Bosch Easy Series User manual

Easy Series
Intrusion Control Panel
Selection Guide

Content
3 1. Core Facts
2. System Overview
5 2.1 Easy Series Control Center
6 Easy Series Display States
7 2.2 Control Panel and Devices
10 2.3 Easy Series Wireless Devices
14 3. Alarm Communication
16 4. False Alarm Reduction
18 5. Features and Benefits
23 6. Programming

1 Core Facts
Easy Series is a revolutionary intrusion control panel for homes and small
businesses that is extremely simple to install and operate. It supports the
cutting-edge wireless SecurityNetwork technology wLSN.
Applications:
Intrusion detection
Fire detection
Panic/Medical
Water/temperature detection
Supervision of freezers, fridges, central heating, etc.
Comfort functions (control of lighting, garage doors, shutters, etc.)
Easy Series Core Facts:
Features and capacity for private homes and small businesses
Stylish control center with extraordinary functionality
– Simple operation through integrated RFID reader
– Full voice support in native language
– Icon-based, text-free display
Various arming options (PIN code, RFID token, key fob, remote arming/disarming)
Numerous features to reduce false alarms
– Intelligent Threat Assessment
– Audio alarm verification
– Cross Zoning
– Graduated Annunciation
Extremely simple documentation
Flexible and personalizable features
– Guard code
– Unattended operation
– Inactivity timer
3

wLSN enables:
– Two-way communication for high reliability and security
– Auto configuration for easy and quick programming
wLSN RF technology:
– 868 MHz security band
– Multi-channel operation (8 channels)
Easy wLSN RF-signal level test at:
– RF Diagnostic Tool
– RF devices
Several integrated alarm transmission options:
– Voice dialer
– Digital dialer (SIA, Contact ID, Fast Format)
– Personal Text Messaging: SMS (TAP)
Remote control capability via DTMF and/or RPS (Remote Programming Software)
8 on-board zones, expandable to up to 32 wired or wireless zones plus 20 key fobs
Up to 4 control centers
4 on-board outputs plus up to 4 wireless outputs
Up to 20 users: each user gets his own PIN (RFID token and RF key fob optionally
available)
500 time/date stamped history events
5 years battery life for most of the wLSN devices
EN 50131-3 grade 2 and EN 50131-5-3 grade 2
Broad band IP communication and GSM/GPRS support
4| 1 Core Facts

2 System Overview 5
Specific buttons [1+2] to initiate police, fire or medical alarm. The other buttons can be used to enter the user
maintenance [3], to turn chimes on or off [4], for volume control [5]
This button gives access to a help menu. It can also be used to turn the system on.
The control center senses the user’s presence. If the system experiences any problems while he is away,
the control center informs him as soon as he approaches.
An integrated speaker provides operating support in native language. Along with the built-in microphone,
two-way voice communication is enabled.
The internal RFID reader can be used to turn the system on and off, to silence alarms and to enter the user menu.
2.1 Easy Series Control Center
The control center combines audio and visual information.
Presence detector Keys for special
functions
Single action
information button
Integrated bubble level for
easy installation
Built-in RFID –
operation
High-contrast, multicolor, icon display
Integrated
speaker
Built-in microphone

Easy Series Display States:
The system is off There is a system problem
One or more points are defective Exit delay in progress
The system is on (occupied) The system is on (unoccupied)
Fire or intrusion alarm
(system is off)
Fire or intrusion alarm (system is on)
6| 2 System Overview

2.2 Control Panel and Devices:
Control panel
Control center
with proximity token
Tamper switch
Power supply
Voice module
Programming key
2 System Overview | 7

8| 2 System Overview
The Easy Series control panel is destined for usage in
small enterprises and residential buildings. The system
can be used for several applications such as intrusion
alarms, fire detection and medical emergency calls.
Easy Series Control Panel and Devices:
Control Panel
The system can be controlled by
a user-specific token.
Proximity Token and Card
For specification please refer to section
“Control Center” on page 5.
Control Center
The voice module contains all the language sequences
in the respective language. More than 30 languages are
available.
Voice Module

2 System Overview | 9
Uploads and downloads programming information.
The programming key is used to quickly program a
group of control panels with the same characteristics,
e.g. in large projects, and for data backups.
Programming Key
The combined tamper switch senses open enclosure
as well as removal from the wall. It contains a wire
loop that can accommodate additional tamper outputs.
Tamper Switch
0-250 VAC wire-in power supply for hardwired
primary power requirements.
Power Supply

