4en | Safety Instructions Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
1 Safety Instructions
1.1 Important safety notes
1. Read, follow, and retain instructions - All safety and operating instructions must be read
and followed properly before putting the unit into operation. Retain instructions for
future reference.
2. Do not ignore warnings - Adhere to all warnings on the unit and in the operating
instructions.
3. Accessories - Use only accessories recommended by the manufacturer or those sold with
the product. Accessories not recommended by the manufacturer must not be used, as
they may cause hazards.
4. Installation precautions - Do not place this unit on an unstable stand, tripod, bracket, or
mount. The unit may fall, causing serious injury to persons and damage to the unit. Mount
the unit according to the manufacturer’s instructions.
5. Service - Do not attempt to service this unit by yourself. Opening or removing covers may
expose you to dangerous voltages or other hazards. Refer all servicing to qualified service
personnel.
6. Damage which requires service - Disconnect the unit from the main AC or DC power
source and refer servicing to qualified service personnel under the following conditions:
– If the power supply cord or plug is damaged.
– If liquid has been spilled or an object has fallen into the unit.
– If the unit has been exposed to water and/or inclement weather (rain, snow, etc.).
– If the unit does not operate normally when following the operating instructions.
Adjust only those controls specified in the operating instructions. Improper
adjustment of other controls may result in damage, and require extensive work by a
qualified technician to restore the unit to normal operation.
– If the unit has been dropped or the cabinet damaged.
– If the unit exhibits a distinct change in performance.
7. Replacement parts - If replacement parts are required, the service technician must use
only replacement parts that are specified by the manufacturer. Unauthorized
replacements may result in fire, electrical shock or other hazards.
8. Safety check - Upon completion of service or repair work on the unit, ask the service
technician to perform safety checks to ensure that the unit operates properly
9. Power sources - Operate the unit only from the type of power source indicated on the
label. If unsure of the type of power supply to use, contact your dealer
10. Lightning - For added protection during electrical storms external lightning conductors
can be installed. This prevents power surges from damaging the unit.
11. The units should be installed in locations with restricted access.

Access Modular Controller 2 Safety Instructions | en 5
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
1.2 Safety precautions
Read the instructions
Before working with the AMC2 device, read these instructions carefully. Make sure you have
understood all information described in this document.
!
Warning!
Risk of electric shock
External power supplies must be installed and put into service by qualified personnel.
Ensure compliance with the relevant regulations.
Ground the controller.
Disconnect both AC and battery power supply before working on the controller.
!
Warning!
Risk of fire
Installation of the AMC2 device must comply with any local fire, health, and safety
regulations. A secured door that may be part of an escape route from an area must be
installed with:
Install a fail-safe lock (A), so that the door will be released if power fails. Ideally, use a
magnetic lock.
Install a normally-closed break glass or a manual pull (B) in the lock supply wiring, so that in
an emergency the fail-safe lock can be immediately powered down.
!
Warning!
Risk of explosion of Lithium battery
The battery can explode if it is replaced incorrectly.
Replace only with the same type as recommended by the manufacturer.
Dispose used batteries according to the battery manufacturer’s instructions.
Notice!
Risk of damage to equipment
Protect the hardware from electrostatic discharge by observing ESD instructions before
unpacking of touching connectors of electronics.
Always switch off power of the AMC2 device before modifying the installation.
Do not connect or disconnect plug connectors, data cables, or screw connectors while power
is on.
Rules and Conditions
There are no specific requirements as for selling and delivery. As for storage and safe
operation, the environmental temperature should not exceed the range of 0°C to 50°C.
Disposal
Your Bosch product is designed and manufactured with high-quality materials and
components which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their end-of-life, should be
disposed of separately from your household waste.

6en | Safety Instructions Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
In the European Union, there are separate collection systems for used electrical and electronic
products. Please dispose of this equipment at your local community waste collection/recycling
center.
1.3 Unpacking
Check the packaging for visible damage. If anything has been damaged during transport,
please inform the transport agency.
Unpack the unit carefully. This is an electronic device that must be handled with care to avoid
damage. Do not attempt to put the unit into operation if components are damaged.
If any parts are missing, inform your customer service representative or a Bosch Security
Systems salesperson. The shipping carton is the safest transport container for the unit. Store
it and the other packaging material for future use. If the unit has to be sent back, use the
original packaging.

