You can mount the DS12R directly onto the intended
surface (flush or semi-flush), or you can mount it on an
electrical box.
1. To open the keypad, use a screwdriver to press the
release tabs on the bottom of the keypad.
Refer to Figure 2.
Figure 2: Opening the DS12R
1- Release tab
2. Mount the base on the intended surface or
electrical box.
Refer to Figure 3.
The three terminal strips provided on the
DS12R base slide in and out of their
respective holders to facilitate installation.
Figure 3: Mounting Holes
1- Holes for surface-mounting
2- Holes for electrical box
3- Terminal Strip 1 (TS1)
4- Terminal Strip 2 (TS2)
5- Terminal Strip 3 (TS3)
6- Wire entrance
7- Tamper switch cover
8- Base
To use the wall tamper feature, remove
the tamper switch cover, and then mount
the DS12R flush against the wall.

DS12R |Installation and Operation Guide | Installation
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 7
2.2 Wiring the DS12R
2.2.1. System Wiring
Warning: Remove power from all devices
before connecting or removing the
DS12R.
Connect devices as shown in Figure 4. If the DS12R is
the last device on the RS-485 bus, connect a 120 Ω
end-of-line (EOL) resistor in parallel with the
RS-485.
Only the last device on the RS-485 bus
requires a 120 ΩEOL resistor (included
with the MTGW CAN-RS-485 BUS
Gateway).
Figure 4: System Wiring
1- 120 Ω EOL resistor
Figure 5 shows the three DS12R terminal strips. Refer
to Table 2 for wiring connections.
Figure 5: DS12R Terminal Strips
1- Terminal Strip 1 (TS1)
2- Terminal Strip 2 (TS2)
3- Terminal Strip 3 (TS3)
Table 2: Terminal Wiring
Terminal Strip 1 (TS1)
Label Description
Z1 Zone 1
COM Common (earth ground)
Z2 Zone 2
Z3 Zone 3
COM Common (earth ground)
Z4 Zone 4
Z5 Zone 5
COM Common (earth ground)
Z6 Zone 6
Z7 Zone 7
COM Common (earth ground)
Z8 Zone 8
Terminal Strip 2 (TS2)
Label Description
+ Power + (12 VDC)
- Power – (common)
A RS-485 A Terminal
B RS-485 B Terminal
KS Keyswitch input
P01 Solid State Output 1
COM Solid State Output Common
P02 Solid State Output 2
Terminal Strip 3 (TS3)
Label Description
Z9 Zone 9
COM Common (earth ground)
Z10 Zone 10
Z11 Zone 11
COM Common (earth ground)
Z12 Zone 12
INS Instant zone
NO Alarm output (normally open)
C Alarm output (common)
NC Alarm output (normally closed)
RF1 RF receiver interface
RF2 RF receiver interface

DS12R |Installation and Operation Guide | Installation
8 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
2.2.2. Input Wiring
Typical Zone Wiring
The DS12R supports zones wired with normally-open
(NO) or normally-closed (NC) contacts. Terminate
each zone with a 47 kΩEOL resistor. Refer to Figure 6.
Figure 6: Typical Zone Wiring
1- Normally-open (NO) contact
2- EOL resistor
3- Normally-closed (NC) contact
Instant Zone Wiring
You can change any Entry/Exit Delay zone to an
Instant zone by closing a switch between the INS
terminal and the zone’s COM terminal. The Entry/Exit
Delay zone returns to the programmed delay when the
switch is open. Refer to Figure 7.
Figure 7: Instant Zone Wiring
Smoke Detector Wiring
The DS12R supports four-wire smoke detectors. Figure
8 shows a smoke detector connected to an end-of-line
(EOL) relay module. Figure 9 shows an EOL resistor
connected to a smoke detector.
The total current draw of the four-wire
smoke detectors and the EOL relay
module must not exceed 250 mA.
Figure 8: Smoke Detector with EOL Relay Module
1- D275 EOL Relay Module
2- Smoke Detector
3- + 12VDC
4- - 12VDC
Figure 9: Smoke Detector with EOL Resistor
1- EOL Resistor
2- Smoke Detector
3- +12 VDC
4- -12 VDC