The wLSN hub supports up to 32 wLSN points plus
4 wLSN outputs and 20 key fobs and has no external
antenna. Due to its small size, it can be integrated
unobtrusively into the living space.
2.3 Easy Series Wireless Devices:
wLSN Hub (RF transceiver)
wLSN Key Fob
The wLSN installation tool helps to determine the best
spots where to install the wLSN devices. It provides
signal strength reading, Signal-to-Noise ratio and
Packet Error Rate measurement.
wLSN Installation Tool
The wLSN glass break detector uses dual acoustic
technology. The audio signal and the pressure wave
are considered to determine whether glass has been
broken. Its range is up to 7.6 meters. There is no
need to mount it directly on the glass, so it can be
integrated unobtrusively into the living space.
wLSN Glass Break Detector
The compact designed 5-button wireless key fob
is used to arm/disarm the system and has a panic
function. It also provides comfort functions, such as
control of garage doors and lighting. Two LEDs give
feedback on the panel status. Moreover, it has a
flashlight function.
10 | 2 System Overview

The pet immune high quality wLSN PIR motion
detector has a high catch performance and covers
12 x 12 meters. As there is no need to adjust the
detector, misalignment is impossible.
wLSN PIR Motion Detector
The pet immune high quality wLSN dual motion
detector PIR/MW provides two detection technologies
for difficult environments. It has a high catch
performance and covers 11 x 11 meters. As there
is no need to adjust the detector, misalignment is
impossible.
wLSN Dual Motion Detector
MW/PIR
The 85 db wLSN indoor siren gives local warning
for inhabitants and deters intruders. It is two-way RF
controlled by the system and can be integrated
unobtrusively into the living space.
wLSN Siren (Indoor)
2 System Overview | 11
The 102 db wLSN outdoor siren gives local warning for
inhabitants and deters intruders. It is two-way RF
controlled by the system.
wLSN Siren (Outdoor)

The 2A/ 28V wLSN relay module (DC/AC) has one
zone input for security or comfort applications.
The connected devices (e.g. garage doors, lighting)
can be controlled via the wLSN key fob and/or by
events (e.g. alarms).
2.3 Easy Series Wireless Devices:
wLSN Relay Module
The wLSN smoke detector provides optical detection
of smoke emission. It has a test function for easy
testing. An integrated sounder base alerts in case of
a fire.
wLSN Smoke Detector
The wLSN inertia detector notices opening of or violent
attacks against doors or windows. Two sensitivity
options can be configured. The magnet can be
mounted either on the left or right hand side of the
detector. The detector can be integrated unobtrusively
into the living space.
wLSN 3405 Inertia Detector
12 | 2 System Overview
The wLSN water/temperature detector provides
protection against water leak damages. It also detects
temperatures below +7°C degrees.
wLSN water/temperature
detector

The wLSN door/window contact contains two reed
contacts to supervise doors and windows. It provides
an additional zone input to connect a second contact.
The magnet can be mounted either on the left or right
hand side of the detector.
wLSN Door-Window Contact
The wLSN mini door/window contact contains two
reed contacts to supervise doors and windows. The
magnet can be mounted either on the left or right hand
side of the detector. Because of its very small size, it
can be integrated unobtrusively into the living space.
wLSN Mini Door-Window
Contact
The wLSN recessed door/window contact supervises
doors and windows invisibly. It is mounted inside of
doors, windows and the respective frames.
wLSN Recessed Door-
Window Contact
2 System Overview | 13

3 Alarm Communication
Different Ways of Alarm Notification:
Digital Dialer
SMS
Voice Dialer
Warning devices
wired/wireless
Sounder/
Strobe
Phone
Cell Phone
Monitoring
Center
Broad Band IP
Communication
GSM/GPRS
communication

Different Ways of Alarm Transmission:
3 Alarm Communication | 15
Digital Dialer
This digital communicator sends reports to a monitoring center.
Based on the type of report received, the monitoring center will
follow a set of predetermined actions. The supported
communicator formats are SIA, Contact ID, and Fast Format.
Voice Dialer
This format is used whenever event reporting requires a preset
voice message to be delivered via telephone. This feature can be
used for both monitoring center reporting and personal messaging.
Personal Text Messaging (SMS)
When configured, this personal messaging format can be used to
inform you about alarms, system problems and status.
Sounder/Strobe (wired or wireless)
These warning devices provide an indication whenever an alarm
has occurred at the protected premises.
Optional alarm transmission
Broad band IP
GSM/GPRS

4 False Alarm Reduction
Different Ways of False Alarm Reduction:
Graduated Annunciation
In case a security point is violated, the indication for an alarm release gradually increases.
The system increases the control center volume, changes the display animation and
eventually activates the warning devices before an actual alarm report is sent to the
monitoring center (reports may still be aborted or cancelled by the user)
Cross Zoning (a.k.a. Sequential Verification)
When two or more input sensors activate within a specified time period, an intrusion alarm
is considered verified: e.g. if a door sensor and a motion detector both initiate an alarm,
the system sends a verified alarm report (otherwise, an unverified alarm report is sent).
Intelligent Threat Assessment
Based on its current level of protection, input device types, input conditions, and
accumulated fault count, the control panel assesses the potential threat. If the threat
reaches a specific level, the system sends a verified alarm report (otherwise, an unverified
alarm report is sent).
Two-Way Audio Alarm Verification
When an alarm occurs, there is the possibility of two-way voice communication.
For details please refer to page 17.