Access Modular Controller 2 Important Information | en 7
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
2 Important Information
Remarks
This hardware is part of a security system. Access should be limited to authorized persons
only.
Some states do not allow the exclusion or limitation of implied warranties, or limitation of
liability for incidental or consequential damages, hence the above limitation or exclusion might
not apply to you.
Bosch Security Systems retains all rights not expressly granted. Nothing in this license
constitutes a waiver of Bosch’s rights under the U.S. Copyright laws or any other federal or
state law.
If you have any questions concerning this license, please, write to:
Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany.
2.1 Explanation of symbols in this document
Throughout this document, warning messages, important notes, and helpful tips are presented
for the reader. These appear as follows:
Danger!
Cause of Hazard
Indicates a hazardous situation, which, if not avoided, will result in death or serious injury.
!
Warning!
Cause of Hazard
Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
!
Caution!
Cause of Hazard
Indicates a hazardous situation, which, if not avoided, could result in minor or moderate
injury.
Notice!
Cause of Hazard
Important Notes that must be followed to avoid damage to the equipment or environment,
and to ensure successful operation and programming.
Tips and shortcuts may also be included in such notes.
2.2 Internet
If you are interested in further information on this product or information on other products,
please consult our website at http://www.boschsecurity.com.

8en | Introduction Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
3 Introduction
3.1 Description
The extension module AMC2-4WE is equipped with four Wiegand type reader-interfaces plus
eight inputs and eight outputs. Hence with the AMC2-4WE it is possible to double the number
of readers on an AMC2-4W from 4 to 8.
Figure3.1: The extension module AMC2-4WE
The AMC2-4WE can not be deployed as an independent controller but only as an extension
module for the AMC2-4W. Control and access decisions and bookings are carried out by the
AMC2-4W alone.
Notice!
The AMC2-4WE can only be used with AMC2-4W. As it provides Wiegand interfaces it cannot
be coupled with an AMC2-4R4.
The AMC2-4W can be extended by a maximum of one AMC2-4WE plus a maximum of three I/O
extension modules. The I/O extension modules AMC2-8IOEAMC2-16IOE (in any combination)
are, like the AMC2-4WE, connected via the AMC2-4W’s extension interface.
Notice!
The AMC2-4WE has no display. The information about the input and outputs will be shown on
special pages of the AMC2 display.
As the extension modules contain neither memory nor display they are controlled and
monitored entirely by the AMC2-4W.
The AMC2-4W can have an additional interface extension module AMC2-4WE, so that the
number of inputs and outputs can grow up to 64.
Notice!
An AMC2-4WE provides signals only to the AMC2 to which it is connected. Signal transfer to
another AMC2 is not possible.
The signal settings and parametrization of the readers connected to the extension module, are
carried out by the configuration applications in the access control system and by the
AMC2-4W to which it belongs.

Access Modular Controller 2 Introduction | en 9
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
3.2 Equipment Configuration
Figure3.2: Overview - Interfaces
1RS-485 extension module bus
2External tamper contact
3Connector for power supply
4Wiegand interfaces for up to 8card readers
5Connectors for eight analog inputs
6Connectors for eight relay outputs
Figure3.3: Jumpers at the bottom side
7Jumper for setting either voltage free relay output (“dry” mode) or looped-in voltage
from the AMC2 internal power supply (“wet” mode).
8Jumper: Equalization of potential between different systems and earth ground
(shield) for the extension interface.

10 en | Introduction Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
3.3 Performance Characteristics
– Controlled by an AMC2 via RS-485
– Reader interfaces
– four two Wiegand interfaces
– Eight relay outputs
– voltage free, power is supplied externally (dry mode)
– powered by internal power supply (wet mode)
– Eight analog inputs with internal power supply
– Transfer rate to the extension interface: 9,6 kBit/s
– Self regulating transmit/receive switching
– Power supply:
– 10V - 30Vdc - max. 3 A
– or over the RS-485 host connector
– Information about the inputs and outputs on the display of the AMC2 controller
– Tamper contact for external covers
Notice!
If an external power supply is used, this should also guarantee an uninterruptable power
supply (UPS). Example: Bosch power supply APS-PSU-60 (F.01U.282.970).
3.4 System Overview
The AMC2-4WE is connected between the access controller AMC2-4W and the various
peripheral devices.
Figure3.4: System overview
1 = Host
2 = AMC2-4W
3 = Card reader
4 = Communication and power supply
5 = AMC2-4WE