DS12R |Installation and Operation Guide | Installation
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 9
Keyswitch Wiring
Depending on programming settings, you can use a
keyswitch to arm or disarm the DS12R:
•If Program Address 47 is set to 1, closing the
keyswitch for one second or more arms the system.
•If Program Address 47 is set to 2, the keyswitch
must remain closed to arm the system. The system
disarms when the keyswitch is open for more than
one sec.
Refer to Figure 10.
Figure 10: Keyswitch Wiring
2.2.3. Output Wiring
The DS12R has Form C (NO/C/NC) contacts rated for
3 A at 28 VDC.
Two solid-state current sinks can be used for devices
with a current draw of up to 250 mA for each device.
Refer to Figure 11.
The operating voltage for attached relays cannot
exceed 15 VDC. Refer to Program Addresses 44 and
45 in Table 3 on page 13 for output options.
Figure 11: Output Wiring
1- Device 1
2- Device 2
3- Normally-open (NO) contact
4- Normally-closed (NC) contact
2.2.4. Wireless Receiver
An RF3212 or RF3212e Receiver is required to use key
fobs and wireless devices with the system.
Refer to Figure 12.
Figure 12: Wireless Receiver Wiring
1- RF Receiver 1
2- RF Data 1
3- RF Receiver 2
4- RF Data 2
5- -12 VDC
6- +12 VDC
7- 12 VDC power supply

DS12R |Installation and Operation Guide | Programming
10 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
3.0 Programming
Use the Master Code for programming. The three User Codes cannot be used to program the
DS12R.
The default Master Code is 1234. If you forget the Master Code, reset the DS12R to its default
values. Refer to Section 3.6 Resetting Default Values on page 17
3.1 Entering Programming Mode
1. Enter the Master Code.
2. Press and hold the [PROGRAM] key for 3 sec.
The keypad beeps and the Armed, Perimeter, and Trouble LEDs flash quickly to indicate that you entered
Programming Mode.
3.2 Changing Programming Values
1. Enter the programming address (xor xx), then press [*].
Addresses 0 through 9 require only one digit. Addresses 10 through 99 require two digits.
2. Enter the desired value.
The programming value can be from one digit to nine digits in length, depending on the address. A beep
indicates the input is accepted. Refer to Table 3 beginning on page 11.
3. Repeat Steps 1 and 2 to program other addresses.
If you make an incorrect entry before completing the number, press [#] to clear the previous entry,
and then re-enter it.
If you enter the wrong digits and complete the number, press [#] and re-enter the program address
number and the program value.
Example 1: To change the Master Code (Program Address 0) to 3345, enter the address, press [*],
then enter the desired value: [0][*][3][3][4][5].
Example 2: To enable the Quick Arm function (Program Address 46): [4][6][*][2].
3.3 Exiting Programming Mode
Press and hold [PROGRAM]for 3 sec to exit from Programming Mode. The keypad beeps and the Armed,
Perimeter, and Trouble LEDs turn off, indicating that you exited from Programming Mode.
3.4 Checking Programmed Data
Press [C] to page down for the next bit digit of the current value. Press [A] to page up for the previous bit digit of
the current value.

DS12R |Installation and Operation Guide | Programming
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 11
Table 3: Programming Values
Program
Address Description Factory Default Value Program Value
0 Master Code 1234 0001 to 9999 (0000 is not allowed)
1 User Code 1 1000 0001 to 9999 (0000 = disable)
2 User Code 2 0000 0001 to 9999 (0000 = disable)
3 User Code 3 0000 0001 to 9999 (0000 = disable)
4 Alarm Time 180 000 to 999 (0 sec to 999 sec)
5 Exit Delay Time 090 000 to 999 (0 sec to 999 sec)
6 Entry Delay time 090 000 to 999 (0 sec to 999 sec)
7 Zone 1 Type12 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
8 Zone 2 Type14 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
9 Zone 3 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
10 Zone 4 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
11 Zone 5 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
12 Zone 6 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
13 Zone 7 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
14 Zone 8 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
15 Zone 9 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
16 Zone 10 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
1Refer to Table 4 on page 15 for descriptions of the zone types.
2The DS12R has only one Entry Delay Timer and One Exit Delay timer. Any zone programmed to “Delay” follows these timers.