Audio Alarm Verification
Each control center includes a speaker and a microphone. In case of an alarm, the
panel transmits the message to a monitoring center. The operator can then
immediately initiate a phone connection to your customer’s panel and listen into his
premises, so the situation can be verified, e.g. corroborate an intrusion attempt or a
false alarm caused by the user. A communication between the person in the
premises and the monitoring station can be established and helps to reduce
unnecessary costs due to (e.g.) police interventions.
4 False Alarm Reduction | 17
Alarm
Listen-in
Speak
Built-in microphone
Integrated
communicator
Example:
1Panel transmits the initiated alarm to the receiving station.
2Monitoring center personnel listens into the premises and distinguishes between
an alarm and a false alarm.
3The personnel can speak to the premises and the other way around. In case
of an accidental alarm, customers provide previously defined codes to identify
themselves as authorized users.
The customers are also able to listen into their premises whenever they like via a
telephone call (e.g. as baby phone function).
Integrated speaker

5 Features and Benefits
wLSN
Features Benefits Installer Benefits User
No wiring • Fastandeasyinstallation
• Lowerinstallationcosts
• Noholesmadethroughwallsorceilings
• Unobtrusiveinstallation
• Lowerinstallationcosts
868 MHz Security
band (EMEA)
• Veryreliable(nointerferencefrom
other RF systems)
• Competitiveadvantage
• Veryreliable
• NointerferencefromotherRFsystems
(e.g. baby monitors, cordless phones etc.)
Multi-channel
operation
(8 channels)
• Highersystemrobustness
• Fewerservicecalls
• Higherreliability
- and system robustness
(no interference from a neighbor’s RF alarm
system)
Two-way
communication
• Installationsarepredictable
• Highersecurity,robustnessand
reliability
• Highersecurity,robustnessandreliability
keyfobfeedbackLEDsprovidehigh
confidence in correct operation
Auto configuration • Easyandquickprogramming/
configuration
• Lowerinstallationcosts
Signal strength
indication
• EasyandquickverifyingofRF-signal
strength before mounting
• Installationsarepredictable
• Reliability
Wireless output
devices
• Additionalbusinessapplications/
opportunities
• Competitiveadvantage
• Comfortandsecurityapplicationsviakey
fob (e.g. control of garage doors, lighting,
etc.)
Upto5yearbattery
life
• Long-lastingsystemreliability
• Fewerservicecalls
• Lessinterruptionsthroughsecurity
company and less costs

Features Benefits Installer Benefits User
Innovative design • Competitiveadvantage • Matchesyourinterior
• Fitsperfectlyintothelivingspace
High-contrast,
multicolor,
icon-based,
text-free display
• Competitiveadvantage • Easyoperation
• Betteroverview
• Intuitiveoperation
Integrated RFID
reader
• Priceadvantage • Fastandeasysystemoperation
• Noextracostsforanadditionaldevice
• Nocodehastobememorized
• Highsecurity
Integrated motion
detector
• Competitiveadvantage • Keypadgivesimportantsysteminformation
as soon as user approaches
Built-in microphone
and speaker
• Two-wayvoiceverication • Immediateassistancefromthereceiving
station
• Easypossibilitytoverifyalarms
Full voice support in
native language
• Simpleorientationwithinmenu • Easyoperation
Quiet control center
mode
• Noannoyancethroughentrydelay
annunciation, e.g. in the bedroom
Control Center
19

Operation
Features Benefits Installer Benefits User
Token • Extremelysafe
• Ifonegetslost,it’sreplaceablebyanother
• Easeofoperation
Single-button
operation
• Quickarming
• Easeofuse
Full remote phone
control
• Quicksupportforend-users
• Easeofmaintenance
• Remoteinformationandoperation
• Easeofuse
• Remotecontrollingofpanelstatus
Individual text
recordings for points
and outputs
• Easeofoperation
Single-button system
test
• Easiermaintenance • Lowerservicecosts
Force protection • Bypassingofopenedpointspossible
Customprotection • Armingwithspecicopenpoints
(e.g. windows of sleeping rooms)
20 | 5 Features and Benefits
Additional Features
Features Benefits Installer Benefits User
Inactivity timer • Statusupdateofpanelusage • Higherservicesatisfaction
Guard code • Additionalbusinessapplicationsand
opportunities
• Directandquicksupervisionofthe
monitored place after an alarm by
professional staff
• Securityguardscannotenterpremises
without alarm notification
Unattendedoperation • TimesavingwhenanalyzingEnd-User
operations