Access Modular Controller 2 Introduction | en 11
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
System configurations for Access Control applications.
– The minimum configuration consists of:
– one PC with system software,
– one AMC2 controller,
– one AMC power supply,
– one AMC enclosure.
– The maximum configuration depends on the system software,
– Each AMC2-4W controller can be extended with an AMC2-4WE extension module.
The using of AMC2-4WE modules has no influence on the limit of the maximum of controllers
in one system, because it is an extension to an AMC2-4W and not a controller.
Using Wiegand reader interfaces, up to four peripheral devices can be connected to each
AMC2-4R4. The interfaces are point-to-point connections, meaning that only one reader can be
connected to one interface.

12 en | Installing Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
4 Installing
Notice!
To build an UL approved system refer the documentation contained in the folder titled "_UL"
on the delivered CD.
4.1 Mounting
The AMC2-4R4 can be attached on a standard 35mm (1.377in.) mounting rail using a snap-in
mechanism. Attach the AMC2-4R4 into the upper edge of the mounting rail [1], then push
down the device and snap it onto the rail by pushing it towards the back [2].
Figure4.1: Mounting the AMC2 device on a mounting rail

Access Modular Controller 2 Installing | en 13
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
4.2 Unmounting
Notice!
To remove the AMC2-4R4 from a mounting rail, first remove all pluggable connectors.
Push down the AMC2-4R4 until the lower edge snaps out of the mounting rail [1]. Pull the
lower end of the AMC2-4R4 from the mounting rail [2].
Figure4.2: Unmounting the AMC2 device from a mounting rail

14 en | Installing Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
4.3 Opening the Case
Notice!
To open the AMC2-4R4, first remove all pluggable connectors.
The AMC2-4R4 case consists of a top cover mounted with a two-point snap-in closure on a
chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the
cover down.
Figure4.3: Opening the AMC2-4WE case

Access Modular Controller 2 Installing | en 15
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
4.4 Closing the Case
Before aligning the covers, unplug any pluggable screw connectors. Insert the hooks on the
lower edge of the front cover into the lugs on lower edge of the plastic back cover [1]. Please
ensure that the BOSCH logo is not upside-down. The upper edge of the front cover now aligns
with the two-point snap-in closures on the upper edge of the back cover [2], and may thus be
clicked gently into place.
Hence the closing process is the reverse of the opening process.
Figure4.4: Closing the extension case
Notice!
Risk of damage to equipment
If excessive force is required to close the front cover then it is probably incorrectly hooked
into the back cover. In such cases the display ’Dialog’ button in the front cover will be
misaligned and will not function correctly.
4.5 Cabling
Notice!
Risk of malfunction
The cables used in the AMC2-4R4 access control system are not prone to electrical
interference. However, you should avoid routing cables close to heavy load switching cables
and equipment. If this is unavoidable, cross the cable at right angles every 1 to 2 m (3 to 6 ft)
to reduce interference.
4.5.1 Conductor data for power to AMC2
With the calculation below you can find out which cable type must be used. If you connect the
power supply and the AMC-device with the delivered cable set from the enclosure the
calculation is not necessary.
For distances below 25m (75ft) use AWG18 conductors (1mm²). For longer distances, install
an additional power supply close to the AMC2 controller.

16 en | Installing Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
Please, calculate the voltage drop by checking the conductor specifications for characteristic
resistance values. The voltage drop shall not exceed 2V.
Example:
Length = 100 m/328 ft
U = 12V, I = 1A, maximum UDrop = 2V
i.e. RAWG18 (acc. specs) = 6.385 or 20,948
UDrop = 20,948 x 0.1 km x 1A = 2.1V
UDrop = 6.385 x 328 ft x 1A = 2.1V
Critical condition! Install the power supply closer to the controller.
Notice!
These specifications apply to power supply, readers, relay outputs, and extension interface.
Regarding inputs, specific voltage-drop values need to be taken into account. Refer to
Connecting Analog Input Devices, page 26.