DS12R |Installation and Operation Guide | Programming
12 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
Table 3: Programming Values (continued)
Program
Address Description Factory Default Value Program Value
17 Zone 11 Type11 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
18 Zone 12 Type13 1 = Instant
2 = Delay2
3 = 24-hour
4 = Follower
5 = Silent zone
6 = Perimeter instant zone
7 = Perimeter delay zone
8 = REX
19 Zone 1 Bypass32 1 = Bypass allowed
2 = No bypass allowed
20 Zone 2 Bypass32 1 = Bypass allowed
2 = No bypass allowed
21 Zone 3 Bypass32 1 = Bypass allowed
2 = No bypass allowed
22 Zone 4 Bypass32 1 = Bypass allowed
2 = No bypass allowed
23 Zone 5 Bypass32 1 = Bypass allowed
2 = No bypass allowed
24 Zone 6 Bypass32 1 = Bypass allowed
2 = No bypass allowed
25 Zone 7 Bypass32 1 = Bypass allowed
2 = No bypass allowed
26 Zone 8 Bypass32 1 = Bypass allowed
2 = No bypass allowed
27 Zone 9 Bypass32 1 = Bypass allowed
2 = No bypass allowed
28 Zone 10 Bypass32 1 = Bypass allowed
2 = No bypass allowed
29 Zone 11 Bypass32 1 = Bypass allowed
2 = No bypass allowed
30 Zone 12 Bypass32 1 = Bypass allowed
2 = No bypass allowed
31 Zone 1 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
32 Zone 2 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
33 Zone 3 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
34 Zone 4 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
35 Zone 5 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
36 Zone 6 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
37 Zone 7 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
1Refer to Table 4 on page 15 for descriptions of the zone types.
2The DS12R has only one Entry Delay Timer and one Exit Delay timer. Any zone programmed to “Delay” follows these timers.
3If a zone is programmed to 24-hour, bypass is not allowed.

DS12R |Installation and Operation Guide | Programming
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 13
Table 3: Programming Values (continued)
Program
Address Description Factory Default Value Program Value
38 Zone 8 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
39 Zone 9 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
40 Zone 10 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass
41 Zone 11 Swinger Bypass 2 1 = Zone shunt allowed
2 = No zone shunt allowed
42 Zone 12 Swinger Bypass 2 1 = Zone swinger bypass allowed
2 = No zone swinger bypass allowed
43 Built-in Buzzer (Alarm Sound) 1 0 = Off
1 = On
44 Solid State Output 111 1 = Follows armed state
2 = Follows alarm output
45 Solid State Output 221 1 = Follows fire reset
2 = Follows zone status
3 = Follows unlock3code
46 Quick Arm 2 1 = Enable Quick Arm
2 = Disable Quick Arm
47 Keyswitch Input41 1 = Allow arm only
2 = Allow arm or disarm
48 Panic Key [C] Enable 0 0 = Off
1 = On
49 Fire Key [A] Enable 0 0 = Off
1 = On
50 Special Emergency Key [B] Enable 0 0 = Off
1 = On
51 Relay Function 0 0 = Follows alarm
1 = Follows Unlock User code
52 Duress User Code50000 0001 to 9999 (0000 = disable)
53 Door Unlock Code 0000 0001 to 9999 (0000 = disable)
54 Door Unlock Time 000 000 to 999 (1 sec to 999 sec) 000 = disable
55 RF Key Fob Enable (up to six) 0 0 = Disable
1 = Enable
56 RF Supervisory Trouble 1 1 = Report supervisory trouble after 12 h
2 = Report supervisory trouble after 24 h
576RF Zone 1 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
1 This output is normally open, but drops to 0 V when the system is armed or an alarm occurs. If this output drops to 0 V after an alarm
occurs, it remains active for the time defined in Program Address 4 (Alarm Time)
2When this output is programmed to the Fire Reset function, the output is normally open (NO) at 0 V during Fire Reset. If this output is
programmed to follow Zone Alarm, it remains active for the entire time that a zone remains in alarm.
3 A user can enter the Door Unlock Code to unlock a door that is controlled by Program Address 45 (Solid State Output 2) or Programming
Address 51 (Relay Function). If Programming Address 45 = 3, the output drops to 0 V after the Door Unlock code is entered. If
Programming Address 51 = 1, the relay activates after the Door Unlock code is entered.
4Turn and hold the keyswitch for at least 1 sec to start the arming sequence. If Program Address 47 is set to 2, a continuous switch or dry
contact can be used.
5 If the Duress code is entered, the control panel disarms normally, but sends a silent alarm to the central station. Use this feature to allow a
user in danger to activate a silent alarm discretely. This code must be unique.
6If an RF ID is entered for Addresses 57 to 80, the zone is a wireless zone. The DS12R ignores the wired zone.

DS12R |Installation and Operation Guide | Programming
14 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
Table 3: Programming Values (continued)
Program
Address Description Factory Default Value Program Value
581RF Zone 1 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
591RF Zone 2 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
601RF Zone 2 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
611RF Zone 3 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
621RF Zone 3 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
631RF Zone 4 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
641RF Zone 4 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
651RF Zone 5 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
661RF Zone 5 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
671RF Zone 6 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
681RF Zone 6 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
691RF Zone 7 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
701RF Zone 7 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
711RF Zone 8 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
721RF Zone 8 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
731RF Zone 9 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
741RF Zone 9 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
751RF Zone 10 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
761RF Zone 10 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
771RF Zone 11 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
781RF Zone 11 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
791RF Zone 12 Device 1 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
801RF Zone 12 Device 2 ID Number 000000000 000000000 = Disabled (zone is hard wired)
Allows 000000001 to 999999999 ID numbers
1If an RF ID is entered for Addresses 57 to 80, the zone is a wireless zone. The DS12R ignores the wired zone.

DS12R |Installation and Operation Guide | Programming
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 15
Table 3: Programming Values (continued)
Program
Address Description Factory Default Value Program Value
81 RF Key fob 1 ID Number 000000000 000000000 = Disabled
Allows 000000001 to 999999999 ID numbers
82 RF Key fob 2 ID Number 000000000 000000000 = Disabled
Allows 000000001 to 999999999 ID numbers
83 RF Key fob 3 ID Number 000000000 000000000 = Disabled
Allows 000000001 to 999999999 ID numbers
84 RF Key fob 4 ID Number 000000000 000000000 = Disabled
Allows 000000001 to 999999999 ID numbers
85 RF Key fob 5 ID Number 000000000 000000000 = Disabled
Allows 000000001 to 999999999 ID numbers
86 RF Key fob 6 ID Number 000000000 000000000 = Disabled
Allows 000000001 to 999999999 ID numbers
87 Send trouble report 0 0 = Disabled
1 = Enabled
99 Return to factory default values 18 Enter this value to return all values except the Master
Code to the factory default values. Use this function for
installation and maintenance. Refer to Section 3.6
Resetting Default Values on page 17.to return the
Master Code to its default value.
Table 4: Zone Types
Type Description
Instant When the system is armed, faulting an Instant zone causes an alarm.
Delay When the system is armed, faulting this zone causes an alarm after the Entry or Exit Delay time setting
expires.
24-hour This zone is always active. Faulting this zone always causes an alarm.
Follower When the system is armed and a Delay zone is not faulted, faulting this zone causes an alarm. If a Delay
zone is faulted, an alarm occurs after the delay time.
Silent Zone When the system is armed, faulting a Silent zone causes a Silent alarm. The keypad is silent and shows no
alarm output, but the DS12R sends an alarm event to the central station.
Perimeter Zone When the perimeter is armed, faulting a Perimeter zone causes an alarm.
Perimeter Delay
Zone
When the perimeter is armed, faulting this zone causes an alarm after the Entry or Exit Delay time setting
expires.
Bypass If a zone is programmed for Bypass, it does not cause an alarm when it is faulted. If a system is force
armed, the zone that is bypassed is not active.The bypass condition clears when the system is disarmed. A
24-hour zone type cannot be bypassed. All other zone types can be bypassed.
Swinger Bypass If a zone is programmed for Swinger Bypass, it causes an alarm only the first time it is faulted. All other
faults during this armed period are ignored. The Swinger Bypass clears when the system is disarmed.
Request-to-exit
(REX)
When this zone is disarmed, activating this input activates the output programmed to follow the Door
Unlock Time setting.
If Zone 12 is programmed to 8=REX, Door Unlock activates after Zone 12 is activated.