Access Modular Controller 2 Installing | en 17
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
4.6 Grounding and Shielding
The AMC2 controller allows you to create a central ground or shielding point, simply by setting
certain jumpers. Set these jumpers only if grounding or shielding is not achieved by other
means.
1. If the AMC2-4R4 has its own power - as in the third example in Overview - Power supply/
consumption, page 19 - the shield will be connected to pin 2 of the power supply
connector - see Connecting Diagrams, page 33.
2. If the extension module is powered from the AMC2 controller - as in the second example
in Overview - Power supply/consumption, page 19 - the connection should be made as in
the RS-485 for extension modules, page 21 diagram.
3. If more than one extension module is to be connected to an AMC2 controller, and all of
them to receive power from it as well, then use the RS-485 extension interface for the
connection.
Notice!
In the second and third case the jumper on the bottom side of the AMC2-controller must to
be set - see the installation manual of the AMC2-4W.
Notice!
Risk of malfunction
Ensure that no ground loops are formed.
Notice!
In general the following apply:
If the devices have their own power supplies, the shielding is applied to one side only. The
free end should be insulated to avoid inadvertent connections.
If one device is fed power by another, the cable shielding should be applied to both sides.
4.6.1 Grounding for Extension Interface
Figure4.5: Location of ground jumper bottom side
The jumper setting A1 shows the factory settings.
Jumper connects the internal ground of the AMC2-4R4 to the ground of the RS-485 slave
interface. Set Jumper A2 only at the first AMC2-4R4 of a party line Overview - Power supply/
consumption, page 19.

18 en | Installing Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
4.7 Connecting Power Supply
Notice!
The battery status is checked every 5 minutes by the power supply unit (APS-PBC-60 or APS-
PSU-60).
As the battery charging/discharging levels tend to vary, the AMC2 provides information about
the battery status every 10 minutes. This feature allows a more reliable battery status
information.
4.7.1 Direct Power Supply
Connect the power supply to the POWER 7-pin pluggable screw connector. Refer to
Connecting Diagrams, page 33 for a complete diagram.
Figure4.6: Location of the power supply connector
Connect an external power supply (10 - 30 Vdc) for AMC2-4R4 at pin 1 (positive) and pin 3 (0
V) of the pluggable screw connector.
If an uninterruptible power supply (UPS) is used, the relay output for power good signals from
the UPS is connected to the following pins:
– pin 4 and 7 for power good AC
– pin 5 and 7 for power good Battery
– pin 6 and 7 for power good DC
Otherwise these pins must be short-circuited.
4.7.2 Power Supply via RS-485 Interface
The power can also be supplied by the AMC2-4W. In this case power pins 1 and 2 should be
connected, as well as data lines on pins 3 - 6.

Access Modular Controller 2 Installing | en 19
Bosch Access Systems B.V. Installation manual 2020-01 | V02 |
Figure4.7: Interface for internal power supply
4.7.3 Overview - Power supply/consumption
Figure4.8: Example configurations
a = AMC2-4WE
b = AMC2 I/O Extension board
line = Power supply
broken line = Data line

20 en | Installing Access Modular Controller 2
2020-01 | V02 | Installation manual Bosch Access Systems B.V.
Example Components used Output power Consumption Available Constant load
1 PS + AMC2-4W 60VA 5VA 55VA 25VA
2 PS + AMC2-4W +
AMC2-4WE
60VA 2 x 5VA 50VA 20VA
PS + AMC2-4W +
AMC2-4WE +
Extension
60VA 3 x 5VA 45VA 15VA
3 PS + AMC2-4W
and
PS + AMC2-4WE
60VA
+
60VA
5VA
+
5VA
55VA
+
55VA
25VA
+
25VA
PS + AMC2-4W
and
PS + AMC2-4WE +
Extension
60VA
+
60VA
5VA
+
2 x 5VA
55VA
+
50VA
25VA
+
20VA
4 PS + AMC2-4W +
Extension
and
PS + AMC2-4WE
60VA
+
60VA
2 x 5VA
+
2 x 5VA
50VA
+
50VA
20VA
+
20VA
Tab.4.1: Overview - power supply and power consumption
Explanations for the table columns:
Output power Power provided by the power supply.
Own usage Power used by AMC2 device
Available Power remaining for external devices
Constant load Amount of the available power that can
be drawn constantly.
Hence Example 1 can be read as follows:
Of the total incoming power (60VA) 5VA will be drawn by the
AMC2 itself . This leaves 55VA to support external devices.
25VA of these 55VA can be used for constant load (e.g. a card
reader) leaving 30VA for occasional peak usage (e.g. a door
opener).