DS12R |Installation and Operation Guide | Programming
16 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
3.5 Programming Wireless Devices
The DS12R supports two RF3212 or RF3212e Wireless
Receivers. Mount the receivers up to 20 m (65.7 ft)
from the DS12R.
The DS12R supports up to 6 key fobs and 24 wireless
devices, including motion detectors, smoke detectors,
and door contacts.
You can assign up to two wireless devices to a zone.
Refer to Table 5.
Table 5: Wireless Device Assignments
RF Zone Program Address Wireless Device
57 Device 1
1 58 Device 2
59 Device 1
2 60 Device 2
61 Device 1
3 62 Device 2
63 Device 1
4 64 Device 2
65 Device 1
5 66 Device 2
67 Device 1
6 68 Device 2
69 Device 1
7 70 Device 2
71 Device 1
8 72 Device 2
73 Device 1
9 74 Device 2
75 Device 1
10 76 Device 2
77 Device 1
11 78 Device 2
79 Device 1
12 80 Device 2
N/A 81 Key fob 1
N/A 82 Key fob 2
N/A 83 Key fob 3
N/A 84 Key fob 4
N/A 85 Key fob 5
N/A 86 Key fob 6
Each wireless device is labeled with a unique, nine-digit
identification number (ID). Refer to Figure 13.
Figure 13: Device Identification Number (ID)
167770187
167770187
167770187
167770187
or
To add a wireless device to the system:
1. Enter Programming Mode.
2. Select the appropriate program address.
Refer to Table 5.
3. Enter the nine-digit ID for the wireless device.
4. For key fobs, set Program Address 55 to 1.
This setting enables up to six key fobs.
You cannot assign the Master Code to a
key fob. Assign each key fob to a different
user. All Exit Delay and Entry Delay times
operate as if the DS12R is armed or
disarmed using a standard user code.

DS12R |Installation and Operation Guide | Programming
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 17
3.6 Resetting Default Values
3.6.1. Reset the Master Code
Warning: Remove power from all devices
before connecting or removing the
DS12R.
1. Remove power from the DS12R.
2. Place the jumper across the PROG P1 jumper pins
(ON).
Refer to Figure 14.
Figure 14: DS12R PCB
1- RS-485 DIP Switches
2- PROG P1 Jumper
3- SMODE P3 Jumper
3. Reapply power to the DS12R.
4. Remove the jumper (OFF).
3.6.2. Reset Programming Default Values
1. Enter Programming Mode.
2. Enter [9][9][*] Program Address 99.
3. Enter 18 for the programming value ([1][8]).
4. Press and hold [PROGRAM] for 3 sec to exit from
Programming Mode.
The DS12R resets all programming values to the
original factory defaults.
3.7 Configuring the Working Mode
The DS12R can be used as stand-alone system or as a
component of an MTS system.
3.7.1. Configure as a Stand-alone System
1. Remove power from the DS12R.
2. Place the jumper across the SMODE P3 jumper
pins (ON).
3. Reapply power to the DS12R. Refer to Figure 14.
3.7.2. Configure for use in an MTS system
1. Remove power from the DS12R.
2. Remove the jumper across the PROG P3 jumper
pins (OFF).
3. Reapply power to the DS12R. Refer to Figure 14.

DS12R |Installation and Operation Guide | Wireless Maintenance
18 Bosch Security Systems, Inc. | 5/08 | F01U081956-01
4.0 Wireless Maintenance
4.1 Wireless Device Test Mode
Disarm the system before using Test
Mode. The DS12R ignores all zone input
while in Test Mode. All keys function
normally.
Use Test Mode to check the signal strength of the
wireless receiver. The DS12R LEDs indicate if the
location of the receiver is acceptable, marginal, or out
of range.
To enter Test Mode:
1. Enter the Master Code.
2. Press and hold [#] for three seconds. Zone LEDs
7–12 flash quickly to indicate that you entered Test
Mode.
Zone LEDs 1, 2, 3, 4, 5, and 6 indicate signal
strength
Refer to Table 6 to interpret LED indications.
Table 6: Wireless Signal Strength
RF
Receiver
LED Signal Strength
1 Poor, relocate RF
receiver
1 and 2 Marginal, relocate RF
receiver
1
1, 2, and 3 Good
4 Poor, relocate RF
receiver
4 and 5 Marginal, relocate RF
receiver
2
4, 5, and 6 Good
3. To exit from Test Mode:
•Press and hold [#] for 3 sec, or
•Wait 3 min for the DS12R to exit
automatically from Test Mode.
The LEDs return to their previous condition after
Test Mode is finished.
4.2 Low Battery Trouble
The DS12R beeps twice every minute when it receives
a low battery signal from the wireless receiver. The
LED for the zone with the low battery condition flashes
once each second.
If [RESET] is pressed, the DS12R ignores the low
battery condition for up to eight hours. If, after eight
hours, the low battery condition is still present, the
DS12R beeps again.
4.3 Supervisory Trouble
You can program the DS12R to ignore Supervisory
Trouble conditions for 12 or 24 hours. After the
programmed time, the DS12R beeps once each minute.
The corresponding zone LED flashes once each
second. When the supervisory condition clears, the
flashing and beeping stop.
Program Address 56 sets the Supervisory Trouble time.
Refer to Table 3 beginning on page 11.
5.0 Specifications
Table 7: DS12R Specifications
Dimensions: 17.0 cm x 13.0 cm x 3.2 cm
(6.7 in. X 5.1 in. x 1.3 in.)
Weight: 0.35 kg (12.3 oz)
Operating
Temperature:
-100C to + 500C
(-40F to +1220F)
Relative Humidity : 0 to 93% non-condensing
Operating Voltage: 9 VDC to 15 VDC
Zones: Normally-open (NO) or normally-
closed (NC) zones.
Zone Response
Time:
500 ms
Zone EOL Resistor: 47 kΩ
Output Relay: Normally open (NO) or normally
closed (NC). Contacts rated for
3 A at 28 VDC
Solid State Outputs: Two DC current sink outputs.
250 mA current sink maximum per
output at 0.1 VDC saturation. The
operating voltage must not exceed
15 VDC.
Compatible Wireless
Receivers:
RF3212 and RF3212e
Tamper: Built-in cover and wall tamper

DS12R |Installation and Operation Guide | RS-485 Bus Address
.
Bosch Security Systems, Inc. | 5/08 | F01U081956-01 19
6.0 RS-485 Bus Address
Assign a unique address to each device connected to the RS-485 bus.
DIP Switch Number
•= DIP switch ON
DIP Switch Number
•= DIP switch ON
DIP Switch Number
•= DIP switch ON
Address
0 1 2 3 4 5 6
Address
0 1 2 3 4 5 6
Address
0 1 2 3 4 5 6
001
•041 •• •081 •• •
002
•042 •••082 •• •
003
••043 ••••083 •• ••
004
•044 •••084 •••
005
••045 ••••085 ••••
006
••046 ••••086 ••••
007
•••047 •••••087 •••••
008
•048 ••088 •••
009
• •049 •• •089 ••• •
010
••050 •• •090 ••••
011
•••051 •• ••091 •••••
012
••052 •••092 ••••
013
•••053 ••••093 •••••
014
•••054 ••••094 •••••
015
••••055 •••••095 ••••••
016
•056 •••096 ••
017
• •057 ••• •097 •• •
018
• •058 ••••098 •• •
019
• ••059 •••••099 •• ••
020
••060 ••••100 •• •
021
•••061 •••••101 •• ••
022
•••062 •••••102 •• ••
023
••••063 ••••••103 •• •••
024
••064 •104 •••
025
•• •065 • •105 ••• •
026
•••066 • •106 ••••
027
••••067 • ••107 •••••
028
•••068 • •108 ••••
029
••••069 • ••109 •••••
030
••••070 • ••110 •••••
031
•••••071 • •••111 ••••••
032
•072 • •112 •••
033
• •073 • • •113 ••• •
034
• •074 • ••114 ••• •
035
• ••075 • •••115 ••• ••
036
• •076 • ••116 ••••
037
• ••077 • •••117 •••••
038
• ••078 • •••118 •••••
039
• •••079 • ••••119 ••••••
040
••080 ••120 ••••

© 2008 Bosch Security Systems, Inc.
F01U081956-01
Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, NY 14450-9199 USA
www.boschsecurity.com
